Quick Start Guide v1.0
Lenovo A606
English/Bahasa Indonesia
English
Learning more
Getting support
Read this guide carefully before using your smartphone.
To learn more information about your
Lenovo smartphone and obtain the latest
smartphone manuals, go to:
http://support.lenovo.com/.
For support on network service and billing,
contact your wireless network operator.
For instructions on how to use your
device, go to:
http://support.lenovo.com/.
Legal notices Lenovo and the Lenovo logo are
trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names
may be trademarks or service marks of
others.
European Union conformity
Radio and Telecommunications
Terminal Equipment Directive
This product is in compliance with the
essential requirements and other relevant
provisions of the Radio and Telecommuni-
cations Terminal Equipment Directive,
1999/5/EC.
Electronic emission
notices
Type: CMOS
Pixels: 8 megapixels (back) + 2 megapixels (front)
Processor: MTK MT6582m, Quad Core, 1.3 GHz
Size: 5 inches Screen: 2-touch
Resolution: 480 × 854 pixels LCD type: IPS
Model: Lenovo A606 System: Android
Wireless Communication
Bluetooth 4.0; WLAN 802.11 b/g/n; LTE, WCDMA, GSM; GPS
Battery: 2000 mAh
Height: 141.5 mm (5.6 inches) Width: 73.2 mm (2.9 inches)
Depth: 9.2 mm (0.36 inch) Weight: 152 g (0.3 lb)
Model and system
Depending on the measuring method, the dimensions and weight
might vary slightly.
Display
Battery
Processor
Dimensions and weight
Camera
Technical specifications
Light/Proximity
sensor Back key
Micro USB
connector
Rear-facing
camera
Menu key Display
On/Off button
1
4
7
10
2
5
8
3
6
9
Front-facing
camera
Receiver
Headset
connector
11 Volume buttons
12
Home key
7 6 5
1
9
8
2 3
12
10
11
13
4
13 Speaker
First glance
You must insert the USIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Step 1. Open the back cover.
Step 2. Insert the USIM card and
the memory card.
Step 3. Install the battery.
a. Align the battery
connectors on the battery
with the pins in the battery
compartment.
b. Push the battery down into
place.
Step 4. Install the back cover.
Always turn off your smartphone first before you insert or remove a
USIM card. Insert or remove a USIM card with your smartphone on
may damage your USIM card or smartphone permanently.
Preparing your smartphone
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Turn off: Press and hold the On/Off button for
a few seconds, then tap Power off.
Restart: Press and hold the On/Off button for
about 10 seconds.
Your smartphone has a rechargeable battery. For more information
about battery safety, see the “Rechargeable battery notice” in the
Important Product Information Guide shipped with your smartphone.
Low battery power Fully charged Charging
2
1
Charge the battery as shown.
Method 1. Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Method 2. Connect your smartphone to a computer using the cable
that comes with your smartphone.
Charging the battery
Pelajari lebih lanjut Untuk mengetahui informasi
selengkapnya tentang ponsel cerdas
Lenovo dan mendapatkan panduan
ponsel cerdas terbaru, kunjungi:
http://support.lenovo.com/.
Untuk dukungan penagihan dan
layanan jaringan, hubungi operator
jaringan nirkabel Anda. Untuk petunjuk
cara menggunakan perangkat Anda,
kunjungi: http://support.lenovo.com/.
Lenovo dan logo Lenovo adalah merek
dagang dari Lenovo di Indonesia, negara
lain, atau keduanya.
Perusahaan, produk, atau nama layanan
lainnya mungkin merek dagang atau
merek layanan dari pihak lain.
Kesesuaian dengan Uni Eropa
Peraturan Perlengkapan Terminal
Telekomunikasi dan Radio
Produk ini telah memenuhi persyaratan
penting dan ketentuan yang relevan
lainnya dari Peraturan Perlengkapan
Terminal Telekomunikasi dan Radio,
1999/5/EC.
Pemberitahuan
emisi elektronik
Bahasa Indonesia
Baca panduan ini dengan saksama sebelum menggunakan
ponsel cerdas.
Mendapatkan
dukungan
Pemberitahuan
hukum
Jenis: CMOS
Piksel: 8 megapiksel (belakang) + 2 megapiksel (depan)
Prosesor: MTK MT6582m, Quad Core, 1,3 GHz
Ukuran: 5 inci Layar: 2-sentuh
Resolusi: 480 × 854 piksel Tipe LCD: IPS
Model: Lenovo A606 Sistem: Android
Komunikasi Nirkabel
Bluetooth 4.0; WLAN 802.11 b/g/n; LTE, WCDMA, GSM; GPS
Baterai: 2.000 mAh
Tinggi: 141,5 mm (5,6 inci) Lebar: 73,2 mm (2,9 inci)
Tebal: 9,2 mm (0,36 inci) Berat: 152 g (0,3 lb)
Model dan sistem
Tergantung pada metode pengukurannya, ukuran dan berat
mungkin sedikit berbeda.
Display
Baterai
Prosesor
Ukuran dan berat
Kamera
Spesifikasi teknis
Sensor
Cahaya/Proksimitas Tombol Kembali
Konektor
USB Mikro
Kamera belakang
Tombol Menu Layar
Tombol Nyala/Mati
1
4
7
10
2
5
8
3
6
9
Kamera depan
Penerima
Konektor headset
11 Tombol Volume
12
Tombol Home
7 6 5
1
9
8
2 3
12
10
11
13
4
13 Speaker
Tampilan sekilas
Menyiapkan ponsel cerdas
Untuk menggunakan layanan seluler, pasang kartu USIM yang
disediakan oleh operator seluler Anda. Siapkan ponsel cerdas
Anda seperti yang ditunjukkan.
Langkah 1. Buka penutup
belakang.
Langkah 2. Masukkan kartu USIM
dan kartu memori.
Langkah 3. Pasang baterai.
a. Sejajarkan konektor
baterai pada baterai
dengan pin di ruang
baterai.
b. Dorong baterai masuk
ke tempatnya.
Langkah 4. Pasang penutup
belakang.
Selalu matikan ponsel cerdas lebih dahulu sebelum Anda
memasukkan atau melepaskan kartu USIM. Memasukkan atau
melepaskan kartu USIM sementara ponsel cerdas masih menyala
dapat merusak kartu USIM atau ponsel cerdas Anda secara permanen.
