Quick Start Guide

Read this guide carefully before using your smartphone.

Lenovo K6

Lenovo K33b36

Reading before using your smartphone

For your safety

Before assembling, charging or using your mobile device for the ﬁrst

time, please read the important product safety and legal information

provided with your product. If your mobile device becomes

unresponsive, try a reboot—press and hold the On/Off button until the

screen goes dark and your device restarts.

Usage

This phone supports apps and services that may use a lot of data, so

make sure your data plan meets your needs. Contact your service

provider for details. Certain apps and features may not be available in

all countries.

Electrical requirements

Battery: 3.85 Vcc 3000 mAh 11.6 Wh

Adapter: AC

Entrance: 100 - 240 Vca 50/60 Hz 0.3/0.5 A

Exit: 5.2 Vcc 2.0 A

First glance

Front-facing camera

1Receiver

On/Off button

Light/Proximity sensor

Indicator

4Volume buttons

Home button

Touch screen

7Back button

Flash

Touch ID

Multitask button

Rear-facing camera

Headset connector

Speaker

1513

Card tray

Micro USB connector

17 18

Microphone

Anti-noise microphone

1211

8199

Installing the Nano-SIM & microSD cards

A Nano-SIM card provided by your carrier is required in order to use

cellular services

①

. A microSD card is required to store data.

Install the Nano-SIM cards and the microSD card as shown

②

①Only Nano-SIM cards work with your smartphone.

②Always turn off your smartphone ﬁrst before you insert or remove a

Nano-SIM card. Insert or remove a Nano-SIM card with your

smartphone on may damage your Nano-SIM card or smartphone

permanently.

③Both of the card slots support 4G/3G/2G data services, but you can

enable only one Nano-SIM card for data connection at a time. If you

want to change the Nano-SIM card used for data connection, go to

Settings > SIM management.

Step 1.

Step 2.

Step 3.

Insert the eject tool that comes with your smartphone into

the hole in the card tray.

Pull out the card tray and do one of the following:

Position a Nano-SIM card in Slot 1 and a microSD card

in Slot 2;

Position a Nano-SIM card in Slot 1 and another

Nano-SIM card in Slot 2

③

Carefully insert the tray with the installed cards back into the

slot.

SIM

microSD

Slot1

Slot2

SIM

microSD

Low battery power Fully charged Charging

Charge the battery as shown.

Turning on or turning off your smartphone

Turn on: Press and hold the On/Off button until

the Lenovo logo appears.

Turn of f: Press and hold the On/Off button for a

few seconds, then tap Power off.Restart: Press and hold the On/Off button for a

few seconds, then tap Restart.

Method 1.

Method 2.

Connect your smartphone to a power outlet using the

cable and USB power adapter that come with your

smartphone.

Connect your smartphone to a computer using the cable

that comes with your smartphone.

Charging the battery

FCC Regulations:

This mobile phone complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired

operation.

This mobile phone has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses and can radiated radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

FCC Note:

Caution: Changes or modiﬁcations not expressly approved by the

party responsible for compliance could void the user‘s authority to

operate the equipment.

RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed the emission

limits for exposure to radio frequency (RF) energy set by the Federal

Communications Commission of the United States.

During SAR testing, this device was set to transmit at its highest

certiﬁed power level in all tested frequency bands, and placed in

positions that simulate RF exposure in usage against the head with

no separation, and near the body with the separation of 10mm.

Although the SAR is determined at the highest certiﬁed power level,

the actual SAR level of the device while operating can be well below

the maximum value. This is because the phone is designed to

operate at multiple power levels so as to use only the power required

to reach the network. In general, the closer you are to a wireless

base station antenna, the lower the power output.

The exposure standard for wireless devices employing a unit of

measurement is known as the Speciﬁc Absorption Rate, or SAR.

The SAR limit set by the FCC is 1.6W/kg.

This device is complied with SAR for general population /uncontrolled

exposure limits in ANSI/IEEE C95.1-1992 and had been tested in

accordance with the measurement methods and procedures

speciﬁed in IEEE1528.

The FCC has granted an Equipment Authorization for this model

phone with all reported SAR levels evaluated as in compliance with

the FCC RF exposure guidelines. SAR information on this model

phone is on ﬁle with the FCC and can be found under the Display

Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:

YCNK33B36.

For this device, the highest reported SAR value for usage against

the head is 0.53 W/kg, for usage near the body is 1.44 W/kg.

While there may be differences between the SAR levels of various

phones and at various positions, they all meet the government

requirements.

SAR compliance for body-worn operation is based on a separation

distance of 10mm between the unit and the human body. Carry this

device at least 10mm away from your body to ensure RF exposure

level compliant or lower to the reported level. To support body-worn

operation, choose the belt clips or holsters, which do not contain

metallic components, to maintain a separation of 10mm between this

device and your body.

RF exposure compliance with any body-worn accessory, which

contains metal, was not tested and certiﬁed, and use such body-worn

accessory should be avoided.

Additional information can be found at www.lenovo.com.

Certain features, services and applications are network dependent

and may not be available in all areas; additional terms, conditions

and/or charges may apply. Contact your service provider for details.

All features, functionality, and other product speciﬁcations, as well as

the information contained in this guide, are based upon the latest

available information and believed to be accurate at the time of

printing. Lenovo reserves the right to change or modify any

information or speciﬁcations without notice or obligation.

Note: The images in this guide are examples only.

Lenovo and the Lenovo logo are trademarks of Lenovo in the United

States, other countries, or both.

Manufactured under license from Dolby Laboratories. Dolby, Dolby

Atmos, and the double-D symbol are trademarks of Dolby

Laboratories.

Android, Google and other trademarks are owned by Google Inc. The

Android robot is reproduced or modiﬁed from work created and

shared by Google and used according to terms described in the

Creative Commons 3.0 Attribution License. All other product or

service names are the property of their respective owners.

Product ID: Lenovo K6 (Model Lenovo K33b36)

① In some countries, LTE is not supported. To know if your

smartphone works with LTE networks in your country, contact

your carrier.

System: Android

System

Technical speciﬁcations

Rear: 13 megapixels

Front: 8 megapixels

Processor: Qualcomm MSM 8937, octa-core

Processor

Camera

Size: 12.7 cm (5.0 inches)

Resolution: 1080 × 1920 pixels

Bluetooth: Bluetooth 4.2;

WLAN: WLAN 802.11 b/g/n, 2.4 GHz;

Data: ①FDD-LTE/WCDMA/GSM;

GPS: Supported

GLONASS: Supported

Display

Wireless communication

Screen: multi-touch

LCD type: IPS
