Lenovo IdeaTab A3000 Bedienungsanleitung

Quick Start Guide v1.0

IdeaTab

A3000

Please read this guide carefully before using your IdeaTab. The guide will

help you learn tips on setting and using IdeaTab.

The information in this guide is based on default settings. Illustrations and

screenshots used here may differ from the actual product appearance and

screen displays.

Front

Front camera

Volume

button

Welcome

Screen lock/unlock

In standby mode, press the Power button to lock your IdeaTab.

To unlock the screen, press the Power button, and then drag the on-screen

slider to enter the interface displayed before it locks.

Sleep/Wake

If you do not touch the screen for a while, IdeaTab dims its screen to enter

sleep mode for power saving.

Turning IdeaTab off

While in standby mode, press and hold the Power button and then follow the

on-screen instructions to conﬁrm shutdown.

Power button

Back

camera

Earphone jack Micro USB

Microphone

Speaker

Getting started

L × W × H: 194mm x 120mm x 11mm

3500 mAh

Weight: Appr. 345g

Color: Black /White

Android 4.2

Bluetooth 4.0

7", 16:9, 1,024 x 600 dpi

Micro USB

5.0 M (back) 0.3 M (front)

64 GB (max.)

Wi-Fi

MTK MT8125/8389

Dimensions/Weight/Color

Integrated camera

Screen

Battery

CPU

GPS

3.5 mm

earphone jack SD card slot

Operating system

Hardware

Operating system

Interface

Communication

*Based on actual measurements.

*SIM Card

*3G WWAN

(3G data only)

*Model: IdeaTab A3000-F

*Version: Wi-Fi

IdeaTab A3000-H

3G+Wi-Fi

Technical speciﬁcations

You can charge your IdeaTab whether it is on or off.

When the battery level falls below the threshold, IdeaTab will alert you with

a tone and the battery status icon will change into . We recommend you

plug the AC power adapter into your IdeaTab in the direction of the orange

arrow as shown above ﬁgure.

If your IdeaTab is being charged while it is on, the battery status icon

(located on the status bar of the screen) will appear as . After the battery

has ﬁnished charging, the status bar will show the fully charged icon .

For more information on battery safety, see the Important Product

Information Guide.

Charging IdeaTab

Keep the metal surface down for SIM card and SD card.

SIM card for 3G data only.

IdeaTab supports SD card and SIM card extension. To insert an

Step . Open the IdeaTab back cover as shown.

Step . Insert the SD card and SIM card as shown.

Close the back cover.

SD card and SIM card , do the following:

SIM2

SIM1

Inserting SD card and SIM card

You can connect IdeaTab to the PC's USB port with the cable provided for

battery charging or data transferring with the PC.

Installing apps and games

Transfer the APK setup ﬁle from the PC to IdeaTab, and then open it in the

ﬁle manager on IdeaTab. The installer will run automatically.

There are three connection methods available: USB storage, Media device

(MTP) and Camera (PTP).

IdeaTab supports SD card and SIM card extension. To insert an

Connecting IdeaTab to PC

Adding apps/widgets to the desktop

Tap and hold the icon of your desired application or widget, until the

desktop background pattern appears on the screen, and then place the

icon wherever you wish.

Touch >WIDGETS. You can drag your favorite applications and

widgets onto the desktop.

Tap and hold any icon on the desktop and then drag it to your preferred

location or delete it from the desktop.

Editing the desktop

Customizing the desktop

Wi-Fi connection

If your computer has an integrated Bluetooth adapter card, it can connect to

and transfer data wirelessly with other Bluetooth enabled devices, such as

notebook computers, PDAs and cell phones. You can transfer data between

these devices without cables and up to 10 meters range in open space.

Bluetooth connection

The actual maximum range may vary due to interference and transmission

barriers.

You can connect your tablet to the Internet using Wi-Fi. When Wi-Fi is on,

your IdeaTab will automatically scan for Wi-Fi hotspots within range. Select

the Wi-Fi hotspot you want to connect to.

Mobile networks

You can enable/disable mobile data connection and change the network

mode and access point in SIM manager or Mobile data settings.

Communication

Add a bookmark

Search or type a URL

Bookmarks, history and saved pages

The above functions require your IdeaTab to connect to the Internet via

Wireless network.

Touch > Browser. Now you can browse the Web and download

applications.

Browsing the web
