Lenovo TAB 2 A10-30 Anleitung zur Verwendung

Lenovo TAB 2 A10-30

Safety, Warranty & Quick Start Guide

Lenovo TB2-X30F

Lenovo TB2-X30L

English/中文（香港）/中文（简体）

English

..............................................................................................1

中文（香港） .....................................................................................5

中文（简体）...................................................................................15

Contents

Read this guide carefully before using your Lenovo TAB 2 A10-30.

All information labeled with * in this guide refers only to the WLAN + LTE model

(Lenovo TB2-X30L).

Read before using your tablet

Read ﬁrst-Regulatory information

Device models equipped with wireless communications comply with the radio

frequency and safety standards of any country or region in which it has been

approved for wireless use. In addition, if your product contains a telecom modem, it

complies with the requirements for connection to the telephone network in your

country.

Be sure to read the Regulatory Notice for your country or region before using the

wireless devices contained in your device. To obtain a PDF version of the Regulatory

Notice, refer to the “Downloading publications” section below.

Getting support

To get support on network service and billing, contact your wireless network operator.

To learn how to use your tablet and view its technical speciﬁcations, go to

http://support.lenovo.com

Downloading publications

Electronic versions of your publications are available from http://support.lenovo.com.

To download the publications for your tablet, go to http://support.lenovo.com and

follow the instructions on the screen.

Accessing your User Guide

Your User Guide contains detailed information about your tablet. To access your User

Guide, go to http://support.lenovo.com and follow the instructions on the screen.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other

countries, or both.

Other company, product, or service names may be trademarks or service marks of

others.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, and the

double-D symbol are trademarks of Dolby Laboratories.

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant

a General Services Administration “GSA” contract, use, reproduction, or disclosure is

subject to restrictions set forth in Contract No. GS-35F-05925.

English

789

Volume button

On/Off button

Microphone

Micro USB connector

Speakers

*Micro SIM card slot

The WLAN model (Lenovo TB2-X30F) does not have a Micro SIM card slot.

8microSD card slot

Rear camera

5 4

Lenovo TAB 2 A10-30 overview

Front camera

Model Version

WLAN

WLAN + LTE

Lenovo TB2-X30F

Lenovo TB2-X30L

Earphone jack

You can use cellular services with the WLAN + LTE model (Lenovo TB2-X30L) by inserting

the Micro SIM card provided by your carrier.

Install the Micro SIM card and the microSD card as shown.

Your tablet only works with Micro SIM card.

!!! DO not insert or remove the Micro SIM card while your

tablet

is turned on. Doing

so can permanently damage your Micro SIM card or

tablet

Step 3. Close the card slot cover.

Step 1. Open the card slot cover.

Step 2. Insert the Micro SIM card and the microSD card as shown.

DOLBY

Place the SIM card into the SIM card slot and the microSD card into the

microSD card slot.

microSD

Preparing your tablet

Micro

SIM

Turning on/off

Before using your tablet, you might need to charge the battery.

Charge the battery as shown.

Connect your tablet to a power outlet using the included cable and USB power adapter.

Low battery Fully charged Charging

Turn on: Press and hold the On/Off button until the

Lenovo logo appears.

Turn off: Press and hold the On/Off button for a few

seconds, then tap Power off.

Restart: Press and hold the On/Off button for

about 10 seconds.

DOLBY

Starting to use your tablet

Taking screenshots

Press and hold the On/Off button and the volume down button at the same time.

在使用 Lenovo TAB 2 A10-30 前小心閱讀此指引。

此指引標記 * 的資訊僅適用於 WLAN + LTE 型號 (Lenovo TB2-X30L)。

使用您的平板電腦之前請先閱讀

請先閱讀規管資訊

配備無線通訊的裝置型號符合任何需批准作無線使用的國家或地區之電台頻率及安全標

準。此外，若您的產品包含電訊數據機，其符合連接您國家電話網絡的要求。

請務必先閱讀您所屬國家或地區的 ，然後才使用裝置內的無線裝置。如要

取得的PDF 版本，請參閱以下的「下載刊物」部分。

取得支援

如需取得關於網絡服務和收費的支援，請聯絡您的無線網絡營運商。如要了解如何使用平

板電腦及檢視其技術規格，請前往：http://support.lenovo.com。

下載刊物

電子版公佈說明文件可從 http://support.lenovo.com 獲取。如要下載有關平板電腦的刊物，

請瀏覽 http://support.lenovo.com 並按照螢幕上的說明下載。

獲得用戶指南

您的用戶指引包含了平板電腦的詳細資訊。如要獲得用戶指引，請前往

http://support.lenovo.com 並根隨螢幕指示。

法律注意事項

Lenovo 及Lenovo 標誌為美國、其他國家或美國及其他國家的 Lenovo 商標。

其他公司、產品或服務名稱可能是其他公司的商標或服務商標。

在Dolby Laboratories 的許可下製造。杜比(Dolby)、杜比全景聲 (Dolby Atmos)及雙 D 標

誌均為杜比實驗室商標。

有限及限制權利注意事項：若數據或軟件根據一般服務管理「GSA」合約提供，使用、再製

作或披露，均受合約號碼 GS-35F-05925 所限。

中文（香港）

規管注意事項

789

音量按鈕

開關按鈕

麥克風

Micro USB 插孔

喇叭

*Micro SIM 卡插槽

WLAN 型號 (Lenovo TB2-X30F) 不設 Micro SIM 卡插槽。

8microSD 卡插槽

後置鏡頭

5 4

Lenovo TAB 2 A10-30 概覽

前相機

型號版本

WLAN

WLAN + LTE

Lenovo TB2-X30F

Lenovo TB2-X30L

耳機插孔

您可透過插入由您營運商提供的 Micro SIM 卡，透過 WLAN + LTE 型號 (Lenovo TB2-X30L)

使用流動上網服務。

如圖所示安裝 Micro SIM 卡及 microSD 卡。

僅有 Micro SIM 卡適用於您的平板電腦。

!!! 請勿在平板電腦開啟時插入或移除 Micro SIM 卡。此舉會永久損害 Micro SIM 卡

或平板電腦。

步驟 3. 關閉卡插槽蓋。

步驟 1. 開啟卡插槽蓋。

步驟 2. 如圖所示插入 Micro SIM 卡及 microSD 卡。

DOLBY

將SIM 卡放入 SIM 卡插槽，然後將 microSD 卡放入 microSD 卡插槽。

microSD 卡插槽。

microSD

準備您的平板電腦

Micro

SIM

開啟關閉

使用平板電腦前，您可能需要充電。

請根據圖示為電池充電。

使用隨附的纜線及 USB 電源適配器將您的平板電腦連接至電源。

低電量已完全充電充電中

開啟

：按住開 /關按鈕直至出現 Lenovo 標誌。

關閉

：按住開 /關按鈕數秒，然後輕按「關機」。

重新開機

：按住開 /關按鈕約 10 秒。

DOLBY

開始使用平板電腦

螢幕截圖

同時按住開關按鈕及降低音量鍵。
