Lenovo Tab P11 Anleitung zur Verwendung
English/Polski
Lenovo Tab P11
Safety, Warranty & Quick Start Guide
Lenovo TB-J606F
Lenovo TB-J606L
Reading before using your device
Reading first - regulatory information
Device models equipped with wireless communications comply with the radio
frequency and safety standards of any country or region in which it has been
approved for wireless use. In addition, if your product contains a telecom modem,
it complies with the requirements for connection to the telephone network in your
country.
Be sure to read the Regulatory Notice for your country or region before using
the wireless devices contained in your device. To obtain a PDF version of the
Regulatory Notice, go to https://support.lenovo.com.
Getting support
To get support on network services and billing, contact your wireless network
operator. To learn how to use your device and view its technical specifications, go
to https://support.lenovo.com.
Accessing your User Guide
Your User Guide contains detailed information about your device. To download
the publications for your device, go to https://support.lenovo.com and follow the
instructions on the screen.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other
countries, or both.
Other company, product, or service names may be trademarks or service marks of
others.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, and the
double-D symbol are trademarks of Dolby Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered
pursuant a General Services Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
English
Read this guide carefully before using your device.
All information labeled with * in this guide only refers to the WLAN + LTE model.
https://support.lenovo.com
https://forums.lenovo.com
Contents
Device overview .........................................................................................1
Preparing your device.............................................................................2
Accessories (optional) ............................................................................3
Keyboard pack...........................................................................................3
Attaching the Keyboard pack..............................................................3
Lenovo Precision Pen 2 ..........................................................................5
Smart Charging Station......................................................................... 9
Important safety and handling information .................................10
Eye Protection and Safety Information........................................... 11
EurAsia compliance mark..................................................................... 11
Service and support information...................................................... 12
Environmental, recycling, and disposal information.................13
European Union compliance statement......................................... 15
Specific Absorption Rate information............................................16
1
Device overview
Model Version
Lenovo TB-J606F WLAN
Lenovo TB-J606L WLAN + LTE
1Volume up button 2Volume down button 3Microphone
4Front-facing camera 5Light sensor 6ToF sensor
7Card tray 8Power button 9Speakers
10 USB-C connector 11 Touch screen
12 4-point pogo-pin smart connector (for the compatible keyboard and
Smart Charging Station)
13 Flashlight 14 Rear camera
1233
4
56
7
8
9
9
9
9
10
11 12 13
14
2
• The WLAN version does not have a Nano-SIM card slot.
• All pictures and illustrations in this document are for your reference only and
may differ from the final product.
• Power o the device before inserting or removing a card.
• Note that the WLAN version does not have a Nano-SIM card slot.
Preparing your device
Installing cards
Install the cards as shown in the figure.
Charging your device
Connect your device to a power
outlet using the USB cable and
power adapter provided.
Turning on
Press and hold the Power button until
the Lenovo logo appears.
microSD
microSD
Nano
*
SIM
WLAN WLAN+LTE
3
Keyboard pack
Keyboard Stand Cover
Attaching the Keyboard pack
Attach the stand cover and keyboard to the tablet as shown in the following
figure.
Accessories (optional)
The accessories do not come with all models, and are sold separately.
1Keyboard connector 2Keyboard 3Trackpad
4Hinge 5Kickstand
Keyboard layouts vary from country to country. The Keyboard layout in
this document is for reference only and your Keyboard may dier.
1
24
5
3
1 2
When you are attaching the Stand Cover to the Tablet, make sure that the
camera hole is aligned with the tablet’s rear camera.
4
Keyboard pack configurations
The Tablet can be used with the entire Keyboard pack attached, or with the
Stand Cover alone.
Opening and adjusting the Kickstand
You can adjust the Tablet angle using the Stand Cover. Grasp either side of
the kickstand and gently open it until you reach the desired angle.
1
2 3
To prevent damage, do not apply excessive pressure to the Stand Cover
or force the Kickstand beyond its natural range of motion.
5
1. Do not overtilt or apply excessive pressure to the Stand Cover, doing so
may damage the hinges.
2. Adjust the tablet angle by opening the Kickstand and changing the
position of the tablet until the desired angle is found.
3. The Tablet, Keyboard, and Stand Cover all contain magnetic materials. To
avoid loss of magnetism, avoid exposing the Tablet, Keyboard, and Stand
Cover to high temperatures or direct sunlight.
4. To prevent demagnetization of credit cards and other items with magnetic
data, keep them away from the Tablet, Keyboard, and Stand Cover.
You can use Lenovo Precision Pen 2 in place of your fingers for a better
experience, such as working with specific applications to write or draw on
the screen.
Overview
Lenovo Precision Pen 2
1Pen cap
2
3
4
5
Indicator LED
Upper button
Lower button
Tip
2
1
3
4
5
6
Charging the pen
1. Remove the pen cap in
the direction shown in the
figure.
2. Connect the pen to a
charger with a USB-C cable.
3. Replace the pen cap on the
pen. You can start to use
the pen after charging.
1 2 3
Replace tip
1. Pinch the tip with tweezers or another suitable tool.
2. Remove the tip.
3. Install the stand-by tip (supplied).
1
13
2
• When you charging the pen, the indicator light will turn amber, and
when it is fully charged, the indicator light automatically goes out.
• Please be cautious when using the pen. The pen contains sensitive
electronic components. Dropping it may cause damage.
7
Method one:
1. Slide the pen into the pen case.
2. Remove the transparent film on the back of the pen case.
3. Stick the pen case to the plastic panel.
4. Thread the ring through the X-shaped hole in the top of the plastic panel.
Method two:
1. Slide the pen into the pen case.
2. Remove the transparent film on the back of the pen case.
3. Stick the pen case to the back of the tablet or stand cover.
Store the Pen
3 4
1 2
1 2
