Lenoxx CD-52 Bedienungsanleitung
®
MODEL CD-52
OPERATING INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE
PROGRAMMABLE
COMPACT DISC PLAYER
CD52(22C-0E7)022100 NL v.1 E
PLAYS ALL MUSIC COMPACT DISCS
BASS BOOST SYSTEM
6 DIGIT LCD VISUAL DISPLAY
TRACK REPEAT & DISC REPEAT
AC ADAPTOR INCLUDED
DELUXE STEREO HEADPHONES INCLUDED
USES 2 SIZE AA BATTERIES (NOT INCLUDED)
AUX OUT JACK - CONNECTS TO YOUR STEREO SYSTEM
(PATCH CORD NOT INCLUDED)
1
INTRODUCTION
Your new Lenoxx Sound model CD-52 portable compact disc player, uses the latest
technology to give you crisp clean sound from all your compact discs.
Please read these operating instructions completely to take advantage of all the features
of this set.
ACCESSORIES INCLUDED
AC ADAPTOR STEREO HEADPHONES
2
LOCATION OF CONTROLS
1. CD DOOR OPEN BUTTON
2. CD DOOR
3. BACKWARD SKIP / SEARCH BUTTON ( )
4. FORWARD SKIP / SEARCH BUTTON ( )
5. STOP AND POWER OFF BUTTON
6. REPEAT/RANDOM BUTTON
7. LCD VISUAL DISPLAY
8. PROGRAM BUTTON
9. PLAY/PAUSE AND POWER ON BUTTON
10. AC ADAPTOR JACK
11. AUX OUT JACK (for home stereo connection)
12. VOLUME CONTROL
13. PHONES JACK (headphone jack)
14. BATTERY DOOR
15. BASS BOOST SWITCH
1
2
3
4
56
8
9
10
11
12
13
7
14
15
POWER SOURCES
1.Using with Batteries
TIPS ON BATTERY USE
Reversing polarities will damage the batteries and possibly your set. Be sure to
follow polarity ( + and - ) as indicated.
Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),
or old batteries with new ones.
When not in use for an extended period of time, or while internal batteries will not
be used, remove them to prevent possible acid leakage or corrosion resulting in
damage to your player.
When the batteries have become discharged, they must be disposed of in a safe
manner that complies with all applicable laws.
Installation of batteries should only be done by an adult (for safety).
WHEN THIS SYMBOL FLASHES IN THE DISPLAY
If the alkaline batteries are weak and discharged, this symbol flashes in the
display, then the power automatically turns off. If this occurs, replace the alkaline
batteries (also if display does not show anything, the batteries are dead).
ALKALINE BATTERY LIFE
Bear in mind that battery life expectancy is based upon volume and bass listening
levels. Maximum battery power consumption happens at maximum settings. Typical
life for 2 size AA alkaline batteries is above 8 hours of continuous use.
Insert two size AA alkaline batteries
according to the + and - markings in
the battery compartment.
3
NOTE: You may use rechargeable batteries on this set. However, because
rechargeable batteries generally have lower voltage (1.2 volts instead of
1.5 volts). Your playing time will be much less than normal fresh alkaline
batteries.
2.Using AC Power
Your player may be powered from any household 120V AC outlet, using the AC
adaptor included. Insert the adaptors small connector plug into the DC 4.5V Jack
marked on player (on the right side of the set), and plug the adaptor into
an AC outlet.
NOTE: If the AC Adaptor is connected, and regular batteries are installed, the
player automatically switches to the AC Adaptor power and the batteries
are not used.
CAUTION:
To prevent electric shock, do not use this AC Adaptor with an extension cord or
outlet, unless it can be fully inserted without exposing any part of the blades. Do
not use any other AC adaptor to power this set or you may damage your set.
4
CONNECTING TO HOME STEREO SYSTEMS
The AUX OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the
cables mini plug to the AUX OUT jack on your player, and the other appropriate end
usually RCA JACKS to the CD/AUX INPUTS of your home stereo.
YOUR
CD PLAYER
TO AUX IN JACKSTO AUX OUT JACK
YOUR STEREO
SYSTEM
OPTIONAL CABLE
3.5mm TO RCA JACKS
CD PLAYING
4Adjust the Volume.
1Load the Disc.
2Connect the Headphones.
3Press the PLAY/PAUSE button.
1234
1234
1234
1234
1234
Push
here
Disc
Label side up Slide right to open
To PHONES jack
Stereo headphones
PLAY/PAUSE
button
5
TRACK NUMBER
CURRENTLY
PLAYING
ELAPSED PLAYING
TIME OF THE
CURRENT TRACK
TOTAL TRACKS TOTAL PLAYING
TIME ON THE CD
VOLUME CONTROL
MAXIMUM MINIMUM
Other Operations
Operation Press Display window shows
To pause play
To release pause
and resume play
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
FLASHES
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
ADVANCES
To stop
To skip to the next track(s)
To skip to the previous track(s)
once (or repeatedly)
once (or repeatedly)
To go ahead at high speed
(search)
Keep depressed and release when the
desired music section of the disc is found.
To go back at high speed
(search) Keep depressed and release when the
desired music section of the disc is found.
BASS BOOST switch
This switch enhances the low frequency (bass)
sounds at low listening levels. Switch this ON or
OFF to suit your taste.
TOTAL TRACKS TOTAL PLAYING TIME
PLAY/PAUSE
button
PLAY/PAUSE
button
STOP button
To turn off the power STOP button once and wait 30 seconds, or press
STOP button twice
BASS BOOST switch
6
Single Track Repeat
Plays one song over and over till you press STOP.
During play, select the song you want to repeat with
either of the SEARCH buttons ( or ), then press
the REPEAT/RANDOM button once, the symbol
REPEAT
1
appears in the display.
The song currently playing will repeat over and over,
until you press STOP.
All Tracks Repeat
Repeats all songs in order over and over, till you press
STOP.
During play, press the REPEAT/RANDOM button twice,
the symbol
REPEAT ALL
will show in the display.
All songs will keep playing in sequence 1, 2, 3, etc. and
when finished, will start all over again until you press the
STOP button.
REPEAT, INTRO AND RANDOM PLAY
You may have repeat, intro or random play using the REPEAT/RANDOM button.
Press the REPEAT/RANDOM button several times, and the display will show the
followings in turn:
REPEAT 1 --> REPEAT ALL --> INTRO --> SHUFF (RANDOM) --> NORMAL PLAY
Intro Play
This plays the first 10 seconds of every song in
sequential order.
1. During play, press the REPEAT/RANDOM button
three times, the word
INTRO
will flash in the display.
2. Press the PLAY button, the word
INTRO
will stop
flashing and the first 10 seconds of each song on the
CD will play in sequential order.
3. When you find a song you like, press the PLAY button,
normal play will be resumed, that song (and the
following songs) will play NORMALLY.
Random Play
This plays the songs on the disc in a random order.
1. During play, press REPEAT/RANDOM button four
times, the word
SHUFF
will flash.
2. Press the PLAY button, this will play all of the songs
in random order selected by the CD player. The word
SHUFF
will be steady on.
3. Press the SEARCH button to skip to the next
random song.
7
REPEAT 1
X
1
REPEAT ALL
X 2
INTRO
SHUFF
X 3
X 4
The tracks (songs) on the disc can be programmed (arranged in advance) to play in
any order you prefer (up to 20 tracks can be programmed).
Programming Example:
Program Number 1 2 3 4 5 6 7 8
Track Number (song number) 3 5 8 1 2 4 1 1
etc.
etc.
PROGRAM PLAY
During programming, the word
PROG
flashes in the display. To program songs to play
in your preferred order, follow steps below:
1.During play, press the PROGRAM
button.
The word
PROG
will flash in the display.
Program number
2.Press the SEARCH button ( or )
to select track number 3 (example).
PROG
and track number 03 will flash in the
display.
Track number
3.Press the PROGRAM button. Track 3 is
now programmed.
Program #2 will now show in the
display, ready for your next selection of
track.
4.Repeat steps 2 and 3 to program other
tracks till you finish (up to 20 selections).
5.After programming is finished, press
PLAY to begin programmed play.
PROG
changes to be steady on in
the display, and music begins to play in
the order you programmed.
NOTE:
- The player will stop automatically after
all programmed tracks have been
played.
- To quit programmed play, press STOP
button once. Then you may press PLAY
button to re-start normal play.
Your programming will be lost:
When the alkaline batteries are
exhausted or removed, or the AC
ADAPTOR is disconnected.
When the power is shut off or the CD
DOOR is opened.
8
PROG
PROG
PROG
Cleaning the cabinet
Wipe with a soft cloth. If the cabinet is
very dirty, dampen (not dripping wet) the
cloth with a weak solution of soapy water,
and then wipe clean.
Cleaning the lens
A dirty lens will cause sound skipping. If
the lens is very dirty, the player may not
work. We suggest using a special
cleaning disk (not included) available in
most music and Hi-Fi stores. However, if
you do not have one, you may use a cotton
swab very slightly dampened with alcohol
to clean the lens.
MAINTENANCE
To remove the Disc
Open the CD DOOR by sliding the DOOR
OPEN button, hold the disc by the edge
while slightly pressing on the center
spindle as illustrated, then lift it from the
edge to release and remove.
Cleaning the Discs
Fingerprints should be carefully wiped
from the surface of disc with a soft cloth.
Unlike conventional records, compact
discs have no grooves to collect dust
and microscopic dirt, so gently wiping
them with a soft cloth should remove
most particles. Wipe in a straight
motion from the center to the edge.
Handling Compact Discs
Dirty, scratched or warped discs may
cause skipping or noise.
Handle the disc only by the edges. To
keep clean, do not touch its surface.
Never use thinner, benzine, record
cleaner or antistatic spray on a compact
disc. Such chemicals can damage its
plastic surface.
Discs should be stored in their cases
after use to avoid scratches.
Do not expose discs to direct sunlight,
high humidity, high temperatures, or
dust, etc. Prolonged exposure to
extreme temperatures can warp the disc
(such as leaving the discs in your car
during summertime).
Do not stick or write anything on either
side of disc. Sharp writing instruments,
or the inks used in some felt-tip pens, may
damage its surface.
NOTE
Always press the STOP button and wait
for the disc to stop rotating before sliding
the DOOR OPEN button to remove the
disc.
9
Andere Handbücher für CD-52
2
Andere Lenoxx CD-Player Handbücher
Lenoxx
Lenoxx CD-88 Installationsanleitung
Lenoxx
Lenoxx Durabrand CD-62 Bedienerhandbuch
Lenoxx
Lenoxx CD-857 Bedienungsanleitung
Lenoxx
Lenoxx CD-85 Bedienungsanleitung
Lenoxx
Lenoxx Durabrand CD-565 Bedienerhandbuch
Lenoxx
Lenoxx CD-89 Bedienerhandbuch
Lenoxx
Lenoxx CD-90 Bedienungsanleitung
Lenoxx
Lenoxx CD-91 Bedienungsanleitung
Lenoxx
Lenoxx CDR-190 Bedienungsanleitung
Lenoxx
Lenoxx CD-52 Bedienungsanleitung
Lenoxx
Lenoxx CD-155 Bedienungsanleitung
Lenoxx
Lenoxx CD-50 Bedienungsanleitung
Lenoxx
Lenoxx CD-78 Bedienungsanleitung
Lenoxx
Lenoxx CD-61 Bedienerhandbuch
Lenoxx
Lenoxx Durabrand CD-62 Bedienungsanleitung
Lenoxx
Lenoxx Durabrand CD-56 Bedienungsanleitung
Lenoxx
Lenoxx CD-91 Bedienungsanleitung
Lenoxx
Lenoxx CD-155 Bedienungsanleitung
Lenoxx
Lenoxx Durabrand CD-565 Bedienungsanleitung
Lenoxx
Lenoxx CD-155 Bedienungsanleitung
