LevelOne WPC-0300 Bedienungsanleitung

LevelOne

WPC-0300

11g Wireless PCMCIA Adapter

User Manual

Contents

1. OVERVIEW ............................................................................................................3

1.1 PRODUCT FEATURE...............................................................................3

1.2 SYSTEM REQUIREMENT ......................................................................3

2. GETTING START WITH WPC-0300 ..................................................................4

2.1 LED INDICATORS ....................................................................................4

2.2 INSTALL WNC-0300 WIRELESS NETWORK PC CARD......4

2.2.1 Utility Installation.....................................................................................4

2.2.2 Driver Installation ....................................................................................7

3. CONFIGURATION ...............................................................................................10

3.1 LINK INFORMATION..................................................................................10

3.2 CONFIGURATION.......................................................................................11

3.3 ADVANCED ...................................................................................................13

3.4 SITE SURVEY..............................................................................................15

3.5 ABOUT US....................................................................................................17

4. GLOSSARY...............................................................................................................18

1. Overview

1.1Product Feature

●Compliance with IEEE 802.11g and 802.11b standards

●Highly efficient design mechanism to provide unbeatable performance

●Achieving data rate up to 54Mbps for 802.11g and 11Mps for 802.11b with

wide range coverage; high performance to deliver up to 108Mbps raw data

rate for 802.11g

●eXtended Range supported which provides users more than 500m

wireless connection ability.

●Strong network security with WEP and WPA support

●Auto-switch between the two standards, IEEE 802.11b and 802.11g

●Driver/Utility support Windows 2000/XP.

1.2System Requirement

●Windows 2000 and XP operating systems

●PC with Pentium III 600MHz system or above is recommended

●Equipped with at least one PC cardbus socket or PC cardbus adapter

●One CD-ROM drive

2. Getting Start with WPC-0300

2.1LED Indicators

The Power LED will be ON when the unit is powered up.

The Link LED will be Blinking indicates a WLAN connection.

2.2Install the WNC-0300 Wireless Network PC Card

2.2.1 Utility Installation

1. Before insert PC card into the PC cardbus of computer, please install the

Utility Program first. Make sure that the 108Mbps wireless Network PC

Card is NOT inserted into the cardbus slot.

NOTE: all the snapped images of installation mentioned in this manual are

based on Windows XP. For other windows operating system, all the

procedures are similar.

2. Turn on the computer. Insert the CD into the CD-ROM Drive. Please

click “Install”.

3. InstallShield Wizard will automatically start. Please click “Next” to

continue.

If user wants to change the installation folder, press “Brower”

to change the directory or press “Next” to continue.

Users can also rename the installation folder, type the

name in the column, or press “Next” to continue.

4. Click “Finish” to finish the installation.

5. Restart computer to make the settings effective.

2.2.2 Driver Installation

1. Insert the PC card into cardbus, and after restarting the computer, there will

be a window popup as the following picture. Please click “Next” for the

following steps.

2. Click “Continue Anyway” to keep installation going.

3. Click “Finish” to finish the driver installation.

4. To make sure if the installation is successful, user could check it through the

device management as below.

5. Once the installation is successful, a utility program icon will show on the

desktop. To lunch the utility, just double click the icon.

3. Configuration

3.1 Link Information

The default page is as below after launching the Utility program.

Status: Shows the BSSID associated, which can be used to identify the wireless

network.

SSID: Shows current SSID, which must be the same for the wireless client and

AP in order for communication to be established.

Frequency: Shows the current frequency used for wireless network.

Wireless Mode: Shows the current wireless mode used for wireless

communication.

Encryption: Shows the current encryption mode used for wireless network.

TxRate: Shows the current data rate used for transmitting.

Channel: Shows the current channel for communication.

Link Quality: Shows the link quality of the 108Mbps wireless LAN PC card with

the Access Point when operating under Infrastructure mode.

Signal Strength: Shows the wireless signal strength of the connection between

the 108Mbps wireless LAN PC card with the Access Point.

Data Rate: Shows the statistics of data transfer, and the calculation is based on

the number of packets transmitted and received.
