LEXIN LX-B4FM Bedienungsanleitung
Table of Contents
1.Introduction...................................................................................1
2.Package Contents.......................................................................2-3
3.Installation Instructions............................................................3-5
4.General Operation Instructions...............................................5-6
-Powering On/Off and Charging
-Pairing LX-B4FM with a Bluetooth Device
5.Controls and Functions...........................................................6-15
6.Maintenance and Care...........................................................15-16
7.Certification and Safety Approvals...........................................16
8.Warranty.................................................................................16-17
9.Waiver and General Release......................................................17
1
1. Introduction
Thank you for choosing the LX-B4FM Motorcycle 4-Way Bluetooth Conference
Intercom. This product has a 1600-meter bike-to-bike full-duplex intercom maximum
range, includes Bluetooth stereo wireless helmet headset(s), and is designed for
installation into most open face, modular, and full-face style helmets.
With the LX-B4FM you can call hands-free on your Bluetooth mobile phone, listen to
stereo music or voice instructions of GPS navigation, and activate wireless Intercom
for rider-to-rider or rider-to-passenger conversation within a range of 1600 meters
when four units are connected.
The LX-B4FM is compliant with Bluetooth Specification v3.0 supporting the
following profiles: Headset Profile (HSP), Hands-Free Profile (HFP), and Advanced
Audio Distribution Profile (A2DP). It supports universal pairing with most Bluetooth
headsets on the market. The user can activate Siri or S-Voice from the main unit for
voice dialing and other voice commands. The FM radio tuner is built into the main
unit and allows for station scanning.
Superior audio fidelity has been achieved with our high fidelity, non-ported, and
ultra-slim helmet speakers. This headset also provides the industry's best combination
of wind and ambient noise reduction with the miniature boom microphone.
The main unit is powered by a rechargeable lithium ion/polymer power cell that
provides 10-15 hours of active use from a full charge. Standby time is over a week.
Please read this User Manual carefully before using this product.
2
How it Works
2. Package Contents
3
• LX-B4FM Main Unit
• Stereo HD Speaker with Interchangeable Microphone for Open Face Helmet or Full
Face Helmet
• USB Cable
• Clip Mounting Bracket
• 3M Tape Bracket
• User Manual
3. Installation Instructions
3.1.1 Insert the Clip Mounting Bracket between the internal padding and external
shell of the helmet.
3.1.2 If have any problems with mounting the bracket, you may use the 3M tape
bracket.Just peel off the protective backing sheet of the 3M tape and adhere the
bracket onto the helmet.Press for 15 seconds and allow the glue dry for 24 hours.
4
Note: Even though the 3M Tape mounting is provided for convenience, LEXIN
recommends using the bracket mounting. The 3M Tape mounting is offered as an
option that you may use at your own risk and responsibility, LEXIN does not
assume any responsibility for use of it.
3.2 Locate an area in the nose section just to the left of center to mount the button
microphone for full helmets . Place the button microphone to the velcro pad and
connect it to the connector of the headset.
If you are installing into an open face helmet, please adjust the direction of the
microphone so that the triangular mark on the microphone is pointing towards your
mouth.
3.3 Place the speakers into the cheek pads. Push the speakers and microphone firmly
against the Velcro pads.
3.4 Press the wires into the gap between the helmet liner and shell.
5
Note: The speaker with shorter wire is for the left ear and the speaker with the
longer one is for the right ear, to enhance the FM radio reception as well.
3.5 Mount the LX-B4FM main unit on the bracket.Slide the main unit down onto the
bracket until it clicks firmly into the bottom portion of the bracket.
3.6 To remove the main unit from the bracket, just push it up from the bracket.
4. General Operation Instructions
4A. Powering On/Off and Charging
• Power On
Press and hold the POWER button for about three seconds to power on. The LED will
blink blue only. You can hear the voice announcement about expected life of the
current battery charge.
• Power Off
Press and hold the POWER Button for about three seconds to power off. The blue
LED will turn red then off.
6
• Charging
Plug the micro USB cable into the USB port. The LED turns red while charging, and
then turns blue when the main unit is fully charged. It takes about 2.5 hours to be
completely charged.
• Low Battery Alert
When the main battery unit falls below 20% charge the LED light will flash red
and there will be a tone alert every five minutes until the condition is remedied.
4B. Pairing the LX-B4FM with a Bluetooth Device
Before using the LX-B4FM Bluetooth headset with any Bluetooth device for the first
time you need to pair them. It can be paired with mobile phones, audio devices such
as MP3 or GPS, and other LEXIN Bluetooth headsets. This pairing operation is only
required once for each Bluetooth device, and the headset will remain paired with each
device and automatically reconnects to the paired devices when within range.
• Pairing a Mobile Phone
Step 1. Start with the unit powered off, press and hold the POWER button for about
6 seconds until the LED light alternates between red and blue.
Step 2. Search for Bluetooth devices on your mobile phone. The headset will be listed
on your mobile phone as “LX-B4FM”.
Step 3. Enter 0000 for the PIN if needed.
Step 4. Your mobile phone will confirm that pairing is complete. The blue LED blinks
after they are connected.
• Pairing a Stereo Bluetooth Adaptor
Step 1. Turn on the audio source and prepare Stereo Bluetooth Adaptor for pairing
Step 2. Put LX-B4FM main unit in Bluetooth pairing mode (see above)
Step 3. Turn on or plug in the Stereo Bluetooth Adaptor
Step 4. The audio source will automatically start playing through the LX-B4FM main
unit when pairing is complete.
• Pairing Bluetooth GPS Navigation
Step 1. The paring procedure is the same with “Pairing Mobile Phone”
Step 2. Please refer to the manual of the Bluetooth GPS navigation for details.
Step 3. You can listen to Bluetooth voice instructions from Bluetooth GPS navigation.
5. Controls and Functions
5.1 Volume and Music Control
You can easily adjust the volume by pressing the Volume- and Volume+ button.
You will hear a beep when maximum or minimum level.
Press the Power button to play and pause music.
When playing music, press and hold the Volume– button to go to next track, press and
hold the Volume+ Button to go to the previous track.
Note:When in music stream mode from Smartphone, you will need to adjust the
volume on smartphone as well to get louder volume.
7
5.2 Safe Mobile Phone Calls - Incoming and Outgoing
5.2.1 Answer incoming call:
The unit will automatically answer the incoming phone call after 12 seconds. Or press
the Power button to answer the incoming phone call immediately.
Note: You can disable and enable the automatically incoming phone call answer
feature by press and hold both the power button and intercom button for 3 seconds,
you can see red light flash 3 times when disabled, or you can see blue light flash 3
time when enabled.
5.2.2 Reject incoming call：
Press and hold the Power button for two seconds.
5.2.3 End active phone call：
Press the Power button to end a phone call.
5.2.4 Voice Dial：
When in standby mode, double click the Power button to activate Siri or S-Voice. You
will hear a beep sound, and then there will be a voice prompt from the mobile phone.
Simply speak the name from your phone list to dial.
5.2.5 Last phone call number redial：
When in standby mode, double click the Volume + button to redial the last phone call
number.
Note: In some cases (e.g. high-power RF radio influence or metal blocking), the
headset might disconnect from the mobile phone. Please short press the Power
button to reconnect.
5.3 Bluetooth Intercom Talk
5.3.1 Pairing with other LX-B4FM headsets for Intercom Talk
The LX-B4FM can be paired with other LX-B4FM for up to a total of four units for
full duplex Bluetooth intercom talk. There is a different pairing process for each
scenario: two intercoms, three intercoms, and four intercoms. When more than two
units are connected, there are End units and Bridge units. To maximize range, the
riders should stay in the same order that the units are connected.
Note
：
Prior to pairing units for communications before riding. We strongly suggest
that existing connections be cleared from unit. To clear existing connections, press
and hold the volume + and volume – together until the red LED flashes, all
previous connections are cleared from unit.
1) Pairing two LX-B4FM headsets to talk
Tips: To start an intercom talk, you should pair the two units first.
8
Step 1. Pairing two LX-B4FM units first
Power on both units, to enter paring mode,press and hold the Intercom button for two
seconds until the red and blue LED flashes quickly on each unit.
unit one unit two
Click the Intercom button on either unit until the blue led flashes quickly on this unit,
once the pairing is complete you will see blue LED flash on both units (no red).
unit one or unit two unit one and unit two
Step 2. Start an intercom talk
Click the Intercom button on one unit to start an Intercom talk. Wait three to five
seconds for the unit to connect. When in Intercom mode, you can see both blue and
red led blinks simultaneously.
unit one or unit two unit one and unit two
Step 3. Disconnect an intercom talk
Click the Intercom button on one unit again to quit the intercom. After disconnected
you will see blue LED flash on both units.
unit one or unit two unit one and unit two
