Lexmark™ X782

Clearing Jams

Guide

Online customer support

Customer support is available on the Lexmark Web

site at www.lexmark.com.

Calling for service

When you call for printer service, describe the

problem you are experiencing, the message on the

display, and the troubleshooting steps you have

already taken to find a solution.

You need to know your printer model type and serial

number. See the label behind the toner waste

container door of the printer for this information. The

toner waste container door is on the left side of the

printer.

The serial number is also listed on the menu settings

page.

For service in the U.S. or Canada, call 1-800-

Lexmark (1-800-539-6275). For other countries/

regions, visit the Lexmark Web site at

www.lexmark.com

Note: When calling for service, call from

the location of the printer.

Checking an unresponsive

printer

If your printer is not responding, first make sure:

•The power cord is plugged into the printer and

a properly grounded electrical outlet.

•The electrical outlet is not turned off by any

switch or breaker.

•The printer is not plugged into any surge

protectors, uninterrupted power supplies, or

extension cords.

•Other electrical equipment plugged into the

outlet is working.

•The printer is turned on.

•The printer cable is securely attached to the

printer and the host computer, print server,

option, or other network device.

•The scanner cable is securely attached to the

MFP and printer.

•Remove the printer operator panel cover, and

verify a menu screen is displayed, then replace

the cover.

Once you have checked each of these

possibilities, turn the printer off, wait at least 10

seconds, and then turn the printer back on. This

often fixes the problem.

Locating the port name

and IP address

The port name appears in the upper right corner of

the MFP home screen and the IP address appears in

the upper left corner of the MFP home screen when

the MFP is connected to a network.

The address also appears on the network setup

page.

To print a network setup page

aTouch the key icon on the MFP control

panel.

bTouch Reports.

cTouch Network Setup Page or Network

<x> Setup Page.

For more information, see “Assigning a printer IP

address” in the MFP Setup guide.

Solving printing problems

Multilanguage PDFs do not print

1Open the document you want to print in Adobe

Acrobat.

2Click the printer icon.

3The Print dialog box appears.

4Check the Print as image box.

Note: For Acrobat 7.x or later, click the

advanced button to display the Print

as Image option.

5Click OK.

The operator panel display is blank

or displays only diamonds

Turn the printer off, wait about 10 seconds, and turn

the printer back on.

Performing Self Test appears on the display.

When the test is completed, the Ready message is

displayed.

If the messages do not appear, turn the printer off

and call for service.

The message Error reading USB

drive appears when using a USB

device

The USB device you are using may not be supported

or has an error. Only specific USB flash memory

devices are supported.

For information regarding tested and approved USB

flash memory devices, see the Lexmark Web site at

www.lexmark.com.

Jobs do not print

The printer is not ready to receive data

Make sure Ready or Power Saver appears on the

display before sending a job to print. Press to

return the printer to the Ready state.

The specified output bin is full

Remove the stack of paper from the output bin, and

then press .

The specified tray is empty

Load paper in the tray.

You are using the wrong printer driver or

are printing to a file

•Verify that you selected the printer driver

associated with the Lexmark ABC.

•If you are using a USB port, make sure you are

running Windows Vista, Windows 2000,

Windows XP, or Windows Server 2003 and

using a Windows Vista, Windows 2000,

Windows XP, or Windows Server 2003

compatible printer driver.

Your MarkNet N8000 series internal print

server is not set up properly or is not

connected properly

Verify that you have properly configured the printer

for network printing.

See the Software and Documentation CD or go to

the Lexmark Web site for information.

You are using the wrong interface cable,

or the cable is not securely connected

Make sure you are using a recommended interface

cable.

Make sure the connection is secure.

Held jobs do not print

A formatting error has occurred

•Print the job. (Only part of the job may print.)

•Delete the job.

•Free up additional printer memory by scrolling

through the list of held jobs and deleting others

you have sent to the printer.

The printer has insufficient memory

•Print the job. (Only part of the job may print.)

•Delete the job.

•Free up additional printer memory by scrolling

through the list of held jobs and deleting others

you have sent to the printer.

The printer has received invalid data

Delete the job.

Job takes longer than expected to

print.

The job is too complex

Reduce the complexity of your print job by

eliminating the number and size of fonts, the number

and complexity of images, and the number of pages

in the job.

Page Protect is set to On

Set Page Protect to Off from Print Recovery.

For more information, see the Menus and Messages

Guide.

Job prints from the wrong tray or on the

wrong paper or specialty media

Make sure the Paper Size and Paper Type specified

in the printer driver match the paper size and type in

the tray and what is set on the printers operator

panel.

Incorrect characters print.

You are using an incompatible parallel

cable.

If you are using a parallel interface, make sure you

are using an IEEE 1284-compliant parallel cable. We

recommend Lexmark part number 1329605 (10 ft) or

1427498 (20 ft) for the standard parallel port.

The printer is in Hex Trace mode

If Ready. Hex Trace appears on the display, you

must exit Hex Trace mode before you can print your

job. Turn the printer off and back on to exit Hex Trace

mode.

Tray linking does not work

•Make sure both the size and type of media are

the same in both trays.

•Make sure the paper guides in the trays are set

for the correct size media.

•Make sure the menu values for both size and

type are set correctly in the Paper Menu.

•For more informations, see the Menus and

Messages Guide.

Large jobs do not collate.

Collate is not set to On

Set Collation to On in the Finishing Menu or

through the printer driver.

Note: Setting Collation to Off in the

driver overrides the setting in the

Finishing Menu.

For more informations, see the Menus and

Messages Guide.

The job is too complex.

Reduce the complexity of the print job by eliminating

the number and size of fonts, the number and

complexity of images, and the number of pages in

the job.

The printer does not have enough

memory

Add printer memory or an optional hard disk.

Unexpected page breaks occur.

The job has timed out

Set Print Timeout to a higher value from the Setup

Menu.

For more informations, see the Menus and

Messages Guide

Solving mailbox problems

The mailbox and the printer are

misaligned

Realign the mailbox and the printer.

The mailbox is not connected

properly

Check the electrical connection.

Solving option problems

If an option does not operate correctly after it is

installed or if it quits working:

•Turn the printer off, wait for about 10 seconds,

and turn the printer on. If this does not fix the

problem, unplug the printer, and check the

connection between the option and printer.

•Print the menu settings page and check to see

if the option is listed in the Installed Options list.

If the option is not listed, reinstall it.

•Make sure the option is selected in the software

application you are using.

Solving high capacity feeder

problems

The paper tray does not raise when the

loading door is closed, or the paper tray

does not lower when the door is opened

and the paper tray button is pushed

Check the following:

•The printer is properly attached to the high

capacity feeder.

•The printer is powered on.

•The power cord is plugged firmly into the back

of the high capacity feeder.

•The power cord is plugged into an outlet.

•The outlet has power.

The paper tray lowers unexpectedly

Check to see if your printer is out of paper or has a

jam.

More than one sheet of paper is fed or a

sheet is fed improperly

Remove the paper in the printer paper path, and

check the stack to ensure the paper has been loaded

properly. Be sure to remove the top and bottom

sheets of each ream of paper that is loaded.

A jam occurs

Remove the paper in the printer paper path, and

check the stack to ensure the paper has been loaded

properly. Be sure to remove the top and bottom

sheets of each ream of paper that is loaded.

Rubber feed rollers do not turn to

advance paper.

Check the following:

•The power cord is plugged firmly into the back

of the high capacity feeder.

•The power cord is plugged into an outlet.

•The outlet has power.

Consistent misfeeds or jams in the

feeder.

Try the following:

•Flex the paper.

Option Action

Drawers • Make sure the connection between

drawers and the printer is secure.

• Make sure the print media is loaded

correctly.

Duplex

unit

Make sure the connection between the

duplex unit and the printer is secure. If the

duplex unit is listed on the menu settings

page, but print media jams when it enters or

exits the duplex unit, the printer and duplex

unit may not be properly aligned.

Flash

memory

Make sure flash memory is securely

connected to the printer system board.

Hard

disk with

adapter

Make sure the hard disk is securely

connected to the printer system board.

Internal

server

• Make sure the internal print server (also

called an internal network adapter or INA)

is securely connected to the printer

system board.

• Make sure you are using the correct cable,

that it is securely connected, and the

network software is correctly set up.

For more details, see the Software and

Documentation CD that shipped with your

printer.

High

capacity

feeder

See Solving high capacity feeder

problems.

Printer

memory

Make sure printer memory is securely

connected to the printer system board.

Serial/

Parallel

interface

• Make sure the Serial/parallel interface

card is securely connected to the printer

system board.

• Make sure you are using the correct cable

and that it is securely connected.

•Turn the print media over.

Check the following:

•Feeder is properly installed.

•Paper is loaded correctly.

•Paper is not damaged.

•Paper meets specifications.

•Guides are positioned correctly for the paper

size selected.

Service messages

A service message indicates printer failure that may

require service.

Turn the printer off, wait about 10 seconds, and then

turn the printer on.

If the error recurs, write down the error number, the

problem, and a detailed description. Call 1-800-

LEXMARK for service.

Solving paper feed

problems

Paper frequently jams

You are using paper that does not meet

the printer specifications.

Use recommended paper and other specialty media.

See the Card Stock & Label Guide available on the

Lexmark Web site at www.lexmark.com for detailed

specifications.

For information that can help prevent jams from

occurring, see the Clearing Jams Guide.

You have loaded too much paper or too

many envelopes.

Make sure the stack of paper you load does not

exceed the maximum stack height indicated at the

front of the tray or on the multipurpose feeder.

Guides in the selected tray are not set to

the appropriate position for the size

paper loaded.

Move the guides in the tray to the correct position.

The paper has absorbed moisture due to

high humidity.

Load paper from a fresh package.

Store paper in its original wrapper until you load it.

The Paper Jam message remains

after you remove the jammed

paper.

Clear paper from the entire paper path, and then

press .

The page that jammed does not

reprint after you clear the jam.

Set Jam Recovery to Auto or On.

For more information, see the Menus and Messages

Guide

Blank pages feed into the output

bin.

Load the correct type media for your print job, or

change the Paper Type to match the type of media

loaded.

For more information, see the Menus and Messages

Guide.

Original documents misfeed in the

ADF

•Adjust the guides toward the media until they

lightly rest against the edge of the media.

•If the pick pad is worn, replace the pick pad.

Solving print quality

problems

To help isolate print quality problems, print the Print

Quality Test Pages.

1Turn the printer off.

2Press and . Hold them while you turn

the printer on, and until the Performing Self

Test message appears.

Config Menu appears.

3Press until Prt Quality Pgs appears,

and then press .

The pages are formatted. The Printing

Quality Test Pages message appears, then

the pages print. The message remains on the

operator panel until all the pages print.

After the Print Quality Test Pages print, to exit

the Config Menu:

4Press until Exit Config Menu

appears, and then press to complete the

procedure.

Color misregistration

Color has shifted outside of the appropriate area or

has been superimposed over another color area.

Open the printer door, and make sure all four

packaging tabs are removed.

Top to Bottom or Left to Right:

1Re-seat the cartridges by removing them from

the printer and then reinserting them.

2Invoke a Color Adjust operation from the

Settings Quality menu.

Repeating defects

Marks occur repeatedly only in one color and multiple

times on a page:

•Replace the cartridge if the defects occur every:

–38 mm (1.5 in.)

–48 mm (1.9 in.)

–97 mm (3.8 in.)

Marks occur down the page repeatedly in all colors:

•Replace the transfer roll if the defects occur

every 60 mm (2.4 in.)

•Check the first transfer bellcranks and springs

or replace the image transfer unit if the defects

occur every 101 mm (4 in.)

•Replace the fuser if the defects occur every

148 mm (5.8 in.)

Marks occur on every third or sixth page in any

color:

Replace the image transfer unit.

White or colored lines

1Replace the color print cartridge that is causing

the line.

2If you still have the problem, replace the image

transfer unit and transfer roller.

3If you still have the problem, replace the fuser.

Streaked horizontal lines

Replace the print cartridge, the transfer roller, the

image transfer unit, or fuser as needed.

From the printer operator panel, print the repetitive

defects guide to determine which component needs

to be replaced.

Streaked vertical lines

•If paper is stiff, try feeding from another tray.

•Replace the print cartridge that corresponds to

the color displayed on the control panel.

Print irregularities

•Load paper from a fresh package in the paper

tray.

•Avoid textured paper with rough finishes.

•Make sure the printer paper type, paper texture,

and paper weight settings match the type of

paper you are using.

•Replace the image transfer unit and transfer

roller.

•Replace the fuser.

Print too light

•Make sure the printer paper type, paper texture,

and paper weight settings match the type of

paper you are using.

•The default Paper Weight setting in the Paper

Menu is Normal. For paper less than 20 lb bond

(75 g/m2), choose the Light setting. For 28 lb

bond to 47 lb bond (105 g/m2to 175 g/m2),

choose the Heavy setting.

•Select a different Toner Darkness setting from

the printer driver before sending the job to print.

•Scroll to the Color Adjust setting in the Quality

Menu and press Select to adjust the color.

•Load paper from a new package.

•Avoid textured paper with rough finishes.

•Make sure the paper you load in the trays is not

damp.

•Shake the specified print cartridge to utilize the

remaining toner.

•Replace the print cartridge that corresponds to

the color displayed on the control panel.

Print too dark

•Select a different Toner Darkness setting from

the printer driver before sending the job to print.

•Scroll to the Color Adjust setting in the Quality

Menu and press Select to adjust the color.

•Replace the print cartridge that corresponds to

the color displayed on the control panel.

Transparency print quality is poor

•Use only transparencies recommended by the

printer’s manufacturer.

•Make sure the Paper Type setting is set to

Transparency.

Toner specks

•Replace the print cartridge that corresponds to

the color displayed on the control panel.

•Replace the transfer roller.

•Replace the image transfer unit.

•Replace the fuser.

•Call for service.

Solving copy quality

problems

Unwanted background is visible

Adjust the Background Removal setting under

Copy Options Advanced Imaging. Touch the

right arrow to remove more background.

Unwanted patterns (Moire) appear

when a document is copied using

Photograph mode

Change the content mode to Printed Image under

CopyOptions Content.

Vertical or horizontal lines are

noticed on copied pages

Clean the ADF scanner glass and backing material.

Black text is too light or

disappearing

•Adjust the Darkness setting under the Copy

menu. Touch the right arrow to increase the

darkness setting.

•Change the content mode to Text under

Copy Options Content.

•Adjust the Background Removal setting under

Copy Options Advanced Imaging.

Touch the left arrow to remove less background.

•Adjust the Contrast setting under Copy 

Options Advanced Imaging. Touch the

right arrow to add more contrast.

•Adjust the Shadow Detail setting under

Copy Options Advanced Imaging.

Touch the left arrow to decrease shadow detail.

The copy looks washed out or

overexposed

•Adjust the Background Removal setting under

Copy Options Advanced Imaging.

Touch the left arrow to remove less background.

•Adjust the Shadow Detail setting under

Copy Options Advanced Imaging.

Touch the left arrow to remove more shadow

detail.

Solving scan quality

problems

The file size is too big when I scan

a document to the network

•Touch Options, then under Resolution,

decrease the output resolution.

•Touch Options, then under Content, change

the Color option to black and white.

•Touch Options, then under Content, change

the setting to Text.

Text characters do not look sharp

when I scan a document to the

network

•Touch Options, then under Resolution,

increase the output resolution.

•Touch Options, then under Content, change

the setting to Text.

Black text is too light or

disappearing

•Adjust the Darkness setting. Touch the right

arrow to increase the darkness setting.

•Change the content mode to Text.

•Adjust the Background Removal setting under

Advanced Imaging. Touch the left arrow to

remove less background.

•Adjust the Contrast setting under Advanced

Imaging. Touch the right arrow to add more

contrast.

•Adjust the Shadow Detail setting under

Advanced Imaging. Touch the left arrow to

decrease shadow detail.

Unwanted background is visible

Adjust the Background Removal setting under

Advanced Imaging. Touch the right arrow to remove

more background.

Solving fax problems

The fax document takes a long

time to transmit

Touch Options, then under Content, change the

setting to Text, and then set the resolution to

Standard.

The images on the fax I sent are

not clear

Touch Options, then under Content, change the

setting to Text/Photo or Photo.

Increase the output resolution.

Note: This will increase the amount of

time required for the scan and will

increase the quality of the fax

output.

Caller ID is not shown

If your region supports caller ID, you may have to

change the default setting. There are two settings

available, FSK (pattern 1) and DTMF (pattern 2).

Contact your telecommunications company to

determine which pattern or switch setting to use.

Andere Handbücher für X782

Inhaltsverzeichnis

Andere Lexmark Multifunktionsdrucker Handbücher

Lexmark

Lexmark MS911 Bedienungsanleitung

Lexmark

Lexmark 43J3400 - Optra S 2455 B/W Laser Printer Bedienungsanleitung

Lexmark

Lexmark 3100 Series Bedienungsanleitung

Lexmark

Lexmark XM3150 Montage- und Wartungsanleitung

Lexmark

Lexmark MX710 Series Montage- und Wartungsanleitung

Lexmark

Lexmark X925 Bedienungsanleitung

Lexmark

Lexmark X6170 4408-K01 Bedienungsanleitung

Lexmark

Lexmark X746 Handbuch

Lexmark

Lexmark X560(n) Bedienungsanleitung

Lexmark

Lexmark E234 Produktinformationsblatt

Lexmark

Lexmark X2530 Betriebsanleitung

Lexmark

Lexmark 544n - X Color Laser Bedienungsanleitung

Lexmark

Lexmark S315 Bedienungsanleitung

Lexmark

Lexmark X664e MFP Handbuch

Lexmark

Lexmark X940E Bedienungsanleitung

Lexmark

Lexmark 464de - X B/W Laser Bedienungsanleitung

Lexmark

Lexmark GENESIS S815 Bedienungsanleitung

Lexmark

Lexmark 22G0320 Bedienungsanleitung

Lexmark

Lexmark XM7100 Series Bedienungsanleitung

Lexmark

Lexmark CX310 series Bedienungsanleitung

Lexmark

Lexmark MB2650 Bedienungsanleitung

Lexmark

Lexmark CX510 series Bedienungsanleitung

Lexmark

Lexmark X850e Bedienungsanleitung

Lexmark

Lexmark OfficeEdge Pro4000c Bedienungsanleitung

Beliebte Multifunktionsdrucker Handbücher anderer Marken

Triumph Adler

Triumph Adler DC 2016 Handbuch

Epson

Epson WorkForce WF-2510 Benutzerhandbuch

Epson

Epson Stylus Scan 2000 Installations- und Betriebshandbuch

Epson

Epson PictureMate Snap PM 240 Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub C35 Bedienungsanleitung

Brother

Brother MFC-J430w Bedienungsanleitung

Konica Minolta

Konica Minolta BIZHUB 558 Bedienungsanleitung

Brother

Brother MFC-9760 Bedienungsanleitung

Sharp

Sharp MX-2310U Leitfaden

Aficio

Aficio 200 Bedienungsanleitung

Canon

Canon ImageCLASS 2300 Handbuch

Ricoh

Ricoh Pro C900 Bedienungsanleitung

Brother

Brother Business Smart MFC-J4510dw Bedienungsanleitung

Epson

Epson Stylus CX8400 Series Bedienungsanleitung

Oce

Oce VarioLink 5022 Bedienungsanleitung

Copystar

Copystar CS 4551ci Bedienungsanleitung

Konica Minolta

Konica Minolta Magicolor 4650EN Bedienungsanleitung

Brother

Brother MFC-9840CDW Bedienungsanleitung
