Quick Reference

Loading paper

Loading trays

CAUTION—TIPPING HAZARD: To reduce the risk of

equipment instability, load each tray separately. Keep all

other trays closed until needed.

Pull out the tray.

Note: Do not remove trays while the printer is busy.

Adjust the guides to match the size of the paper you are

Note: Use the indicators on the bottom of the tray to position

the guides.

Flex, fan, and align the paper edges before loading.

Load the paper with the printable side faceup.

Notes:

•

Do not slide paper into the tray.

•

Make sure that the stack height is below the maximum

paper ﬁll indicator. Overﬁlling may cause paper jams.

Insert the tray.

If loading a paper type other than plain, set the paper size and

type to match the paper loaded in the tray.

Loading the multipurpose feeder

Open the multipurpose feeder.

Adjust the guide to match the size of the paper you are loading.

Flex, fan, and align the paper edges before loading.

Load the paper.

•

Load paper, card stock, and transparencies with the

printable side facedown and the top edge entering the

printer ﬁrst.

•

Load envelopes with the ﬂap side up and against the left

side of the paper guide. Load European envelopes with the

ﬂap side up and entering the printer ﬁrst.

Warning—Potential Damage: Do not use envelopes with

stamps, clasps, snaps, windows, coated linings, or

self

‑

stick adhesives.

From the control panel, set the paper size and type to match

the paper loaded in the tray.

Setting the size and type of the

specialty media

The trays automatically detect the size of plain paper. For specialty

media like labels, card stock, or envelopes, do the following:

From the home screen, navigate to:

Settings > Paper > Tray Conﬁguration > select a tray

Conﬁgure the size and type of the specialty media.

Printing

Printing from a computer

Note: For specialty media such as labels, card stock, and

envelopes, set the paper size and type in the printer before

sending the print job.

With a document open, click File > Print.

If necessary, adjust the settings.

Send the print job.

Printing held jobs

With a document open, select File > Print.

Select the printer, and then do the following:

•

For Windows users, click Properties or Preferences, and

then click Print and Hold.

•

For Macintosh users, select Print and Hold.

Select the print job type.

If necessary, assign a user name.

Send the print job.

From the printer home screen, touch Held Jobs.

Send the print job.

Canceling a print job

From the printer control panel

From the home screen, touch Job Queue.

Note: You can also access this setting by touching the top

section of the home screen.

Select the job to cancel.

From the computer

Depending on the operating system, do either of the following:

•

Open the printers folder, and then select your printer.

•

From the System Preferences in the Apple menu, navigate

to your printer.

Select the job to cancel.

Maintaining the printer

Replacing a toner cartridge

Open door A.

Remove the toner cartridge.

Unpack the new toner cartridge.

Insert the new toner cartridge until it clicks into place.

Close door A.

Clearing jams

Avoiding jams

Load paper properly

•

Make sure that the paper lies ﬂat in the tray.

Correct loading of paper Incorrect loading of paper

•

Do not load or remove a tray while the printer is printing.

•

Do not load too much paper. Make sure that the stack height

is below the maximum paper ﬁll indicator.

•

Do not slide paper into the tray. Load paper as shown in the

illustration.

•

Make sure that the paper guides are positioned correctly and

are not pressing tightly against the paper or envelopes.

•

Push the tray ﬁrmly into the printer after loading paper.

Use recommended paper

•

Use only recommended paper or specialty media.

•

Do not load paper that is wrinkled, creased, damp, bent, or

curled.

•

Flex, fan, and align the paper edges before loading.

•

Do not use paper that has been cut or trimmed by hand.

•

Do not mix paper sizes, weights, or types in the same tray.

•

Make sure that the paper size and type are set correctly on the

computer or printer control panel.

•

Store paper according to manufacturer recommendations.

Paper jam in trays

Pull out the tray.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Insert the tray.

Open the tray cover.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Close the tray cover.

Paper jam in the multipurpose feeder

Remove paper from the multipurpose feeder.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Open door B, and then remove any paper fragments.

CAUTION—HOT SURFACE: The inside of the printer

might be hot. To reduce the risk of injury from a hot

component, allow the surface to cool before touching

it.

Close door B.

Flex, fan, and align the paper edges before loading.

Reload paper.

Paper jam in the standard bin

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Open door B, and then remove any paper fragments.

CAUTION—HOT SURFACE: The inside of the printer

might be hot. To reduce the risk of injury from a hot

component, allow the surface to cool before touching

it.

Close door B.

Paper jam in door B

Paper jam in the fuser

Open door B.

CAUTION—HOT SURFACE: The inside of the printer

might be hot. To reduce the risk of injury from a hot

component, allow the surface to cool before touching

it.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Open the fuser access door.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Close door B.

Paper jam in the duplex unit

Open door B.

CAUTION—HOT SURFACE: The inside of the printer

might be hot. To reduce the risk of injury from a hot

component, allow the surface to cool before touching

it.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Open the duplex cover.

Remove the jammed paper.

Note: Make sure that all paper fragments are removed.

Close the duplex cover and door B.
