Limefuel BLAST L156X Bedienungsanleitung
BLAST
L156X
limefuel.com
facebook.com/limefuel
@limefuel
Warranty
Limefuel provides our customers with a 12 month warranty from the date of
purchase. Please visit limefuel.com for terms and to learn more.
Contact
For questions, inquiries or comments concerning our products, please email
[email protected]. Additional product information and a downloadable
version of this manual can be found online at limefuel.com.
WHAT’S IN THE BOX?
15600mAh External Battery
2-in-1 Micro USB with Lightning Compatible Power Cable
124
mm
(4.8")
79mm
(3.1")
24mm
(0.9")
WEIGHT
363g
(12.8oz)
SPECIFICATIONS
OUT OUTLED
IN
BATTERY CAPACITY
BATTERY CELL
INPUT
INPUT CHARGING TIME
CYCLE LIFE
INTERNET
TALK
MUSIC
GAMING
15600 MAH / 57.72 WH
LITHIUM-ION
5V/2.0A (MAX)
9-16 HOURS
OVER 500 USES
Performance (Depending on device)
Up to 103 additional hours
Up to 134 additional hours
Up to 359 additional hours
Up to 109 additional hours
OUTPUT 1
OUTPUT 2
5V/2.4A (MAX)
5V/2.4A (MAX)
TOTAL OUTPUT 5V/4.2A
MICRO
USB
LIGHTNING
COMPATIBLLE COMPATIBLE END,
GRASP & PULL
TO REMOVE
LIGHTNING
INSTRUCTIONS
Powering On and Off
Simply pressing the power button turns on the unit. Power level of the external battery is
indicated by four LED lights. Each LED light represents a 25% range of power. Unit will
automatically turn off after being unplugged from charger/device or once device is fully
charged. Press power button twice to turn built-in flash light on and off.
Charging Your Battery
Connect the Micro USB end of the included charging cable into the external battery input
port. Insert the USB end into a compatible wall charger, car charger or computer USB port
and battery will begin to charge. Once battery is fully charged, all LED lights will be lit and
unit will automatically turn off after being unplugged.
LED POWER
LEVEL INDICATOR
100%
75%
50%
25%
POWER
BUTTON
USB TO
COMPATIBLE
CHARGER
MICRO-
USB TO
2.0A IN
OUT OUTLEDIN
Charging Your Device
The external battery has two output ports, both 5V/2.4A. Connect the USB power cable to
one of the two USB output ports on the battery. If using the included USB power cable,
attach the proper adapter for your device and connect the device to the cable. Battery will
automatically turn on when cable and device are connected to the output port.
Compatible Devices
Most electronic devices meant to be charged from a USB source:
iPhone, iPad, iPod, MP3 players, Android Phones, Windows Phones, Smartphones, Tablets,
Kindle, Gaming Devices, GPS, digital cameras and camcorders, mobile phones, portable
speakers and headphones, and bluetooth devices.
Does NOT charge laptops.
Proper Use and Safety
Read the following information before using external battery. Charging time for battery
depends on charging method used. Do not pierce or mechanically damage the battery. Do
not expose battery to heat over 45˚C (113˚F). Never throw into water, chemical solvents
or fire. Use for intended purpose only. Do not disassemble or modify battery. Stop using
battery immediately if it begins to smoke, a strange smell appears, battery leaks or
distorts in any way. Not for children.
Recycle
When your Limefuel battery is no longer pumping up your devices, please recycle it
responsibly so it can live again. The lithium-ion and lithium polymer batteries contained
in Limefuel external battery packs should not be tossed out with everyday refuse. Doing
so could harm the environment. Team Limefuel asks that you recycle your Limefuel
battery responsibly. Many cities offer battery recycling services. Regulations may vary per
municipality or state.
USB CABLE
TO BATTERY
OUTPUT
CONNECT
YOUR DEVICE
WITH EITHER
MICRO-USB
OR LIGHTNING
ADAPTER
