LIMIT Limit 21 Bedienungsanleitung

Red Black

fig.1 DC/AC Voltage Measurement

Red Black

fig.2 Testing for Continuity

40A

400A

fig.3 DC/AC Current Measurement

Screw

fig.4 Replacing the Battery

Illustrations

A. DC Voltage

Range Resolution Accuracy Overload protection

400.0mV

4.000V

40.00V

400.0V

600V

0.1mV

1mV

10mV

100mV

(0.8%+3)

(0.8%+1)

(1%+3)

600V DC/AC

B. AC Voltage

Range Resolution Accuracy Overload protection

4.000V

40.00V

400.0V

600V

1mV

10mV

100mV

(1%+5)

(1.2%+5)

600V DC/AC

C. Resistance

Range Resolution Accuracy Overload protection

400.0

4.000k

40.00k

400.0k

4.000M

40.00M

100m

100

10k

(1.2%+2)

(1%+2)

(1.2%+2)

(1.5%+2)

600Vp

D. Diode Test

Range Resolution Accuracy Overload protection

1mV Display forward voltage

drop nearest value 600Vp

E. Continuity Test

Range Resolution Accuracy Overload protection

100m Around 50 ,

the buzzer beeps 600Vp

Tables

F. Frequency

Range Resolution Accuracy Overload protection

10Hz

100Hz

1kHz

10kHz

100kHz

1MHz

10MHz

0.001Hz

0.01Hz

0.1Hz

1Hz

10Hz

100Hz

1kHz

(0.1%+3) 600Vp

For reference only

G. Duty Cycle

Range Resolution Accuracy Overload protection

0.1% For reference only 600Vp0.1%~99.9%

H. DC Current

Range Resolution Accuracy Overload protection

0.01A

0.1A 400A DC/AC

40.00A

400.0A (2%+5)

(2%+3)

I. AC Current

Range Resolution Accuracy Overload protection

0.01A

0.1A 400A DC/AC

40.00A

400.0A (2.5%+8)

(2.5%+5) 50Hz ~ 60Hz

Frequency Response

Tables

Language Contents

Language page

English ································································································7-14

Svenska ····························································································15-21

Norsk·································································································22-28

Dansk································································································29-35

Suomi································································································36-42

Deutsch·····························································································43-51

Nederlands························································································52-60

Français ····························································································61-69

Italiano·······························································································70-78

Español ·····························································································79-87

Português··························································································88-96

Ελληvikά··························································································97-105

Polski·····························································································106-115

Eesti ······························································································116-123

LietuviŠkai·····················································································124-131

Latviski ··························································································132-139

Pycckий ························································································140-148

Contents

Overview

General specification

Safety information

Voltage DC and AC

Current DC and AC

Resistance

Frequence and Duty cycle

Diodes test

Continuity test

Battery

English

Overview

This Operating Manual covers information on safety and cautions. Please read the

relevant information carefully and observe all the Warnings and Notes strictly.

Limit 21 is a clampmeter/multimeter for professional use. The instrument have

autorange and the display have large digits, shows rotary switch position witch

makes this instrument easy to handle for the user. For indoor use.

General Specifications

Measuring range and accuracy see page 2.

• Auto range.

• Display shows selected function.

• Maximum Display: 3999 or 3 ¾ digits.

• Displays OL when the instrument is overloaded.

• Max conductor diameter for clamp 26 mm.

• Sleep mode. Instrument turn off automatic if not active for 15 minutes.

• Measurement Speed: Updates 3 times /second.

• Temperature: Operating: 0°C~30°C

Storage: -20°C~60°C

• Battery 1 pcs 9 V Type 6F22.

English

• Safety/Compliances: IEC61010 CAT II 600V CAT III 300 V over voltage and

double insulation standard.

• Certification: CE

Safety Information

This Meter complies with the standards IEC61010: in pollution degree 2, category

CAT II 600V, CAT III 300V over voltage and double insulation.

Warning

To avoid possible electric shock or personal injury, and to avoid possible damage

to the Meter or to the equipment under test, adhere to the following rules:.

• Before using the Meter inspect the case. Do not use the Meter if it is damaged or

the case (or part of the case) is removed. Look for cracks or missing plastics. Pay

attention to the insulation around the connectors.

• Inspect the test leads for damages insulation or exposed metal. Check the test

leads for continuity.

• Do not apply more than the rated voltage, as marked on the Meter, between the

terminals or between any terminal and the grounding.

English
