DEMO MANUAL DC1929A

Description

LT3752-1/LT8311

200W Active Clamp Forward

Converter with Input Voltage 150V to 400V

Demonstration circuit 1929A is a 200W active clamp for-

ward converter featuring the LT

3752-1/LT8311 chipset.

It operates at about 100kHz and produces a regulated 12V

output from an input voltage ranging from 150V to 400V,

making it well suited for automotive, industrial, and other

applications. Table 1 summarizes the performance of the

demo board.

The LT3752-1 is a current mode PWM controller opti-

mized for a forward converter with high-side active clamp

transformerreset.Anaccurate,programmablevolt-second

clamp allows primary switch duty cycles above 50% for

better utilization of switch, transformer and rectifier. The

AOUT control signal can be used to power a gate drive

transformer, level-shift driver, or opto-coupler driver

for the high-side N-channel FET. The SOUT controls the

secondary side synchronous rectification. The integrated

housekeeping flyback controller brings great convenience

for both primary and secondary bias circuits. During its

soft-start and soft-stop, LT3752-1 folds back switching

L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear

Technology Corporation. All other trademarks are the property of their respective owners.

performance summary

frequency and duty-ratio clamp, thus reduces the electri-

cal stresses over the output inductor, and transformer.

TheLT3752-1featuresasetofsafetyprotectionsincluding

undervoltage,overvoltageandovercurrentprotections.Its

precise overcurrent protection allows for continuous reli-

able operation under short-circuit conditions. The LT8311

controlsthesecondarysidesynchronousrectification,with

enhanced regulation of the output voltage during startup,

shutdown or recovery from a fault.

The LT3752-1 and LT8311 data sheets give complete

descriptions of the parts, operation and application infor-

mation. The data sheet must be read in conjunction with

this quick start guide for Demo Circuit 1929A.

Design files for this circuit board are available at

http://www.linear.com/demo/DC1929A

Specifications are at TA= 25°C

PARAMETER CONDITIONS MIN TYP MAX UNITS

Input Voltage Range (VIN) 150 250 400 V

Startup Voltage 150 V

UVLO Shutdown Voltage 147 V

OVLO Shutdown Voltage 416 V

Output Voltage (VOUT) VIN = 150V to 400V 11.76 12 12.24 V

Rated Output Current Continuous (IOUT) 300LFM 16.7 A

Short-term Output Current (IMAX) 300LFM, 1 Minute 20 A

Switching Frequency (fSW) 100 kHz

Output Voltage Ripple (Peak_to_Peak) 120 mVP-P

No Load Current IOUT = 0A, VIN = 400V 18 mA

Efficiency VIN = 250V, IOUT = 16.7A, 300LFM 93.9 %

Isolation (Primary and Secondary) 1500 V

dc1929afa

DEMO MANUAL DC1929A

Quick start proceDure

IMPORTANT NOTE TO CUSTOMERS:

HAZARDOUS HIGH VOLTAGES ARE PRESENTED ON

THE DEMO CIRCUIT. IMPROPER OR UNSAFE HAN-

DLING OF THIS DEMO BOARD CAN LEAD TO LETHAL

INJURIES TO HUMAN BODY. ONLY QUALIFIED PER-

SONEL SHOULD OPERATE IT. YOU ARE STRONGLY

RECOMMENDED TO USE SAFETY GLASSES AND

AN ISOLATION TRANSFORMER. IMPROPER COM-

PONENTS REPLACEMENT ON THE DEMO CIRCUIT

CAN CAUSE PERFORMANCE DETERIORATIONS,

CIRCUITMALFUNCTION,PROPERTY DAMAGE,AND

EVEN LIFE-THREATHENING INJURIES. CONTACT

LINEAR TECHNOLOGY APPLICATIONS ENGINEERS

FOR PROPER COMPONENT REPLACEMENT AND

CIRCUIT MODIFICATION.

Demonstration circuit 1929A must be set up as follows

to evaluate the performance of the LT3752-1/LT8311.

Refer to Figure 1 for proper equipment setup and follow

the procedure below.

NOTE. Do not operate DC1929A unless you have the ap-

propriate safety precautions in place on your bench to

guarantee safety. Always remove power before touching,

servicing, or attaching probes to the demo board. Never

leave the DC1929A unattended when under power.

1. With power off, connect the input power supply to the

board. The power supply should be adjustable over

100V ~ 450V range, and at least 3A current capability.

An ammeter capable of measuring 3ADC can be put in

series with the input supply to measure the input cur-

rent. Connect the load to the terminals VOUT+(J1) and

VOUT–(J2) on the board. The load should be adjustable

up to 20A. If efﬁciency measurements are desired, an

ammeter capable of measuring 20ADC or a resistor

shunt can be put in series with the load to measure the

output current. A voltmeter can be placed across the

output terminals (E4, E5) in order to get an accurate

output voltage measurement.

2. Direct airﬂow of 300LFM across the demo circuit for

sustained operation at full load. Refer to Figure 1 for

proper airﬂow direction.

3. Turn on the power at the input. Increase VIN slowly to

150V.

NOTE. Make sure that the input voltage does not exceed

400V. Make sure the load current does not exceed the

specifications.

NOTE. Check the standby current without any load applied

and it should be less or around 25mA at 150V input, or

20mAat400Vinput.Anycross-conductionoftheprimary-

secondary switches will significantly increase the standby

current.

4. Checkfortheproperoutputvoltages.Theoutputshould

be regulated at 12.0V (±2%).

NOTE. If there is no output, temporarily disconnect the

load to make sure that the load is not set too high.

NOTE. By removing the resistor R2, and applying the VIN

between VBand –VIN, the main power circuit is discon-

nected from the control/bias circuits, and the control/bias

circuit can be debugged separately. The standby current

of the control/bias circuit should be less than 2mA.

NOTE. By removing R37 and R40, and adjusting R25 to

107k, the feedback loop is disabled, and the circuit runs

in no-opto bus converter mode.

5. Once the proper output voltage is established, adjust

the input voltage and load current within the operating

range and observe the output voltage regulation, ripple

voltage, efﬁciency and other parameters.

NOTE. When measuring the output voltage ripples, care

must be taken to avoid a long ground lead on the oscillo-

scopeprobe.SeeFigure2forproperscopeprobetechnique.

NOTE. Airflow should be directed to the demo circuit ac-

cording to the direction shown in Figure 1. Running the

circuitatfullload without airflowcouldoverheatthepower

components, and lead to damage of the board. Overload

operationofthedemocircuitisfeasibleforshort-termonly.

Long term overcurrent operation is not recommended,

unless enhanced cooling methods are used.

6. Turn off the load at the output, the power at the input,

and then turn off the airﬂow.

dc1929afa

DEMO MANUAL DC1929A

Quick start proceDure

+ –

VOUT GND

COUT

–

–LOAD

IOUT

VOUT

VIN

IIN

–

POWER

SUPPLY

Figure 1. Proper Measurement Equipment Setup

Figure 2. Proper Scope Probe Placement for Measuring Output Ripple

dc1929afa

DEMO MANUAL DC1929A

Quick start proceDure

80.00

82.00

84.00

86.00

88.00

90.00

92.00

94.00

96.00

0.0 2.0 4.0 6.0 8.0 10.0

LOAD CURRENT (A)

EFFICIENCY (%)

12.0 14.0 16.0 18.0

VIN = 150V

VIN = 250V

VIN = 400V

Figure 3. Typical Efficiency Curve, (300LFM, TA= 25°C)

Figure 4. Output Ripple at 250VIN at 16.7AOUT

VOUT

50mV/DIV

dc1929afa

DEMO MANUAL DC1929A

Quick start proceDure

Figure 5. Short-Circuit at Output at VIN = 400V

SW1

50V/DIV

20V/DIV

DRAIN

200V/DIV

SW2

dc1929afa

DEMO MANUAL DC1929A

parts List

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

1 9 CIN1-CIN9 CAP., X7T, 0.22µF, 630V, 10% 1812 TDK, C4532X7T2J224K

2 4 CO1, CO2, CO3, CO4 CAP., X7R, 33µF, 16V, 20%, 1812 TDK, C4532X7R1C336M

3 1 CSYS1 CAP., ALUM, 1000µF, 16V, SEPF SERIES PANASONIC, 16SEPF1000M

4 1 CY1 CAP., CER, 2200pF, 500VAC, 20% RADIAL VISHAY, VY1222M47Y5UG63V0

5 1 C1 CAP., X7R, 10nF, 250V, 10% 1210 AVX, 1210PC103KAT1A

6 1 C4 CAP., X7R, 4.7µF, 25V, 10%, 1206 TDK, C3216X7R1E475K

7 2 C5, C8 CAP., X7R, 47nF, 630V, 10%, 1812 AVX, 1812CC473KAT1A

8 1 C6 CAP., X7R, 22µF, 25V, 10%, 1210 MÜRATA, GRM32ER71E226K

9 1 C7 CAP., CH, 10nF, 630V, 10%, 1210 TDK, C3225CH2J103J125AA

10 1 C10 CAP., X7R, 10µF, 25V, 10%, 1210 AVX, 12103C106KAT2A

11 2 C11, C27 CAP., X7R, 22nF, 50V, 10%, 0603 AVX, 06035C223KAT2A

12 1 C12 CAP., C0G, 220pF, 25V, 5%, 0603 AVX, 06033A221JAT2A

13 2 C13, C21 CAP., C0G, 470pF, 25V, 5%, 0603 AVX, 06033A471JAT2A

14 1 C14 CAP., X7R, 1nF, 25V, 10%, 0603 AVX, 06033C102KAT2A

15 2 C22, C26 CAP., X5R, 4.7µF, 25V, 10%, 0805 AVX, 08053D475KAT2A

16 1 C23 CAP., X7R, 0.47µF, 16V, 10%, 0603 TDK, C1608X7R1C474K

17 1 C24 CAP., X7R, 0.22µF, 25V, 10%, 0603 AVX, 06033C224KAT2A

18 2 C25, C31 CAP., X5R, 2.2µF, 16V, 10%, 0603 AVX, 0603YD225KAT2A

19 1 C28 CAP., C0G, 68pF, 50V, 5%, 0603 AVX, 06035A680JAT2A

20 1 C29 CAP., X7R, 1µF, 25V, 10%, 0603 AVX, 06033C105KAT2A

21 1 C30 CAP., X7R, 0.22µF, 50V, 10%, 0805 AVX, 08055C224KAT2A

22 1 C32 CAP., C0G, 10pF, 50V, 5%, 0603 AVX, 06035A100JAT2A

23 1 C33 CAP., Alum. Electro. 2.2µF, 450V, G13 size Panasonic, EEVEB2W2R2Q

24 2 D1, D2 Schottky Barrier Rec., POWER-DI-123 DIODE INC., DFLS1200-7

25 4 D4, D5 Diode, High-Speed Diode, SOD-523 NXP/Phillips Semi. BAS516

26 1 D10 Schottky Barrier Rec., SOD-123 CENTRAL SEMI., CMMR1U-02

27 1 D12 Rectifier, 1000V, 1A, SMB CENTRAL SEMI., CMR1U-10

28 1 F1 FUSE, 600V, 2.5A, 485 SERIES Littelfuse, 048502.5DR

29 1 L1 IND., 15µH Coilcraft, AGP2923-153KL

30 1 L2 IND., 4.7µH, XAL40xx SERIES Coilcraft, XAL4030-472ME

31 1 Q1 N-Chan. BSP300, SOT-223 infineon, BSP300

32 3 Q2, Q3, Q8 FET, N-CH, POWER 56 Fairchild, FDMS86200

33 2 Q4, Q5 FET, N-CH, LFPAK RENESAS, RJK0653DPB-00#J5

34 1 Q6 Power Transistor, 600V, DPAK Infineon, IPD60R1K4C6

35 1 Q7 Power Transistor, 650V, DPAK Infineon, IPD65R250C6

36 1 Q9 NPN/PNP Transistor, SC-74 NXP SEMI., PBSS4140DPN

37 1 RCS1 RES., CHIP., 0.2, 1/8W, 1% 0805 VISHAY, WSL0805R200FEA

38 1 RCS2 RES., CHIP., 0.039, 1W, 1%, PRL1632 SUSUMU, PRL1632-R039-F-T1

39 1 RCS3 RES., CHIP., 0.002, 1W, 2%, PML18 ROHM, PML18EZPGV2L00

40 2 R1,R6 RES., CHIP., 20k, 1/4W, 1%, 1206 VISHAY, CRCW120620K0FKEA

41 1 R2 RES., CHIP., 2, 1/4W, 1%, 1206 VISHAY, CRCW12062R00FKEA

dc1929afa

DEMO MANUAL DC1929A

parts List

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

42 1 R5 RES., CHIP., 3.3, 1/10W,1%, 0603 VISHAY, CRCW06033R30FKEA

43 2 R7, R14 RES., CHIP., 374k, 1/4W, 1%, 1206 VISHAY, CRCW1206374KFKEA

44 1 R8 RES., CHIP., 402, 1/4W, 1%, 1210 VISHAY, CRCW1210402RFKEA

45 2 R9, R17 RES., CHIP., 499k, 1/4W, 1%, 1206 VISHAY, CRCW1206499KFKEA

46 1 R10 RES., CHIP., 232, 1/10W,1%, 0603 VISHAY, CRCW0603232RFKEA

47 1 R11 RES., CHIP., 499, 1/10W,1%, 0603 VISHAY, CRCW0603499RFKEA

48 1 R15 RES., CHIP., 806, 1/10W,1%, 0603 VISHAY, CRCW0603806RFKEA

49 1 R16 RES., CHIP., 2.80k, 1/10W, 1%, 0603 VISHAY, CRCW06032K80FKEA

50 1 R18 RES., CHIP., 5.76k, 1/10W, 1%, 0603 VISHAY, CRCW06035K76FKEA

51 1 R19 RES., CHIP., 200, 1/10W, 5%, 0603 VISHAY, CRCW0603200RJKEA

52 1 R22 RES., CHIP., 2.94k, 1/10W,1%, 0603 VISHAY, CRCW06032K94FKEA

53 1 R23 RES., CHIP., 1.5k, 1/10W, 1%, 0603 VISHAY, CRCW06031K50FKEA

54 3 R3, R24, R31 RES., CHIP., 10, 1/10W, 5%, 0603 VISHAY, CRCW060310R0JKEA

55 1 R25 RES., CHIP., 124k, 1/10W, 1% 0603 VISHAY, CRCW0603124KFKEA

56 1 R28 RES., CHIP., 124k, 1/10W, 1%, 0603 VISHAY, CRCW0603124KFKEA

57 1 R29 RES., CHIP., 20k, 1/10W, 1%, 0603 VISHAY, CRCW060320K0FKEA

58 1 R30 RES., CHIP., 40.2k, 1/10W, 1%, 0603 VISHAY, CRCW060340K2FKEA

59 3 R12, R32, R46 RES., CHIP., 10k, 1/10W, 5%, 0603 VISHAY, CRCW060310K0JNEA

60 1 R33 RES., CHIP., 75k, 1/10W, 1%, 0603 VISHAY, CRCW060375K0FKEA

61 1 R34 RES., CHIP., 154, 1/10W, 1%, 0603 VISHAY, CRCW0603154RFKEA

62 4 R35, R36, R41, R63 RES., CHIP., 100k, 1/10W, 1%, 0603 VISHAY, CRCW0603100KFKEA

63 1 R37 RES., CHIP., 100, 1/10W, 5%, 0603 VISHAY, CRCW0603100RJNEA

64 1 R38 RES., CHIP., 5.62k, 1/10W, 1%, 0603 VISHAY, CRCW06035K62FKEA

65 1 R39 RES., CHIP., 78.7k, 1/10W, 1%, 0603 VISHAY, CRCW060378K7FKEA

66 1 R40 RES., CHIP., 3.16k, 1/10W, 1%, 0603 VISHAY, CRCW06033K16FKEA

67 3 R42, R55, R62 RES., CHIP., 1k, 1/10W, 1%, 0603 VISHAY, CRCW06031K00FKEA

68 1 R43 RES., CHIP., 12.7k, 1/10W, 1%, 0603 VISHAY, CRCW060312K7FKEA

69 1 R49 RES., CHIP., 1.13k, 1/10W, 1%, 0603 VISHAY, CRCW06031K13FKEA

70 5 R50, R56, R59-R61 RES., CHIP., 0, 1%, 0603 VISHAY, CRCW06030000Z0EA

71 1 R51 RES., CHIP., 309, 1/10W, 1%, 0603 VISHAY, CRCW0603309RFKEA

72 1 R53 RES., CHIP., 4.42, 1/4W, 1%, 1206 VISHAY, CRCW12064R42FKEA

73 1 R54 RES., CHIP., 523k, 1/10W, 1%, 0603 VISHAY, CRCW0603523KFKEA

74 1 R65 RES., CHIP., 10, 1/8W, 5%, 0805 VISHAY, CRCW080510R0JNEA

75 1 T1 Transformer, LT80R2-12AC-3124005 REV 01 CHAMPS, LT80R2-12AC-3124005 REV 01

76 1 T2 Transformer, WE750817020 REV 1 WE., 750817020 REV 1

77 1 T3 Transformer,PE-68386NL PULSE ENG., PE-68386NL

78 1 U1 I.C., Synch. Reg. TSSOP-38(331) Linear Tech., LT3752EFE-1#PBF

79 1 U2 I.C., LT8311EFE TSSOP-20(16) Linear Tech., LT8311EFE#PBF

80 1 U3 I.C., PS2801C-1 NEC, PS2801C-1

81 1 U4 I.C., ACPL-W346 AVAGO, ACPL-W346

dc1929afa

DEMO MANUAL DC1929A

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Additional Demo Board Circuit Components

1 0 CO5, CO6 (OPT) CAP., X7R, 1812

2 0 C2 (OPT) CAP., 1210

3 0 C3 (OPT) CAP., 1206

4 0 C15, C34-C36 (OPT) CAP., 0603

5 0 D6 (OPT) Diode, SOD-523

6 0 D8, D9 (OPT) Diode, SOD323

7 0 D11 (OPT) Rectifier, SMA

8 0 R4, R26, R27 (OPT) RES., CHIP., 1206

9 0 R44, R52, R57, R64, R66 (OPT) RES., 0603

10 0 R45 (OPT) RES., 1210

11 0 R47, R48, R58 (OPT) RES., 0805

12 0 T4 (OPT) Transformer., GT05-111-100 ICE, GT05-111-100

Hardware: For Demo Board Only

1 1 E1 TESTPOINT, TURRET, .061" pbf MILL-MAX, 2308-2-00-80-00-00-07-0

2 4 E2-E5 TESTPOINT, TURRET, .094" pbf MILL-MAX, 2501-2-00-80-00-00-07-0

3 2 J1, J2 JACK BANANA KEYSTONE, 575-4

parts List

dc1929afa

DEMO MANUAL DC1929A

Information furnished by Linear Technology Corporation is believed to be accurate and reliable.

However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-

tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.

schematic Diagram

+VOUT

+12V / 16.7A

16SEPF1000M

-VOUT

SYNC

VBGND

103KHz

150V - 400V

+VIN

-VIN

C3: CGA54X7R2J153K

C5, C7: CGA6M4X7R2J473K

C8: CGA8N4X7R2J104K

QSG

1. ALL RESISTORS ARE 0603.

ALL CAPACITORS ARE 0603.

NOTE: UNLESS OTHERWISE SPECIFIED

SOUT

AOUT

SOUT

AOUT

SW1 +VO1

+VT

INTVCC

VAUX

VFB

INTVCC

VHK

+VT

SW1

SW2

+VO1 VAUX

COM

VAUX

SW2

INTVCC

VAUX

+VO1

COM

CS+

CS-

CS+

CS-

SIZE

DATE:

IC NO. REV.

SHEET OF

TITLE:

TECHNOLOGY Fax: (408)434-0507

Milpitas, CA 95035

Phone: (408)432-1900

1630 McCarthy Blvd.

LTC Confidential-For Customer Use Only

CUSTOMER NOTICE

LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A

CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS;

HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO

VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL

APPLICATION. COMPONENT SUBSTITUTION AND PRINTED

CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT

PERFORMANCE OR RELIABILITY. CONTACT LINEAR

TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE.

THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND

SCHEMATIC

SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.

www.linear.com

DEMO CIRCUIT 1929A

Tuesday, February 25, 2014 11

HIGH VIN TO 12V, 16.7A ISOLATED DC/DC CONVERTER

N/A

LT3752EFE-1

SIZE

DATE:

IC NO. REV.

SHEET OF

TITLE:

TECHNOLOGY Fax: (408)434-0507

Milpitas, CA 95035

Phone: (408)432-1900

1630 McCarthy Blvd.

LTC Confidential-For Customer Use Only

CUSTOMER NOTICE

LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A

CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS;

HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO

VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL

APPLICATION. COMPONENT SUBSTITUTION AND PRINTED

CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT

PERFORMANCE OR RELIABILITY. CONTACT LINEAR

TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE.

THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND

SCHEMATIC

SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.

www.linear.com

DEMO CIRCUIT 1929A

Tuesday, February 25, 2014 11

HIGH VIN TO 12V, 16.7A ISOLATED DC/DC CONVERTER

N/A

LT3752EFE-1

SIZE

DATE:

IC NO. REV.

SHEET OF

TITLE:

TECHNOLOGY Fax: (408)434-0507

Milpitas, CA 95035

Phone: (408)432-1900

1630 McCarthy Blvd.

LTC Confidential-For Customer Use Only

CUSTOMER NOTICE

LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A

CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS;

HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO

VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL

APPLICATION. COMPONENT SUBSTITUTION AND PRINTED

CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT

PERFORMANCE OR RELIABILITY. CONTACT LINEAR

TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE.

THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND

SCHEMATIC

SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.

www.linear.com

DEMO CIRCUIT 1929A

Tuesday, February 25, 2014 11

HIGH VIN TO 12V, 16.7A ISOLATED DC/DC CONVERTER

N/A

LT3752EFE-1

WE 750817020

R41

100K

R28 124k

CIN4

R62 1K

R44

0(OPT)

C11

22nF

R19

200

CO5

R57

OPT

LT80R2-12AC-3124005

R59

C21

470pF

CO6

1812

OPT

C15

OPT

E2 CIN1

C28

68pF

RCS3

0.002

PRL1632

OPT

R61

C12

220pF

C23

0.47uF

R63

100K

C10

10uF

25V

1210

R12

10k

R24

C34 OPT

CY1

2.2nF

400V

440LD22-R

CO1

CIN7

C24

0.22uF

R4 OPT

1206

D12

CMR1U-10

SMB

R6 20k

1206

CIN2

0.22uF

630V

1812

R50 0

R39

78.7k

R54

523K

33uF

TDK

16V CO4

1812

C35

OPT

R55 1K

C14

1nF

R22 2.94k

C31

2.2uF

PE-68386NL

3 4

R31 10

499k

1206

R25 124k

R11

499

BSP300

SOT-223

CO7

R14

374K

1206

22uF 1210

4.7uF

1206

R35 100k

RJK0653DPB

OPT

GT05-111-100

CIN5

47nF

630V

1812

R17 499k

1206

47nF

630V

1812

C27

22nF

R56

R27

OPT

1206

RCS2

0.039

PRL1632

10nF

1210

250V

4.7uH

XFL4030-472ME

CIN8

2.5Amp

R53

4.42

1206

CSYS1

1000uF

16V

C13

470pF

D6 OPT

R23

1.5K

C30

0.22uF 50V

0805

DFLS1200-7

Q9A

PBSS4140DPN

R16

2.8K

R33 75k

R47 OPT

0805

15uH

AGP2923-153

<5th Part Field>

C26

4.7uF 0805

R26

OPT

1206

C25

2.2uF

16V

CO2

OPT

R42

Q9B

PBSS4140DPN

D11 OPT

SMA

R34

154

LT3752-EFE-1

COMP

SYNC

TBLNK

SS1

TOS

GND

HCOMP

SS2

OUT

AOUT

ISENSEN

ISENSEP

VIN

HOUT

HISENSE

HFB

TAS

TAO

IVSEC

UVLO_VSEC

OVLO

INTVCC

SOUT

PGND

3.3

1206

IPD65R250C6

DPAK

650V

ACPL-W346

VEE

VOUT

VCC

R60 0

10nF

630V

1210

TP2

R46

10K

R49

1.13K

R40

3.16K

RCS1

0.2

0805

TP1

R45

OPT

1210

R15

806

CIN9

R51 309

402

1210

DFLS1200-7 D10

CMMR1U-02

C33

2.2uF

450V

IPD60R1K4C6

DPAK

600V

R58 OPT

0805

R43 12.7K

CO3

LT8311EFE

CSW

FSW

INTVCC

VIN

PMODE

OPTO

COMP

TIMER

PGOOD

SYNC

CSN

CSP

GND

R48 OPT

0805

TP3

PGOOD

C22

4.7uF

25V

0805

R37

100

R65 10 0805

R38

5.62K

R36

100K

R30 40.2k

C32

10pF

OPT 1206

630V

BAS516

20k

1206

BAS516

R29 20K

C29

1uF

CIN3

R32

10K

R52 OPT

FDMS86200

374K

1206

R66 OPT

PS2801-1

OPT

1210

C36

OPT

CIN6

R64 OPT

R18

5.76k

R10

232

Inhaltsverzeichnis

Andere Linear Technology Medienkonverter Handbücher

Linear Technology

Linear Technology DC2641A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC2341A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC164 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1228A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1731A-A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology LTM8057 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1739B-C Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology LT3748 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology LT1930ES5 Bedienungsanleitung

Linear Technology

Linear Technology LTC3864 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology LT3956 Series Bedienungsanleitung

Linear Technology

Linear Technology LTC3440 Bedienungsanleitung

Linear Technology

Linear Technology DC2221A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1745A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology LTC2635 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1345 Bedienungsanleitung

Linear Technology

Linear Technology LTC2668 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1185B-A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1687A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DEMONSTRATION CIRCUIT 518 Bedienungsanleitung

Linear Technology

Linear Technology DC2372A Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology LTC3444 Bedienungsanleitung

Linear Technology

Linear Technology LTM8045 Kurzanleitung zur Einrichtung

Linear Technology

Linear Technology DC1523A Kurzanleitung zur Einrichtung

Beliebte Medienkonverter Handbücher anderer Marken

SoundTraxx

SoundTraxx Blunami BLU-2200 Bedienungsanleitung

SPROLINK

SPROLINK VA1 Bedienungsanleitung

Acclaim Lighting

Acclaim Lighting DDC-1-AC Bedienungsanleitung

Nikon

Nikon AF-S TC-20E III Bedienungsanleitung

Axis

Axis AXIS Q7406 Bedienungsanleitung

Omega

Omega TAC80B-J Bedienungsanleitung

Zoom

Zoom Thunderbolt TAC-2R Bedienungsanleitung

OST

OST iConverter 10/100M Bedienungsanleitung

Vertiv

Vertiv Netsure Bedienungsanleitung

birddog

birddog MINI Bedienungsanleitung

Roland

Roland GI-10 Bedienungsanleitung

Wallenstein

Wallenstein WX310 Bedienungsanleitung

Pace

Pace MSS 200-1 Bedienungsanleitung

Solar Converters

Solar Converters EQ 12/24-50 Bedienungsanleitung

CYP

CYP EL-7400V Bedienungsanleitung

TIE

TIE MIDI 1i1o Bedienungsanleitung

DCS

DCS Vivaldi Upsampler Bedienungsanleitung

Westermo

Westermo MCW-211 SERIES Bedienungsanleitung
