DEMO MANUAL DC2125

Description

LT4275, LT4321, LTM8027

Small Highly-Integrated Highly-Efficient

Non-Isolated PoE Powered Device

Demonstration circuit 2125 is a small, highly-integrated,

non-isolatedPoEPowered Device (PD) solution. Itfeatures

a PD Interface Controller (LT

4275), which interfaces with

a PoE Power Sourcing Equipment (PSE), an ideal diode

bridgecontroller(LT4321),whichminimizesbridgelosses,

and a DC/DC µModule

regulator (LT M

8027).

The DC2125 is initially configured as a 38.7W LTPoE++

™

PD that is capable of providing 12V and 3A at the output.

Users can configure the PD circuit to be an IEEE802.3

L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear

Technology Corporation. All other trademarks are the property of their respective owners.

performance summary

BoarD photos

compliant Type 2 (25.5W, “at”) or Type 1 (13W, “af”) PD

by changing the RCLASS and RCLASS++ resistors. See

the LT4275 data sheet for further information. The output

voltage of the LTM8027 can be easily configured for differ-

ent output voltages as shown in the LTM8027 data sheet.

Gerber files for this circuit board are available. Call

the LT C factory.

Specifications are at TA= 25°C

SYMBOL CONDITIONS UNITS

VPORT RJ-45 Port Voltage Range 37V to 57V

IOUT(MAX) Maximum Current from VOUT+to VOUT–3A

VOUT Output Voltage 12V (typ)

ΔVOUT(RIPPLE) Output Voltage Ripple at VPORT = 50V, IOUT = 3A 58mVpp (typ)

ΔVOUT(REG) Output Voltage Regulation, IOUT = 0A to 3A, VPORT ±0.031% (typ)

Efficiency Maximum Efficiency, VPORT = 41V, IOUT = 3A 90% (typ)

fSW Switching Frequency 300kHz (typ)

Top Side Bottom Side

dc2125f

DEMO MANUAL DC2125

typical performance characteristics

Figure 1. Thermal Pictures – VPORT = 50V, IOUT = 3A

Efficiency and Regulation

Top Side Bottom Side

dc2125f

DEMO MANUAL DC2125

Quick start proceDure

NOTE:HandletheDC2125printedcircuitboard bytheedges.

1. Refer to Figure 2 below to evaluate the DC2125 while

powering a 12V Load such as power resistors or an

electronic load.

2. Connect the positive terminal of the 12V Load to the

VOUT+turret, E1. Connect the negative terminal of the

12V Load to the VOUT–turret, E2. If using an electronic

load, power it on and turn the load current down to 0A.

3. Check the power delivery capability of the LTPoE++

PSE to ensure it can power the PD and the 12V Load.

Power-up the LTPoE++ PSE. NOTE: The DC1814A-A

LTPoE++ PSE demo board can power the DC2125 to

its full rated power.

4. Connect the output of the PSE to the input RJ45 connec-

tor, J1, of the DC2125 with a CAT5e or CAT6 Ethernet

cable ≤ 100 meters in length.

5. After connection has been established, verify that the

LED (D2) is lit. This indicates the PSE has successfully

detected and powered the PD.

6. The 12V Load can now be adjusted to exercise the

DC2125 over its full operating load range.

Figure 2. Setup Diagram for the DC2125 Using an LTPoE++ PSE and a Load

–

LTPoE++

PSE

EXAMPLE:

DC1814A-AE

CAT-5E

CAT-6

CABLE

12V

LOAD

DC2125 F01

dc2125f

DEMO MANUAL DC2125

parts list

QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

2 C1, C3 CAP., X7S, 0.047µF 100V, 10%, 0603 TDK, C1608X7S2A473K

1 C2 CAP., X7R, 47nF 100V, 10%, 0805 AVX, 08051C473KAT2A

1 C4 CAP., X7R, 22µF 16V, 20%, 1210 AVX, 1210YC226MAT2A

2 C5, C6 CAP., TQC, 68µF 16V, 7343 PANASONIC, 16TQC68MYF

1 C7 CAP., X7R, 0.1µF 50V, 10%, 0603 MURATA, GRM188R71H104KA93D

1 C8 CAP., ALUMINUM, 22µF 63V,C-CE-BS-6.3X7.7 SUN ELECT., 63CE22BS

1 C9 CAP., X7R, 2.2µF 100V, 1210 AVX, 12101C225KAT2A

1 C10 CAP., X7R, 1500pF 100V, 5%, 0603 AVX, 06031C152JAT2A

1 D1 DIODE, 600W TRANSIENT VOLTAGE SUPPRESSOR, SOD128 NXP, PTVS58VP1UP

1 J1 CONN., MAGJACK 1PORT 1000BASE-T WE, 7499511001

1 L1 IND, 10µH, DO1608C COILCRAFT, DO1608C-103MLB

9 Q1-Q9 MOSFET, N-CH, LFPAK33 NXP, PSMN075-100MSE

1 R2 RES., CHIP, 8.2Ω, 5%, 0603 VISHAY, CRCW06038R20JNEA

1 R3 RES., CHIP, 3.3k, 5%, 0603 VISHAY, CRCW06033K30JNEA

2 R4, R5 RES., CHIP, 100k, 5%, 0603 VISHAY, CRCW0603100KJNEA

1 R9 RES., CHIP, 34.8Ω, 1%, 0805 VISHAY, CRCW080534R8FKEA

1 R12 RES., CHIP, 56.2k, 1%, 0603 VISHAY, CRCW060356K2FKEA

1 R13 RES., CHIP, 49.9k, 1%, 0603 VISHAY, CRCW060349K9FKEA

1 U1 IC, LT4275AIDD#PBF, DFN10DD-3X3 LINEAR TECHNOLOGY CORPORATION, LT4275AIDD#PBF

1 U2 IC, LT4321IUF#PBF, QFN16UF-4X4 LINEAR TECHNOLOGY CORPORATION, LT4321IUF#PBF

1 U3 IC, µModule REGULATOR, LGA113-15X15X4.32 LINEAR TECHNOLOGY CORPORATION, LTM8027EV#PBF

Optional Circuit Components

1 CG1 CAP., X7R, 1000pF, 2KV, 10% 1808 TDK, C4520X7R3D102K

1 D2 LED, GREEN ROHM, SML-010FTT86L

1 J2 CONN., SS-7188S-A-NF STEWART CONNECTOR, SS-7188S-A-NF

4RT1-RT4 RES., CHIP, 75Ω, 5%, 0603 VISHAY, CRCW060375R0JNEA

3 R1, R6, R7 RES., CHIP, 0Ω, 5%, 0603 VISHAY, CRCW06030000Z0EA

0 R8 RES., 0805 OPT

1 R11 RES., CHIP, 2k, 5%, 0805 VISHAY, CRCW08052K00JNEA

2 R10, R14 RES., CHIP, 0Ω, 5%, 0402 VISHAY, CRCW04020000Z0ED

Hardware: For Demo Board Only

2 E1, E2 TP, TURRET, 0.094" MILL-MAX 2501-2-00-80-00-00-07-0

4 MH1-MH4 STANDOFF, NYLON, 0.5, 1/2" KEYSTONE, 8833 (SNAP ON)

dc2125f
