Linksys WRT100 - RangePlus Wireless Router Bedienungsanleitung

PRODUCT DATA

Expand your wireless

coverage with MIMO!

Internet-sharing Router and 4-port

Switch, with a built-in speed and

range enhanced Wireless

Access Point

MIMO smart antenna technology

captures faint signals for extended

range and reduced dead spots

Much faster than Wireless-G when

connected to Wireless-N, but also

works great with Wireless-G and -B

devices

Wireless signals protected by

wireless encryption, and your

network protected from Internet

attacks by a powerful SPI ﬁrewall

RangePlus Wireless Router

Model: WRT100

PRODUCT DATA

RangePlus Wireless Router

The RangePlus Wireless Router is really three devices in one box. First, there’s the

Wireless Access Point, which lets you connect to the network without wires. There’s

also a built-in 4-port full-duplex 10/100 Switch to connect your wired-Ethernet devices

together. Finally, the Router function ties it all together and lets your whole network

share a high-speed cable or DSL Internet connection.

The Access Point built into the Router uses smart antenna technology to achieve

extended range. Unlike ordinary wireless networking technologies that are confused

by signal reﬂections, the“Multiple In, Multiple Out” (MIMO) technology actually

uses these reﬂections to increase the range and reduce “dead spots” in the wireless

coverage area. The robust signal travels farther, maintaining wireless connections

much farther than standard Wireless-G.

With MIMO, the farther away you are, the more speed advantage you get. It works

great with standard Wireless-G and -B equipment, but when both ends of the

wireless link are MIMO enabled, the router can increase the throughput even more

by using twice as much radio band. But unlike other speed-enhanced technologies,

the RangePlus Wireless Router can dynamically enable this double-speed mode for

compatible devices, while still connecting to other wireless devices at their respective

fastest speeds.

To help protect your data and privacy, the Router can encode all wireless transmissions

with industrial-strength 256-bit encryption. It can serve as your network’s DHCP

Server, has a powerful SPI ﬁrewall to protect your PCs against intruders and most

known Internet attacks, and supports VPN pass-through. Conﬁguration is a snap with

the web browser-based conﬁguration utility.

With the Linksys RangePlus Wireless Router at the center of your home or oﬃce

network, you can share a high-speed Internet connection, ﬁles, printers, and multi-

player games, and run media-intensive applications at incredible speeds, without the

hassle of stringing wires!

Features

Complies with IEEE 802.11b and

802.11g standards

Expanded wireless coverage

with MIMO technology

Unsurpassed wireless security

with Wi-Fi Protected Access™ 2

(WPA2)

Enhanced Internet security

management functions

including Internet access

policies with time schedules

All LAN ports support auto-

crossover (MDI/MDI-X)—no

need for crossover cables

•

PRODUCT DATA

The maximum performance for wireless is derived from IEEE Standard 802.11 speciﬁcations. Actual performance can vary, including lower wireless

network capacity, data throughput rate, range and coverage. Performance depends on many factors, conditions and variables, including distance

from the access point, volume of network traﬃc, building materials and construction, operating system used, mix of wireless products used,

interference and other adverse conditions.

Check the product package and contents for speciﬁc features supported. Speciﬁcations are subject to change without notice. Linksys is a registered

8032610A-DF Model: WRT100

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

Web: www.linksys.com

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional

Oﬃces throughout the world. For a complete

list of local Linksys Sales and Technical Support

contacts, visit our worldwide website at

www.linksys.com

RangePlus Wireless Router

Specifications

Model WRT100

Standards IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u

Ports Internet: One 10/100 RJ-45 Port

Ethernet: Four 10/100 RJ-45 Ports

One Power Port

Buttons One Reset Button

LEDs Power, Ethernet (1-4), Internet, Wireless, Security

Cabling Type CAT 5e

# of Antennas 2

Detachable (Y/N) No

RF Power (EIRP) in dBm 16.5 dBm

Antenna Gain in dBi 1.8 dBi

UPnP able/cert Able

Security Features Stateful Packet Inspection (SPI) Firewall, Internet Policy

Wireless Security Wi-Fi Protected Access™ 2 (WPA2), WEP, Wireless

MAC Filtering

Security Key Bits 128 Bits, 256 Bits

Environmental

Dimensions 5.83" x 1.42" x 6.69" (148 x 36 x 170 mm)

Weight 0.74 lb (334 g)

Power 12V, 1A

Certiﬁcation FCC, CE, ICES-003, Wi-Fi (802.11b/g), WPA2, WMM

Operating Temp. 32 to 104°F (0 to 40°C)

Storage Temp. -4 to 140°F (-20 to 60°C)

Operating Humidity 10 to 85%, Noncondensing

Storage Humidity 5 to 90%, Noncondensing

Package Contents

RangePlus Wireless Router

Setup CD-ROM with Norton Internet Security

User Guide on CD-ROM

Network Cable

Power Adapter

Minimum Requirements

Internet Explorer 6.0 or Firefox 1.0 or Higher for Web-Based Conﬁguration

CD-ROM Drive

Windows 2000, XP or Vista

Network Adapter or Wireless Network Adapter

•
