UPS®Centennial

Ready-to-Run Set

Owner’s Manual

CAUTION—ELECTRIC TOY

NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH

ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING

HANDLING AND USE TO REDUCE THE RISK OF ELECTRIC SHOCK.

TRANSFORMER RATINGS—INPUT: 120 VAC; 60 HZ ONLY.

AC OUTPUT: 18 V; 80 VA

CAUTION—ELECTRIC TOY

NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH

ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING

HANDLING AND USE TO REDUCE THE RISK OF ELECTRIC SHOCK.

TRANSFORMER RATINGS—INPUT: 120 VAC; 60 HZ ONLY.

AC OUTPUT: 18 V; 80 VA

Congratulations!

Congratulations on your purchase of the ready-to-run UPS®Centennial Set! This set features

everything you need to get started—a mighty CW-80 Transformer, a huge loop of easy-to-

assemble FasTrack track, a string of detailed cars, and a powerful Lionel locomotive.

Have fun growing with this complete train set! Start with the set components, then follow

your imagination into your own miniature world. Expand your railroad empire with addition-

al FasTrack track sections, enhance your layout with accessories, lengthen your consist with

extra cars, or operate a new locomotive at the head end of your train! Explore the possibilities

at your authorized Lionel dealer.

Use this Owner’s Manual to learn how to set up, operate, and maintain your train set for

years of reliable operation.

The transformer included with this set should be periodically

examined for conditions that may result in the risk of fire,

electric shock, or injury to persons (such as damage to the

output cord, blades, housing, or other parts). In the event that

such conditions exist, the transformer should not be used until

properly repaired.

Parents!

UPS®Centennial Set Features

Bright

headlight

Pufﬁng

smoke

Operating

couplers

Boxcar

Flatcar with

UPS van

Lighted

caboose

interior

Air whistle

Forward-Neutral-Reverse

operation

UPS®, the UPS shield, and the color brow are trademarks of United Parcel Service of America, Inc.

used under license.

The following Lionel marks may be used throughout this instruction manual and are protected under

Lionel®, TrainMaster®, Odyssey®, RailSounds®, CrewTalk™, TowerCom™, DynaChuff™,

StationSounds™, Pullmor®, ElectroCoupler™, Magne-Traction®, CAB-1®Remote Controller,

PowerMaster®, Lionel ZW®, ZW®, PowerHouse®, TMCC®, Lionelville™, Lockon®, Wireless

Tether™, LionMaster®, FatBoy™, American Flyer®, TrainSounds™, CW-80™

The name FasTrack®is used with permission from Pitsco, Inc.

UPS®Centennial Set Inventory

• 4-4-2 Locomotive

• Tender with air whistle

• Boxcar

• Flatcar with UPS van

• Square window caboose

• CW-80 Transformer with accessory wire

• Three straight FasTrack track sections

• Eight curved FasTrack track sections

• One straight FasTrack terminal track section

• Smoke fluid

• Replacement traction tire

• Owner’s Manual

• Lionel RailRoader Club flyer

Table of contents

Creating your layout

Operating your CW-80 Transformer safely 4

Building your Lionel layout 5

Joining the FasTrack track sections 6

Wiring your CW-80 Transformer 7

Running your train

Running your train set 8

Adding smoke fluid to your locomotive’s smoke generator 9

Coupling 10

Operating your traain 10

Experiencing the features of the CW-80 Transformer 11-12

Reverse unit procedure 13

CW-80 Transformer operation

Powering your layout with the CW-80 Transformer 14

Setting the accessory output 14

Maintaining and servicing your set

Lubricating your locomotive 15

Replacing your locomotive’s traction tire 16

Replacing your locomotive’s headlamp 16

Replacing your Square Window Caboose lamp 17

Advanced connections: powering two isolated blocks with two transformers 18

Troubleshooting 19

Limited Warranty/Lionel Service 20

Operating your CW-80 Transformer safely

Creating your layout

Your Lionel CW-80 Transformer is listed by Underwriter’s Laboratory Inc. and has been

carefully designed to ensure peak performance. When using electrical products, basic

safety precautions should be maintained.

Be sure to observe the following guidelines:

• Read the manual thoroughly before using this device.

• This device is not recommended for children under eight years of age.

• Parents should periodically inspect this product for potential hazards and, if necessary,

have them repaired by an authorized Lionel Service Center. In the event that such a condi-

tion exists, the transformer should not be used until it has been properly repaired.

• The CW-80 Transformer is intended to be used indoors. Do not use this device if water is

present. Serious or fatal injuries may result.

• Use the CW-80 Transformer only for its intended purpose.

• The CW-80 Transformer was meant to operate on 120-volt, 60-Hertz power. Do not connect

this product to any other power supply.

• Do not operate the CW-80 Transformer with a damaged cord, plug, or case.

• To avoid the risk of electrical shock, do not disassemble the unit. There are no user service-

able parts inside. If damaged, take this product to an authorized Lionel Service Center. A

list of authorized Service Centers is packed with this unit.

• Do not operate the CW-80 Transformer on your layout unattended. Obstructed accessories

or stalled trains may overheat, resulting in damage to your layout.

• Always unplug the CW-80 Transformer from the power source when not in use.

• Never insert objects into the ventilation slots on this product. Damage to sensitive

electronic components can result.

Building your Lionel layout

Your set comes with eight curved, three straight, and one terminal section of track. Figure

1 provides some examples of layouts that you can build with these track sections.

By adding more FasTrack track sections, you can create an endless number of exciting

track arrangements for more fun, action, and variety. The railroad empire of your dreams can

quickly become a reality!

Creating your layout

Figure 1. Track layout ideas

Creating your layout

Joining the FasTrack track sections

FasTrack track sections join together easily. With interlocking roadbed sections and large

rail tabs, the track fits together securely so you always get good electrical contact. Take a

look at Figure 2 to see how to join the track sections.

1. Line up your two sections of track.

2. Insert the rail tabs into the openings at the ends of the corresponding

rails.

3. Press the sections together until the interlocking roadbed snaps into

place.

Figure 2. Joining the track sections

Rail tab

Wiring your CW-80 Transformer

Creating your layout

To prevent the excessive build up of heat, be sure to select the proper wire gauge

for your layout. Track connections must be made with 18-gauge wire or heavier.

Larger layouts require a minimum of 16-gauge wire.

Caution!

120/60z

0~18VAC

ACCESSORY

Figure 3. Controller connections

FasTrack terminal section

Notch

Spade-shaped

connector

Connect your FasTrack terminal section to the CW-80 Transformer. Use the wires that

are already attached to the terminal section. Make sure that all connections are secure.

Loose connections can produce extremely high temperatures. For this reason, do not touch

the terminals or track connections during use. Also, do not locate scenery materials such as

lichen or ground foam near the terminals.

1. Feed the wires through the notch in the FasTrack terminal section. Refer to

Figure 3.

2. Loosen the red TRACK thumbscrew terminal, then slide the red

spade-shaped connector into position. The thumbscrew post should be positioned

between the “blades” of the spade connector. Be sure that the blades are touching the

metal post. Tighten the thumbscrew to secure the connection.

3. Loosen the black TRACK thumbscrew terminal, then slide the black

spade-shaped connector into position. Tighten the thumbscrew to secure the

connection. The thumbscrew post should be positioned between the “blades” of the spade

connector. Be sure that the blades are touching the metal post.

4. If you need to power an accessory (available separately at your

authorized Lionel dealer), connect the accessory to the ACCESSORY

thumbscrew terminals. Use the accessory wire included with the CW-80 Transformer.

5. Plug the CW-80 Transformer into your wall outlet (120 volts).

As your layout expands, you may also make power connections with the stripped ends

of wires, placing no more than two wires on each terminal. For best performance on large

layouts, it is recommended that you use 16-gauge wire to connect your CW-80 Transformer to

the track. On larger layouts where several track connections are required, the use of separate

junctions/terminal strips (available at your local electronics store) is recommended to

prevent voltage drops.

Running your trains

Running your train set

With track power off, place your train set on the track.

Refer to page 10 for information on coupling the cars.

Power up your locomotive with your transformer.

Your locomotive is designed to operate on 7-15 volts alternating cur-

rent. Virtually all Lionel and Lionel-compatible alternating-current transformers

are suitable.

Do not power your locomotive with direct-current (DC) transformers.

The locomotive was designed for use with alternating-current (AC)

transformers only.

Move ‘em out!

Get your locomotive moving. Your locomotive goes through a repeating pattern

of operations: forward, neutral, reverse, neutral, and so on. To sequence the reverse

unit, press the DIRECTION button on your transformer, or briefly bring the throttle

all the way back to the OFF position and then forward. Each press of the DIRECTION

button or interruption in track power causes the locomotive to advance to the next

operational state.

Adjust track voltage until your locomotive moves at your desired speed.

Connect the drawbar between the locomotive and tender.

See Figure 4.

If the smoke unit switch is in the ON position, add smoke fluid to your

locomotive’s stack to prevent damage to the smoke unit. Refer to

page 9 for additional information.

Caution!

Note!

Figure 4. Drawbar connection

Running your train

Adding smoke ﬂuid to your locomotive’s smoke generator

our locomotive is equipped with a smoke generator that produces safe, clean white smoke

during operation if the smoke unit switch is in the ON position. Refer to Figure 7 on

page 13 for the location of the switch.

The smoke generator requires the periodic addition of Lionel smoke ﬂuid in order to function.

A small bottle of smoke ﬂuid is included with this set. Press down and unscrew the cap. Pierce

the end of the nozzle with a pin, then add about four drops of ﬂuid directly into the locomotive’s

stack. Smoke production commences momentarily. It will start faster if you run your locomotive

at higher speeds. When smoke production decreases, add more ﬂuid (about four drops). An idle

locomotive will not smoke.

Smoke production is greater at higher voltages and when the locomotive is pulling a heavy

load or a long consist.

Caution! When the smoke unit switch is in the ON position, always keep a small amount

of smoke fluid in the locomotive’s smoke generator; the generator’s element

can become damaged if operated without smoke fluid. This is particularly true

if your locomotive sits in neutral for an extended period of time without smoke

fluid in the generator.

If you prefer to operate the locomotive without smoke or you do not want to add

smoke fluid, slide the smoke unit switch to the OFF position.

Note!

Operating your trains with the CW-80 Transformer

You’re clear for departure! Move the throttle control handle forward to increase power to

the track. The farther forward you push the handle, the faster your train will go.

Quickly shutting off or throwing the throttle all the way forward will not result in

an instant change in track voltage.

When operating in the conventional (non-Command) environment, remember that the great-

er the load on the engine (adding more cars for the engine to pull, for example), the farther

forward the handle must be pushed before it will operate the locomotive.

Note!

Running your train

Coupling

When coupling your cars, at least one of the mating couplers must be open as shown at the left

in Figure 5. Press down on the lock release to open the coupler, then push the cars toward

each other until they lock together.

Keep in mind that it’s easier to couple cars on a straight stretch of track.

Lock release

Figure 5. Coupler operation

Note!

Inhaltsverzeichnis

Andere Lionel Modelleisenbahn Handbücher

Lionel

Lionel 267W O Gauge Flying Yankee Outfit Bedienungsanleitung

Lionel

Lionel H-7 Class 2-8-8-2 Bedienungsanleitung

Lionel

Lionel Holiday Tradition Special Bedienungsanleitung

Lionel

Lionel Amtrak Bedienungsanleitung

Lionel

Lionel Pepsi-Cola Bedienungsanleitung

Lionel

Lionel GP-7 diesel locomotive Bedienungsanleitung

Lionel

Lionel 4-12-2 Bedienungsanleitung

Lionel

Lionel LionMaster SD-80 Bedienungsanleitung

Lionel

Lionel 2-8-2 Mikado Bedienungsanleitung

Lionel

Lionel NJ Transit Bedienungsanleitung

Lionel

Lionel QVC Soo Line Transportation O-27 Bedienungsanleitung

Lionel

Lionel Grand Central Express Bedienungsanleitung

Lionel

Lionel 2545WS N&W Space-Freight Bedienungsanleitung

Lionel

Lionel Pennsylvania flyer Bedienungsanleitung

Lionel

Lionel ALCo PA A-A Diesel Locomotive Set Bedienungsanleitung

Lionel

Lionel The Polar Express Streamliner Bedienungsanleitung

Lionel

Lionel Neiman Marcus Holiday Express Bedienungsanleitung

Lionel

Lionel USRA 0-8-0 Yard Goat Bedienungsanleitung

Lionel

Lionel Cascade series Bedienungsanleitung

Beliebte Modelleisenbahn Handbücher anderer Marken

marklin

marklin 55717 Bedienungsanleitung

Rail King

Rail King RKS SD-45 Bedienungsanleitung

Rail King

Rail King RKS GP7 Bedienungsanleitung

marklin

marklin 55182 Bedienungsanleitung

marklin

marklin 58027 Bedienungsanleitung

M.T.H.

M.T.H. USRA 0-6-0 Bedienungsanleitung

marklin

marklin 55184 Bedienungsanleitung

Rail King

Rail King RAILKING E-8 AA Bedienungsanleitung

marklin

marklin 55414 Bedienungsanleitung

M.T.H.

M.T.H. PREMIER U50C Bedienungsanleitung

marklin

marklin 260 V 60 Bedienungsanleitung

M.T.H.

M.T.H. Premier 4-6-6-4 Challenger Bedienungsanleitung

M.T.H.

M.T.H. Alco S-2 Bedienungsanleitung

marklin

marklin 58013 Bedienungsanleitung

MTHTrains

MTHTrains MTH F-3 DIESEL ENGINE Bedienungsanleitung

marklin

marklin 55716 Bedienungsanleitung

marklin

marklin 55565 Bedienungsanleitung

marklin

marklin 55247 Bedienungsanleitung
