Model: KB3000
Programmable Keypad
176 Programmable Keys
USER MANUAL
NOTICE
The manufacturer of the POS cash drawer makes no representations or
warranties, either expressed or implied, by or with respect to anything in
this manual, and shall not be liable for any implied warranties of fitness for
a particular purpose or for any indirect, special or consequential damages.
Information in this document is subject to change without notice and does
not represent a commitment on the part of the manufacturer.
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy
and if not installed and used in accordance with this manual, may cause
interference to radio communications. It has been tested and found to
comply with the limits for a Class A digital device pursuant to Subpart J of
Part 15ofFCCRules,whicharedesigned toprovidereasonableprotection
againstinterferencewhenoperatedina commercialenvironment. Operation
of this equipment in a residential area is likely to cause interference in
which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
i
LOGICCONTROLS, INC.
355Denton Ave
NewHydePark,NY 11040
TEL:(516)248-0400
FAX:(516)248-0443
Email:[email protected]
http://www.logiccontrols.com
TABLE OF CONTENTS
FEATURES...............................................................................1
CARTON CONTENTS..............................................................2
HARDWARE CONNECTIONS .................................................3
FUNCTIONAL TEST ................................................................5
UTILITY DISK CONTENTS......................................................6
INSTALLING THE KB3000.EXE UTILITY PROGRAM .............7
STARTING THE KB3000.EXE PROGRAM ..............................7
PROGRAMMING THE KB3000 KEYPAD.................................9
ADVANCED PROGRAMMING .................................................10
SPECIAL FEATURES OF THE KB3000...................................12
INTER-STRING DELAY ............................................12
MULTI-LEVEL DEFINITION ......................................12
SELF PROGRAMMING ............................................15
SPECIAL CONFIGURATIONS .................................................16
DATA TRANSFER MENU .........................................................18
KB3000 SPECIFICATIONS ...................................................... 20
ii
(XT, AT, PS/2 are registered trademarks of International Business Machines Corporation.)
1
FEATURES
•Unmembrane keypad.
•Enclosed in a heavy duty steel uni-chassis case.
•Uses stainless steel dome disk switches to provide over 1 million tactile key
cycles.
•Requires no TSR programs and thus avoids software crashes.
•Requires no expensive programming kits.
•Requires no battery. Holds data over 100 years.
•Multi-level key definition.
•Programmable inter-string delay.
•Self programmable with a single key stroke.
•176 programmable keys with standard spacing of 0.75” between-keys.
•Records and plays back up to 120 alphanumeric characters per key.
•Provides true keyboard wedge function that operates with or without the
normal computer keyboard connected.
•Provides optional output formats: Standard keyboard emulation (KB3000),
or RS232 (KB3000-R9).
•Supports the following character sets:
· all alphanumeric characters
· 12 function keys
· all IBM keyboard’s special keys (Shift, CTRL, Alt, ESC, etc.)
· 255 ASCII codes
•Permits simple field programmability.
•Downloads an entire 176 key template into the internal non-volatile memory
in just 7 seconds.
•Includes erasable and replaceable legend sheet.
•Built with spill-proof construction.
•Includes cable, legend sheet, and utility software.
2
CARTON CONTENTS
KB3000
1. POS keyboard, Model KB3000
2. Interface cable
3. Utility software disk
4. Reusable legend sheet (inserted under the keypad
cover sheet)
5. IBM 101 type legend sheet
6. User’s manual
KB3000-R9
1.POS keyboard, Model KB3000-R9
2. Interface cable
3.RS232C Interface cable
4. Utility software disk
5. Reusable legend sheet (inserted under the keypad
cover sheet)
6. IBM 101 type legend sheet
3
HARDWARE CONNECTIONS
The KB3000 can be connected to an IBM101 PC, XT, AT or clone
computer, PS/2 computer, or computer terminal. The following diagram
shows how the KB3000 connects to the computer and standard key-
board or other keyboard peripheral (magnetic stripe reader, scanner,
etc.). When the KB3000 is used in a stand alone configuration then no
connections are made to J5.
NOTE:
Before making any connections it is always advisable to
turn off the computer.
A. Connecting the KB3000 to an IBM101 PC, XT, AT, or Clone
computer’s keyboard port:
1. Use the supplied interface cable. Plug the 6-pin connector into J2
of the KB3000. Plug the 5-pin connector into the computer’s
keyboard port.
2. Connect the computer’s keyboard into J5 of the KB3000.
NOTE:
J1 and J6 are not used in this configuration.
To computer
keyboard port To computer keyboard or
other keyboard wedge devices
4
B. Connecting the KB3000 to a PS/2 computer:
1. Use the supplied interface cable. Plug in the 6-pin DIN
connector of the interfacecable into J2 of the KB3000.
2. Connect the 5 pin DIN connector of the interface cable into the 5
pin DIN of the AT-to-PS/2 adapter.
3. Plug the PS/2 connector of the adapter into the computer’s key
board port.
4. Connect the PS/2 keyboard into J1 of the KB3000.
NOTE 1:
J5 and J6 are not used in this configuration.
NOTE 2:
The AT-to-PS/2 adapter is not supplied but can be ordered
from the manufacturer.
C.Connecting the KB3001-R9 to a computer terminal:
1. Connect J6 of the KB3001-R9 to a RS232 port of the computer
terminal using the RS232C interface cable supplied.
NOTE 1:
J1, J2, and J5 are not used in this configuration.
NOTE 2:
A different utility program comes with all KB3001-R9
keypads. An RS232C interface cable is included with all
KB3001 keypads.
NOTE 3:
ProgrammingtheKB3001-R9 mustbedoneon aPC computer.
When programming is completed, remove the cable going to
J6 and install the RS232C interface cable.
NOTE 4:
Before writing the file to the keypad open the F3 menu and
set the RS232C option toYES. Make any changes necessary
to the communications protocol setup.
5
FUNCTIONAL TEST
Fortesting purposes,yourKB3000 keypadwas pre-programmedwiththe
template shown at the right. The following simple steps will verify that the
KB3000isin good workingcondition:
1. Follow the Hardware Connections procedure described earlier in
this manual to connect the KB3000 to your computer.
2. Turn on your computer.
3. Press the upper left corner key of the keypad (intersection of
Row 1 and Column A).
4. The keypad is working correctly when the words “LOGIC
CONTROLS PROGRAMMABLE KEYPAD, MODEL KB3000”
appears on the monitor.
NOTE:
To verify if a KB3001 is working it will be necessary to use
a communications program. Set the protocol to 9600
baud, no parity, and 8 data bits. Repeat steps 3 and 4
above to verify KB3001 is working correctly.
6
UTILITY DISK CONTENTS
The KB3000 keypad comes with a utility software disk. This disk contains
several important files:
KB3D.EXE - Use this utility with or without the keypad being attached.
It is used to program the keypad.For a complete
description of how this program works see the section
“Programming the KB3000,KB3001 keypad”.
IBM101.TPL - This template was pre-programmed into the keypad
and matches the legend sheetsuppliedwith thekeypad.
If there are questions on how to enter a particular key you
can refer back to this template to see how it was originally
programmed.
DL3.COM - This utility program allows you to download a stored
template without entering theKB3000.EXEutility program.
Simply add the KB3 directory to the path statement of the
autoexec.bat file. When you want to change the stored
program simply type thedownload command plus the file
you want to write into the keypad. For example, to
download a file called lunch, you would type DL
LUNCH.TPL and press ENTER. The download
program will take approximately 7 seconds to over-write
the existing file and install the lunch file.
KEY2TPL.EXE - This utility program converts any .KEY file (from earlier
version keypads) to .TPL file. It is recommended
to copy any .KEY files you may have into the KB3
directory before you start the conversion process. When
you are finished you will have both .KEY and .TPL files
in the KB3 directory.
README.DOC - This document contains the latest information which
may not be included in the manual.
7
INSTALLING THE KB3D.EXE UTILITY PROGRAM
The first step in using the KB3D.EXE utility program is to copy the
program to your hard drive.
1.Insert the KB3000 utility software into drive A or B.
2. Type MD KB3 at the “C>“ prompt to make a directory named KB3.
3.Type CD KB3to make the KB3 directory active.
4. Type COPY A:*.* If the disk was inserted into drive A then all files
will be copied into the hard drive’s directory (KB3). If drive B is used
then you must type COPY B:*.*
STARTING THE KB3D.EXE PROGRAM
This program can be used with or without the keypad being attached to the
computer.Note that the PC must be booted up in DOS before starting
the program. It will not run properly under Windows DOS prompt.
If the Windows version do not provide option to boot up computer in DOS,
a DOS boot up diskette created from another computer will be required to
boot up the computer.
Refer to Windows user manuals for further details.
To start the program, type KB3D and press ENTER. When the program
is up, it will automatically display the graphic screen on next page.
