Logitech YR0073 Technisches Datenblatt
User Manual of Product 1:
Logitech YR0073 MX Keys Advanced Wireless Illuminated
Keyboard for Mac, Backlit LED Keys, Bluetooth, USB-C,
MacBook Pro, Macbook Air, iMac, iPad Compatible, Metal
Build, Silver
User Manual of Product 2:
Logitech MX Master 2S Wireless Mouse with Flow
Cross-Computer Control and File Sharing for PC and Mac, Grey
Getting Started - MX Keys for Mac
QUICK SETUP
Go to the interactive setup guide for quick interactive setup instructions.
If you want more in-depth information, go to the ‘Detailed Setup’ below.
DETAILED SETUP
1. Make sure the keyboard is turned on.
The number 1 LED on the keyboard should blink quickly.
NOTE: If the LED is not blinking quickly, perform a long press (three seconds).
2. Choose how you want to connect.
Important
FileVault is an encryption system available on some Mac computers. When enabled, it
might prevent Bluetooth® devices from connecting with your computer if you have not
yet logged in. If you have FileVault enabled, we recommend using a Logitech USB
receiver to use your mouse. If you need more information, click here.
oUse the included wireless receiver:
Plug the receiver into a USB port on your computer. If you are working on a
desktop, we recommend using the USB receiver.
oConnect using Bluetooth:
Open the Bluetooth settings on your computer to complete the pairing.
Click here for more details on how to do this on your computer. If you
experience issues with Bluetooth, click here for Bluetooth troubleshooting.
3. Install Logi Options+ Software
Download Logi Options+ to use all the possibilities this keyboard has to offer. To
download and learn more, go to logitech.com/optionsplus.
PAIR TO A SECOND COMPUTER WITH EASY-SWITCH
Your keyboard can be paired with up to three different computers using the Easy-Switch button
to change the channel.
1. Select the channel you want and press and hold the Easy-Switch button for three
seconds. This will put the keyboard in discoverable mode so that it can be seen by your
computer. The LED will start blinking quickly.
2. To connect your keyboard to your computer:
oBluetooth: Open the Bluetooth settings on your computer to complete the
pairing. You can find more details here.
oUSB receiver: Plug the receiver to a USB port, open Logitech Options, and select:
Add devices > Setup Unifying device, and follow the instructions.
3. Once paired, a short press on the Easy-Switch button will allow you to switch channels.
INSTALL SOFTWARE
Download Logi Options+ to use all the possibilities this keyboard has to offer. To download and
learn more about the possibilities go to logitech.com/optionsplus.
Click here for the list of supported OS versions for Options+.
LEARN MORE ABOUT YOUR PRODUCT
Product Overview
1 - Mac layout
2 - Easy-Switch keys
3 - ON/OFF switch
4 - Battery status LED and ambient light sensor
Battery Status Notification
Your keyboard will let you know when it is running low. From 100% to 11% your LED will be
green. From 10% and below, the LED will be red. You can continue typing for more than 500
hours without backlighting when the battery is low.
Plug the USB-C cable at the top right corner of your keyboard. You can continue typing while it
is charging.
Smart backlighting
Your keyboard has an embedded ambient light sensor that reads and adapts the level of
backlighting accordingly.
Room brightness
Backlight level
Low light - under 100 lux
L2 - 25%
Mid light - between 100 and 200 lux
L4 - 50%
High light - over 200 lux
L0 - no backlight*
Backlight is turned OFF.
There are eight backlight levels.
You can change the backlight levels at any time, with two exceptions: the backlight cannot be
turned ON when:
•The room brightness is high (above 200 lux)
•The keyboard battery is low (below 10%)
Software notifications
Install Logitech Options+ software to get the most out of your keyboard. Click
logitech.com/optionsplus for more information.
1. Backlight level notifications
Change the backlight level and to know in real-time what level you have.
2. Backlighting disabled
There are two factors that will disable backlighting:
When your keyboard has only 10% of battery left when you try to enable backlighting,
this message will appear. If you want backlight back, plug your keyboard to charge.
When the environment around you is too bright, your keyboard will automatically
disable backlighting to avoid using it when not needed. This will also allow you to use it
longer with backlight in low light conditions. You will see this notification when you try
to turn backlighting ON.
3. Low battery
When your keyboard reaches 10% of battery left, backlighting turns OFF and you get a
battery notification on the screen.
4. F-Keys switch
Press Fn + Esc to swap between Media keys and F-Keys. We’ve added a notification to
let you know you’ve swapped.
NOTE: By default, the keyboard has direct access to Media Keys.
Logitech Flow
You can work on multiple computers with your MX Keys keyboard. With a Flow-enabled
Logitech mouse, such as MX Master 3, you can work and type on multiple computers with the
same mouse and keyboard using Logitech Flow technology.
You can use the mouse cursor to move from one computer to the next. The MX Keys keyboard
will follow the mouse and switch computers at the same time. You can even copy and paste
between computers. You will need to install Logi Options+ software on both computers and
follow these instructions.
You can check which other mice are Flow enabled here.
Eject key functions
Does nothing on its own
Dialog box for sleep, restart, and
shutdown
Sleep
Restart
Turn off
Puts display to sleep but Mac is
awake
GETTING STARTED
Questions about your MX MASTER 2S? We've got the answers, videos, downloads and information you
need. Search for articles or select a topic below to get started.
Step-1
Download Logitech Options to use all the possibilities this mouse has to offer. To download and
learn more about the possibilities go to logitech.com/options.
Step-2
Turn your mouse on.
Step-3
This mouse allows you to use it with up to three different computers. Just use the Easy-Switch™
button to change the channel. Select the channel you want and go to the next step.
Step-4
To connect your mouse to your computer press the Easy-Switch™ button for 3 seconds. When it
blinks fast it means it's in discoverable mode.
Step-5
Choose if you want to pair with Bluetooth or with the provided Unifying receiver.
Product Overview:
MX MASTER 2S AT A GLANCE
1 –Speed-adaptive scroll wheel
6 –Darkfield high precision sensor
2 –Manual shift button
7 –Easy-Switch & connect button
3 –Gesture button
8 –Battery status LED
4 –Micro USB port
9 –Thumb wheel
5 –On/Off button
10 –Back/forward buttons
Features:
Speed adaptive scroll-wheel
If SmartShift™ is enabled, the speed-adaptive scroll wheel shifts between two scrolling modes
automatically, in response to your touch.
•Click-to-click (ratchet) mode —ideal for precise navigation of items and lists.
•Hyper-fast (freespin) mode —near-frictionless spinning, letting you fly through long documents and
web pages.
