Lokkii 828T Bedienungsanleitung

ASSEMBLY INSTRUCTION

PRODUCT GUIDE

Model. 828T

Features

• AllWeatherPowderCoatedFrame

• PorcelainCoatedlid,PorcelainCoatedBowl

• StainlessSteelFrameJoints

• PorcelainLid&FireBowl

• PorcelainCookingSurface

• HingedCookingLid

• UpperRack

• 2sidetableswithaccessoryhooks

• StainlessSteelTemperatureGauge

• StainlessSteelAirVent

• LiftoutGrillCentrewithRemovableHandle

• OneClick™AirControlAshPan

• AllTerrainRubberWheels

• EasyAssembly

Assembled Size

Width:26.5”/67cm

Height:37”/94cm

Length:45.5”/115cm

CookingHeight:30.7”/78cm

CookingBowlWidth:22”/56cm

PERFECTION trolley

Thebrand“Lokkii”,“PerfectionBarbecue”andallTradeMarksUnderthebrandarethepropertyofGHHCL.

www.lokkii.com

Safety Instructions

Non-observanceofthesesafetyinstructionsandprecautionscanleadtoseriousinjuryandvoidofwar-

ranty.

Pleasereadthefollowinginstructionsbeforeusingyourbarbecue.

1. Thisbarbecuemayonlybeusedoutdoors,neverindoors.

2. Beforeusingthebarbecue,positiontheBBQonaatsurface,awayfromoverhangsandtreesoutof

thewindasmuchaspossible.

3. Keepasecuredistanceof1.5metersfromcombustiblematerials.

4. Donotuseuidssuchaspetrolorsimilarhighlyammablespiritstolightorre-lightthebarbecueor

addtowarmorhotcharcoal!

5. Donotleavehotgrillorhotcoalsandashesunattended.

6. ThemaximumamountoffuelfortheseBBQsis3.6KG(8Lb)

• Followinstructionsonthefuelbagcarefully.

• DonotputthelidontheBBQbeforetheamehasdiedout.

• “Donotcookbeforethefuelhasacoatingofash”.

Warning:

1. TheCharcoalwillbeveryhot,takesuitableprecautions.

2. Donotlightandoperategrillwithouttheashpaninplace.

3. Wearheatresistantovenmittswhengrillingoradjustingtheventholes.

4. Whenextinguishingcharcoalbriquettes,placethelidonthebowlandcloseallairvents.

Donotusewater.

5. Donotremoveashesuntilallcharcoalbriquettesarecompletelyburnedoutandfullyextinguished.

6. Removeashesbeforegrillingagain.Insuretheashesarecold.

7. Alwayskeepchildrenandpetsawayfromthebarbecue.

Maintenance:

• Cleanthegrillwithacleanersuitableforporcelainsurfaces.Cleanthedroppanwithsoapand

water.

• NEVERusesteelbrushes,aggressivedetergentsorsharpobjectsonporcelainsurfaces!

Thiswilldamagethesurface!

• Toextendthelifeofyourbarbecue,useasuitablecover.

• StoretheBBQinadryarea.

“ATTENTION!

This barbecue will become very hot, do not move it during operation”

“Do not use indoors”

“CAUTION!

Do not use spirit, petrol or comparable uids for lighting or re-lighting”

“WARNING! Keep children and pets away”

P. 2

Preparing to use your grill

Lighting

Beforecookingwithyourgrill,thefollowingstepsshouldbefollowed.

• Cleanallinteriorsurfacesincludinggrillsandgrateswithmildsoapandwater,anddrythesurfaces.

• Buildasmallreonthecharcoalpan.

• Oncethecharcoalhasturnedgrey,closelid,positionallventstofullyopen.

• Allowthecharcoaltoburnforatleasttwohours.

NEVERPAINTTHEINTERIOROFTHEGRILL!Yourgrillisporcelaincoatedandifcaredforcorrectly,willgive

youmanyyearsofuse.

NOTE:

• Thegrateiscoatedwithporcelain,whichisafragilecoating.Handlewithcaretoavoiddamage.Do

notcoolthegrateincoldwaterwhileitisstillhotorthecoatingmaycrack.Letgratecoolonit’s

own.

• Somepartsofthegrillhavebeenpre-oiledatthefactory.Pleaseburnotheoilbeforecooking.

Please see information regarding Uncoated Cast Iron Inserts below.

Cast Iron Inserts: (Sold Separately)

Beforeusingacastirongrateorothercastironcookinginserts,washitthoroughlywithamildsoapand

water.Rinsewithhotwateranddrycompletelywithasoftclothorpapertowel.NEVERALLOWTODRAIN

DRYORWASHINDISHWASHER.Nowseasonthegrateswithvegetablecookingoiltopreventrustand

sticking.

RegularBriquette’s,InstantLightBriquettesorLumpwoodmayuseasafuelsourceforgrilling.When

ignitingregularbriquettesorlumpwoodcharcoal,donotuserelightersthathavepetroleumbasesor

thelikeasthesewilltaintthefoodyoueat.

DonotuseaChimneystarterforinstantlightbriquettes

Building Your Fire:

1. FormthecharcoalbriquettesorLumpwoodintoapyramidonthecharcoalgrate.

Themaximumamountofcharcoalforthisgrillis3.6KG(8LBS).

2. SolidFirestarters:           

A:Placetherestarterinthebaseofthepyramid.LighttheFirestartesinseverallocationstoensure

anevenburn.

3. LiquidorGelFirestarters,coatthebriquettesorlumpwoodwiththeliquidorgelandlightaccording

tothemanufacturer’sinstructions.

4. Always light the re with the grill lid open.

Leavelidopenuntilbriquettesarefullylit.

Caution:Failuretoleavethelidopencouldtrapfumesfromcharcoallighteruidingrillandmay

resultinaashrewhenlidisopened.

P. 3

Grill Maintenance

5.Neveraddcharcoallighteruidortheliketohotorwarmcoalsthiscanbeextremelydangerous.

6.Oncetherehasburnedoutthecharcoalhasturnedgrey,spreadthecharcoaloutusingalong

HandledBBQtool

7.Youarereadytocook

*Always use caution when handling hot coals to prevent injury.

• Allowenoughtimeforproperlybuildingthereandgettingthegrilluptodesiredtemperature

beforeattemptingtocook.

• Risingheatwillmoveupandoutofthegrillpullingincoolerairbehinditwhichprovidesoxygen

forthere.Yourgrillhasairventsthatcontrolairowwhichletsyounetunethetemperature.

Afterthereisestablishedandthegrillreachesthedesiredcookingtemperature,theairventscan

beleftcompletelyopen,providingmaximumairowforahighertemperatureorclosedasneeded

todecreaseairowforalowertemperature.

• IfyourBBQistoohot,spreadthecoalsoutabitmore,thismakestherelessintense.

• Partiallyclosingthegrillventsreducestheamountofoxygenthatfeedsthere.

• Whenaddingbriquettes,allowthecoalstoashoverbeforecooking.

• Direct Grilling,theignitedcoalsarespreadinasinglelayerunderthefood.Thisiscalleddirectgrill-

ingandisappropriateforquick-cookingitemssuchashamburgers,steaksandmostseafood.

• Indirect Grilling,thismethodisforlong,slowcookinginacoveredgrill.

• Indirectgrillingmethod,withcoalstoeithersideofadrippanandthefoodoverthepanratherthan

directlyoverthecoals.Thecoalsarepiledtwoorthreecoalsdeepononesideofthegrill,ordivided

andpiledontwosides.Leaveanemptyspacenexttothecoalsorbetweenthem.Placeadrippan

inthecentreofthegrillingrack,llthiswithwater,wineorbeer,thiswillenhancetheavourofthe

foodandstopthefoodfromdryingout.Indirectgrillingtakeslongertocookyourfood.

Makesurecoalsarecompletelyextinguishedandcoldbeforecleaninginsideofthegrill.

Cleanoutallremainingashes,Ashescollectmoisture,whichcanleadtodecayofyourgrill.

Wipeouttheinsideofthegrillwithadampclothorpapertowels.

ItisadvisabletocoveryourBBQtoprotectitfromtheelements.

Porcelain Cooking Surface:

Thecookingsurfaceofyourgrillisporcelain.Donotusescrapers,sharpinstrumentsortheliketoclean

thegrillingsurface,thiswilldamagetheporcelain.Oncethegrillingsurfacehascooleddownthesurface

canbewashedwithmilddetergentandwater,besuretothoroughlydrythesurfaceonceclean.

Grilling

P. 4

Package Contents

PART

DESCRIPTION

Temperature Gauge

Lid

Handle

Warming Rack

Centre Grill

Main Grill

Charcoal Rack

Insert Vent

Side Rack

Upper Support Bar

Left Leg Joints

Left Back Leg

Left Front Leg

Wheel Axle

Wheel

Wheel Hub

QUANTITY

PART

DESCRIPTION

Bottom Frame

Right Front Leg

Right Back Leg

Centre Frame Panel

Ash Pan

Bottom Bowl

Right Hinge Bowl

Left Hinge Bowl

Grill Lifter

Right Hinge Lid

Left Hinge Lid

Top Upper Vent

Bottom Upper Vent

QUANTITY

P. 5

Hardware List

PART

Qty

5 pcs

44 pcs

1 pc

6 pcs

2 pcs

15 pcs

4 pcs

NAME

M6 Flange Nut

M6 x 12 Bolt

M6 x 20 Bolt

M6 Nut

Cotter Pin

Hinge Pin

Flat Washer

M8 Lock Bolt


Preparation

Beforebeginningassemblyofproduct,makesureallpartsarepresent.Comparepartswithpackage

contentslistandhardwarecontentslist.Ifanypartismissingordamaged,donotattempttoassemble

theproduct.

Estimated Assembly Time: 30minutes.

ToolsRequiredforAssembly(notincluded):PhilipsHeadScrewdriverandAdjustableWrench.

P. 6

P. 7

Assembly Instructions

Hardware Used:

M6x12Boltx8

Hardware Used:

M6x12Boltx8

Payattentiononassemblythesideholes

directionofthelegs.

P. 8

Hardware Used:

M6x12Boltx8

Hardware Used:

CotterPinx2

Payattentiononlegscombinationside

holesaret.

P. 9

Hardware Used:

M6x12Boltx8

Hardware Used:

M8LockNutx4

Donottightenthescrewstemporarily.

Hardware Used:

M6x12Boltx4

FlatWasherx4

Hardware Used:

M6x12Boltx4

FlatWasherx6

P.10
