Long Range Systems T74C232 Technisches Datenblatt

Interface Descri tion

The interface transmitter is designed to translate paging commands from a host computer

to signals understood by LRS Pagers

Key ad Installation

1. Unpac the system. Be sure the following items are found:

• Interface unit

• Computer serial interface cable

• 10-Vac wall adpter

• Antenna with right angle elbow

• Pager

2. Plug the 10-Volt power adapter into a wall outlet

3. Plug the power supply into the interface transmitter

4. Connect the antenna.

5. Connect the serial cable from the connector on the interface

transmitter to the serial port on the host computer

6. The unit is ready for operation

7. Refer to the operating instructions delivered with the inter-

face transmitter

Long Range Systems 1T74B232 & T74C232 Quick Guide

T74B232 & T74C232

RS232 Paging System Interface Transmitter

QUICK SETUP & OPERATION

T74C232

FCCID:M74T7400

RS-232

Receive

Transmit

Power

9VAC

800.437.4996

www.pager.net

CONDOR

CLASS2TRANSFORMER

(408)745-7141

INPUT:AC12OV60Hz19w

OUTPUT:AC9V1800mA

P/N:A91A8

RoHS

LISTED

MODEL:48A-9-1800

EIA3630635S

MADEINCHINA

AC Power Outlet

10-V Power

Adapter

Antenna

Interface Transmitter

Serial Interface Cable

www.lrspagers.co.uk | www.pagers.co | www.hospitalpagers.co.uk

System S ecification

Required voltage: One 110V outlet for the pager eypad.

O erating Frequency: 420-470 MHz

Radiated Power <4900 micro-volts/meter

O erating Range: Dependent upon pagers used and topography and environment.

Long Range Systems, Inc. reserves the right to ma e changes without further notice to

any products herein. Long Range Systems, Inc. ma es no warranty, representation or

guarantee regarding the suitability of its products for any particular purpose, nor does

Long Range Systems, Inc. assume any liability arising out of the application or use of

any product or circuit, and specifically disclaims any and all liability, including without

limitation consequential or incidental damages. “Typical” parameters that may be pro-

vided in Long Range Systems, Inc. data sheets and/or specifications can and do vary in

different applications and actual performance may vary over time. All operating parame-

ters, including “Typicals”, must be validated for each customer application by cus-

tomer’s technical experts. Long Range Systems, Inc. products are not designed,

intended, or authorized for use as components in systems intended to support or sustain

life, or for any other application in which the failure of the Long Range Systems, Inc.

product could create a situation where personal injury or death may occur.

Should Buyer purchase or use Long Range Systems, Inc. products for any such unin-

tended or unauthorized application, Buyer shall indemnify and hold Long Range Sys-

tems, Inc. and its officers, employees, subsidiaries, affiliates, and distributors harmless

against all claims, costs, damages, and expenses, and reasonable attorney fees arising

out of, directly or indirectly, any claim of personal injury or death associated with such

unintended or unauthorized use, even if such claim alleges that Long Range Systems,

Inc. was negligent regarding the design or manufacture of the part, device or system.

Long Range Systems 2T74B232 & T74C232 Quick Guide

XU-0056 073009

www.lrspagers.co.uk | www.pagers.co | www.hospitalpagers.co.uk
