Longman 25W*6PCS Bedienungsanleitung
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
1
19
USER MANUAL
(25W*6PCS,RGBAW 5-IN-1 LED)
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
2
19
1. Summariz
Summariz
Thank you for purchasing our Light Please read these instructions carefully before begin
and
operate the fixtures according to these instructions to avoid any possible damages and
accidents
causes by misusage.
Product introduction
This LED all asher is
designed in a fashion of hydrodynamic form. It uses high po er
RGBAW
5-in-1 25W COB
LED, means each LED is made of R,G,B.A.W five led chips. It performs long
life time, lo po er consumption, high brightness stable
capability and colorful. The built-in
program includes dimmer, strobe, ater, gradual change, fading and so on. It has the function of lo
eight, lo po er consumption and stable. International standard DMX 512 signal is requested.
Packing list
LIGHT 1PC
Po er Cable 1Set
DMX Signal cable 1Set
The use manual 1PC
2. Saf ty Information
Saf ty Not s
!
Enquire
the
skilled
people
before
any
repair;
!
Al ays
make
sure
disconnect
from
the
po er
source
before
setting
up,
serving
and
moving;.
!Avoid direct eye exposure to the fixture hen it is on;
Saf ty instruction
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
3
19
●Make sure the po er supply voltage are consistent ith this lights，Ensure the use of voltage is in
the range of the request technical parameter.
●before the installation, please check the light’s fasteners and mechanical structure have been
received in good condition and appear no damage.
●
This light is designed for indoor or outdoor,
orking
temperature should be lo er than 50
degree.
●The fixtures should be mounted in any position provided there is adequate room for ventilation.
Make sure there are no inflammable and explosive items (ornaments) in 0.5 meters a ay.
●Yello / green cabling earthling safety; no flicker hen the fixture is orking on.
3. Dim nsion diagram
4. Main Function
Input voltage: AC 100V-264V/47-63HZ
Consume
150W
Lamp Type
25W LED 5-in-1 R
G
B
A
W (6PCS)
Life span: 50000~100000hours
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
4
19
PWM Dimmer
1500HZ(16666 grades)
Control Signal
DMX512
Control mode
stand alone/ Master slave mode
Channel
38CH,30CH,23CH,23CH-2,18CH,18CH-2,11CH,6CH,5CH
Function Effect: Smooth dimmer, strobes, gradual change, rainbo effect , autos, auto programming
Built-in temperature control measurement function, hen LED ork overheated, intelligent reduce LED
output po er, current po er output could be checked
Cooling mode: Fan cooling Convection, Fan speed can be set to reduce noise
Beam Angle: 30°,60° Optional
Anti-electricity intension
1.5KV
Insulation Resistance:
M Ω
Size: 512*130*232mm
Net Weight: 5.1 Kg
IP Protection: IP65
5. DMX Control Function
DMX Chann ls
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
5
19
Illustrations:The same numbers represent the same group.
38CH 30CH
CHANN
EL NAME
CHANN
EL NAME
1 DIM ALL 1 R1
2 R1 2 G1
3 G1 3 B1
4 B1 4 A1
5 A1 5 W1
6 W1 6 R2
7 R2 7 G2
8 G2 8 B2
9 B2 9 A2
10 A2 10 W2
11 W2 11 R3
12 R3 12 G3
13 G3 13 B3
14 B3 14 A3
15 A3 15 W3
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
6
19
16 W3 16 R4
17 R4 17 G4
18 G4 18 B4
19 B4 19 A4
20 A4 20 W4
21 W4 21 R5
22 R5 22 G5
23 G5 23 B5
24 B5 24 A5
25 A5 25 W5
26 W5 26 R6
27 R6 27 G6
28 G6 28 B6
29 B6 29 A6
30 A6 30 W6
31 W6
32 STROBE
33 EFFECT
34 AUTO SPEED
35
VIRTUAL COLOR
WHEEL
36 DIMMER MODE
37 ID FUNCTION
38 ID ADDRESS
23CH 23CH. 18CH 18CH.
CHANN
EL NAME
CHANN
EL NAME
1 DIM ALL 1 DIM ALL
2 R1 2 R1
3 G1 3 G1
4 B1 4 B1
5 A1 5 A1
6 W1 6 W1
7 R2 7 R2
8 G2 8 G2
9 B2 9 B2
10 A2 10 A2
11 W2 11 W2
12 R3 12 STROBE
13 G3 13 EFFECT
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
7
19
14 B3 14 AUTO SPEED
15 A3 15
VIRTUAL COLOR
WHEEL
16 W3 16 DIMMER MODE
17 STROBE 17 ID FUNCTION
18 EFFECT 18 ID ADDRESS
19 AUTO SPEED
20
VIRTUAL COLOR
WHEEL
21 DIMMER MODE
22 ID FUNCTION
23 ID ADDRESS
11CH 6CH 5CH
CHANNE
L NAME CHANNEL NAME
CHANNE
L NAME
1 DIM ALL 1
DIM
ALL 1 R
2 R 2 R 2 G
3 G 3 G 3 B
4 B 4 B 4 A
5 A 5 A 5 W
6 W 6 W
7 STROBE
8 EFFECT
9 AUTO SPEED
10
VIRTUAL
COLOR WHEEL
11 DIMMER MODE
NAME VAL
UE FUNCTION
DIM ALL 0-255 DARK->LIGHT
RED 0-255 DARK->LIGHT
GREEN 0-255 DARK->LIGHT
BLUE 0-255 DARK->LIGHT
AMBER 0-255 DARK->LIGHT
WHITE 0-5 DARK->LIGHT
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
8
19
STROBE 0-5 No strobe
6-20 Not synchronous strobe(slo to
fast)
21-60 Synchronous strobe(slo to fast)
61-10
0Electronic Sine ave(slo to fast)
101-1
40 Random Strobe(slo to fast)
141-1
80 Opening pulse(slo to fast)
181-2
20 Closing pulse(slo to fast)
221-2
55
Electronic Square ave(slo to
fast)
EFFECT 0-5 NO EFFECT
6-10 CT01(Call custom color CT01)
11-15 CT02
16-20 CT03
21-25 CT04
26-30 CT05
31-35 CT06
36-40 CT07
41-45 CT08
46-50 CT09
51-55 CT10
56-60 AUTO 1(0-255S)
61-65 AUTO 2(0-255S)
66-70 AUTO 3(0-255S)
71-75 AUTO 4(0-255S)
76-80 AUTO 5(0-255S)
81-85 AUTO 6(0-127.5S)
86-90 AUTO 7(0-25.5S)
91-95 AUTO 8(0-12.25S)
96-10
0AUTO 9(0-17S)
101-1
05 AUTO 10(0-25.5S)
106-1
10 AUTO 11(0-25.5S)
111-1
15 AUTO 12(0-25.5S)
116-1
20 AUTO 13(0-17S)
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
9
19
121-1
25 AUTO 14(0-17S)
126-1
30 AUTO 15(0-12.25S)
131-1
35 AUTO 16(0-12.25S)
136-1
40 AUTO 17(0-25S)
141-1
45 AUTO 18(0-25S)
146-1
50 AUTO 19(0-25.5S)
151-1
55 AUTO 20(0-255S)
156-1
60 AUTO 21(0-25.5S)
161-1
65 AUTO 22(0-12.25S)
166-1
70 AUTO 23(0-17S)
171-1
75 AUTO 24(0-25.5S)
176-1
80 AUTO 25(0-25.5S)
181-1
85 AUTO 26(0-25.5S)
186-1
90 AUTO 27(0-17S)
191-1
95 AUTO 28(0-17S)
196-2
00 AUTO 29(0-12.25S)
201-2
05 AUTO 30(0-12.25S)
206-2
10 AUTO 31(0-25S)
211-2
15 AUTO 32(0-25S)
216-2
20 AUTO 33(0-255S)
221-2
25 CHASE1
226-2
30 CHASE2
广州朗文光电有限公司
GUANGZHOU LONGMAN PRO LIGHT FACTORY CO,. LTD.
10
! "
19
!
231-2
35 CHASE3
236-2
40
SOUND 1:SOUND CHANGE
COLOR
241-2
45
SOUND 2:SOUND
STROBE(WHITE COLOR
ONLY)
246-2
55 RESERVED
AUTO SPEED 0-255 AUTO SPEED,FAST->SLOW
VIRTUAL
COLOR WHEEL 0-10 No effect
(RGB color
mixing instead of
RGB channels but
A W channels not
affected)
11 Blue (Blue=full,
Red+Green+White=0)(step)
12-50 Red=0, Green->up,Blue =full,
White=0(proportional)
51 Light Blue (Red=0, Green=full,
Blue =full, White=0)(step)
52-90 Red=0, Green=full, Blue->do n,
White=0(proportional)
91 Green (Red=0, Green=full, Blue
=0, White=0)(step)
92-13
0
Red->up, Green=full, Blue=0,
White=0(proportional)
131 Yello (Red=full, Green=full,
Blue=0, White=0)(step)
132-1
70
Red=full, Green->do n, Blue=0,
White=0(proportional)
171 Red(Red=full, Green=0, Blue=0,
White=0)(step)
172-2
10
Red=full, Green=0, Blue->up,
White=0(proportional)
211 Magenta (Red=full, Green=0,
Blue=full, White=0)(step)
212-2
50
Red -> do n, Green=0,
Blue=full, White=0(proportional)
