PS1500 and PSFP1500 6/3/15

Maximum Capacity......................1500-Lbs. ................. 1500-Lbs.

Minimum Height ............................53-3/8" .......................53-3/8"

Maximum Height ...........................80-1/8" ....................... 80-1/8"

Base Size.......................................... 12" .................................12"

Weight ......................................... 30.8-Lbs.................... 31.9-Lbs.

PS1500 PSFP1500

SPECIFICATIONS

OWNER'S MANUAL

PS1500 AND PSFP1500

1500-LBS. CAPACIT Y

UNDERHOIST STANDS

PS1500

1500-LBS.

CAPACITY

UNDERHOIST

STAND

PSFP1500

1500-LBS.

CAPACITY

UNDERHOIST

STAND WITH

PEDAL

ASME PASE-2014

PS1500 and PSFP1500 2 6/3/15

WARNINg INFORMATION

This is the safety alert symbol. It is used to alert you to

potential personal injury hazards. Obey all safety messages

that follow this symbol to avoid possible injury or death.

IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING

BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY, UNDERSTAND ITS OPERATING PROCEDURES, SAFETY WARNINGS

AND MAINTENANCE REQUIREMENTS. SAVE THESE INSTRUCTIONS.

It is the responsibility of the owner to make sure all personnel read this manual prior to using these stands. It is also the responsibility of the stand owner

to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost or not legible, contact Mac Tools for

replacements. If the operator is not ﬂuent in English, the product and safety instructions shall be read to and discussed with the operator in the operator's

native language by the purchaser/owner or his designee, making sure that the operator comprehends its contents.

This product is intended only for use in lifting and supporting vehicle components. Do not use or modify this product for any other purpose than that for which

it was designed without consulting the manufacturer's authorized representative. The use of portable automotive lifting and support devices are subject to

certain hazards that cannot be prevented by mechanical means, but only by the exercise of intelligence, care, and common sense. It is therefore essential to

have owners and personnel involved in the use and operation of the equipment who are careful, competent, trained, and qualiﬁed in the safe operation of the

equipment and its proper use. Examples of hazards are dropping, tipping or slipping of loads caused primarily by improperly securing loads, overloading,

off-centered loads, use on other than hard level surfaces, and using equipment for a purpose for which it was not designed.

METHODS TO AVOID HAZARDOUS SITUATIONS

• Read,study,understandandfollowallinstructionsbeforeoperatingthisdevice

• Thisstandisintendedtoassistinsupportingundervehiclecomponents,notthevehicle

• Inspectthestandbeforeeachuse.Donotuseifdamaged,altered,modied,inpoorcondition,orhaslooseormissinghardwareorcomponents.Take

corrective action before using the stand

• Donotuseormodifythisproductforanyotherpurposethanthatforwhichitwasdesignedwithoutconsultingthemanufacturer'sauthorizedrepresentative

• Donotusebeyondratedcapacity.Donotshockload

• WeareyeprotectionthatmeetsANSIZ87.1andOSHAstandards(usersandbystanders)

• Useonlyonahardlevelsurfacecapableofsupportingtheload

• Centerloadonsaddle.Donotuseendsofsaddletosupportload

• Adequatelysupportthevehiclebeforestartingrepairs

• Besurevehicle,vehiclecomponentandstandarestablebeforeperforminganywork

• ThisproductmaycontainoneormorechemicalsknowntotheStateofCaliforniatocausecancerandbirthdefectsorotherreproductiveharm.Wash hands

thoroughly after handling

• Failuretoheedthesewarningsmayresultinseriousorfatalpersonalinjuryand/orpropertydamage

CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS

Failuretoreadthismanualcompletelyandthoroughly,failuretounderstanditsOPERATINGINSTRUCTIONS,SAFETYWARNINGS,MAINTENANCEINSTRUCTIONS

andcomplywiththem,andfailuretocomplywiththeMETHODSTOAVOIDHAZARDOUSSITUATIONScouldcauseaccidentsresultinginseriousorfatalpersonal

injury and/or property damage.

WARNING: Indicates a hazardous situation

which, if not avoided, could result in death

or serious injury.

WARNING

THIS INSTRUCTION MANUAL USES THE FOLLOWING SYMBOLS AND DEFINITIONS TO ALERT YOU TO HAZARDOUS CONDITIONS WHICH MAY CREATE A RISK

OF PERSONAL INJURY AND/OR PROPERTY DAMAGE.

PS1500 and PSFP1500 3 6/3/15

SETUP INSTRUCTIONS

OPERATINg INSTRUCTIONS

PREVENTATIVE MAINTENANCE

PS1500 AND PSFP1500

1500-LBS. CAPACIT Y

UNDERHOIST STANDS

1. Screw the post support in the round base.

2. Thread the large spin handle on the extension screw.

3. Install the bearing assembly in the receiver on top of the support tube.

4. Insert the extension screw assembly through the bearing and into the support tube until the underside of the spin handle rests on the bearing assembly.

5. The model PSFP1500 includes a pedal. Insert the other end of the pedal through the parallel ﬂanges of the post support; raise the pedal high enough

so the clevis pin can be installed through the parallel ﬂanges of the post support. Secure the clevis pin with the washers and cotter pin provided.

1. Makesurethevehicleisproperlysupported,stableandattherequiredworkheightbeforepositioningthestand(s)underthevehiclecomponentto

be supported.

2. Consult the vehicle manufacturer for the proper handling of the component and use of underhoist stands.

3. Oncethestand(s)hasbeenpositionedproperlyunderthecomponent,holdthestand'ssaddleinplacewithonehandwhileturningthespinhandleina

 clockwisedirectionwiththeotherhand.Removetheonehandfromthestand'ssaddlewhenitcomesclosetomakingcontactwiththecomponent.

4. Continue turning the stand's spin handle in a clockwise direction until it applies pressure against the component. This pressure should not exceed what

 isrequiredtosupportthecomponent.Excessivepressuremightcausethevehicleoritscomponenttobecomeunstable.Additionalprecautionshouldbe

taken when using a stand equipped with a foot pedal which can raise the stand's saddle another inch more in height and produce as much as 400 pounds

of force when depressed.

5. Before removing the stand from the component, make sure the component is securely fastened to the vehicle or properly supported by another means.

 Removalofthestandcanbeaccomplishedbyturningthespinhandleinacounterclockwisedirectionuntilthestand'ssaddleisclearofthecomponent.

1. Alwaysstorethestandsinawellprotectedareawheretheywillnotbeexposedtoinclementweather,corrosivevapors,abrasivedust,oranyother

harmful elements. The stands must be cleaned of water, snow, sand, grit, oil, grease or other foreign matter before using.

2. Useageneralpurposegreasetolubricatetheextensionscrewandfootpedallinkageifsoequipped.

3. Everystandownerisresponsibleforkeepingthestandlabelscleanandreadable.Useamildsoapsolutiontowashexternalsurfacesofthestand.

Contact Mac Tools for a replacement label if your stand's label is not readable.

4. Inspect the stand before each use. Do not use the stand if any component is cracked, broken or bent. Do not use the stand if it has loose or missing

hardware or components, or is modiﬁed in any way. Take corrective action before using the stand again. Premature wearing or damage to components

caused by loose or missing hardware is not eligible for warranty consideration.

Failure to follow these Setup Instructions may result in serious injury or death, and/or property damage.

Failure to follow these Operating Instructions may result in serious injury or death, and/or property damage.

WARNING

Failure to follow these Preventative Maintenance instructions may result in serious injury or death, and/or property damage.

WARNING

PS1500 and PSFP1500 4 6/3/15

PARTS LIST AND DIAgRAM

PS1500 AND PSFP1500

1500-LBS. CAPACIT Y

UNDERHOIST STANDS

Item No. Part No. Description Qty.

 1 RS6809A01 Base 1

 2 RS6809A02 Post 1

 3 RS6809A03 HandleGrip 2

 4 RS6809A04 PostSupport 1

 5 RS6809A05 ClevisPin 1

 6 RS6809A06 FlatWasher(16) 2

 7 RS6809A07 CotterPin 1

 8 RS150011 Saddle 1

 9 RS6809A12 HexBolt(M8x16) 1

 10 RS6809A08 Handle 1

 11 RS6808BD02 Bearing(8106) 1

 12 RS6809A09 ScrewStem 1

  RSPS1500PL Productlabel(notshown) 1

Item No. Part No. Description Qty.

 1 RS6809A01 Base 1

 2 RS681002 Post 1

 3 RS6809A03 HandleGrip 2

 4 RS681004 PostSupport 1

 5 RS6809A05 ClevisPin 1

 6 RS6809A06 FlatWasher(16) 2

 7 RS6809A07 CotterPin 2

 8 RS681008 ClevisPin(12x35) 1

 9 RS681009 FlatWasher(12) 2

 10 RS150010 FootPedal 1

 11 RS150011 Saddle 1

 12 RS6809A12 HexBolt(M8x16) 1

 13 RS6809A08 Handle 1

 14 RS6808BD02 Bearing(8106) 1

 15 RS6809A09 ScrewStem 1

  RSPSFP1500PL ProductLabel(notshown) 1

PS1500

1500-LBS.

CAPACITY

UNDERHOIST

STAND

PSFP1500

1500-LBS.

CAPACITY

UNDERHOIST

STAND WITH

PEDAL

7 9

PS1500 and PSFP1500 5 6/3/15
