MachPower SM-DLCB-006 Bedienungsanleitung
USER MANUAL
SMART DOOR LOCK
MANUALE D'USO
SMART DOOR LOCK
MANUAL DEL USUARIO
SMART DOOR LOCK
SM-DLCB-006
EN
ITA
ES
1. Technical Specifications
2. Product Description
3. Installation instructions
4. Settings
5. Reset to factory settings
6. Language settings
7. Open the door
8. Door opening event log
9. Low battery alarm
10. Incorrect entry of the opening code
11. The key light is off
4
4
5
6
9
9
10
10
10
10
11
ENG
3
INDEX
Door types
Door thickness
Door thickness
Power supply
Operating current
Operating current
1. Smart DoorLock SM-DLCB-006
2. Emergency micro magnetic induction keys
3. Tools for installation
Armored doors, wooden doors, glass
doors
40mm / 100mm
15kv
3.6V - 5V
<135mA: Standby <10uA
- 20 ° C / 70 ° C
2. PRODUCT DESCRIPTION
1. TECHNICAL SPECIFICATIONS
4
3. INSTALLATION INSTRUCTIONS
3.4 Install the lock
Screw in the lock screws.
3.5 After installing the knob
1. Pull the knob backwards and using
the supplied tool, tighten the screws.
2. Use the rear knob to make sure you
have installed the cylinder correctly.
Check that the cylinder opens correctly.
3.1 Remove the original lock cylinder
Unscrew the screws and remove the
cylinder of the original mechanical lock.
Install the lock cylinder and secure the
front, rear and side panels.
3.2 Remove the cylinder of the smart
lock and knob
Remove the smart lock cylinder and
knob.
3.3 Installing the smart lock cylinder
Install the smart lock cylinder on the
front panel. Adjust the position to match
the screw holes.
ENG
5
3.6 Battery Installation
1. Remove the front knob cover and
unscrew the battery compartment cover
using the supplied tool.
2. Insert 3 AAA size batteries into the
battery compartment. Pay attention to
the direction of the positive and nega-
tive poles. The end of the spring is the
negative pole.
3. After inserting the batteries, close the
battery compartment and the knob
cover.
3.7 Test after installation
1. Verify that the lock is securely installed
on the door. Check that the rear knob
opens the door in the correct way.
2. After connecting the power supply,
the motor reverses. It will be possible to
turn the knob minimally. Enter the initial
password to open normally.
3.8 Use of emergency keys
1. Open the front knob cover.
2. Insert the emergency key and turn
the key 30 degrees clockwise. The front
knob cannot rotate.
3. Turn the front knob to open the door.
Before following the instructions below, check that the blueto-
oth of the mobile phone is active, and that the phone and the
port are close, we recommend a maximum distance of 5 meters.
4. SETTINGS
6
ENG
1. Connect the APP
Download the Tuya App from the store, depending on the
smartphone.
Open and follow the registration commands. Click on “+” located
at the top right of the homepage.
1.1 Manual Add
Click on “Protection sensor” --- “BLE lock”, confirm the guided
item, on the left. Press any key to activate the keyboard of the de-
vice, press “<” to activate the bluetooth of the device. Wait a few
seconds and the device name will appear, then click connect.
1.2 Automatic search
Click on “automatic search” at the top, to make sure the lock
is powered correctly, press any button to activate the device
keyboard, press “<” to activate the device’s bluetooth. Wait a few
seconds and the device name will appear, then click connect.
2. Fingerprint configuration
2.1 Add fingerprint
Click on the device name from the home page, enter the confi-
guration screen, and click “Settings-fingerprint management-top
right corner + number-add fingerprint”, select the user, click
“Start scan “, enter 4 fingerprints according to the command,
after entering successfully will show” Fingerprint Name “, enter
the name and add correctly.
2.2 Remove fingerprint
Click the device from the home, enter the management screen,
click “Fingerprint Management”, click the icon to the right of the
fingerprint to delete.
7
3. Password configuration
3.1 Add Password
After clicking on the device name, enter the configuration
screen, click on “Settings, password management - add the
password in the upper right corner + Nu.”, Select the user, enter
the password and the nickname as per commands shown on
the page, the password must be between 6 and 0 characters in
length, click save to complete the procedure.
3.2 Delete Password
After clicking on the device name, enter the management
screen, click “Password Management”, click the icon to the right
of the fingerprint to delete.
4. User configuration
In the configuration screen it is possible to choose between two
different types of users:
1. Relatives
Users already present in the “Family” group in the application,
new users who are added to the “family” group will also be auto-
matically added to the lock group. Note: it is possible to delete
a user from the “family” group only through the management
page of “family” users.
2. Other Users
They are users present only in the lock group, not in the “family”
group. Adding and deleting these users will have no effect on
the “family” group
4.1 User Management - Other User Management
4.1.1 Period of validity
The administrator can decide the other users, choosing whether
8
Open the application, click on the device, enter the manage-
ment screen and click on “Language Settings” to select the
language.
Click on the device from the home screen, enter the device
management screen, click on the icon at the top right, enter the
device, go down to find factory reset, and click on it.
5.1 It is possible to restore the factory settings when both the
smartphone and the lock are connected via Bluetooth. All
methods of opening the door will be cleared, and the lock will
be reset to factory settings. After about 3 minutes, users will be
able to re-add the lock on the application.
5.2 If the smartphone is not connected to the lock via bluetooth,
the lock is reset to the factory setting. The way the door is ope-
ned on the door lock remains unaffected
ENG
to set as a permanent user or set a start and end time for using
the lock.
4.1.2 Open the door
The administrator can determine the type of permission that
each member can obtain to open the door; if the administrator
decides to block the door opening, no user will be able to open
the door via the application, the door must be opened manually.
4.1.3 After adding a new user
The administrator can associate the new user with the use of the
application through the “Share” operation. At the end of the time
set for sharing, the user will no longer be able to use the device.
6. LANGUAGE SETTINGS
5. RESET TO FACTORY SETTINGS
9
7. OPEN THE DOOR
Door opening event log
Voice Prompt 3.6v: Replace the batteries if the battery level is
low.
Open the application, select the device, move left to the
“Dynamic Password” screen, click “Get”, to generate a dynamic
password, valid for 5 minutes after it has been generated, Enter
the 8 digits + “ ”, to open the lock.
Entering the wrong fingerprint 5 times consecutively (3 times the
wrong password). The device will lock up and cannot be used for
the next 3 minutes.
Press any key to activate the keypad on the knob, enter the pas-
sword and click on “ ” the lock will open and the light will be
blue, at the end of the time for opening the door, the lock will will
close and the blue light will go out.
Place the fingerprint, the lock will open and the light will be blue,
at the end of the time for opening the door, the lock will close and
the blue light will go out.
Open the application, select the device, enter the device manage-
ment page, click “Smartphone Opening - OK” to open the lock.
9. LOW BATTERY ALARM
8. DOOR OPENING EVENT LOG
10. INCORRECT ENTRY OF THE OPENING CODE
10
After pressing a button, the light will stay on for 10 seconds, at
the end of which in case of inactivity, it will turn off automati-
cally, press the back button to turn the light back on.
11. THE KEY LIGHT IS OFF
ENG
11
