Magellan eXplorist XL

Reference Manual

IN THE INTEREST OF SAFETY, DO NOT USE THIS NAVIGATION DEVICE WHILE DRIVING A VEHICLE.

Please do not try and change any settings on the Magellan eXplorist while driving. Come to a complete stop or

have a passenger make any changes. Taking your eyes off the road is dangerous and can result in an accident

in which you or others could be injured.

USE GOOD JUDGEMENT

This product is an excellent navigation aid, but does not replace the need for careful orienteering and good

judgement. Never rely solely on one device for navigating.

USE CARE

The Global Positioning System (GPS) is operated by the U.S. Government, which is solely responsible for the

accuracy and maintenance of the GPS network.The accuracy of position fixes can be affected by the periodic

adjustments to GPS satellites made by the U.S. government and is subject to change in accordance with the

Department of Defense civil GPS user policy and the Federal Radionavigation Plan. Accuracy can also be

affected by poor satellite geometry and obstructions, like buildings and large trees.

USE PROPER ACCESSORIES

Use only Magellan cables and antennas; the use of non-Magellan cables and antennas may severely degrade

performance or damage the receiver, and will void the warranty.

LICENSE AGREEMENT

Thales grants you, the purchaser, the right to use the software supplied in and with Thales Navigation GPS

products (the “SOFTWARE”) in the normal operation of the equipment in accordance with the terms of the

End User License Agreement that is with the product.

The SOFTWARE is the property of Thales and/or its suppliers and is protected by United States copyright laws

and international treaty provisions; therefore, you must treat the SOFTWARE like any other copyright material.

You may not use, copy, modify, reverse engineer or transfer this SOFTWARE except as expressly provided in the

license. All rights not expressly granted are reserved by Thales and/or its suppliers.

* * *

No part of this guide may be reproduced or transmitted in any form or by any means, electronic or mechanical,

including photocopying and recording, for any purpose other than the purchaser’s personal use without the

prior written permission of Thales.

* * *

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this

device must accept any interference, including interference that may cause undesired operation of the device.

The Magellan Logo, Magellan, eXplorist and TrueFix are trademarks of Thales Navigation Inc.

631288-18 B

***WARNINGS***

eXplorist XL GPS Receiver 1

Features of the Magellan eXplorist GPS receiver: 1

Button Descriptions 2

Starting Up 5

Turning the eXplorist On 5

Turning the eXplorist Off 5

Turning the Display Backlight On/Off 5

Using the eXplorist for the First Time 6

Conclusion 10

Using the eXplorist XL 11

Going to a Destination 11

Saving Your Position 12

Additional Features 13

Tracing Your Steps 13

Navigation Screens 14

Accessing the Navigation Screens 14

Map Screen 14

Compass Screen 21

Position Screen 23

Satellite Status Screen 24

eXplorist XL GPS File Structure 25

Basic File Structure 25

File Structure Overview 25

Using the Filing System with POIs 26

Using the Filing System with Routes 26

Using the Filing System with Track Logs 27

Points of Interest 28

Marking Your Position 28

The POI Database 32

Routes 39

GOTO Routes 39

Multi-Leg Routes 41

Track Logs 48

Advanced Features 54

Computing Best Fish/Hunt Times 55

Displaying Sun and Moon Information 56

Viewing the Vertical Profile 57

Using the Simulator 58

Communicating with a Personal Computer 59

Table of Contents

Magellan Geocache Manager 61

Using the Magellan Geocache Manager 62

Working with Geocache Files 64

Using the eXplorist with MapSend 66

Overview of Uploading Detail Maps from MapSend to the eXplorist 66

Transferring POIs, Routes, and Track Between MapSend and eXplorist 69

Preferences 71

Restarting the GPS 71

Using Active Setup 73

Setting the Map Units 74

Selecting the Background or Detail Map 74

Using the Power Management Tool 76

Personalizing the eXplorist 77

Clearing Memory 78

Selecting Languages 78

Setting Alarms 80

Setting the Clock 81

Specifications 83

Performance 83

Physical 83

Memory 84

Coordinate Systems 84

Routes 84

Track Logs 84

Power 84

Navigation Screens 85

Alarms 85

Points of Interest 85

Accessories 86

Contacting Magellan Support 87

Table of Contents

eXplorist XL GPS Receiver

Antenna

Display Backlight

Button

Arrow Joystick

ZOOM IN

NAV

MARK ESC

GOTO

ZOOM OUT

ENTER

On/Off Button

Features of the Magellan eXplorist GPS receiver:

• Built-in background map (28 MB)

• High-definition color display

• Preloaded points of interest

• Rugged design, rubber-protected

• 28 MB of usable memory

• Superior tracking with 14 parallel channels

• TrueFix™ GPS technology

• 3 meter accuracy (WAAS/EGNOS)

• Multiple track logs

• Pocket-sized and water resistant

• Unlimited storage of data using SD cards

eXplorist XL GPS Receiver 2

Button Descriptions:

On/Off Turns the eXplorist on or off.

Backlight Turns the display backlight on. Sequences from off to low to high intensity.

ENTER Used to access highlighted menu items or accept highlighted buttons.

ESC Cancels data inputs.

Closes the accessed function and goes back to the last viewed screen.

Steps backwards through the navigation screens.

ZOOM IN Used on the Map screen to zoom in the map displayed. The map display can be

zoomed in to 100 ft. (35.0 m).

Also used to quickly step through the list of POIs when doing an alphabetical

search.

ZOOM OUT Used on the Map screen to zoom out the map displayed. The map display can

be zoomed out to 1700 mi (2700 km).

Also used to quickly step through the list of POIs when doing an alphabetical

search.

MENU Brings up a menu with available options. Options can be selected by using the

arrow joystick to highlight the option and pressing ENTER to access it.

NAV Steps through the navigation screens. (Map screen > Compass screen > Position

screen > Satellite Status screen)

MARK Used to save your present position as a point of interest. Points of interest that

you save are stored in the POIs portion of the database.

GOTO Creates a one-leg route from your present position to a destination selected from

the Points of Interest database or by using the cursor on the background map

Arrow joystick Pans the cursor on the Map screen.

Moves the highlight bar to select menu options and data entry fields.

eXplorist XL GPS Receiver 3

Remove battery cover by turning the silver latch on the back of

the unit one quarter turn. The eXplorist XL uses four AA batteries

that are installed as shown in the accompanying diagram. Be

sure to observe the proper polarity when installing the batteries.

Under normal operating conditions you can expect to get more

than 19 hours of battery life when using fresh batteries.

Tips on conserving battery life:

• Turn the eXplorist off when not in use. Whether you are

moving or standing still, the eXplorist is constantly

calculating position fixes and using power at the same

rate. If you are going to be at the same position for any

length of time, turn the eXplorist off.

• Use the Power Timer to automatically turn the eXplorist off. The Power Timer option allows you to set

a time that the eXplorist will automatically turn off when none of the buttons have been pressed and

you are not moving for a selected time. You can select from 5, 10, 30 or 60 minutes.

• Use the display backlight sparingly. The most severe drain on the batteries is the use of the display

backlight. You will notice a drastic drop in battery life with the backlight display on high. You should

use the Light Timer to set a time interval that the display backlight will automatically turn to the lowest

setting when none of the buttons have been pressed and the computed location hasn’t changed.

Setting the Power Timer

From any Nav screen press MENU. Highlight Preferences and press ENTER. Highlight Pwr Management and

press ENTER twice. Use the arrow joystick to select 5 Minutes, 10 Minutes, 30 Minutes, 60 Minutes or Off.

Press ENTER. Press NAV to return to the last viewed navigation screen.

Setting the Light Timer

From any NAV screen press MENU. Highlight Preferences and press ENTER. Highlight Pwr Management and

press ENTER. Use the down arrow to highlight the Light Timer field. Press ENTER. Use the arrow joystick to

select 30 Seconds, 1 Minute, 2 Minutes, 4 Minutes, 10 Minutes or Timer Off. Press ENTER. Press NAV to

return to the last viewed navigation screen.

Install the SD card as shown here.

Installing the Batteries

Installing an Optional SD Card

eXplorist XL GPS Receiver 4

Turn your eXplorist off and connect the connector of the eXplorist data cable to the back of your eXplorist and

tighten the locking screw. There are alignment tabs on the connector to make sure that the connector is

installed properly. It is recommended that you connect the eXplorist to external power using the external AC

power adapter.

The other end of the eXplorist data cable has a standard USB connector that you connect to your personal

computer USB ports (normally found on the back of your personal computer). Turn your personal computer on

and then turn on your eXplorist. You may see a message on your computer indicating that it has found a new

USB hardware device. On your eXplorist, a screen is displayed indicating that it is in USB File transfer mode.

Right click the “My Computer” icon on the desktop of your computer and select the “Explore” option. From

here you are able to copy files to and from the eXplorist or SD card, depending upon what you have selected.

From here you are able to copy files to and from the installed SD card to your computer.

WARNING: When connecting the USB cable, always connect it to the eXplorist first before plugging the

AC power adapter into a wall socket.

Connecting to a Personal Computer

To turn the eXplorist on, press the POWER button on the top right side.

To turn the eXplorist off, press the POWER button on the top right side.

There is a 5 second countdown after you press the POWER button. If you change

your mind and decide to leave the eXplorist on, just press the ESC button. If you

press the POWER button during this countdown period, the eXplorist will

immediately turn off.

The display backlight has three levels of intensity: high, low and off. When the eXplorist is first turned on, the

display backlight is on high. Press the LIGHT button on the top left side of the eXplorist to turn the backlight

on low. Pressing the LIGHT button a second time turns the backlight off.

Backlight intensity changes each time you press

the LIGHT button.

Remember: Using the display

backlight causes severe drain on the batteries.

Turning the eXplorist On

Turning the eXplorist Off

Turning the Display Backlight On/Off

Starting Up

Starting Up 6

Turn the eXplorist on. Press the Power button. When the Startup screen is

displayed, press ENTER.

Select Language. When you turn on the eXplorist for the first time you are

given the option of selecting one of the ten languages that will be used.

You can change the language selection at any time by accessing Menu >

Preferences > Languages.

Tip: If you accidentally change the language and you can’t read the text and

need to change it back, press the NAV button until the Satellite Status

screen is displayed. Press MENU. Use the Arrow joystick to highlight the

fourth line and press ENTER. Use the Arrow joystick to highlight the fifth

line and press ENTER. The Language Select screen will be displayed.

Read Warning. When you agree to the warning statement, press ENTER to

continue.

Compute Initial Position. For this operation, it is best if you are outside and

have a clear, unobstructed view of the sky. Without a clear view, this will

take much longer and could result in the eXplorist being unable to compute

the initial position automatically.

The eXplorist begins to compute your initial position. This may take a few

minutes as it is doing a cold start.

Normally, when you first turn the eXplorist on it will compute your position

in a manner of seconds as it is able to do a warm start. (An explanation of

cold start vs. warm start is explained following this section.)

The Satellite Status screen is displayed, showing you the progress of the

collection of satellite data.

Using the eXplorist for the First Time

Use arrow joystick to move the

highlight up and down. Press

ENTER to accept.

Press ENTER to continue.

Satellite Status screen shows

how many satellites are being

tracked as well as the relative

strength of the signal.

Andere Handbücher für eXplorist XL

Inhaltsverzeichnis

Andere Magellan GPS Handbücher

Magellan

Magellan ROADMATE 5045 Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan 1000M Bedienungsanleitung

Magellan

Magellan Maestro 4200 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan Maestro 4000 - Automotive GPS Receiver Stücklistenhandbuch

Magellan

Magellan RoadMate 5190T Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan Triton 500 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan GPS Receiver SkyNav 5000 Bedienungsanleitung

Magellan

Magellan SmartGPS 5390 Bedienungsanleitung

Magellan

Magellan eXplorist 500 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan RoadMate 360 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan eXplorist TRX7 Bedienungsanleitung

Magellan

Magellan FAST Survey Bedienungsanleitung

Magellan

Magellan eXplorist 210 Bedienungsanleitung

Magellan

Magellan RoadMate 3055 Bedienungsanleitung

Magellan

Magellan RoadMate 3000T - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan RoadMate 3055-MU Bedienungsanleitung

Magellan

Magellan RoadMate 760 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist TRX7 Bedienungsanleitung

Magellan

Magellan SporTrak SporTrak Color Bedienungsanleitung

Magellan

Magellan Maestro 3220 - Automotive GPS Receiver Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung

Garmin

Garmin GPSMAP 78 series Bedienungsanleitung

Magellan eXplorist XL Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken
