Basic Instructions for the Operation

of the

Magellan RoadMate 500/700

Magellan®RoadMate™

Basic User Manual

This document covers the basic operation of the Magellan RoadMate 500 and the

Magellan RoadMate 700 Vehicle Navigation Systems. The information provided

here is enough to give you all the normal operating features for using this product.

If you need additional information or if you require details on other functions, refer

to the Reference Manual found on the compact disc (CD-ROM) supplied with your

Magellan RoadMate.

The Magellan RoadMate is a vehicle navigation aid designed to assist you in arriving at your

selected destination. When using the Magellan RoadMate, these safety rules must be followed

to prevent accidents that can result in injury or death to yourself or others:

• When driving, the need to view the display is minimal. Voice prompts

will guide you to your destination. The driver should enter data or

program the unit only when the vehicle is stopped. Only a vehicle

passenger should enter data or program the unit while the vehicle is

moving.

• It is your responsibility to comply with all traffic laws.

• While every attempt is made to ensure that the database is accurate,

roadways, points of interest, and business and service locations may

change over time. The database does not include, analyze, process,

consider or reflect any of the following: legal restrictions (such as

vehicular type, weight, height, width, load and speed restrictions); road

slope or grade; bridge height, width, weight or other limits; population

density; neighborhood quality or safety; availability or proximity of law

enforcement, emergency rescue, medical or other assistance; construction

work zones or hazards; road or lane closures; road, traffic or traffic

facilities safety or condition; weather conditions; pavement characteristics

or conditions; special events; traffic congestion. It is your responsibility

to disregard any unsafe, hazardous or illegal route suggestions.

*** IMPORTANT SAFETY WARNINGS ***

Magellan, RoadMate, TrueView and QuickSpell are trademarks of Thales Navigation.

No part of this user manual may be reproduced or transmitted in any form or by any

means, electronic or mechanical, including photocopying and recording, for any

purpose other then the purchaser’s personal use, without the prior written permission

of Thales Navigation.

The Magellan RoadMate

Thank you for purchasing the Magellan RoadMate. We hope you will enjoy using your

new vehicle guidance system and encourage you to provide us with feedback. Please

take a moment to register your Magellan RoadMate with us at www.magellangps.com.

Table of Contents

Magellan RoadMate (Front View) . . . . . . . . . . . . . . . . . . . . . . . . . .2

Magellan RoadMate (Rear View) . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Basic Operation

How Do I Enter Text? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Where is the Volume Control? . . . . . . . . . . . . . . . . . . . . . . . . .7

Can the Voice Command be Repeated? . . . . . . . . . . . . . . . . . .7

How Do I Adjust the Contrast and Brightness? . . . . . . . . . . . .7

Traveling with the Magellan RoadMate

How Do I Read the Guidance Screen? . . . . . . . . . . . . . . . . . . .8

Viewing the Guidance Screen . . . . . . . . . . . . . . . . . . . . . .8

Changing the Map Zoom Levels . . . . . . . . . . . . . . . . . . . .9

How Do I See the Entire Route? . . . . . . . . . . . . . . . . . . . . . . .9

How Can I See What the Next Instruction Will Be? . . . . . . . .9

How Do I Cancel a Route? . . . . . . . . . . . . . . . . . . . . . . . . . . .10

How Do I Get Back on the Route after a Detour? . . . . . . . . .10

Selecting Trip Destinations

How Do I Go to a New Street Address? . . . . . . . . . . . . . . . . .11

How Do I Select a Point of Interest as a Destination? . . . . . .12

How Do I Go to a Previous Destination? . . . . . . . . . . . . . . . .15

How Do I Go to an Address from My Address Book? . . . . . .16

Using the Trip Computer

Is There a Way I Can Record Mileage for My Trip? . . . . . . . .17

Using the Tutorial

Can I Get Help While I’m Using the Magellan RoadMate? . .18

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Registration Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

2Magellan RoadMate (Front View)

12 10

On/Off Button Press to turn the Magellan RoadMate on or off.

Volume Control Adjust to set the volume of the speaker.

Repeat Button Press to repeat the last spoken prompt.

Zoom In Button While viewing the map, press to zoom in on the

center of the display.

Option Button Press to access the User Options menu.

Enter Button Press to confirm highlighted selections.

Cancel Button Press to stop the current function.

8-Way Arrow Keypad Press to move the cursor or to highlight other

options.

Locate Button Press to display current location details.

View Button Press to view map display, maneuver list or

Tr u e V i e w ®3D display.

Light Sensor Automatically changes the contrast and brightness of

the display to adjust for changes in lighting.

Zoom Out Button While viewing the map, press to zoom out from the

center of the display.

The Magellan RoadMate (Rear View)

234

Speaker Used for audible maneuvering instructions.

Repeat Button Press to repeat the last spoken prompt.

Volume Control Adjust to set the volume of the speaker.

Antenna Rotate up when in use to receive signals from the

GPS satellite network.

Compact Flash This compartment stores the compact flash memory

card.

Power/Data Connector Connection for power and data for the Magellan

RoadMate.

The difference between the Magellan RoadMate 500 and the Magellan RoadMate

700 is in how the mapping data is stored. The Magellan RoadMate 500 uses

compact flash memory card which can store a selected area of mapping data that

can then be uploaded from the supplied software. The Magellan RoadMate 700

has an internal hard drive, pre-loaded with mapping data and over 2 million

Points of Interest for the United States and Canada.

For this document, both models will be referred to as the Magellan RoadMate

unless noted. Since the Magellan RoadMate 500 can store only a portion of the

United States and Canada, you may notice that the information displayed on your

Magellan RoadMate 500 may differ slightly from what is shown here.

Magellan RoadMate 500/700

4Basic Operation

How Do I Enter Text?

Whenever you need to input names, street addresses, etc., the Magellan RoadMate

will display a keyboard that allows you to use the 8-way arrow keypad and the Enter

key to highlight and select the alphanumeric characters.

Space Bar

Additional Characters

Accept Entry

Numerical Characters

Cancel

Backspace

Both the Magellan RoadMate 500 and the Magellan RoadMate 700 have a

touchscreen display and keypad giving you two easy ways to input

information into your Magellan RoadMate. The examples here describe

using the 8-way arrow keypad and the Enter button to input and accept

changes.

If you prefer to use the touchscreen, touch the

key directly on the screen with your finger.

Please use the method that is easiest for you.

Notepad

The Magellan RoadMate uses QuickSpell technology to provide you the

fastest method possible to enter characters. QuickSpell eliminates the

possibility of a mispelled word or looking for a city or street that is not in

the loaded database. As you begin entering characters, the QuickSpell

feature of the Magellan RoadMate dims out those characters which are not

available, thereby speeding up the process of entering data.

What Is QuickSpell®?

Example:

Suppose that you need to input the name of a city, in this case, San Francisco.

QuickSpell checks the cities in the database

and determines which characters are

available based on city names in the

database. Use the 8-way arrow keypad to

highlight the “A” and press Enter.

The full keypad is displayed. Use the 8-way

arrow keypad to move around the keyboard,

and press Enter when the letter “S” is

selected.

Basic Operation

The available characters changes and the

text you are typing appears at the top of the

keyboard. Use the 8-way arrow keypad to

highlight the “N” and press Enter.

With “SAN” entered, QuickSpell determines

the only characters availble are “D”, “T”,

and the spacebar. In this example, we want

to continue to narrow the search. Use the 8-

way arrow keypad to highlight the spacebar

and press Enter.

You can now select “OK” and get a list of

cities that begin with “SAN ” and select San

Francisco from the list.

Using the QuickSpell keyboard, add “F” to

our city select text. Now the city list can be

checked again. Select “OK” and press Enter.

For the database used in this example, San

Francisco, CA is the only city displayed. Your

database could still show more cities and you

may need to enter more characters.

When you are entering characters you may

need to add punctuation or other special

characters. When available, pressing the

“More” button brings up a keypad with the

characters shown here.

Addtional Characters (“More” Button)

When available, pressing the “123” button

brings up a keypad with the numeric

characters shown here.

Numeric Characters (“123” Button)

6Basic Operation

Selecting “OK” brings up a list that would be

similar to the one displayed here. For this

example, you could select San Francisco very

easily. With a larger database installed, this

list could be very long and still difficult to

find the city you are looking for. Press the

escape button (or using the touchscreen,

touch the “X” in the upper right corner) to go back to the

QuickSpell keyboard to continue entering characters.

Where is the Volume Control?

The volume control is located at the top of the Magellan RoadMate. Use the

thumbwheel to set the volume of the speaker to a desired level.

Can the Voice Command be Repeated?

Yes. Anytime you may have missed a voice prompt, simply press the Repeat button

on the top of the Magellan RoadMate to have the last voice promt repeated.

Repeat ButtonVolume Control

How Do I Adjust the Contrast and Brightness?

The Magellan RoadMate has a light sensor on the front of the unit that will

automatically detect changes in lighting and adjust the brightness and contrast for

optimum viewing levels. You may also manually adjust the brightness and contrast

levels.

To access the contrast and brightness controls, press the

Option button and select “Configuration” from the list of

menu items. From the “Configuration” menu items, select

“Contrast” or “Brightness” and press Enter.

Use the left and right arrows from the 8-way arrow keypad

to adjust the contrast or the brightness to the levels desired.

Press Enter when you have the setting you want.

Traveling with the Magellan RoadMate

How Do I Read the Guidance Screen?

Viewing the Guidance Screen

The Guidance screen is the most commonly used screen in the Magellan RoadMate

and provides you with detailed information about where you are and where you are

going.

Distance to

Destination

Position Cursor

(points in the

direction you are

heading)

Estimated

Time to

Destination

Distance to

Maneuver

Command

Direction of

Travel and GPS

Signal Strength

Planned Route

As you travel, the Guidance screen constantly updates your location and provides

you with not only a map, but a visual indication of where you are on the map.

You can view the Guidance screen at anytime by pressing the View button on the

Magellan RoadMate. While viewing the Guidance screen, the View button steps

through the Guidance screen, the Maneuver List and the TrueView 3D display.

Blue = WAAS Signal

Green = Strong Signal

Yellow = Average Signal

Red = No Signal

Direction of

Destination

View Button

8Traveling with the Magellan RoadMate

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Magellan GPS Handbücher

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan smartGPS Bedienungsanleitung

Magellan

Magellan RoadMate 1412 Bedienungsanleitung

Magellan

Magellan NAV6000 Bedienungsanleitung

Magellan

Magellan RoadMate 1200 - Automotive GPS Receiver Service-Handbuch

Magellan

Magellan iCGRS Bedienungsanleitung

Magellan

Magellan RoadMate 3000T - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan Maestro 3220 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan Maestro 3220 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan Maestro 4370 - Widescreen Bluetooth Portable GPS... Montageanleitung

Magellan

Magellan RoadMate 1440 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan smartGPS Bedienungsanleitung

Magellan

Magellan SmartGPS 5390 Bedienungsanleitung

Magellan

Magellan RoadMate Series Bedienungsanleitung

Magellan

Magellan Triton 200 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan GPS Receiver Bedienungsanleitung

Magellan

Magellan RoadMate 1200 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan SporTrak SporTrak Color Bedienungsanleitung

Magellan

Magellan RoadMate 760 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan RoadMate 3065 Bedienungsanleitung

Magellan

Magellan 980588-01 - GPS Companion For Palm V/Vx Leitfaden

Magellan

Magellan MobileMapper CE - Hiking GPS Receiver Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung

Garmin

Garmin GPSMAP 78 series Bedienungsanleitung
