MAP 330 and MAP 330M

Product:

Map330

Question:

How many batteries are required for MAP 330?

Answer:

MAP 330 uses two AA batteries that are installed from the back

through the battery cover.

Product:

Map330,

Map330M

Question:

If I am using fresh batteries how long will my GPS stay on?

Answer:

You have up to 10 hours of usage on two fresh AA batteries with the

backlight turned off.

Product:

Map330,

Map330M

Question:

How much time do I have to replace the batteries before I loose

waypoints?

Answer:

Any waypoints or routes you have created are stored in permanent

memory and should not be lost for months with the batteries

removed. Present position and time data is not stored in permanent

memory, but will be held in memory for at least two hours without

batteries installed.

Product:

Map330,

Map330M

Question:

How do I connect the wrist strap to my GPS?

Answer:

The wrist strap attaches to the ring on the screw for the battery door

cover

Product:

Map330,

Map330M

Question:

Does the MAP 330 or MAP 330M come with a power or data cable?

Answer:

No. You must purchase it separately.

Product:

Map330,

Map330M

Question:

How do I adjust contrast in MAP 330 and MAP 330M?

Answer:

Press the menu button, then use the up/down arrows to highlight

contrast and then use the left/right arrow to adjust the contrast.

Product:

Map330,

Map330M

Question:

How many navigation screens does MAP 330 and 330M have?

Answer:

The Map 330 and 330M have seven navigation screens: Map

screen, compass screen, large data screen, position screen, sat

status screen, Speedometer screen and the road screen. The NAV

button provides a means of accessing the navigation screens.

Product:

Map330,

Map330M

Question:

How do I save a Waypoint with a receiver-generated name?

Answer:

From any screen, press and hold the mark button for two seconds

and the mark screen is displayed. The “save” button is highlighted

and you can press enter to save the waypoint using the default name

and icon.

Product:

Map330,

Map330M

Question:

How do I save a waypoint with a user-input name?

Answer:

From any screen, press and hold the mark button for two seconds.

Use the up/down arrows and notice that the highlight moves from

field to field and then back to “save.” Highlight the Icon field using the

up/down arrows. Press enter.

Product:

Map330,

Map330M

Question:

Is there a limit to the number of waypoints I can store in the MAP

330 and the MAP 330M?

Answer:

Yes, the MAP 330 and 330M will store up to 500 user waypoints in

memory.

Product:

Map330,

Map330M

Question:

Why is my GPSnot allowing me to create a message for waypoints?

Answer:

With the MAP 330 you can only create messages or 200 waypoints.

If you should ever get that many and need to input more, to make

room you will have to delete ones that you no longer need.

Product:

Map330,

Map330M

Question:

How do I create a GOTO route?

Answer:

The two ways to create a GOTO route are the following:

Creating GOTO using destination waypoint from “Near

Position”

Press GOTO. Use the UP/DOWN arrows to highlight the

category that your destination waypoint is in. Use the left/right arrows

to select near position. Use the up/down arrows to highlight your

choice of waypoint to be your destination and press enter. The

GOTO route is now active and you are returned to the last viewed

navigation screen.

Creating a destination waypoint from the database using

“Alphabetical”

Press GOTO. Use the up/down arrows to highlight the

category that your destination waypoint is in. Use the left/right arrows

to select “Alphabetical”. Use the up/down arrows to highlight your

choice of waypoint to be your destination and press enter. The

GOTO route is now active and you are returned to the last viewed

navigation screen

Product:

Map330,

Map330M

Question:

How do I turn on the display waypoint on map screen?

Answer:

From map screen press the menu button highlight map setup and

use the arrow to select the “display waypoints “and press enter. Use

the arrow to select on and press enter and nav button.

Product:

Map330,

Map330M

Question:

How do I change map orientation from north up to course up?

Answer:

From map screen press menu button highlight map setup and use

the arrow to select the “orientation“ and press enter. Use thearrow to

select on, press enter and nav button.

Product:

Map330,

Map330M

Question:

How do I clear track in my GPS?

Answer:

From map screen press the menu button, highlight clear track, and

press enter. Click on confirm and press enter.

Product:

Map330,

Map330M

Question:

How do I reset the trip odometer?

Answer:

Press the nav button to get the position screen and press the

menu button and highlight reset trip and click on yes and press

enter.

Product:

Map330,

Map330M

Question:

What information I can get from the satellite screen?

Answer:

Thes The satellite status screen visually displays the satellites being

used and the strength of the received signal. Additionally, this screen

displays the power source you are connected to and, if internal

batteries, how much battery life is remaining.

Product:

Map330,

Map330M

Question:

How do I access a waypoint in my GPS?

Answer:

Press the menu button and highlight database and press enter. Use

the up/down arrows to select category. Use the left/right arrow to

select “find by” and press enter. You can find the waypoint by

selecting waypoints from the nearest list and selecting waypoints

from the Alphabetical list.

Product:

Map330,

Map330M

Question:

How do I save my present location?

Answer:

From any screen press and hold the mark button for a few seconds.

You can change the name and put the message in the GPS.

Product:

Map330,

Map330M

Question:

How do I manually create waypoint?

Answer:

From any screen press and hold the mark button and highlight the

location field and press enter. Edit line 1 of the location field and

press enter. Also Edit line 2 of the location field and press enter. Edit

elevation field and press enter. If you want to enter a message you

can modify it. Highlight save button.

Product:

Map330,

Map330M

Question:

How do I delete a waypoint in my GPS?

Answer:

From any menu button highlight database. Press enter and highlight

user. Use the left/right arrow to select by “find by” and press enter.

Select waypoint to delete and press menu. Highlight delete wpt

,press enter, confirm yes and enter.

Product:

Map330,

Map330M

Question:

Can I use MapSend Street and Destination in MAP 330M?

Answer:

Yes you can use Magellan MapSend Streets.

Product:

Map330,

Question:

How do I create a route in MAP 330 and in MAP 330M?

Map330M

Answer:

From any menu button highlight database and press enter. Highlight

upload map region and press enter. Highlight address and press

enter. Use the arrows to enter street name press enter.

Product:

Map330,

Map330M

Question:

How do I create a back route in MAP 330 and in MAP 330M?

Answer:

From any screen press, the menu button. Highlight routes and press

enter. Select “backroute” from route list and press enter. Highlight

activate backrt and press enter.

Product:

Map330,

Map330M

Question:

How do I activate the route in

MAP 330 and in MAP 330M?

Answer:

From any menu button highlight routes and press enter. Highlight

select route and press menu. Highlight activate routes and press

enter.

Product:

Map330,

Map330M

Question:

How do I view a route in my GPS?

Answer:

From any menu button highlight routes and press enter. Highlight

select route and press menu. Highlight view/edit route and press

enter.

Product:

Map330,

Map330M

Question:

How do I delete a route in my GPS?

Answer:

From any menu button highlight routes and press enter. Highlight

select route and press menu. Highlight delete route and press enter.

Product:

Map330,

Map330M

Question:

How do I view a route on map screen?

Answer:

From any menu button highlight routes and press enter. Highlight

select route and press menu. Highlight map view route and press

enter.

Product:

Map330,

Map330M

Question:

How do I initialize the MAP 330 and the MAP 330M?

Answer:

Press the menu button from any screen. Highlight setup and press

enter. Highlight initialize and press enter. Highlight region and press

enter. Highlight area and press enter again. Input date and time and

press enter twice.

Product:

Map330,

Map330M

Question:

What are the default primary and secondary co-ordinate systems in

MAP 330 and in 330M?

Answer:

Primary - Lat/Lon DEG.MIN.MMM

Secondary – UTM

Product:

Map330,

Map330M

Question:

How can I change the co-ordinate system in MAP 330 and 330M?

Answer:

From any screen press the menu button highlight setup and press

enter. Highlight co-ordinate system and press enter. Select primary

or secondary and press enter. Select co-ordinate system and press

enter.

Product: Question:

What is the default map datum in MAP 330 and in 330M?

Map330,

Map330M

Answer:

Default: Primary - WGS84 Secondary - WGS84

Product:

Map330,

Map330M

Question:

How do I change map datum in MAP 330 and in330M?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight map datum and press enter. Select primary or

secondary and press enter. Select map datum and press enter.

Product:

Map330,

Map330M

Question:

How do I change the elevation mode in MAP 330 and in 330M?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight eleve mode and press enter. Select 2D and press

enter.

Product:

Map330,

Map330M

Question:

How do I change the time format in MAP 330 and in330M?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight time format and press enter. Select format and press

enter. If local time is selected (24 hour. or AM/PM) you will be

prompted to enter your local time.

Product:

Map330,

Map330M

Question:

How can I change the nav units from KM/KPH to miles/MPH?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight nav units and press enter. Select miles/MPH and

press enter.

Product:

Map330,

Map330M

Question:

What is the default elevation mode?

Answer:

Product:

Map330,

Map330M

Question:

How do I select the backlight timer in MAP 330 and in330M?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight light timer and press enter. Select time duration and

press enter. Time duration: 30 seconds, 1 minute, 2 minutes, 4

minutes, 10 minutes.

Product:

Map330,

Map330M

Question:

What is the default Baud rate for MAP 330 and 330M?

Answer:

4800 Baud.

Product:

Map330,

Map330M

Question:

How do I change the Baud rate in MAP 330 and in 330M?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight Baud rate and press enter. Select Baud rate and

press enter. You can choose 1200 Baud, 4800 Baud, 9600 Baud or

1920 Baud.

Product:

Map330,

Map330M

Question:

How do I clear memory in MAP 330 and in 330M?

Answer:

From any screen press the menu button, highlight setup, and press

enter. Highlight clear memory and press enter. Select the choice and

press enter. Confirm yes and press enter.

Clearing Track History

Clearing Wpts/Routes

Clearing all Routes

Product:

Map330,

Map330M

Question:

How can I clear all memory in MAP 330?

Answer:

From any screen press the menu button, highlight setup, and press

enter.

Highlight clear memory and press enter.

Highlight all and press enter...

Confirm yes and press enter.

Your GPS will turnoff.

Product:

Map330,

Map330M

Question:

How do I access the sun/moon screen?

Answer:

Press menu and highlight sun/moon and press enter.

Product:

Map330,

Map330M

Question:

What information can I get from the about screen?

Answer:

The ”about” screen displays the status of MAP 330 and MAP

330M.Using the about screen you can tell what the version of the

software is, the version and memory size of the base map, the

number of and total memory size of detailed maps you may have

installed using MapSend Street, and how much free memory is

available.

Product:

Map330,

Map330M

Question:

What is the difference between degrees/minutes/seconds

(DEG/MIN/SEC) and degrees/minutes/minutes (DEG/MIN/MMM or

DEG/MIN/MM)?

Answer:

There are different ways to express the coordinates computed using

latitude/longitude coordinate system. With DEG/MIN/SEC the final

set of numbers (SEC) is expressed as 0-59 while DEG/MIN/MM

expresses the same value as 0-99 and DEG/MIN/MMM is from 0-

999. It would be the same as if you had one clock that expressed

time as hour/minutes/seconds and another clock that expressed the

same time as hours/minutes/decimals. The accuracy for any of the

three is the same.

Product:

Map330,

Map330M

Question:

When the time changes for daylight savings will the time in your GPS

change automatically?

Answer:

No. The time transmitted by the satellites atomic clock is UTC

(Universal Time Coordinated) and provides no correction for daylight

savings. When daylight savings time changes (or when you move to

a new time zone), you need to go into setup —time format and re-

select the time format you are using unless you are using UTC. After

selecting the format you will be given the opportunity to change the

time.

Product: Question:

What waypoints come preloaded on my MAP 330database?

Map330

Answer:

The Map 330 database contains cities, highways, airports,

waterways, and national parks.

Product:

Map330,

Map330M

Question:

Can I delete preloaded waypoints that I don’t use?

Answer:

No. Waypoints that are preloaded into the MAP 330 will always be

available, even when all of the MAP 330’s memory has been

cleared.

Product:

Map330,

Map330M

Question:

Why does my compass not point in the right direction?

Answer:

For that you should be moving at a minimum of 2.0 mph for the

compass to compute the direction properly.

Product:

Map330,

Map330M

Question:

What is a backtrack route?

Answer:

A backtrack route allows you to “retrace” your steps. As you are

moving, the MAP 330 automatically creates and stores hidden

waypoints into memory. These waypoints are the ones that the MAP

330 will use to retrace your steps. When you create a backtrack

route, the MAP 330 converts these hidden waypoints into user

waypoints

Product:

Map330,

Map330M

Question:

How do I know which route is active?

Answer:

Access the route menu by pressing the menu button and select the

option routes. The route menu lists all of the routes in memory with

the active route displayed in bold characters.

Product:

Map330,

Map330M

Question:

Why does my MAP 330 and 330M not make an audible beep when I

have an alarm active?

Answer:

Check your setup settings for the Beeper. If the selection is off or

keys only, the beeper will not sound for alarms.

Product:

Map330,

Map330M

Question:

What can I do if the receiver will not turn on?

Answer:

1. Check to see if the batteries are installed correctly.

2. Replace with two new AA alkaline batteries.

Product:

Map330,

Map330M

Question:

My GPS takes more than 10 minutes to get the position. What can I

do?

Answer:

If there are any obstacles nearby or overhead, move to a new

location. Make sure that the antenna is pointing up, has a clear view

of the sky and is a reasonable distance away from your body.

Check satellite status screen to see where the satellites are and if

the receiver is acquiring data. If the receiver still does not get a

position fix within 10 minutes, you may wish to repeat the

initialization procedure.

Product:

Map330,

Map330M

Question:

Why does my GPS Receiver turn off unexpectedly?

Answer:

Excessive static electricity Is a common cause for this problem. Turn

the receiver back on and it should operate normally. Move the

receiver to a new location to avoid a similar occurrence.

Product:

Map330,

Map330M

Question:

Battery life seems shorter than it should be. What can I do?

Answer:

Make sure that you are using two AA alkaline batteries.Shorter life

span of the batteries can be due to excessive use of the backlight.

Turn the backlight off when not needed.

Product:

Map330,

Map330M

Question:

Why do the position coordinates on my receiver not match the

location on my

map.

Answer:

Make sure that your receiver is set up to use the same datum as

your map. The map datum is generally shown in the map legend.

2. Check your latitude/longitude format. Make sure that the format

selected in coordinate system (DEG/MIN/SEC or DEG/MIN.MM) is in

the same format as the map you are using.

Product:

Map330,

Map330M

Question:

Why is the position on a map not exactly the position on a road?

Answer:

This could be caused by distance shifts to the map. Use map data

for reference, but do not rely completely on it.

Product:

Map330,

Map330M

Question:

What is the temperature range in my MAP 330 and MAP 330M?

Answer:

Operating 14˚F to 140˚F to (-10˚C to 60˚C)

Storage -4˚F to 158˚F (-20˚C to 70˚C)

Product:

Map330,

Map330M

Question:

What is the function of the MapSend Street in my MAP 330??

Answer:

The MapSend Streets CD allows you to load detailed street maps

into your MAP 330. The maps supplied on the MapSend Streets CD

contain full street detail of US cities.

Product:

Map330,

Map330M

Question:

How do I check the trip odometer in my MAP 330 and MAP 330M?

Answer:

Press the nav button to get the position screen. At the bottom of the

page you can get the trip odometer.

Product:

Map330,

Map330M

Question:

What is the difference between MAP 330 and MAP 330M?

Answer:

MAP 330M has fixed nvaids which include buoys, lighthouses,

Marinas, and obstructions (wrecks, rocks, and so forth.). These

navaids can

be accessed through the database in the same manner that any

other waypoint or map object can be accessed using the database

function.

Product:

Map330,

Map330M

Question:

Where is GOTO route stored?

Answer:

GOTO routes are NOT saved in memory when the MAP 330 is

turned off. If you are navigating on a GOTO route and you need to

turn the MAP 330 off, you will need to restart the GOTO. Routes,

however, are stored in memory. If you need to make a GOTO but

expect to turn your MAP 330 off before arriving, you might consider

making a one-leg route using the route menu. More information on

routes can be found in the reference chapter of this manual.

Product:

Map330,

Map330M

Question:

How do I check the battery life of MAP 330 and MAP 330M?

Answer:

Press the nav button so that you can get the satellite status screen.

This is where you can check the battery life indicator.

Product:

Map330,

Map330M

Question:

How do I change the primary usage from land to marine?

Answer:

As a default, the MAP 330 is in the “land mode.” From the Map

screen press menu. Highlight map set up and press enter. Highlight

primary usage and press enter. Use up/down arrows to select

marine and press enter.

Product:

Map330,

Map330M

Question:

Can I purchase a hard copy of the user manual?

Answer:

No. However ,you can download the user manual at no charge

and print the pages that you need. Use this link to get the manual.

http://www.magellangps.com/support/product.asp?prodid=92

Product:

Map330,

Map330M

Question:

Can I use an external power source to MAP 330 and MAP 330M?

Answer:

Yes.

Dieses Handbuch passt für folgende Modelle

Andere Magellan GPS Handbücher

Magellan

Magellan Maestro 4200 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan RoadMate 9055-LM Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan Cyclo 500 Series Bedienungsanleitung

Magellan

Magellan RoadMate 2036 Bedienungsanleitung

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan RoadMate 3055 Bedienungsanleitung

Magellan

Magellan GPS Tracker Bedienungsanleitung

Magellan

Magellan Magellan GPS 310 Bedienungsanleitung

Magellan

Magellan SporTrak SporTrak Color Montage- und Bedienungsanleitung

Magellan

Magellan eXplorist XL Bedienungsanleitung

Magellan

Magellan Maestro 4220 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan Maestro 4040 - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 400 - Wilderness Bundle Bedienungsanleitung

Magellan

Magellan MobileMapper MobileMapper 6 Bedienungsanleitung

Magellan

Magellan RoadMate 1424-LM Bedienungsanleitung

Magellan

Magellan RoadMate 3000T - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan RoadMate 3000T - Automotive GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist 110 Bedienungsanleitung

Magellan

Magellan eXplorist 500 - Hiking GPS Receiver Bedienungsanleitung

Magellan

Magellan eXplorist TRX7 Bedienungsanleitung

Magellan

Magellan Maestro 3220 - Automotive GPS Receiver Konfigurationshandbuch

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung

Garmin

Garmin GPSMAP 78 series Bedienungsanleitung
