Magic Play CAPSULE BOXER Bedienungsanleitung

CAPSULE BOXER

Operation Manual (v1.0)

MAGIC PLAY SP Z O.O.

CHOCIMSKA 6, 62800 KALISZ, POLAND

Phone/Fax: +48 62 753 21 88. e-mail: service@magicplay.pl

website: www.magicplay.eu

Serial number:______________________________________________________

Distributor:_________________________________________________________

Date:______________________________________________________________

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

TABLE OF CONTENTS

1. PACKAGE CONTENTS

2. SPECIFICATIONS

3. SET UP & INSTALATION

3.1. DEVICE AND MOST IMPORTANT ELEMENTS

3.2. PLAY ZONE

3.2. TRANSPORTING THE GAME

3.4. CONNECTING THE POWER

4. UPDATE AND GAMEPLAY

4.1. SOFTWARE UPDATE

4.2. GAMEPLAY

5. SERVICE MENU

6. MAINTENANCE, INSPECTION

6.1. SAFETY CHECK

6.2. TROUBLESHOOTING

7. TERMS OF WARRANTY

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

Thank You for purchasing CAPSULE BOXER. We hope you enjoy the product. The manual contains valuable

information about how to operate and maintain your game machine properly and safetly. It is intended for

the owner and/ or personnel in charge of product operation. Carefully read and understand the

instructions.

If you need any help during instalation and setup please utilize this manual and troubleshooting guide. If

the product fails to function properly, non-technical personnel should under no circumstance sttempt to

service the machine. Contact your distributor or manufacturer for help.

READ BEFORE USE

INSPECT IMMEDIATELY AFTER TRANSPORTING THE PRODUCT

After receiving the shipment, inspect the product thoroughly to ensure that it has been shipped with care.

Before turning the power on, please check the following:

• Check the cabinet for damage or shifting that may have occurred during shipping. Are there any dented

portions or defects (cuts, etc.) on the external surfaces of the cabinet?

• Are all the legs and adjusters/levelers/feet intact?

• Do the power supply voltage and frequency requirements meet with those of the location (110V/220V)?

• Are all wires linked correctly and securely connected to each other? If coupled in an incorrect manner,

the connection will not be made accurately and it could cause not only irreparable damage to the machine,

but also is a potential fire hazard. DO NOT INSERT CONNECTORS FORCIBLY.

• Check that the all the cables, including power cables, are undamaged. Do power cables or other wires

have any splices, cuts, or dents?

• Have you been provided with all of the associated accessories?

• Can all doors/lids be opened with the accessory keys? Can doors/lids be firmly closed? Does the coin box

key open the coin box(es)?

1. PACKAGE CONTENTS

Open the package and make sure all the items are included:

•1 x Body Assembly

•Following accessories

No.

Name

Qty.

Note

Top cover

Top cover screws set

Set of four

Pump

Power cable

If any items are found missing, please contact your sales representative for help immediately.

NOTE: Part models are subject to change without notice.

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

IMPORTANT SAFETY INSTRUCTIONS

To ensure the safe usage of this product, carefully read and understand these

instructions before operating your game.

Save these instructions for future reference.

Use this product only as described in this manual. Other uses not recomended may cause fire,

electric shock or personal injury. Unplug the game from the outlet when not in use, when moving from one

location to another, and before cleaning/servicing.

Explanations witch require special attention are indicated by signs of warning. Depending on the potential

hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.

NOTE: A NOTE indicates useful hints or information about product usage.

NOTICE: A NOTICE inticades potential damage to product and how to avoid the problem.

WARNING: A WARNING indicates a potential for product damage or serious personal injury.

It is important to understand the meaning of the following HAZARD SIGNS befor contuning:

High Voltage and Shock Hazard:

High voltage can cause electric shock.

Turn off/unplug power before servicing.

High Temperature Hazard:

This part may cause scalding.

Do not touch. Surface may be hot.

Do Not Touch Hazard:

This may be hot or can cause electric shock.

Do not touch.

Use the following safety guidelines to help ensure your own personal safety and to help protect your

equipment and surrounding enviroment from potential damage.

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

THE PRODUCT IS A DEVICE FOR INDOOR AND OUTDOOR

USE. HOWEVER, AVOID DIRECT EXPOSURE OF THE

DEVICE DURING VERY UNFAVORABLE WEATHER

CONDITIONS, SUCH AS HEAVY RAIN OR STRONG WIND

Avoid installing in the following places to prevent fire, electric shock, injury and/ or

machine malfunctioning:

•Places subject to rain/ moisture, or places subject to high humidy.

•Places subject to direct sunlight, or places subject to extremely hot or cold temperatures to

ensure that it is used within the specified operating range.

•Places where inflammable gas may be present or in the vicinity of highly inflammable/

volatile chemicals or items that can easly catch fire

•On unstable or sloped surfaces. The machine may topple or cause unforeseen accidents.

•Vicinty of fire exist, fire extinguishers.

WARNING!

Non-technical personnel who do not have technical knowledge and experience

should refrain from performing such work that this manual require or perform

tasks which are not explained in this manual. Failing to comply can cause severe

accidents such as electric shock or other serious injuries.

WARNING: To reduce the risk of fire, electric shock or personal injury, unplug or

disconnect the machine from the power supply before servicing.

2. SPECIFICATIONS

Rated power supply: 110 - 240V

Dimensions (d x w x h): 137 x 73 x 217cm

Weight: 150Kg

NOTICE: After turning off the game, please wait at least 1 minute before restarting again.

Inspect Immediately after Transporting the Product After receiving the shipment, inspect the product

thoroughly to ensure that it has been shipped with care. Before turning the power on, please check the

following:

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

•Check the cabinet for damage or shifting that may have occurred during shipping. Are there any

dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?

•Are all the legs and adjusters/levelers/feet intact?

•Do the power supply voltage and frequency requirements meet with those of the location

(110V/220V)? Are all wires linked correctly and securely connected to each other? If coupled in an

incorrect manner, the connection will not be made accurately and it could cause not only

irreparable damage to the machine, but also is a potential fire hazard. DO NOT INSERT

CONNECTORS FORCIBLY.

•Check that the all the cables, including power cables, are undamaged. Do power cables or other

wires have any splices, cuts, or dents?

•Have you been provided with all of the associated accessories?

•Can all doors/lids be opened with the accessory keys? Can doors/lids be firmly closed? Does the

coin box key open the coin box(es)?

3. SETUP & INSTALLATION

•Refer to IMPORTANT SAFETY INSTRUCTIONS for places to avoid

•Place the unit on dry level surface

•Ventilation openings in the back of the unit must not be obstructed by objects or by wall.

IMPORTANT!

For the device to work properly, there must be capsules on the wheel. Before the

first run, use the LOAD PRIZES option (see subsection 5 of this manual - SERVICE

MENU - 4. PRIZE > 3. LOAD PRIZES)

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

3.1 DEVICE AND IMPORTANT ELEMENTS

1. START button

2. Punch-ball

3. Capsule carousel

4. Speakers

5. Display

6. Capsule pick-up

7. Coin acceptor

8. Capsule filling door

9. Service door

10. Coin-box acces

11. Power socket

3.2 PLAY ZONE

This machine requires space for playing and for maintenance as shown below.

Leave space around the game upon instalation:

Service area: 50cm

Play area: 100cm

3.3 TRANSPORTING THE GAME

NOTICE

•Be careful not to damage the machine durning transport.

•The machine should be handled with care when brining it down from a high level.

•Always unplug the game before moving.

•Keep the machine in upright position during transport.

•For longer distance transport, package the game properly to prevent damages

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

3.4 CONNECTING POWER

IMPORTANT!

POWER SUPPLY ADJUSTS AUTOMATICALLY

•Machines electrical system (power supplys and display) will adjusts automatically to 230V or 115V

voltage.

•Do not plug the equipment power cables into an electrical outlet if the power cable is damaged.

•Avoid putting many loads on one electrical outlet as it could generate heat the fire resulting from

overload.

Connect the grounding conductor to the earth terminal

(GND):

Ensure that nothing rests on the power cord and that it

is not located where it can be stepped on or tripped

over.

To disconnect the game, grip the plug and pul lit from

the wall outlet. Never pull by the cord.

To prevent electric shock, do not touch the power plug

when hand is wet.

4. UPDATE AND GAMEPLAY

IMPORTANT!

DEVICE SOFTWARE IS COPYRIGHT PROTECTED. COPYING AND DISTRIBUTION IS

STRICTLY PROHIBITED. IT IS ALSO FORBIDDEN TO INTERFERE IN THE INTEGRITY OF

SOFTWARE THROUGH MODIFICATION OR IMPLEMENTATION OF ANY CHANGES

WITHOUT APPROVAL OF THE MANUFACTURER. ANY ATTEMPTS OF SOFTWARE

CHANGES, OTHER THAN THOSE SPECIFIED BY THE MANUFACTURER MAY RESULT IN

WARRANTY LOSS.

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

4.1. SOFTWARE UPDATE

Software update steps:

1. Hold down SETUP buton on mainboard when powering up machine

2. Connect to WiFi called „Boxer”, password: MagicPlay

3. Open web browser and follow to 192.168.4.1 adress

4. Browse for update file and click Update

5. Wait for machine reboot byself

6. Done

4.2 GAMEPLAY

1. The player places a coin in the coin acceptor or a bill in the bill acceptor

2. Accepting the credit top-up is confirmed by a sound signal

3. The player presses the "START" button on the top front of the device

4. The release mechanism lowers the ball for hitting

5. The player hits the ball, which closes in the mechanism upon impact

6. The shot score countdown appears in the center of the display and an arrow appears at the top of the

display. The carousel with the capsules starts to rotate

7. The final result appears on the display and the carousel begins to slow down until it comes to a complete

stop

8. If the carousel stops with the arrow on the display pointing directly at the capsule, the player has won

the capsule

9. The mechanism will push the indicated capsule and it will fall down to the place where the player can

collect the prize

10. Free space after winning a capsule will be filled automatically

IMPORTANT!

REMEMBER THAT CHANGES IN THE SERVICE MENU CAN RELATE TO ELEMENTS SUCH AS

THE COST OF THE GAME AND THE NUMBER OF WON TICKETS, AND WHICH MAY

AFFECT THE EARNINGS OF THE DEVICE. MAKE SURE THAT THE CHANGES AND ENTERED

VALUES ARE VALID.

CAPSULE BOXER - USER’S MANUAL

www.magicplay.eu

5. SERVICE MENU

SERVICE MENU is available directly on the device (by pressing the button on the mainboard display) or

remotely (via the WEB SETUP service)

WEB SETUP ACCES

1. Hold down SETUP button on mainboard when machine is on

2. Connect to WiFi named „Boxer”, password: MagicPlay

3. Open web browser and follow to 192.168.4.1 address

4. Use the website links to change any desired data

MAIN MENU

1. DEVICE

1. DISP BRIGHT

0-100%

Set display brightness

2. SOUND VOLUME

0-100%

Set game volume

3. SND DEMO VOLUME

0-100%

Set demo volume

4. SND DEMO

INTERVAL

0-60 minutes Set demo frequency (0=infinity music loop)

5. WHEEL DEMO

0-60 minutes

Set wheel spin in demo frequency

6. LCD COUNTERS

ON/OFF

Show electronic counters on LCD

7. SOFT VERSION

Shows software version

8. SERIAL NUMBER

Shows mainboard serial number

9. BALL TIME

50-500 milisec / DEF: 150

Punch ball realease time

10. BALL PULSES

1-3 pulse / DEF: 1

Number of release pulses on each punch ball drop attempt

2. GAME

1. DIFF

0-100%

Set difficulty (higher values need stronger punch for better scores)

2. RECORD

Current record

3. RECORD DEF

0-1000

Set default record

4. REC DEF TIME

0-600 min

When reset record, 0 = OFF

5. GAME TYPE

777 TYPE / RANDOM

Select game type to win prize

3. CREDIT

1. FREE GAME

ON / OFF

Play FREE game, no credits needed

2. GAME PRICE

1-20

How many credits value needed to play 1 game

3. COIN CH1 VALUE

1-50

Value of CH1 coin acceptor

4. COIN CH2 VALUE

1-50

Value of CH2 coin acceptor

5. COIN CH3 VALUE

1-50

Value of CH3 coin acceptor

6. COIN CH4 VALUE

1-50

Value of CH4 coin acceptor

7. COIN CH5 VALUE

1-50

Value of CH5 coin acceptor

8. COIN CH6 VALUE

1-50

Value of CH6 coin acceptor

9. BILL VALUE

1-200

Value of PULSE bill acceptor & for counters

10 .BONUS CRED

OFF (0) - 10

Bonus means number of credits required to be inserted in a row for

an extra credit

11. CLEAR CRED

Clears current game credits

4. PRIZE

1. PRIZE WIN

0-100%

Prize payout per 100 games (5% gives 5 prizes for 100 games)

2. CRED FOR REC

0-10 Credit

Bonus credits for RECORD

3. LOAD PRIZES

Automatically refill all prizes one by one

5.COUNTERS

1. CLR MONEY

Resetable money counter

2. MONEY

Money counter

3. FREE GAMES

Free games counter

4. PRIZES

Total prizes given

5. HITS

Total hits

6. RECORDS

Total records

Total tickets given

6. STATS

AVE SCORE

Show average score (right arrow to reset)

AVE RECORDS

Show average record (right arrow to reset)

AVE PRIZE

Show average prize win (right arrow to reset)

7. TESTS

1. PUNCH

Punch test

2. WHEEL

Wheel spin test

3. PROPELLER

Prize propeller test

4. MIXER

Prize mixer test

5. DISPLAY

Front display test

6. COINS INP

Coins input test (insert coin)

7. BANK INP

Bills input test (insert bill)

8. ALL INPUTS

Shows all inputs - trigger sensor manually to see data

9. ALL OUTPUTS

Test all outputs devices

8. FACTORY SETTINGS

Reset to factory settings

Inhaltsverzeichnis

Andere Magic Play Arcade-Spielautomat Handbücher

Magic Play

Magic Play Zombie War Water Shooting Game Bedienungsanleitung

Magic Play

Magic Play Ninja Challenge Bedienungsanleitung

Magic Play

Magic Play LuckyNumbers Bedienungsanleitung

Magic Play

Magic Play ALL STAR BASKETBALL Bedienungsanleitung

Magic Play

Magic Play SWEET SPINNER Bedienungsanleitung

Magic Play

Magic Play WATER SHOOTER Bedienungsanleitung

Magic Play

Magic Play TIMBERMAN HERO Bedienungsanleitung

Beliebte Arcade-Spielautomat Handbücher anderer Marken

Universal Space

Universal Space COCONUT BASH Bedienungsanleitung

Bay-Tek

Bay-Tek EVOLVE Bedienungsanleitung

Global VR

Global VR America's Army Montage- und Bedienungsanleitung

Atronic

Atronic Cashline Bedienungsanleitung

Universal Space

Universal Space Checky Monkey Bedienungsanleitung

Bay-Tek

Bay-Tek Skee Ball 1908 Alley Bedienungsanleitung

Aristocrat Technologies

Aristocrat Technologies Mars X Upright Bedienungsanleitung

Family Fun Companies

Family Fun Companies Reactor Kurzanleitung

Universal Space

Universal Space FRUIT MANIA Extreme Bedienungsanleitung

falgas

falgas CARRUSEL FIESTA Bedienungsanleitung

Konami

Konami DanceDanceRevolution Bedienungsanleitung

Bay-Tek

Bay-Tek quik drop Bedienungsanleitung

Bandai Namco

Bandai Namco PAC-MAN BATTLE ROYALE CHOMPIONSHIP DELUXE Bedienungsanleitung

Adrenaline

Adrenaline Flying Tickets Montage- und Bedienungsanleitung

Swinks

Swinks Stern Pinball Ghostbusters Bedienungsanleitung

Innovative Concepts in Entertainment

Innovative Concepts in Entertainment MONOPOLY ROLL-N-GO Bedienungsanleitung

jakar

jakar SPEED CARS Bedienungsanleitung

Carmelli

Carmelli HAT TRICK NG1015H Bedienungsanleitung
