Mainnav MG-950d Bedienungsanleitung

MG-950d Sport GPS data logger

Table of content

A. Quick Use ---------------------------------------------------------------------------- 2-4

B. Introduction ---------------------------------------------------------------------------- 5

C. Feature ---------------------------------------------------------------------------------- 5

D. Specification -------------------------------------------------------------------------- 5

Physical Dimension------------------------------------------------------------------------ 5

Environmental Characteristics---------------------------------------------------------- 6

GPS-------------------------------------------------------------------------------------------- 6

LED Status ---------------------------------------------------------------------------------- 6

Bluetooth ------------------------------------------------------------------------------------ 6

Position accuracy -------------------------------------------------------------------------- 6

Interfaces------------------------------------------------------------------------------------- 7

Connector------------------------------------------------------------------------------------ 7

Battery---------------------------------------------------------------------------------------- 7

Accessory ----------------------------------------------------------------------------------- 7

Certification: -------------------------------------------------------------------------------- 7

Warranty ------------------------------------------------------------------------------------- 7

E. Operational characteristics-------------------------------------------------------- 7

F. Safety Statement----------------------------------------------------------------------- 8

G Earth Datums &output setting ---------------------------------------------------- 9-11

H . Bike mounting installs ------------------------------------------------------------- 12

A.Quick use

1.Standard package

GPS Unit +Car charger + travel charger + Li-ion Rechargeable Battery + Document CD +

Warranty Card

2.10 hours full charge is required before using (recommendation)

Fully charge the battery for at least 10 hours before using can last for 8 hours continuously

operation facilitating the low power consumption design at 66 mA .

3.Turn on the Bluetooth function in your PDA or PC

Start up MG-950d receiver for pairing before set off Bluetooth function in PDAor PC.

Moreover, check the device is equipped with Bluetooth function.

If not, you may need to acquire an optional CF or SD Bluetooth card.

4.Found a shortcut automatically in Bluetooth Manager window

The system will automatically set up quick connect device, Mainnav in Bluetooth Manager.

Further step, click the device to connect Bluetooth receiver.

5.Check the Serial Port in Bluetooth Setting and Set up correct Serial Port in your

map software

Click Serial Port to confirm the COM port after pairing with the receiver. Using PDA / PC to

pair the receiver. Start your map function and choose the right serial port and select

“Outbound COM port “. The pass word for paring is “0000”.

6.Switch off the Bluetooth function

Switch off the Bluetooth function before you turn off your PDA/PC, and Switch off receiver

disconnect the GPS function.

7. GPS data logger

Turn on the MG-950d and press Power button then enter data logger recorded system, start

to record your journey. Stop the data logger function, press “Power” button, it will turn off.

Check the GPS data—Using USB cable connect MG-950d to your PC (please install

Mainnav software application), then you could view recorded data on Google Maps. For

detail instruction , please check CD file ( software instruction)

8. LCD display

Speed/Elevation Speed/time Speed/total mileage Speed/moved time

Speed/moved distance Speed/average Speed Speed/ Maximum speed Data turns Zero

(time except)

GPS signal Bluetooth on Data logger on Memory full backlight on Power

9.Button intro

Power

Back- lighted

Touch pad—move to next page

10. Function switch

Operation display Definition

Press Power button 3 seconds Stay on –GPS and Bluetooth is on

When Power on , press power

button 2 seconds Data logger is on

Press back-lighted button 3

seconds Back-lighted is on

Press back-lighted button 5

seconds

Data turns Zero

Press back-lighted button 12

seconds

Total mileage turns Zero(ODO)

Power on—press two buttons

together

switch to metric and imperial(mph)/(kph)

Power off , press two buttons

together

Adjust time Zone

Touch pad Touch --Move to next page and show different data

Press this button 3 seconds

It will move to next page automatically

When unit is on, press power and back-lighted button together (3 sec) ----you could

switch to metric and imperial.

When unit is off, press two buttons together (3 seconds) ---- you could set the right

time zone.

Press Back-lighted button 5 seconds ----data back to zero.

Touch pad --- move to next page

Press touch pad 3 seconds—it will move to next page automatically

B. Introduction

MG-950d is marvelous Sport GPS with data logger. The chip designed based on SiRF Star

III LP which provides the high sensitivity for personal navigation and the wireless Bluetooth

transmission in the world.

This new gadget with LCD monitor is ideal for biking, driving and long journey. User could

easy to view the screen while workout such as total mileage/kilometer, moved time,

elevation and speed. This new device is compact and easy to carry.

MG-950d is a small, robust unit that records NMEA position data from a GPS. It is really

convenient, economical alternative to using a laptop computer especially on long road.

Simply connect the logger to a GPS during your trip then download the track data to a PC.

Also, our photo map part is one of brilliant function, User could match photo in certain

waypoint by their own which show on Google earth.

C. Feature

Store up to 130,000 waypoints

LCD display and Touch pad

Automatically change to next page

Absolutely bike meter upgrading

SiRF Star III Hot start 6 sec, warm start 38sec, cold start 42 sec

Calculates precise speed and distance while you biking

Record track-logs of vehicle movement

User can select among Google earth, Satellite or Hybrid to show the track

Built-in GPS application software, could save as KMZ, CSV, GPX and NMEA

Integrated Photo with Mainnav Software

Transmission data via USB and Bluetooth

Weather Proof IPX6

Bluetooth—pair PDA or smart phone for navigation.

Replay the recorded routes/ time/ speed... point by point

Lightweight and compact --suitable for biking, hiking and traveling.

D. Specification

PhysicalDimension

Size: 73(L)X49(W)x21 (H) (mm)

LCM: 33(mm)X 33(mm)

Weight:70g

Environmental Characteristics

1. Working temperature: -20oC to +75oC (internal temperature).

2. storage temperature: -55oC to +90oC.

3. input voltage: 5.5 ± 0.5VDC

4. Backup power: 3.7V Rechargeable Li-ion Battery 700mAh,

GPS

1) Acquisition:20 channel parallel

2) Tracking: up to 12 satellites

3) Update rate: 1 second

4) Acquisition time

Reacquisition 0.1 sec, averaged

Snap start 3 sec, averaged

Hot start 6 sec, averaged

Warm start 38 sec, averaged

Cold start 42 sec, averaged

Bluetooth

1) Transmits up to 10 meters.

2) Version V2.0

Position accuracy:

1.Non DGPS (Differential GPS)

Position: <10 M at 2D RMS

Velocity :0.1 meters/second, with SA off

Time:1 microsecond synchronized GPS time

2. DGPS (Differential GPS) or WAAS / EGNOS ON (Built by demand)

Position: 1 ~ 5 meter, typical

Velocity: 0.05 meters/second, typical

3. Dynamic Conditions:

Altitude: 18,000 meters (60,000 feet) max

Velocity: 515 meters / second (1000 knots) max

Jerk: 20 meters/second, max

Acceleration: 4 G, max

Interfaces

1) USB 2.0 Bluetooth 2.0

2) NMEA 0183 Version 2.2 ASCII output (GPGGA, GPGLL, GPGSA, GPGSV, GPRMC,

GPVTG).

3) Real-time Differential Correction input (RTCM SC-104 message types 1, 5 and 9).

(Optional model)

SiRF protocol. (optional)

Connector

Battery recharging connector: Mini USB

Battery

Capacity: 700mAh.

Type: Li-ion rechargeable

Normal use: 17.5 hours

Accessory

1. Rechargeable battery, 700mAh

2. Car charger: Mini USB , IP:10~30V, OP:5V 500mA

3. CD

4. bike mounting

5. USB cable

6. warranty card

7.Travel charger

Certification:

RoHs

CE&FCC

Warranty

All of our GPS products have the one-year warranty and repair policy from the day of

purchase.

The MG-950d is warranted to be free from defects in material and function for one year from

the date of purchase. Any fault product within this period under normal conditions will be

replaced without any charge.

E. Operational characteristics

Initialization

Once the initial self-test is complete, MG-950d start the process of satellite acquisition and

tracking automatically. MG-950D takes about 45 seconds to achieve a position fix in normal

circumstances. After a position fix has been calculated, valid position, velocity and time is

transmitted over the output channel.

Also, our MG-950d records NMEA position data from a GPS. It is really convenient,

economical alternative to using a laptop computer, especially on long road. Simply connect

the logger to a GPS during your trip then download the track data to a PC.

Data logger

1. LCD screen which shows speed altitude/latitude

2. Reads NMEA data from GPS

3. Compact size and lightweight

4. Store up to 130,000 waypoints

5. User friendly Windows based Mainnav software

6. Whether proof IPX6

7. With user friendly Windows based Google earth software

8. Replay the recorded routes/ time/ speed... point by point

Navigation

With the acquisition process is completed, the MG-950d sends valid navigation information

over output channels. The data include:

1) Velocity

2) Error estimates

3) Date/time

4) Latitude/longitude/altitude

5) Satellite and receiver status F. Safety Statement

R&TTE / CE

This device complies with ETSI EN 300 328-1, ETSI EN 301 489-1 / 17, EN60950.

FCC

This device complies with Part 15C, Part 15B and ID Application of the FCC rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

BQB

G. Earth Datums &output setting

NMEA Transmitted Messages Output Messages NMEA Sentence

GPGGA: Global positioning system fixed data

GPGLL: Geographic position latitude \ longitude

GPGSA: GNSS DOP and active satellites

GPGSV: GNSS satellites in view.

GPRMC: Recommended minimum specific GNSS data

GPVTG: Course over ground and ground speed

Global Positioning System Fix Data

$GPGGA,161229.487,3723.2475,N,12158.3416,W,1,07,1.0,9.0,M, , ,0000*18

Name Example Units Description

Message ID $GPGGA GGA protocol header

UTC Time 161229.487 Hhmmss.sss

Latitude 3723.2475

ddmm.mmmm

N/S Indicator N N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

Position Fix

Indicator 1 See Table 5-3

Satellites Used 07 Range 0 to 12

HDOP 1.0 Horizontal Dilution of Precision

MSLAltitude 9.0 Meters

Units M Meters

GeoidSeparation Meters

Units M Meters

ge of Diff. Corr. second Null fields when DGPS is not used

Diff.Ref.StationID 0000

Checksum *18

Andere Handbücher für MG-950d

Inhaltsverzeichnis

Andere mainnav GPS Handbücher

mainnav

mainnav MG-950d Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

Magellan

Magellan eXplorist 100 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung
