Majority Girton
DAB / DAB+ / FM Radio
CB23A-DAB-WDN
User Guide
Contents
Controls and Functions.............................. 1
What’s in the Box? .................................. 3
Instruction Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic Operation...........................................4
DAB Radio and Set up Preset for DAB Radio................5
FM Radio and Set up Preset for FM Radio ..................7
Station Information for DAB and FM Radio ................10
Clock and Date Setting...................................12
Dual Alarm Setting ......................................14
Other Functions ...................................16
Technical Specification .............................19
Warranty ..........................................19
Important Safety Information ......................20
Watch video tutorials and register
your product for a FREE 3-year
warranty at www.majorityradios.co.uk
3
Y
E
A
R
F
R
E
E
E
X
T
E
N
D
E
D
W
A
R
R
A
N
T
Y
Instructions GuideControls and Functions
1
1. Preset 1/6
2. Preset 2/7
3. Tune/Snooze/
Enter
4. Preset 3/8
5. Preset 4/9
6. Info/Menu
7. Shift
8. Scan
9. Preset 5/10
10. Power/Mode
11. Volume –
Down/+Up
12. Alarm/Sleep
1
2
3
4
5
6
7
9
8
10
11
12
13 15
16
14
Instructions Guide
Controls and Functions
2
13. Battery
Compartment
14. Earphone jack
15. DC 5V
16. Antenna
1
2
3
4
5
6
7
9
8
10
11
12
13 15
16
14
Instructions Guide
What’s in the Box?
3
●Majority Girton DAB/DAB+/FM Radio
●UK Standard Plug DC 5v Power Supply
●User Guide
Majority Girton
DAB/FM Radio
CB23A-DAB-WDN
User Guide
Instructions Guide
4
Please note all (Ref.) refer to the Controls and Functions
mapping guide on Pages 1-2.
Basic Operation
For mains power, insert the power supply connector into the
power input socket labelled DC 5V (Ref.15) on the back of the
system and plug the power supply into the mains. See page 18
for battery powered information.
Ensure the Antenna (Ref.16) is extended as far as possible so
that you can rotate it, enabling you to get the best signal that
you can.
Press the ‘Power/Mode’ button (Ref.10) to turn on the unit.
The system will show “Welcome to Digital Radio” on first use.
To change the mode, press the‘Power/Mode’ button (Ref.10) to
switch between DAB Radio and FM Radio.
Standby or Off
To place the system in standby mode or to switch it off, press
and hold the ‘Power/Mode’ button (Ref.10). The display will
show “Standby or Power Off”. Turn the ‘Tune/Select/Enter’ dial
(Ref.3) to select your choice. Press the ‘Tune/Select/Enter’ dial
(Ref.3) to confirm your choice. To turn off completely, switch off
at the mains. The cord must be out of reach of children.
Instructions Guide
Instructions Guide
5
DAB / DAB+ Radio
Press the ‘Power/Mode’ button (Ref.10) to switch to DAB Radio.
On first use it will automatically scan all stations and save them.
Fully extend the antenna (Ref.16).
To auto scan, press the ‘Scan’ button (Ref.8) and then release.
This will start scanning up the frequency band and store all
stations that have a good signal.
After searching has finished it will automatically play the first
station stored.
Turn the ‘Tune/Select/Enter’ dial (Ref.3) to scroll through all
stations that have been stored, and press the‘Tune/Select/Enter’
dial (Ref.3) to listen to the selected station.
The radio will display station information when you press the
‘Info’ button (Ref.6). Press it multiple times for different
information. See page 10 for further details.
When you power up the radio again after switching off, it will
automatically tune to the same station (DAB or FM) that was last
selected. If there is no signal,“No DAB station” will be displayed.
IMPORTANT: Please make sure you have
extended the antenna (Ref.16) to its full
length. This will then enable you to rotate it
to get the best signal.
6
Instructions Guide
How to store a preset radio station
Up to 10 preset stations can be set. To store a station that you
are currently playing:
Press and hold one of the 'Preset' buttons (Ref.1, 2, 4, 5 or 9) on
the front of your radio for 3 seconds. Press the button that
matches the number (1-5) you would like to save the station to.
The display will show “Preset In (x) stored” Press the ‘Tune/
Snooze/Enter’ dial (Ref.3) to confirm. “Preset (1) Stored” will
show on the display.
To store presets 6 to 10 press the ‘Shift’ button (Ref.7).
Press and hold the 'Preset' button on the front of your radio
that you would like to store the station to (6-10) for 3 seconds.
The display will show “Preset In (x) stored”.
NOTE: If there is already an existing DAB station stored under a
preset it will be over-written when you store the new station.
How to play a preset radio station
For presets 1-5, press the preset button of your choice and
“Preset Out (x)”will be displayed. Press the ‘Tune/Snooze/Enter’
dial (Ref.3) to confirm your choice.
For presets 6-10 press the ‘Shift’ button first, then press the
preset button of your choice and “Preset Out (x)” will be
displayed Press the‘Tune/Snooze/Enter’ dial (Ref.3) to confirm
your choice.
7
Instructions Guide
FM Radio
Press the ‘Power/Mode’ button (Ref.10) to switch to FM.
The first time you do this, FM frequency “87.5 MHz” will be
displayed on the screen.
Fully extend the antenna (Ref.16).
To auto-scan, press the ‘Scan’ button (Ref.8). The unit will then
start scanning up the frequency band and play the first station
it finds with a good signal.
To scan down the frequency band press and hold the ‘Scan’
button (Ref.8) for a few seconds.
The radio will display station information when you press
the ‘Info’ button (Ref.3) multiple times. Please see page 11 for
further details.
How to tune a specific frequency manually
To listen to a specific frequency, turn the ‘Tune/Snooze/Enter’
dial (Ref.3) until you are tuned in to the required frequency.
IMPORTANT: Please make sure you have
extended the antenna (Ref.16) to its full
length. This will then enable you to rotate it
to get the best signal.
8
Instructions Guide
Mono and Stereo
To change between Mono and Stereo, press the ‘Tune/Snooze/
Enter’ dial (Ref.3).
How to store a preset radio station
Up to 10 preset stations can be set. To store a station that you
are currently playing:
Press and hold one of the 'Preset' buttons (Ref.1, 2, 4, 5 or 9) on
the front of your radio for 3 seconds. Press the button that
matches the number (1-5) you would like to save the station to.
The display will show ‘Preset In (x) stored’, then press the ‘Tune/
Snooze/Enter’ dial (Ref.3) to confirm. ‘Preset 1 stored’ will show
on the display.
To store presets 6 to 10 press the ‘Shift’ button (Ref.7).
Press and hold the preset button on the front of your radio that
you would like to store the station to (6-10) for 3 seconds.
The display will show ‘Preset In (x) stored’.
NOTE: If there is already an existing FM station stored under a
preset it will be over written when you store the new station.
