Volt Current Frequency Continuous rating input

100V 5.5 A 50-60 Hz 520 W

Abrasive paper size 114 x 280 mm

Pad size 114 x 234 mm

No load speed (R.P.M.) 10000 rpm

Overall length 268 x 132 x 160 mm

Net weight 2.8 kg

Power supply cord 2.5 m

Abrasive paper --- #60, #100, #120, #150, #180 two pieces for each

Parts no Names Applications

7425019 Abrasive paper 114-60 For wood #60, 10 pieces contained

7425027 Abrasive paper 114-100 For wood #100, 10 pieces contained

7425035 Abrasive paper 114-120 For wood #120, 10 pieces contained

7425043 Abrasive paper 114-150 For wood #150, 10 pieces contained

7425051 Abrasive paper 114-180 For wood #180, 10 pieces contained

The standard equipment for the tools shown may differ form country to country

CONCEPT AND MAIN APPLICATIONS

The model 9045N has been developed as the new

model of the current type of 9045. Unlike the

conventional type, the dust collecting unit is

installed and the machine vibration has been

minimized to extremely improve the working efficiency.

Appearace layout

Models No.

Description

New Tool

TECHNICAL INFORMATION

9045N

MAKITA Finishing sander

Specifications

Standard equipment

Optional accessories

(1) Disassembling

(a) Remove the steel band(for holding the rubber sleeve)mounted on the base from between the base and the frame.

(b) Remove the push buttons(2 pieces at back/forth) protruded above the top of frame.

(c) Remove the bearing retainer at center on the base. To disconnect it, place the minus screw driver on the cracked

point on the bearing retainer and turn the bearing retainer in left.

(d) Remove the pan head screw M5x12 holding the balance weight on the bearing #6003ZZ. At this time insert the

minus screw driver into the rubber sleeve to protect the balance weight from turning for easy disconnection.

Repair

(2) Cautions in assembling

(a) Slightly grease the Grease(Albania No.2)on the needle bearing housed in the frame.

(b) When assembling the base, assemble it so that the face at base side can be parallel to the face at the frame side.

(e) Next disconnect the base. If hard to disconnect it due to the base tightly connected, insert the screw driver

between the frame and the base and disconnect while slightly twisting the driver.
