Malatech NEPHRITE 4G Bedienungsanleitung

MANUFACTURER/IMPORTER:

MALATECH WATER, LTD.

1/E Vanyi way, Alsonemedi, 2351

Hungary

+36 30 377 8089

info@malatechsolar.com

USER MANUAL

4G SOLAR SECURITY SMART CAMERA

NEPHRITE 4G

Operation system: Linux

Online visitor number: Support 4 visitors at the same time

Application: O-KAM

Processor: Ingenic T31 ZL /T31 ZX

Memory: 512 Mb

Image sensor: GC2063,1/2.9 inch Progressive Scan CMOS 3MP

Minimum night-time illumination: 0.8 Lux/F1.4 (Color mode) ,0.3Lux/F1.4 (B&W

mode)

Lens: 3.6 mm F1.6 Starlight Lens 5-20 m

PTZ (remotely rotatable camera head): Horizontal 355°, vertical 90°

Lens/View angle: D110° diagonal

Night vision mode: Full-color night vision + IR, dual light source

Video encode format: H.265 /H.264 /MJPEF/JPEG

Video stream: 3K (2304*1296P/15fps)

Video bit rate: 128~4096kbps

Image adjustment: Brightness and contrast can be adjusted

Audio input: Built-in -38 dB microphone

Audio output: (8Ω1.84W/4Ω3W)

Audio sampling frequency / width: 8KHz/16bit

Audio compression standard: G711A

Humanoid detection: Humanoid detection with invalid video content

ltering

Area detection: Available

Smart notication sound: Dierent push notication alarm sounds can

be set up for dierent devices

NEPHRITE 4G

Smart alarm sound: Dierent device-alarm sounds can be set up for

dierent devices

Sleep mode:

Default is sleep mode, camera wakes up when

motion sensor is triggered or it can be waken

up by the app

Smart sleep mode: Optional: when battery charge drops below

30% the camera goes to sleep mode

Deep sleep mode: Optional: only motion detection wakes up the

device, it cannot be activated from the app

4G (EU): WCDMA:B1/B8 FDD:B1/B3/B7/B8/B20/B28A

TDD:B38/B40/B41

TF card: TF push-push socket, maximum 256GB

supported

Cloud storage: Paid service, free cloud storage of 3-day cycle

(alarm recording)

Alarm detection: By PIR motion detection with human body

ltering

Alarm action: Alarm recording and push notication through

the App

Rated voltage: DC 5V ± 5%

Battery: 18000mAh, 3.7V (66 Wh) Li-ion battery

Charge: Solar panel or DC 5V (USB)

Solar Panel: 5W/5V monocrystalline silicon

Power consumption: Stand-by current: 500uA (ultra-low power

consumption 60uA), Working current: 250mA

Working conditions: -10 - +50°C, humidity <90%

Weight: 1.235 kg

Product box length: 216 mm

Product box width: 205 mm

Product box height: 134 mm

NEPHRITE 4G

LIGHT STRUCTURE, CONTENT OF THE BOX

ATTENTION! IF YOU INTEND TO CHANGE YOUR SMARTPHONE OR

TABLET, PLEASE DO NOT FORGET TO REMOVE YOUR CAMERA(S) FROM

THE APPLICATION ON YOUR OLD DEVICE/ PLEASE READ THIS MANUAL

CAREFULLY, YOU FIND DETAILED DESCRIPTION ABOUT HOW TO REMOVE

YOUR DEVICES FROM THE APP BELOW!

ATTENTION! The life span of the battery depends on you as well! Please

use the camera correctly as described in this manual. If you intend to use

the solar panel eciently for recharging the battery, install the camera

in a sunny place where sucient sunlight is provided for charging the

battery every day. Adjust the solar panel’s vertical angle correctly (ideal

is app. 45 degrees), horizontally it should face towards the midday sun.

Please pay attention to place your camera in a non-shaded place with

sucient sunshine provided for the solar panel operating eciently.

If you prefer to charge the camera battery by grid power with the USB

cable, please care about charging your camera when the battery level

runs low.

If you intend to turn o your camera, and you do not want to use it for a

while, please make sure that the battery has sucient charge, and it is

not totally discharged. If you would like to store the camera instead of

using it, please turn o the camera with the ON/OFF button. In case of

a longer storage, please turn on the camera once every month, and full-

charge the battery. It may decrease the life span of the battery if the

camera is stored for a longer period with a totally discharged battery,

moreover it can damage the battery!

ATTENTION! The camera has infrared motion sensor. Infrared motion

sensors are pretty much sensitive to direct sunlight! In case of outdoor

applications, when you choose the location of your camera, and there

are no roofs or any objects above the camera providing a shade, we

recommend you TO AVOID FACING THE CAMERA HEAD TOWARDS THE

SUN! Facing the camera towards the sun does not aect the operation of

the camera in any ways, but it may increase the number of false alarms!

NEPHRITE 4G

USB port DC 5V

LIGHT STRUCTURE, CONTENT OF THE BOX

CONTENT OF THE BOX:

1. Nephrite 4G camera - 1 pc

2. Solar panel - 1 pc

3. Solar panel console - 1 pc

4. USB cable - 1 pc

5. Screws and anchors - 1 package

CAMERA STRUCTURE:

PIR sensor

HD lens

Indicator light

TF card slot

SIM card slot

ON/OFF button

Reset button

Speaker

NEPHRITE 4G

FIRST USE - START-UP THE CAMERA

INDICATOR LIGHT COLOR CODES:

Reset: green and blue light ash simultaneously

Charging: red indicator light shines continuously, and goes o when

battery is full-charged

No network connection: blue light ashes slowly

Healthy operation: blue light shines continuously

Sleep mode: all lights are o

BASIC FUNCTIONS:

Once you turn on the device for the rst time, the blue light ashes slowly.

Reset: by pressing, and holding the Reset button for 3 seconds, the blue

and green indicator lights are ashing simultaneously during the process.

Once the factory settings are restored, and the camera restarted, the blue

light ashes slowly.

Turning o the camera: by pressing and holding the ON/OFF button the

device shuts down, and all indicator lights turn o.

CHARGING THE BATTERY FOR THE FIRST TIME:

Before starting-up your camera, please full-charge the battery with the

USB DC-5V cable by grid power. Depending on the charge level of the

battery, the full-charge may take 5-10 hours.

NEPHRITE 4G

APP SETTINGS

DOWNLOADING THE APPLICATION:

Please scan the QR code with your cell phone,

and download O-K AM app, or search for the

O-KAM app in App Store or Google Play, and

download it to your cell phone.

REGISTRATION IN THE APP:

1. Tap “Register now” in the login page, then

choose your geographic location, and provide your e-mail address

where you would like the app to send the verication code to.

2. After entering the verication code, please provide your password,

and tap “Finish”.

NEPHRITE 4G

APP SETTINGS

ADD A DEVICE:

1. Tap “+Add” or the “+” icon in the top right corner of the screen.

2. At the QR code scanning page tap the “4G camera” option.

3. Insert a FAT32 formatted micro TF card correctly in the port. (Care!

The TF card is not the part of the package! The device supports TF

cards up to 256 GB!)

4. Insert the SIM card into the SIM card slot, and tap “Next”. The SIM

card is not the part of the package.

5. Tap “Hear a beep or see a steady light” then tap “Next”.

6. Hold the screen of your cell phone at a 10-20 cm distance from the

lens of the camera to let the camera scan the QR code. Do not shake

or move the camera or the phone during the scanning process. The

camera releases a sound if pairing is successful.

7. Tap “Bind now”.

NEPHRITE 4G

APP SETTINGS

IF ANY ERROR OCCURS DURING THE PAIRING PROCESS:

1. Please check whether the SIM card is inserted properly in its slot.

2. Please check with your provider whether the SIM card is active, and

recharged.

3. Please apply a reset on the device, and try the pairing

process again.

4. Please try a SIM card of another provider.

FUNCTIONS OF THE APP

1. Functions of Home screen

Adjust the size of the screen

Add device

Battery charge display

“Do not disturb” mode

TF card

4G recharge

Cloud service

System settings
