Manhattan 432351 Bedienungsanleitung

LCD WaLL Mount

QuICK InStaLL GuIDE

Model 432351

MH-432351-miniQIG-1009-02

Thank you for purchasing this MANHATTAN®LCD

Wall Mount, Model 432351.

Fully adjustable tilt, rotate, side-to-side and tension

settings allow a single LCD display to be reliably

secured and positioned for a comfortable viewing

position.

Instructions are on the back of this sheet.

MANHATTAN®offers a complete line of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information or visit us online at

www.manhattan-products.com

All products mentioned are trademarks or registered trademarks of their respective owners.

GENERAL

• Fits 75 x 75 mm / 100 x 100 mm

VESA-compliant monitors up to 22”

• Monitor weight capacity: up to 12 kg

(26 lbs.)

• Installs approximately 12.5 cm (5 in.)

from most vertical surfaces

DIMENSIONS

• Bracket dimensions: 8 x 6.5 cm

(3.15 x 2.5 in.)

• Arm length: 12.5 cm (5 in.)

• Weight: 0.7 kg (1.5 lbs.)

PACKAGE CONTENTS

• LCD Wall Mount

• Installation hardware with instructions

SPECIFICATIONS

•Optimizes monitor view with tilt,

rotate, side-to-side and tension

adjustments

•Two-piece bracket with heavy-duty, steel construction

easily mounts to most vertical surfaces

• Meets VESA standards — ts monitors up to 22” and up to

26 pounds

•Lifetime Warranty

ASSEMBLY INSTRUCTIONS

Bracket-

mounting

anchors

and screws

(2 ea.)

Open-end

wrench

Mini-level

Display-

mounting

screws (4)

4. Slide the wall mount with monitor attached into the bracket

already secured to the vertical surface, then tighten the

wall bracket knob (it should align with the center hole).

Always handle the LCD monitor with care during assembly

of this LCD Wall Mount. Disconnect any cords or cables

that could otherwise interfere with the placement of any

of the components, and make sure that any screws and

bolts are properly tightened to prevent possible damage to

the monitor or nearby items. After assembly, periodically

check the ttings to ensure no slippage or loosening has

occured that could result in monitor damage.

5. Position the monitor to suit your viewing preferences,

then tighten the joints (remove the snap-on covers to

access the bolt heads as shown).

Wall mount

with bracket

1. Check that the package contains the components shown here.

2. Using the mini-level

as shown, position

the wall bracket

against the vertical

mounting surface

and mark the

positions of the two

bracket holes.

Punch or drill pilot/

starter holes, if/as

needed, then use

either the 2 bracket-

mounting anchors or

screws included in this

package to secure the bracket

to the vertical surface.

3. Making sure

the wall mount

is right-side up

(to t into the

wall bracket),

align the holes

in the display

bracket with

those on the

LCD monitor

and secure

the monitor

to the bracket

using the four

display-

mounting

screws.
