Instructions Manual EN 1298 – IM – it x en

Mobile access towers must only be used for nishing, maintenance and similar works. This instructions

manual contains important instructions on use, maintenance and safety of the mobile access tower;

the operator must be completely aware of them before use. Strictly complying with this manual

means working in compliance with the provisions of the current standard on health and safety in the

workplace Leg. Decree. 09.04.2008 no. 81.

Code 10731

CUSTOMER ASSISTANCE DOCUMENT

NR. 35 REV. 8 OF 27/08/2020

MARCHETTI S.r.l.

Via Piemonte, 22

06062 Città della Pieve - Perugia - Italy

info@marchetti.eu

www.marchetti.eu

Instructions for use

and maintenance

The products identied in this handbook have been ma-

nufactured by MARCHETTI s.r.l. With QUALITY SYSTEM

MANAGEMENT, certied by Tuv Italia, in accordance with

ISO 9001

MOBILE ACCESS TOWER

SYSTEM

System 120x200

System 120x180

System 100x200

System 100x180

System 75x200

System 75x180

European standard EN 1004

www.marchetti.eu

ATTENTION:

• Read and understand this manual in its entirety.

• Follow the instructions as indicated.

• Before any installation, verify the integrity of each individual

component.

Do not use damaged or not whole components

The mobile access tower is made according to the standards.

Any changes made by others invalidate the manifacturer’s

responsibility.

WARRANTY

All MARCHETTI products are covered by the company’s ocial guarantee, pursuant to

applicable norms. The guarantee is immediately eective and is ratied by the invoice

accompanying the goods. A product found to be faulty is guaranteed. We shall accept no

responsibility for products used incorrectly or damaged during use or transport. The product

must be returned with its original packaging, undamaged; it shall be covered by guarantee if

it has not been dismantled, modied or tampered with.

This documentation is protected by copyright. Any copying or reproduction, including

extracts thereof,and the reproduction of images(even in a modied state),in only permitted

with the written authorisation of the manufacturer.

ENG

REFERENCE STANDARDS

- Leg. Decree 09.04.2008 no. 81 (O.G. no. 101 dated 30.04.08) “Consolidating act on health and

safety in the workplace”.

- EN 1004 (July 2005) “Mobile access and working towers) composed of prefabricated elements.

Materials, dimensions, design loads, safety and performance requirements”;

- EN 1298 (February 1996) “Mobile access towers. Regulations and guidelines for preparation of an

instructions manual”;

- Leg. Decree 06.09.2005 no. 206 (O.G. no. 235 on 08.10.05 – Ordinary Supplement no. 162)

“Consumers’ Code”.

DESIGNATION, CLASS, CAPACITY

System 120x200 working tower EN 1004 – 3 – 8 / 12 XXCD.

System 120x180 working tower EN 1004 – 3 – 8 / 12 XXCD.

System 100x200 working tower EN 1004 – 3 – 8 / 8,5 XXCD.

System 100x180 working tower EN 1004 – 3 – 8 / 8,5 XXCD.

System 75x200 working tower EN 1004 – 3 – 7 / 7 XXCD.

System 75x180 working tower EN 1004 – 3 – 7 / 7 XXCD.

manufactured in compliance with Leg. Decree 81/08 and Technical Standard EN 1004

Class of loads distributed uniformly equal to “3” (2.0 KN/m2);

• max height work platform without stabilizers: m 2,50 / max height work platform with stabilizers:

m 6,10 (H max tower: m 3,50).

• SYSTEM 120: max height work platform with stabilizers: m 8,00 outside of buildings, m 12,00

inside of buildings

• SYSTEM 100: max height work platform with stabilizers: m 8,00 outside of buildings, m 8,50

inside of buildings

• SYSTEM 75: max height work platform with stabilizers: m 7,00 outside of buildings and inside

of buildings

• The sum of the loads relating to each surface must not exceed the overall value of the load

permitted for the scaolding.

• Minimum height clearance between work platforms is: m 1,90.

• Maximum vertical distance between work platform: m 4,20.

• Maximum vertical distance between the ground and the rst level: m 4,60.

www.marchetti.eu

• There are two types of stabilizers: Normal-35 and Super-35.

• Normal-35 stabilizers must be always tted inside of buildings.

• Outside the buildings they can be tted for work platform heights less than to m 6,00 (H max tower

less than m 7,00) in wind exposed conditions.

• When the tower on wheels are mounted next to a wall (ex. building ) such as to constitute a barrier

to the wind, the Normal brackets can be mounted as an alternative to the Supers. In the latter case,

the wall-side brackets must be oriented towards the outside of the tower in a position parallel to

the wall.

• Super-35 stabilizers must be tted to towers with work platform above m 5,00 and when the tower

is completely exposed to the wind (for example, in the middle of a square next to a structure, such

as a light pole, that does not act as a wind barrier, etc.).

Access to work platform

Access to the work platform can only take place inside the tower using one of the following methods:

- vertical rung ladder, composed of uprights on the side frames of the structure

- inclined rung ladder, internal

- inclined step ladder, internal.

Base

dimensions

Overall load

permitted ( kg)

max n° of

working

platform

H max mobile

tower EN1004 (m)

H max mobile

tower D.LGS.81

(m)

120x200 390 3 12,50 17,00

120x180 350 3 12,50 14,00

100x200 330 3 9,50 11,00

100x180 295 39,50 9,50

75x200 226 2 8,00 8,00

75x180 204 2 8,00 8,00

ENG

www.marchetti.eu

DECLARATION OF CONFORMITY

MARCHETTI s.r.l.

with headquarters in Città della Pieve (Pg) - Via Piemonte, 22:

- that the mobile tower called SYSTEM 120X200 - 120X180 - 100X200

- 100X180 - 75X200 - 75X180 are manufactured in compliance

with Leg. Decree 09.04.2008 no. 81 and in particular the Technical

Standard EN 1004 (July 2005)

- that are manufactured in compliance with the prototype which

has surpassed rigidity testing, pursuant to Appendix “A” of the

Technical Standard EN 1004 (2005) and that it was subject, with a

positive outcome, with the ASSESSMENT as outlined in point 13 of

the Technical Standard EN 1004 (2005) at the:

UNIVERSITY OF PERUGIA

Department of Industrial Engineering

Certicate no. Marc 77/79/81/82/83/84

- the identication marking is outlined on all specimens of the

products and on the Instructions Manual drafted according to

specications in Technical Specication EN1298 (point 9 of the

Technical Standard EN 1004).

DECLARES

www.marchetti.eu

IDENTIFICATION SYSTEM 120X200

Cod. Component Elements Weight

CONFIGURATIONS

A1T A2T A3T A4T A5T B6T B7T

20585 TOWER

21 20557 Bearing frame - 120 5,80 2 2 2 2 2 2 2

11 20563 Connecting brace - 200 3,90 2 2 2 2 2 2 2

22 20565 Terminal diagonal bracing - 200 1,10 4 4 4 4 4 4 4

For congurations with H=0,90 m terminal riser A1T-A2T-A3T-A4T-A5T-B6T-B7T, add the following elements:

Cod. Component Elements Weight

CONFIGURATIONS

A1 A2 A3 A4 A5 B6 B7 B8

20579 EXTRACTABLE BASE

1 20551 Wheel-bearing section for extr. Base S120 12,70 1 1 1 1 1 1 1 1

2 20550 Wheel-bearing section for extr. Base S120 12,60 1 1 1 1 1 1 1 1

3 20552 Base brace - 200 6,40 2 2 2 2 2 2 2 2

4 20318 Extractable adjustable foot 3,50 4 4 4 4 4 4 4 4

5 30523 Handgrip screw M14x50 0,14 4 4 4 4 4 4 4 4

20583 TOWER

10 20556 Bearing frame - 120 9,50 2 4 6 8 10 12 14 16

11 20563 Connecting brace - 200 3,90 2 4 6 8 10 12 14 16

12 20564 Diagonal bracing - 200 1,30 4 8 12 16 20 24 28 32

21076 WORK PLATFORM - STEEL

21083

Platform w/trapdoor - 200x51 15,14 1 1 1 2 2 2 3 3

26 Long toeboard - 200 3,92 2 22 4 4 4 6 6

25 21084 Platform w/out trapdoor - 200x51 15,09 1 1 1 2 2 2 3 3

27 Short toeboard - 120 1,59 2 2 2 4 4 4 6 6

20748 COMPLETE GUARDRAILS

17 20632 Long guardrail - 200 5,50 2 2 2 2 2 2 2 2

18 20784 Short guardrail - 120 2,30 2 2 2 2 2 2 2 2

GUARDRAIL BARS

28 20188 Guardrail bar - 200 2,20 0 0 0 2 2 2 4 4

20753 COMPLETE STABILIZERS

19 20765 Stabilizers - 35 9,80 0 0 4 4 4 4 4 4

20 31383 Stabilizers coupler for round tube -35 1,00 0 0 8 8 8 8 8 8

21557 COMPLETE STABILIZERS

19 21557 Telescopic Stabilizer - 35 6,25 0 0 4 4 4 4 4 4

Table of elements composing the congurations

ENG

Cod. Component Elements Weight

CONFIGURATIONS

A1 A2 A3 A4 A5 B6 B7 B8

20580 EXTRACTABLE BASE

1 20551 Wheel-bearing section for extr. Base S120 12,70 1 1 1 1 1 1 1 1

2 20550 Wheel-bearing section for extr. Base S120 12,60 1 1 1 1 1 1 1 1

3 20554 Base brace - 180 6,00 2 2 2 2 2 2 2 2

4 20318 Extractable adjustable foot 3,50 4 4 4 4 4 4 4 4

5 30523 Handgrip screw M14x50 0,14 4 4 4 4 4 4 4 4

20584 TOWER

10 20556 Bearing frame - 120 9,50 2 4 6 8 10 12 14 16

11 20562 Connecting brace - 180 3,50 2 4 6 8 10 12 14 16

12 20566 Diagonal bracing - 180 1,20 4 8 12 16 20 24 28 32

21077 WORK PLATFORM - STEEL

21086

Platform w/trapdoor - 180x51 13,74 1 1 1 2 2 2 3 3

26 Long toeboard - 180 3,55 2 2 2 4 4 4 6 6

25 21087 Platform w/out trapdoor - 180x51 13,64 1 1 1 2 2 2 3 3

27 Short toeboard - 180 1,59 2 2 2 4 4 4 6 6

20749 COMPLETE GUARDRAILS

17 20631 Long guardrail - 180 5,10 2 2 2 2 2 2 2 2

18 20784 Short guardrail - 120 2,30 2 2 2 2 2 2 2 2

GUARDRAIL BARS

28 20600 Guardrail bar - 180 1,95 0 0 0 2 2 2 4 4

20753 COMPLETE STABILIZERS

19 20765 Stabilizers - 35 9,80 0 0 4 4 4 4 4 4

20 31383 Stabilizers coupler for round tube- 35 1,00 0 0 8 8 8 8 8 8

21557 COMPLETE STABILIZERS

19 21557 Telescopic Stabilizer - 35 6,25 0 0 4 4 4 4 4 4

Table of elements composing the congurations

IDENTIFICATION SYSTEM 120X180

For congurations with H=0,90 m terminal riser A1T-A2T-A3T-A4T-A5T-B6T-B7T, add the following elements:

Cod. Component Elements Weight

CONFIGURATIONS

A1T A2T A3T A4T A5T B6T B7T

20586 TOWER

21 20557 Bearing frame - 120 5,80 2 2 2 2 2 2 2

11 20562 Connecting brace - 180 3,50 2 2 2 2 2 2 2

22 20567 Terminal diagonal bracing - 180 1,10 4 4 4 4 4 4 4

www.marchetti.eu

COMPONENTS ELEMENTS

Guardrail bars

Work platform

Tower H=1,50 m

Guardrail

Extractable base

Terminal tower H=0,90 m

24 25

SYSTEM 120X200

SYSTEM 120X180

ENG

CONFIGURATIONS A1 A2 A3 A4 A5 B6 B7 B8

H max mobile tower m 2,00 3,50 5,00 6,50 8,00 9,50 11,00 12,50

H max work platform m 1,00 2,50 4,00 5,50 7,00 8,50 10,00 11,50

H tower ( H= 1,50 m) n° 1 2 3 4 5 6 7 8

Work platform n° 1 1 1 2 2 2 3 3

Complete guardrail n° 1 1 1 1 1 1 1 1

Guardrail bars n° 0 0 0 2 2 2 4 4

Stabilizers-35 n° 0 0 4 4 4 4 4 4

Base section n° 1 1 1 1 1 1 1 1

CONFIGURATION INSIDE AND OUTSIDE OF BUILDING CONFIGURATION INSIDE OF BUILDING

CONFIGURATIONS A1T A2T A3T A4T A5T B6T B7T

H max mobile tower m 2,90 4,40 5,90 7,40 8,90 10,40 11,90

H max work platform m 1,90 3,40 4,90 6,40 7,90 9,40 10,90

H tower ( H= 1,50 m) n° 1 2 3 4 5 6 7

H tower ( H= 0,90 m) n° 1 1 1 1 1 1 1

Work platform with parapet n° 1 1 2 2 2 2 3

Complete guardrail n° 1 1 1 1 1 1 1

Guardrail bars n° 0 0 2 2 2 2 4

Stabilizers-35 n° 0 4 4 4 4 4 4

Base section n° 1 1 1 1 1 1 1

SYSTEM EN 1004 CONFIGURATION

SYSTEM 120X200

SYSTEM 120X180

WITHOUT TERMINAL TOWER H=0,90 m

WITH TERMINAL TOWER DA H=0,90 m

CONFIGURATION INSIDE AND OUTSIDE OF BUILDING CONFIGURATION INSIDE OF BUILDING

www.marchetti.eu

IDENTIFICATION SYSTEM 100x200

Cod. Component Elements Weight

CONFIGURATIONS

A1T A2T A3T A4T A5T

20589 TOWER

9 20559 Bearing frame - 120 4,90 2 2 2 2 2

7 20563 Connecting brace - 180 3,90 2 2 2 2 2

10 20565 Terminal diagonal bracing - 180 1,10 4 4 4 4 4

For congurations with H=0,90 m terminal riser da H=0,90 m ( A1T - A2T - A3T - A4T - A5T ) add the following

elements:

Cod. Component Elements Weight

CONFIGURATIONS

A1 A2 A3 A4 A5 B6

20575 EXTRACTABLE BASE

1 20547 Wheel-bearing section for extr. Base S100 12,30 1 1 1 1 1 1

2 20546 Wheel-bearing section for extr. Base S100 12,20 1 1 1 1 1 1

3 20552 Base brace - 200 6,40 2 2 2 2 2 2

4 20318 Extractable adjustable foot 3,50 4 4 4 4 4 4

5 30523 Handgrip screw M14x50 0,14 4 4 4 4 4 4

20587 TOWER

6 20558 Bearing frame - 100 8,40 2 4 6 8 10 12

7 20563 Connecting brace - 200 3,90 2 4 6 8 10 12

8 20564 Diagonal bracing - 200 1,30 4 8 12 16 20 24

21078 WORK PLATFORM - STEEL

21083

Platform w/trapdoor - 200x51 15,14 1 1 1 2 2 2

22 Long toeboard - 200 3,92 2 2 2 4 4 4

21 21085 Platform w/out trapdoor - 200x36 12,30 1 1 1 2 2 2

23 Short toeboard - 100 1,39 2 2 2 4 4 4

20746 COMPLETE GUARDRAILS

15 20632 Long guardrail - 200 5,50 2 2 2 2 2 2

16 20785 Short guardrail - 100 2,00 2 2 2 2 2 2

GUARDRAIL BARS

24 20188 Guardrail bar - 200 2,20 0 0 0 2 2 2

20753 COMPLETE STABILIZERS

17 20765 Stabilizers - 35 9,80 0 0 4 4 4 4

18 31383 Stabilizers coupler for round tube- 35 1,00 0 0 8 8 8 8

21557 COMPLETE STABILIZERS

17 21557 Telescopic Stabilizer - 35 6,25 0 0 4 4 4 4

Table of elements composing the congurations

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Marchetti Desktop Handbücher

Marchetti

Marchetti OLYMPO Technisches Datenblatt

Beliebte Desktop Handbücher anderer Marken

HP m9060n - Pavilion - Elite Technisches Datenblatt

Asus

Asus E210 Series Bedienungsanleitung

Dell

Dell Inspiron 600m Bedienungsanleitung

Dell

Dell Inspiron 3662 Bedienungsanleitung

TotalFlow

TotalFlow uFLO Bedienungsanleitung

HP Presario SV7000 - Desktop PC Bedienungsanleitung

HP ProDesk 400 G5 Handbuch

Logitech

Logitech MK320 Bedienungsanleitung

Dell

Dell XPS 730 H2C Bedienungsanleitung

Sony

Sony Vaio Series Bedienungsanleitung

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Bedienungsanleitung

Alto

Alto MD 250 Bedienungsanleitung

Lenovo

Lenovo ThinkCentre Edge 72 Handbuch

Lenovo

Lenovo ThinkStation D20 Handbuch

Arbor Technology

Arbor Technology FPC-7800 Series Bedienungsanleitung

Sony

Sony VAIO VGX-TP1 Series Bedienungsanleitung

Asus

Asus Eee Box B204 Bedienungsanleitung

Dell

Dell Optiplex 9010 All In One Bedienungsanleitung
