USER MANUAL
E-Motion
CRUISER
Introduction 1
Overview
Use of this manual 2
Explanation of parts 4
Assembly
Front wheel installation 7
Pedal installation 8
Seat installation 9
Seat adjustment 10
Folding and unfolding 11
Tyres and gears 12
Battery & Charger
Battery and charger overview 13
Battery installation 15
Charging instruction 15
Charging care 18
Range and storage 19
Meter Operation
Meter instruction 22
Safety
Safety 23
Practical
Emergency 31
Cleaning, lubrications and storage 33
Maintenance recommendations. 34
Quick release mechanisms (QR) 37
Technical Information
Technical data 37
Torques 37
Troubleshooting LCD error codes 38
General Information
Environment 39
Legal 40
Mark2 Guarantee Programme 42
Insurance 42
Contents
Introduction
Introduction | Page 1
Congratulations on your purchase of a new Mark2 electric bike!
Every Mark2 has been designed with intelligently integrated and hidden
electronics, supreme reliability and exceptional ease of use. But more
than this, they are a means of bringing real fun, enjoyment and a true
sense of freedom. We adore our product for its ability to deliver this,
and we really hope you do too.
For safety reasons, it is most important that you read this User Manual
before you operate the bike, as it contains some important information
concerning the use and maintenance of your new eBike. Improper
handling can reduce its riding, performance and most importantly, cause
danger to your health and safety.
Safety Notice
Do not at any time dismantle or disassemble any of the eBike
components. Please check all parts are tightened and locked before
riding. Please make sure that the battery charger and charging plug
are always kept dry and do not get wet. The charger should only be
cleaned with a dry cloth. Never use a wet cloth, oil or any other liquid.
Use of this manual
(!!!) – This symbol is used to highlight an
instruction that concerns safety or requires
special attention.
You should pay particular attention to the texts
marked by this symbol and the warnings to avoid
potential risks of injury to yourself or damage
to your eBike. It is important that anyone who
uses the eBike is familiar with and follows the
instructions
We, Mark2, are ready to consult you and, if
necessary, to provide timely and competent
support. To contact us, please email
Product Description
Your eBike is produced, and CE approved
according to the guidelines in Standard ISO4210
and EPAC EN 15194.
The frame is manufactured from aluminium,
which provides a strong, rigid and lightweight
construction.
To achieve optimal weight distribution and to hide
the electronics from the untrained eye, the motor
has been integrated into the rear hub and the
battery integrated into the downtube.
The Mark2s handle and ride brilliantly with or
without the power assistance.
To ensure safety while riding, the electrical
controls have been ergonomically designed for
comfortable use.
Appropriate Use
Your Mark2 has been designed as a rugged
and tough eBike. As well as being capable on
the road, it is well suited to limited off-road
conditions. Specifically, this means a normal
Overview
and reasonable use of the eBike on terrains that
cannot be classified as a road
We must stress that your Mark2 should not be
used on off-road terrain that exceeds these
limits, such as sports activities, jumping, riding
down from mountain peaks or downhill on rough
terrain, freestyle, extreme ride, etc. Your Mark2
is not designed for the challenging and harsh
conditions experienced at such special events,
stunts and acrobatic performances. The eBike
must only be used as intended.
Extreme use may be dangerous. The user is
responsible for any injuries or material damages
that they suffer due to extreme or improper use
of the product or when used for purposes which
the eBike has not been designed and built for.
If the purchased eBike is intended to be used
by a minor, it is of uttermost importance for
an adult or a parent to present the child with
this instruction in an appropriate way. It is
obligatory to pay particular attention to the safety
measures, the behaviour on the road, and how
important it is to follow the rules to avoid the
risk of serious injuries or impairment. It is the
responsibility of the adult or parent to evaluate
the readiness of the minor for the use of the
ebike.
It is the responsibility of the rider to know and
follow the national and local laws and rules.
Overview | Page 3
Explanation of Parts - Model E-Motion
The diagram to the right provides an overview of the parts
on your new eBike. These will be referenced throughout the
manual, and it may be useful to bookmark this page for quick
reference.
1. Handlebar
2. Display
3. Mud guard
4. Front fork
5. Tyre/ Inner tube
6. Spokes
7. Disc Brake
8. Hub
9. Brake Caliper
10. Battery
11. Chainwheel
12. Pedal
13. 6 Speed Derailleur
14. Motor power disconnect
15. Chain
16. Seat Post
17. Saddle
Overview | Page 5
1
2
3
4
5
6
7
8
9
10
11
13
12
14
17
16
15
3
Necessary tools:
• Wrenches from 8 to 15 mm
• Hexagon socket wrenches from 2 to 8
mm (Allen keys)
• Flat-head screwdriver
• Cross-head screwdriver
• Knife or snips
Take the eBike out of the cardboard box
and cut out all the plastic ties fixing the
disassembled components.
When removing the front wheel, you should
bear in mind that the crank arm may be
entangled with the spokes, and if you are
not careful, you may bend them.
Please, remove all the packaging parts
carefully, especially if you use a knife or a
blade. Proceed in such a way as to avoid
scratching any part of the eBike or cutting
one of the tyres.
Your Mark2 requires some adjustments and
minor assembly before it can be ridden. You
may need to attach the front wheel to the
quick release mechanism, straighten the
handlebars and attach the pedals and seat
post. These processes are outlined on the
next few pages.
Assembly
