Marsden VS 250E Bedienungsanleitung

IN-8276 80001D

Marsden VS 250E

Veterinary Scales

MANUAL

Manufacturer’s Declaration of Conformity

This product has been manufactured in accordance with the

harmonised European standards, following the provisions of the

below stated directives:

Electro Magnetic Compatibility Directive 89/336/EEC

Low Voltage Directive 73/23/EEC

MARSDEN Equipment Co. Ltd..

DISPLAY AND KEY FUNCTION

Description:

1. ON/OFF : Power on or off

2. HOLD : The balance has an integrated animal weighing function (mean

value) with which it is possible to weigh small or domestic animals

(minimum weight 1 kg) precisely, even when they do not stand still on the

weighing platform.

Remark: With to lively movement (strong diplay fluctuation) no mean value

can take place.

Place the animal to be weighed on the weighing platform and press the

HOLD key.A triangle will start to flash on the left hand side of the display,

and during this time the balance will record several values, then calculate

and display an mean value.

By pressing the HOLD key again, the weighing machine will be reset to

standard weighing mode.

By pressing the HOLD key again, this function can be repeated as often as

desired.

3. UNIT : Select the units of kg, lb

4. TARE:

1) When there’s load on the scale, press this key to return to zero.

2) Put a container on the scale, press this key to tare the weight, and

the tarred value is stored.

SPECIFICATION

Capacity 250kg x 0.1 kg

Display 1.0" LCD display with 5 1/2 active digits

Operating temperature 5℃~ 35℃

Weight 17.5kg

Dimensions

Platform 1093 mm x508 mm x 43 mm

Display head 216 mm x107 mm x 40mm

Power supply 9V DC adapter

POWER SUPPLY

Battery Operation

Remove the battery cover underneath the weighing scale. Connect 6 x 1.5V

round cells. Re-insert the battery cover.

Battery conservation through automatic power-off 3 minutes after ending a

weighing operation.

When the battery power is used up the display will show “LO”. Press the OFF

key and change the batteries at once.

When the balance is not in use for a longer period of time remove batteries and

keep them separately. Leakage of battery liquid might damage the balance.

AC adaptor

The scale uses battery (1.5v x 6) or 9V100mADC adapter.

CALIBRATION

1. Switch the scale on

2. Press and hold "UNIT" key for 6 seconds, display "Cal" then "200.0" kg

3. Load 200 kg on the center of platform, Press "UNIT" key one time, display

"200.0" kg

4. Remove the weight, and the calibration is finished.

ERROR MESSAGES

Low Battery

Overload

Over Zero

If zero count is high than the setting range, the

display will show “Err” message. The scale will

turn off if the status continues 30 seconds.

Below Zero

If zero count is below the setting, the display will

show “Errl” message. The scale will turn off if

the status continues 30 seconds.

If battery is discharged, the display will show.

The operator should start to recharge

the battery.

If the total load exceeds the maximum capacity of

scale, the display will show the “Err” message. The

weight must be removed from the platform right away.
