Ribbon Microphone Upgrade for MXL 990

Microphone

TL;DR –3D printed ribbon bracket, 3D printed transformer bracket for MXL 990

Mic, along with a Ribbon alignment jig for a www.diyribbonmic.com/parts ribbon

element.

My Journey

I’ve been a long time audio buff and musician, who has a little recording studio in my basement. It’s always fascinated

me how expensive “good” ribbon microphones were, yet their construction was terribly simple. If you traverse the web,

you’ll see I’m certainly not the first to go down this path of homemade Ribbon Mics. There are a number of good

resources out there on the series of tubes. But of course, I’d like to think I’m a little different, and you can be the judge

of that. My approach has been to use cheap microphone bodies and upgrade, rather than making a body from scratch.

This has some limitations with respect to the dimensions of the body, but I think it gives a much more professional look.

At the same time, you now have to convince someone that the guts in that MXL is a whole lot better than they might

think. But once they listen to it, I think they will be able to make that judgement themselves. In addition, with my new

3-D printer, I figured I could design and print anything I might need to help the process, and it seemed some tools and

jigs were missing from all of the other posts I had seen.

Starting with a Kit

What started this journey for me was running into Rick at www.diyribbonmic.com/parts (sadly, it was more than a year

before I could finally get the time to finish this project). I saw he had everything you need to make a Ribbon mic

element (motor), transformers and even a complete mic, along with an excellent set of instructions and videos. He was

very easy to communicate with, and I had numerous emails with him before I even bought the kit. But to save some time

and cash, I wanted to upfit an old MXL mic.

Being an engineer, the first thing I did immediately after ordering my kit, was to look how to improve what was already a

good thing. A couple of things immediately struck me. 1st was that no matter what, I knew full well I would need to

eventually re-ribbon the thing. And I wanted to make that process as easy as possible. And I wanted to be able assemble

and disassemble the mic cleanly. So I started to work on some 3-D Printed parts.

But before you get started you will need to hit Rick’s site at www.diyribbonmic.com/parts and buy the ribbon motor kit

and his OTA transformer. You will need an MXL 990 mic, and the 3-D printer files on thingiverse.

Why MXL Mics

In a word, they’re cheap, easy to find, and many folks buy them as part of their 1st studio equipment, to then end up

tossing them in the back of the closet somewhere as they move on to get better quality gear. So they are good

candidates for cannibalizing for upgrades. While ripping the inner layers of mesh out of the basket is a bit of a pain in

the butt, you can’t beat them as a nice mic body as a base for an upgrade. And they most often come with a decent

shock mount. I often find them used for less than $50 each on craigslist, and found 4 for $25 each. Sticking a quality

Ribbon Motor and Transformer into one, quickly turns them into sounding like a mic costing $1,000 or more.

1st is a Series

This is in fact the 1st in a series of Instructables, with adjoining 3-D printable files to either upgrade or entirely build a

Ribbon Microphone. Since it’s my first, I’m making it fairly detailed. The ones that follow won’t be as long.

This Instructable is to take a ribbon microphone element (motor) from Rick at www.diyribbonmic.com/parts along with

his OTA transformer and upgrade an MXL 990 using some 3-D printed fixtures and tools.

Over the coming months I will be offering up other Instructables. I have recently completed an upgrade for the MXL

R144 Ribbon Mic (Ultimately, I plan to build in a phantom powered preamp into this body), and will shortly be working

on similar upgrades to the MXL R80 Ribbon Mic. All this will ultimately culminate in an entirely 3-D printable Ribbon

microphone (active, with a Phantom powered preamp), which I also hope to CNC a metal motor. They will come in time.

Needing Some Tools (Here’s where some CAD skills and a 3D printer helped)

When I traversed the web, what seemed to be missing, were some tools that would make things much easier to deal

with ribbon prep, installation and the final build. And that’s what I wanted to accomplish in this Instructable. Some

things I realized would make things so much easier.

Cutting Guides –Terribly simple, but really necessary. You need to cut the Ribbon straight and of a particular

width. So I fired up InDesign, and made a very simple cutting guide of parallel lines for different Ribbon Widths.

Paper Ribbon Carrier –Again, a simple set of parallel lines 20mm apart to cut some parchment paper, to allow

you to fold it in half, and gently tuck your ribbon into it so you can corrugate it. Once you cut your ribbon, you

need some place to gently stow it, before you corrugate it.

Plastic Tweezers –So much easier than toothpicks to move the ribbon around, although, you will still love to use

those toothpicks in some places

Glass –Since I have a 3D printer, I always print on glass, and found it so much easier to cut the ribbon on glass.

1st tape down your ribbon cutting guide, then some parchment paper, then lay the foil on the parchment, and

top off with another layer of parchment paper. I also just used some picture frame glass.

Ribbon Alignment Jig –This 3D Printed part is probably the single most important thing I made. Getting the

ribbon properly aligned and tensioned in the motor is really tough when you just lay the motor on your desk,

and try to do everything free hand. This jig allows you to place the Ribbon Motor in it, than drape the ribbon

element across it to more easily align it, and put tension on it. I used brass nuts, to hold the ribbon in place, and

used a toothpick to slide them (the brass nuts) around to align and tension the ribbon. The ribbon really needs

something to help keep it aligned. This really did the trick. Then tighten up the clamps to hold the ribbon in

place (one end 1st, make final adjustments, then the other end). If there was any one thing that I was happy

about, it was this jig. I literally was able to use my very 1st ribbon and got it done in like 5 minutes. I attribute it

to this tool. After working on some other ribbon motors, I came up with a simplified version. Both versions are

included for download and print.

Ribbon Corrugator –In traversing the web, I learned that corrugations of 20 or so per inch were optimal. I tried

to 3D print some gears to that specification, but the teeth are just too fine for my 3D printer (a friend’s got an

SLA, I might hit him up). And again hitting the Internet and various Ribbon Mic sites, I came across a very simple

arts and craft corrugator, which works perfectly. I of course wanted to 3D print some fancy contraption for it,

but the simple device works just fine.

3D Printed Ribbon Motor Mounting Bracket –Again, my biggest motivation here was to create a means to

allow the Ribbon Motor to be easily removed to be re-ribboned. This is what I ended up with. This is a little

recess in the bottom so the copper strip has room, and little channels in the back, so you can press fit the

positive wires in place.

3D Printed Transformer Bracket –Again, rather than just use some stuffing to hold it in place, I wanted

something a little neater. So I came up with a similar looking bracket, where Rick’s OTA transformer slides into.

This rotates the transformer on its side so the 2 ribbon motor wires go up through the holes on the same side to

connect to the motor on the back. It also has a bit of a stand off, to move the transformer further away from

the motor, so the magnets don’t effect it as much. It makes wiring things up easier.

Part List

This is the list of parts used and where to get them

Ribbon Motor Kit and OTA transformer from Rick, you don’t really need the full MXL 660 upgrade kit, as you will

use my 3-D printed parts, just email him for the two parts, he’ll hook you up.

ohttp://diyribbonmic.com

3D printable ribbon fixture jig, motor bracket and transformer bracket

oYou can get them from Rick as part of his kit (PLA, .02mm, 100% infill) or print them yourselves, getting

them from Thingiverse below.

MXL 990 Upgrade - http://www.thingiverse.com/thing:1271932

Just the Austin Ribbon Mic Alignment Jig - http://www.thingiverse.com/thing:1271926

PDF of ribbon cutting guide and ribbon pocket cutting guide

Ribbon Corrugator –Like I said, I was going to make a fancy ribbon corrugator, but this works very well as is.

Maybe later I’ll 3-D print something.

ohttp://www.amazon.com/gp/product/B0054G623Y?psc=1&redirect=true&ref_=oh_aui_detailpage_o02

_s00

Connecting wire –I really like this wire, nice jacket, fine strands. Perfect for this purpose.

ohttp://www.amazon.com/gp/product/B00CUKSITS?psc=1&redirect=true&ref_=oh_aui_detailpage_o07_

s00

Heat shrink tubing –just a couple of inches of 3/32” and 1/8”. I got this kit, which was great

ohttp://www.amazon.com/NTE-Heat-Shrink-Assorted-

Colors/dp/B000FIDTYG/ref=sr_1_15?s=industrial&ie=UTF8&qid=1451328474&sr=1-

15&keywords=3+32+heat+shrink

Non-metallic tweezers –I love these and they are cheap. Very helpful in really being able to handle the ribbon

delicately. You can’t use your fingers, as the ribbon will stick to them.

ohttp://www.amazon.com/gp/product/B00HGAKMMI?psc=1&redirect=true&ref_=oh_aui_detailpage_o0

7_s00

2 Brass nuts for the ribbon alignment jig

1 inch piece of 3m double back foam tape

Soldering Iron and Solder

Heat Gun

Wire cutters, long nose, jewelers screwdrivers and other basic tools, jewelers nut driver for the ribbon motor

Thick cotton sock –OK, laugh now, but when you carry the mic around, and the wind going through it, and blows

the element out, then you’ll get a sock to cover it. Ribbon’s are delicate. You cough on it, its shot. Just walking

with it unprotected in your hand, with the air movement going over it, can stretch the ribbon. Think of it as the

condom for a mic. We’ll be removing some grille material for better frequency response, which makes it more

susceptible to wind. For me, I just happen to have some of these little nVidia bags for their 3D glasses, which fits

perfectly.

Glass –From a picture frame will do

Printer to print the PDFs out

Parchment paper –Rick’s ribbon motor kit includes some decent ribbon material. If you want to go hog wild and

buy a sheet of 1.8 micron foil, it will set you back $25 plus shipping. Not a whole lot of difference, but I spent

the extra money. Hit the site below, then email them with what you want to buy, contrary to what the site says,

you only need to buy one sheet at a time. You then pay with PayPal, and they ship the next day. Good

company.

ohttp://www.lebowcompany.com/foils_list.htm#ALUMINUM

OK, Let’s Get Started

MXL Mic Disassembly

Basically, you just want to strip it down to where you only have the case, XLR connector and basket. The mic basket has

3 layers of grille material. You really want to remove the two interior layers

1. Unscrew the black base nut at the bottom of the mic. This is used to trap the non-shock mount, but also helps

hold the thing together.

2. Once that has been removed, you can then unscrew the upper and lower halves of the mic.

3. There are 2 screws that hold the basket to the metal plate. Unscrew those, and the basket will come loose,

revealing the condenser element.

4. Unscrew the condenser element, and cut the wires. Hang on to the element, as you will need that little solder

tab for a ground tab later.

5. Cut the wires for the XLR connector close to the circuit board, and remove the circuit board.

6. Loosen the screw that is holding the XLR connector in the body, and let it drop out. Desolder the + & - wires

from the XLR. You will also need to add a new chassis ground wire later.

7. Grille –OK, this is a little bit of work. The grille on the Mic has 3 layers. Now on one hand you can just leave it

alone, but it does impact the frequency response of the mic. Therefore, I suggest you remove the inner 2 layers.

This is a little tough, as the layers are soldered in a number of places. I used long nosed plyers and some long

necked wire cutters. But if you are patient, you can completely remove the 2 inner layers. One thing to point

out, is that in removing the inner layers, you may deform or pull down on the top of the mic grille. The ribbon

element has some tight tolerances. So make sure you take a screwdriver handle and push up on the inside of

the grille to again return the top to where it is curved out. You don’t want to have the top of the ribbon element

touch the grille, as it will short. Ultimately, if you don’t trust the clearance, you can use a piece of electrical tape.

Putting it Together

Let’s first get the Mic body prepped for the new ribbon motor (element)

1. You will need to drill 2 holes in the metal plate (that the condenser element was mounted to), to secure the 3D

printed ribbon element bracket and transformer holder. I would suggest that you use the transformer holder as

your guide. Place the transformer holder aligning it with the 4 large center holes in the plate, and use a punch

to mark your 2 drill holes. Drill to fit a 4-40 or similar size screw. Don’t forget to deburr.

2. Using a film of silicone seal on the bottom of each bracket, secure the brackets to the metal plate. I would

suggest screws going through the ribbon element bracket, with the nuts on the transformer side.

See that little Intent in the bottom there? See the little grooves in the back of the bracket? Those grooves

are for the plus (+) wires to sit into. This is the BACK of the MIC

Wiring it Up

3. Before you wire up the OTA transformer, you should test fit the transformer into the bracket, to make sure it’s

not TOO tight. You may need to use an Xacto blade to shave it a bit. But you do want it very snug.

4. Now you need to prep the OTA transformer. Solder a 6” black wire to the mic input – side, and TWO 8” red

wires to the mic input + side of the transformer. Then heat shrink. 3/32” heat shrink for the single wire, and the

1/8” heat shrink for the plus leads. Don’t make the heat shrink too long up the black or red wire, as you need

them to be pretty flexible close to the metal plate.

5. You will then want to wire the transformer up to the XLR connector. If you haven’t done so already, loosen the

screw for the XLR connect in the side of the mic body. The XLR connector should drop out the bottom of the mic

body.

6. The output wires of the OTA transformer are plenty long, in fact you can see if you might want to trim them a

bit. But I left mine alone.

7. Slide some heat shrink tubing up the transformer wires, and put the wires THROUGH THE MIC BODY

8. You need to run the wires through the mic body BEFORE you solder them to the XLR connector. Then solder the

red lead to the + pin, which is pin 2. Solder the black lead to the –pin, which is pin 3. Slide the heat shrink over

the pins, and shrink with a heat gun.

9. Now, while that XLR screw you loosened to drop the XLR connector out of the body should provide ground for

the mic body, I went ahead and soldered a ground wire, that I then connected to one of the mic body screws

just to be safe. It should look like this

10. Now twist the transformer output wires a bit. Insert the XLR connector back into the body, making sure you

properly align the connector with the key slot and tighten.

11. First check the orientation of the Mic brackets. Remember that little notch in the bottom of the ribbon element

bracket? See those little channels going up the bracket? Those are for the wire to sit in. That’s the BACK of the

mic. Take the red and black transformer input wires, and slide them through the hole in the back of the bracket.

Next put a little blob of silicone seal in the transformer bracket, and you will want to insert the transformer into

the bracket so the back of the transformer, with the 2 mic input wires face the back of the mic. Slide the

transformer in. It will be a tight fit. It’s supposed to be.

Andere Handbücher für MXL 990 Stereo

Inhaltsverzeichnis

Andere Marshall Electronics Mikrofon Handbücher

Marshall Electronics

Marshall Electronics MXL 870 Bedienungsanleitung

Marshall Electronics

Marshall Electronics CE90V Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 990 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 860 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL V88 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 990 Stereo Bedienungsanleitung

Marshall Electronics

Marshall Electronics Live LSC-1 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL Cr89 Series Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL FR-366K Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 840 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL V88s Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL V900D Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL USB .006 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 990 Stereo Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL Cr30 Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL REVELATION II Bedienungsanleitung

Marshall Electronics

Marshall Electronics Orchid OR-434 Bedienungsanleitung

Marshall Electronics

Marshall Electronics V67I Tube Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 603 PAIR Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 9000 Bedienungsanleitung

Marshall Electronics

Marshall Electronics Genesis Bedienungsanleitung

Marshall Electronics

Marshall Electronics Revelation Stereo Bedienungsanleitung

Marshall Electronics

Marshall Electronics MXL 990 USB Bedienungsanleitung

Beliebte Mikrofon Handbücher anderer Marken

IK Multimedia

IK Multimedia iRig Stream MIC PRO Bedienungsanleitung

DAPAudio

DAPAudio RM-101 Bedienungsanleitung

AKG

AKG CHM 21 Bedienungsanleitung

Sennheiser

Sennheiser evolution wireless series EM 100 Bedienungsanleitung

Sony

Sony C-48 Bedienungsanleitung

GIGAMEDIA

GIGAMEDIA GGM PAMICUHFG Bedienungsanleitung

Shure

Shure WH30TQG Bedienungsanleitung

auna PRO

auna PRO MIC-900 Bedienungsanleitung

AKG

AKG D 3800 Bedienungsanleitung

Shure

Shure KSM141 Bedienungsanleitung

MAIIN SOUND

MAIIN SOUND IIN style Bedienungsanleitung

Earthworks

Earthworks TC25 Bedienungsanleitung

Sennheiser

Sennheiser evolution D1 Bedienungsanleitung

Alesis

Alesis MicLink Wireless Bedienungsanleitung

DSPPA

DSPPA D6234 Bedienungsanleitung

Monacor

Monacor IMG STAGELINE ECM-300B Bedienungsanleitung

Ansr Audio

Ansr Audio Scan16 Bedienungsanleitung

Shure

Shure MXA710 Series Bedienungsanleitung
