For more information, contact Marshall Electronics, Industrial Video & Security (800) 800-6608

Marshall

Industrial Video/Security Div.

Marshall Lynx LCD

Universal Monitors

User Manual

www.mars-cam.com

Lynx LCD Monitor User Manual Lynx LCD Monitor User Manual

Caution:To reduce the risk of electric

shock, do not remove the back.

There are no user-serviceable

parts inside. Always refer

servicing to qualified personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightening ﬂash symbol inside the triangle is intended to

alert the user to the presence of un-insulated and dangerous

voltage within the product’s enclosure that may be of sufﬁcient

magnitude to constitute a risk of electric shock.

The exclamation point within the triangle is intended to alert the

user to the presence of important operating and maintenance

(servicing) instructions.

Graphic Symbol Explanation

Warning– To Prevent Fire or Shock Hazard, DO NOT

Expose this Monitor to Rain or Moisture

This product must be grounded.

Product specifications are subject to change without notice.

Important Safegaurds .....................................................4

Introduction ....................................................................6

Specifications ..................................................................7

Front Panel Components and Controls ........................12

Setting Up the Monitor ..................................................13

Audio/Video Inputs ........................................................19

Troubleshooting .............................................................21

Remote Control Functions ............................................22

Lynx Monitors VGA Resolution Chart ..............................23

CONTENTS

Lynx LCD Monitor User Manual

IMPORTANT SAFEGUARDS

Please comply with warning regarding power requirements. The power

source contains high voltage parts. If the cover is removed, it may cause

ﬁre or electric shock. Do NOT remove the cover.

Caution

1. Read the Instructions: All safety and operating instructions should be read

before the monitor is operated.

2. Follow the Instructions: All operating and user instructions should be followed.

3. Cleaning: Unplug the monitor from the wall outlet before cleaning.

Do not use liquid aerosol cleaners. Use only a damp,

soft cloth.

4. Water and Moisture: Do not use the monitor in damp environments. For

example, do not operate the monitor in bathrooms,

sinks, laundry rooms, wet basements or near a

swimming pool. Lynx monitors are not recommended

for outdoor use.

5. Accessories: Always ensure that the monitor is placed on a solid,

steady surface/stand. To avoid any possible danger

and/or damage, do not place the monitor on an

unsteady stand, stool, or other surface that could

result in the monitor falling.

6. Ventilation: Slots and openings in the monitor’s cabinet are

provided for ventilation and ensure reliable operation

of the monitor and to protect it from over-heating.

These openings must never be blocked. The monitor

should never be placed near or over a radiator or

head register. This monitor should not be placed or

built in to a rack or bookshelf unless proper ventilation

is provided and supplier instructions have been

adhered to.

7. Object and Liquid Entry: Never push any kind of object into this monitor

through an opening as it may touch dangerous volt-

age points or short out parts that would result in ﬁre

or electric shock. Never spill liquid of any kind into

the monitor.

8. Repair (Servicing): Do not attempt to repair this monitor yourself by

opening or removing covers. This may expose you to

dangerous voltage or other hazards. Refer to a qualiﬁed

service technician if servicing is necessary. If monitor is

opened by anyone other than a factory authorized

service center, the warranty is voided. If serial number is

removed or tampered with, the warranty is voided.

9. Parts Replacement: When part replacement is required, make sure it is

performed by a qualiﬁed technician and that the parts

are supported by the manufacturer.

10. Safety Check: Upon completion of any service or repair to the

monitor, ask the service technician to perform a

safety check to ensure that the monitor is in

proper operating condition.

11. Keep the Instructions: The safety and operating instructions should be

kept for future reference.

Lynx LCD Monitor User Manual

INTRODUCTION

Thank you for purchasing the Marshall Lynx LCD Monitor. The Lynx Series of Universal

Monitors offers high performance features and excellent picture quality for use in a variety

of industrial/commercial applications.

The information contained in this instruction manual covers the installation and operation

of the monitors, and we encourage you to read it carefully. All the installation materials,

wire/cables must pass quality inspections in accordance with international electrical rules

and laws. When installing your monitor, remember to always adhere to local ordinances

and laws concerning wire and cable installation.

Note: A/V inputs/outputs as well as optimal resolution will vary by screen size. Refer to

Speciﬁcations section for more in-depth details.

SPECIFICATIONS

Display Unit 15” 4:3 TFT/LCD

Video Input/Output 1-channel s-video input/output

2-channel multiple video BNC input/output

1-channel VGA input, 1 channel DVI input

1-channel YPbPr input.

Audio Input/Output 3-channels RCA input/output

Front Panel Controls Menu, Volume, Channel, and Stand-by Power

Power Input AC100V ~ 230V 50 ~60Hz

Power Consumption Max: 32W

Dimensions 358mm x 300mm x 68.5mm

(W x H x D)

Weight 9.9 lbs/4.5kg

Maximum Vertical Resolution Max 1080 lines

Video System NTSC/PAL

VGA/DVI connector Resolution: 1024 x 768

Speakers Max: 2 x 1.0W

Maximum Brightness 300cd/m2

Maximum Contrast 450:1

Response Time 8ms

Viewing Angle 170º/150º

Operating Environment Temperature: 0º C ~ 40º C

Humidity: 10% ~ 85%

Lynx LCD Monitor User Manual

Display Unit 17” 5:4 TFT/LCD

Video Input/Output 1-channel s-video input/output

2-channel multiple video BNC input/output

1-channel VGA input, 1 channel DVI input

1-channel YPbPr input.

Audio Input/Output 3-channels RCA input/output

Front Panel Controls Menu, Volume, Channel, and stand-by Power

Power Input AC100V ~ 230V 50 ~60Hz

Power Consumption Max: 32W

Dimensions 15.2” x 13.3” x 2.6” / 387mm x 338mm x 67mm

(W x H x D)

Weight 11 lbs/5.0kg

Maximum Vertical Resolution Max 1080 lines

Video System NTSC/PAL

VGA/DVI connector Resolution: 1280 x 1024

Speakers Max: 2 x 1.0W

Maximum Brightness 300cd/m2

Maximum Contrast: 1000:1

Response Time 8ms

Viewing Angle 170º/160º

Operating Environment Temperature: 0º C ~ 40º C

Humidity: 10% ~ 85%

Display Unit 19” 5:4 TFT/LCD

Video Input/Output 1-channel s-video input/output

2-channel multiple video BNC input/output

1-channel VGA input, 1 channel DVI input

1-channel YPbPr input.

Audio Input/Output 3-channels RCA input/output

Front Panel Controls Menu, Volume, Channel, and stand-by Power

Power Input AC100V ~ 230V 50 ~60Hz

Power Consumption Max: 40W

Dimensions 18” x 14.6” x 3”/ 458mm x 373mm x 77mm

(W x H x D)

Weight 11 lbs/5.0kg

Maximum Vertical Resolution Max 1080 lines

Video System NTSC/PAL

VGA/DVI connector Resolution: 1280 x 1024

Speakers Max: 2 x 1.0W

Maximum Brightness 300cd/m2

Maximum Contrast: 1000:1

Response Time 8ms

Viewing Angle 170º/160º

Operating Environment Temperature: 0º C ~ 40º C

Humidity:10% ~ 85%

Lynx LCD Monitor User Manual

Display Unit 26” 16:9 TFT/LCD

Video Input/Output 1-channel s-video input/output

2-channel multiple video BNC input/output

1-channel VGA input, 1 channel DVI input

1-channel YPbPr input.

Audio Input/Output 3-channels RCA input/output

Front Panel Controls Menu, Volume, Channel, and stand-by Power

Power Input AC100V ~ 230V 50 ~60Hz

Power Consumption Max: 110W

Dimensions 26.4” x 16.5” x 4.9” / 673mm x 421mm x 125mm

(W x H x D)

Weight 27.5 lbs/12.5kg

Maximum Vertical Resolution Max 1080 lines

Video System NTSC/PAL

VGA/DVI connector Resolution: 1600 x 1200

Speakers Max: 2 x 1.0W

Maximum Brightness 500cd/m2

Maximum Contrast: 1000:1

Response Time 8ms

Viewing Angle 176º/176º

Operating Environment Temperature: 0º C ~ 40º C

Humidity:10% ~ 85%

Display Unit 20” 4:3 TFT/LCD

Video Input/Output 1-channel s-video input/output

2-channel multiple video BNC input/output

1-channel VGA input, 1 channel DVI input

1-channel YPbPr input.

Audio Input/Output 3-channels RCA input/output

Front Panel Controls Menu, Volume, Channel, and stand-by Power

Power Input AC100V ~ 230V 50 ~60Hz

Power Consumption Max: 50W

Dimensions 18” x 14.6” x 3”/ 458mm x 373mm x 77mm

(W x H x D)

Weight 15.8 lbs/7.2kg

Maximum Vertical Resolution Max 1080 lines

Video System NTSC/PAL

VGA/DVI connector Resolution: 1600 x 1200

Speakers Max: 2 x 1.0W

Maximum Brightness 450cd/m2

Maximum Contrast: 1000:1

Response Time 8ms

Viewing Angle 178º/178º

Operating Environment Temperature: 0º C ~ 40º C

Humidity: 10% ~ 85%

Lynx LCD Monitor User Manual

SETTING UP THE MONITOR

Carefully unpack the items from the box and take a moment to ensure that the

following items are included:

1. Lynx monitor

2. Power cord

3. VGA cable

4. Remote control (Lithium battery included)

If any of these items are missing, contact customer support at 800 800-6608.

Next, take a few moments to familiarize yourself with the front and rear panel

controls and inputs. The front panel of the Lynx Monitor includes hard-button

controls for Menu, Volume, Channels and Power (stand-by).

The rear panel of your Lynx monitor includes S-video inputs, 2-channel multiple

video BNC input/outputs, and 1 channel YPbPr input.

After ﬁnding a suitable and secure location for the monitor, plug the power cord

into the rear panel and then to an AC power source. Turn the Power Switch on.

VIDEO MAIN MENU

To access the Main Menu features, press Menu on the remote control or the

button on the front panel.

The Image Settings screen will appear along with three icons on the left-hand side:

Image Settings, Display Settings, and Setup. See Figures 1, 2 and 3. Use the arrow

buttons on the remote control or front panel to scroll through the settings.

VOLUME CONTROL

To adjust the volume on the Lynx monitor, press the on the front panel of the

monitor. Use the left and right arrow keys on the remote or front panel to adjust the

volume.

Power button (stand-by)

Exit Menu

With menu off, adjust volume (0 ~100).

With menu on, use to scroll through menu

With menu on, use to select or change menu functions

When menu is off, selects video input: Video 1, Video 2,

S-video, YPbPr, VGA, DVI

Select item

FRONT PANEL COMPONENTS AND CONTROLS

Lynx LCD Monitor User Manual

14 15

Figure 3. Pressing

the

button on the

front panel or

Enter on the remote

will highlight the

feature presets you

want to adjust.

Figure 4. Advanced

settings like Noise

Reduction and

Dynamic Contrast

can also be adjusted.

Figure 2. The Setup

screen allows you

to select language

and reset to factory

settings.

Figure 1. The Image

Settings screen allows

you to adjust picture

settings such as

brightness, contrast,

sharpness, etc.

Adjust the Image Settings

In the Image Settings Screen, you can adjust Brightness, Contrast, Sharpness,

as well as more Advanced Settings like Noise Reduction and Flesh Tone. To

select, press the

button on the front panel or Enter on the remote control.

The settings will be highlighted (see Figure 4). Use

◄►

arrow keys on the front

panel or the remote control to scroll through the settings. Press Enter on the

remote or

on the front panel to access the settings. When ﬁnished making

adjustments (

◄►)

, press the

or Enter on the remote. Press Menu button on

the remote or the

button on the front panel to exit Image Settings menu.

Lynx LCD Monitor User Manual

Figures 5 & 6. Other

features that can be

accessed in Image

Settings include

MPEG Noise Reduc-

tion (MPEG NR).

Figure 7. Advanced

features in Image

Settings allow you

to adjust the Red,

Green and Blue Color

Scheme.

Figures 8 & 9.

Display Settings

allow you to make

adjustments to the

screen. (Note: PIP

mode disabled)

Adjust the Display Settings

To select, press the

button on the front panel or Enter on the remote control.

The settings will be highlighted (see Figure 9). Use

◄►

arrow keys on the front

panel or the remote control to scroll through the settings. Press Enter on the

remote or

on the front panel to access the settings. When ﬁnished making

adjustments (

◄►)

, press the

or Enter on the remote. Press Menu button on

the remote or the

button on the front panel to exit Display Settings menu.

Lynx LCD Monitor User Manual

Adjust the Setup Up Menu

To access Setup Menu, press the

button on the front panel or Enter on

the remote control. The settings will be highlighted (see Figure 11). Use

◄►

arrow keys on the front panel or the remote control to scroll through the

settings. Press Enter on the remote or

on the front panel to access the

settings. When ﬁnished making adjustments (

◄►)

, press the

or Enter on

the remote. Press Menu button on the remote or the

button on the front

panel to exit the Setup menu.

Figure 10.

The Set up menu

allows you to set

the language of

preference as well

as factory presets.

Audio/Video Inputs

The rear panel of the Lynx monitor includes inputs for connection to devices

such as computer networks, DVD players, cameras, etc. These inputs include:

IN IN IN

OUTOUT OUT

VGA

DVI

AUDIO 1 AUDIO 2AUDIO 3

IN OUT

S-VHS

IN OUT

VIDEO 1

VIDEO 2

RGB/YUV

R/Y

B/V

G/U

SYNC

1. YUV/YPbPr inputs

2. Video 1: input/output

3. Video 2 input output

4. S-Video input/output

5. Audio 1, Audio 2, Audio 3

6. VGA input

7. DVI input

Note: Corresponding interface of YPbPr input: Y to R/Y, Pb to G/U, Pr to B/V

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Marshall Electronics Monitor Handbücher

Marshall Electronics

Marshall Electronics V-LCD8P-02 Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R102DP-2C Bedienungsanleitung

Marshall Electronics

Marshall Electronics M-LYNX-702W Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R573P Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD50-HDMI Bedienungsanleitung

Marshall Electronics

Marshall Electronics QV261-HDSDI Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R53P Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD84SB-AFHD Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD70MD Bedienungsanleitung

Marshall Electronics

Marshall Electronics 8.4-inch TFT/LCD Monitor V-R84DP-SD Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD90MD-3G Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R44P-HDSDI Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R1042DP-TE4U Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R84DP-2SDI Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R82DP-HDA Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD17HR Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD70MD-3G Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R151P Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-DV-PWR1 Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD90MD Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R44P-DVI Bedienungsanleitung

Marshall Electronics

Marshall Electronics Dual 10.4-inch LCD Rack Mounted Monitor... Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-R1041-IMD-TE4U Bedienungsanleitung

Marshall Electronics

Marshall Electronics V-LCD70XP-HDMI Bedienungsanleitung

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Asus

Asus VB171D - 17" LCD Monitor Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

NEC

NEC AccuSync LCD5V Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung
