V-R53P-SDI Instruction Sheet

http://www.LCDRacks.com e-mail: [email protected]

The operation of the V-R53P-SDI is fairly straightforward, however, please take note of the following:

1. The V-R53P-SDI has been designed to fit in a 3U space on your rack. It may be necessary to center the unit

up or down in order to not touch any adjacent units in your rack when tilting unit up or down. The auto signal

detection will display a blue screen with the absence of a signal. The V-R53P-SDI has a memory function that

will remember the settings of each monitor including power and channel selection even if power has been dis-

connected from the unit.

2. Each LCD Panel comes with a protective plastic film that must be removed by carefully lifting the film from

the corner and peeling it off. Be certain not to apply any pressure on the LCD panels, they are fragile and can

break. Scratched, cracked or broken LCD screens are not covered by our warranty.

3. The V-R53P-SDI uses 12VDC, 3.0amp regulated power. Be certain that these specifications are met when

using a power supply other than the one supplied to you by Marshall Electronics. The center pin on the coaxial

power connector for the V-R53P-SDI is the POSITIVE terminal and the outside ring is NEGATIVE. Any battery

operation of the V-R53P-SDI must have this polarity configuration.

4. The Video inputs on the rear of the panel are 75 Ohm self-terminated. The loopthrough feature uses active

components and is always active as long as power is supplied to the unit regardless of the monitor being On or

Off. The V-R53P-SDI is also equipped with a 10-bit D/A convertor that converts the SDI input from that channel.

This D/A convertor uses the SMPTE 259M standard and is reclocked.

5. In the VGA mode, the signal is converted from 640 x 480 pixels to 640 x 320 pixels. Since the pixel count on

these panels is 960 x 234, 6 bottom lines will be lost.

Side View

2.5”

The V-R53P-SDI is a rack mountable unit that has three independently controlled 5” active matrix LCD panels with

loop through capability. These 5” panels have 960 x 234 pixels making them a true high resolution LCD panel. Each

monitor has a composite video, SDI, and a VGA input. Each of the three screens also have a built-in color bar gen-

erator, individual front mounted selector buttons with LED’s and color, tint, brightness and contrast controls. The unit

fits into an EIA standard 19” rack, three rack spaces high. In addition to the digital and analog loopthroughs, this unit

also has a 10-bit converted output from the digital input. Unit comes with power supply and dry erase marker.

5” LCD

Active Matrix

4.75” x 2.95”

each panel

0.107mm x

0.320mm 960H x 234V 1 SDI,1 Comp,

1 VGA per panel Built into unit 19.125W x

5.14H x 2.50D

12 VDC

3.0 Amps

Display Viewing Area Dot Pitch Inputs Color Bars Dimensions


Elements

Power

Consumption

http://www.LCDRacks.com

Back View

Marshall

Warranty

Marshall Electronics warranties to the first consumer, that this V-R53P-SDI rackmount monitor will,

under normal use, be free from defects in workmanship and materials, when received in its origi-

nal container, for a period of one year from the purchase date.

This warranty is extended to the first consumer only and proof of purchase is necessary to honor

the warranty. If there is no proof of purchase provided with a warranty claim, Marshall Electronics

reserves the right, not to honor the warranty set forth above. Therefore, labor and parts may be

charged to you.

This warranty does not apply to product exterior and cosmetics. Misuse, abnormal service or han-

dling, improper alterations or modifications in design or construction, voids this warranty.

No sales personnel of the seller, nor any other person is authorized to make any warranties other

than those described above, or to extend the duration of any warranties on behalf of Marshall

Electronics, beyond the time period described above.

Due to constant effort to improve products and product features, specifications may change with-

out notice.

Marshall

http://www.LCDRacks.com
