V-MD1012

Dual 10.1” Rack Mount Monitor with Modular Input / Output

User Manual

V-MD1012

2User Manual v1.0

Table of Contents

1. Introduction, Installation and Setup.........................................................................................................3

2. Product Overview & Features.................................................................................................................4

3. Dimensions ............................................................................................................................................8

4. Navigation Menu ....................................................................................................................................9

4.1 Scaling Configuration Submenu...................................................................................................9

4.2 Color Configuration Submenu....................................................................................................11

4.3 Markers Configuration Submenu................................................................................................13

4.4 Filter Configuration Submenu.....................................................................................................14

4.5 Audio Configuration Submenu....................................................................................................17

4.6 Signal Analysis Configuration Submenu.....................................................................................17

4.7 User Settings Configuration Submenu .......................................................................................18

4.8 System Configuration Submenu.................................................................................................19

5. Monitor Care ........................................................................................................................................21

6. Warranty...............................................................................................................................................21

IMPORTANT SAFETY INSTRUCTIONS:

The V-MD1012 Dual Monitor with HDMI I/O and MD Slots has been tested for conformance to safety

regulations and requirements, and has been certified for international use. However, like all electronic

equipment, this unit should be used with care. Please read and follow the safety instructions to protect

yourself from possible injury and to minimize the risk of damage to the unit.

• Follow all instructions and warnings marked on this unit.

• Do not attempt to service this unit yourself, except where explained in this manual.

• Provide proper ventilation and air circulation and do not use near water.

• Keep objects that might damage the device and assure that the placement of this unit is on a stable surface.

• Use only the power adapter and power cords and connection cables designed for this unit.

• Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.

V-MD1012

3User Manual v1.0

1. Introduction, Installation and Setup

Introduction

The V-MD1012 is a dual 10.1” rack mount monitor with modular slots and HDMI I/O. This monitor offers a high resolution 1920 x

1200 LED backlit panel. Standard features include markers, 4 user-configurable front panel function buttons, RGB gain and bias

control.

Installation

This monitor can be mounted with any standard 19” equipment rack. The attached rack ears can be angled to provide the user

control overthe viewing angle. Adequate ventilation is required when installed to prevent possible damage to the monitor’s internal

components.

Package Contents

Carefully unpack the V-MD1012 monitor and verify that the following items are included:

• 1x - V-MD1012 Dual 10.1” Monitor

• 1x – 12V Power Supply

Connections, Power-On and Initial Setup

Plug the power supply into an AC power source (100-240 V @ 50/60 Hz). Attach the power connector to the back of the monitor.

Connect the required cables for video signal input and output. (Power must be applied to the V-MD1012 to activate the loop-

though output.) The monitor defaults to ‘ON’ when power is supplied. Video is automatically detected and displayed on the screen.

V-MD1012

4User Manual v1.0

2. Product Overview & Features

Top and Front Panel Features

1. Power Button

The Power Button will turn the Display ON and OFF. The LED button will dim when the power is ON. The LED is at full power in

the OFF state.

2. Input Select Button

Use the Input Select Button to select between the On-Board HDMI Input or the Module Input (when available).

3. User-Definable Function Buttons

Four user-definable function buttons can beused for direct access to various settings. Functions are assigned using the onscreen

menu or by highlighting a function and selecting that function button.

4. Menu Navigation Buttons

Use the Menu, ↑, ↓, and Select buttons to display and navigate the on-screen menu. See MAIN MENU AND NAVIGATION for

details on using the Menu.

5. Image Adjustment Knobs

Use the Image Adjustment Knobs to adjust image color saturation, brightness and contrast. The status of each adjustment is

shown on the bottom left screen, with values ranging from 0 to 100. Pressing a knob once displays the current value. Pressing a

knob twice resets the value to the default settings.

6. User Control Knob

The User Control Knob can be customized to control multiple functions. Functions can be changed in the main menu.

7. Stereo Headphone Jack

The 1/8” Headphone Jack can receive two channels of embedded HDMI or SDI Audio and will provide an Audio Signal.

V-MD1012

5User Manual v1.0

Rear Panel Features

1. Power Connector

Insert the included Power Supply Coax Cable. Optional DC sources supplying the appropriate voltage can be used as well.

2. HDMI Input and Output

The V-MD1012 has 2 HDMI Inputs and 2 Active Loop-Through Outputs. The HDMI Output is HDCP Compliant and will NOT

pass through HDCP protected content.

3. Module Slot

Use the Module Slot to install any of the compatible MD Series Modules. This functions as a second video input or output.

4. Upgrade Port

Use for upgrade / debugging purposes ONLY. Please contact Marshall Electronics before attempting to use this port.

V-MD1012

6User Manual v1.0

Specifications

Model Name

V-MD1012

Description

Dual 10.1” Rack Monitor

Panel

• Screen Size: Dual 10.1” Diagonal

• Backlight Feature: WLED

• Resolution: 1920x1200

• Contrast Ratio: 800:1

• Luminance: 800 cd/m2

• Contrast Ratio: 800:1

• Display Colors: 16.7M (8-Bit)

• Signal Interface: 8-Bit

• Viewing Angle: 85/85/85/85 (R/L/U/D)

Power Consumption

• Power Input: 12VDC

• Wattage: 30W

• No Over Voltage Protection

• No Reverse Polarity Protection

Loop-Through

• Yes

Cable Lengths

• SDI 300m/ HD 200m/ 3G 100m

Thermal Operating and Storage Temperature

• Operating Temp: 10C – 40C

• Storage Temp: 0C – 40C

Dimensions

• Vertical Hole Spacing: Pass (3RU)

• Horizontal Spacing: Pass (18.31”)

• Rack Opening: Pass (17.7”)

Tally Pinout

1 Screen

• Pin 1– Green

• Pin 2 – Red

• Pin 3 – Yellow

• Pin 4 – Ground

• Pin 5 – No Contact

Screen 2

• Pin 11 – Green

• Pin 12 – Red

• Pin 13 – Yellow

• Pin 14 – Ground

Module and Format Compatibility

MD-3GE (Modular)

• 480i 59.94Hz

• 576i 50Hz

• 720p 25Hz

• 720p 29.97Hz

• 720p 30Hz

• 720p 50Hz

• 720p 59.94Hz

• 720p 60Hz

• 1080psf 23.98Hz

• 1080psf 24Hz

• 1080p 23.98Hz

• 1080p 24z

• 1080p 29.97Hz

• 1080i 50Hz

• 1080i 60Hz

• 3G – Level A 1080p 50Hz

• 3G – Level A 1080p 59.94Hz

• 3G – Level A 1080p 60Hz

V-MD1012

7User Manual v1.0

MDO-3G (Modular)

• 720p 50Hz

• 720p 59.94Hz

• 720p 60Hz

• 1080p 23.98Hz

• 1080p 24Hz

• 1080p 25Hz

• 1080p 29.97Hz

• 1080p 30Hz

• 1080i 50Hz

• 1080i 59.94Hz

• 1080i 60Hz

• 3G – Level A 1080p 50Hz

• 3G – Level A 1080p 59.94Hz

• 3G – Level A 1080p 60Hz

*MDO-3G module output is converted from HDMI input. HDCP protected will not be looped through.

HDMI Input (Board)

• 480p 59.94Hz

• 576p 50Hz

• 720p 25Hz

• 720p 29.97Hz

• 720p 30Hz

• 720p 50Hz

• 720p 59.94Hz

• 720p 60Hz

• 1080psf 23.98Hz

• 1080psf 24Hz

• 1080p 23.98Hz

• 1080p 24Hz

• 1080p 25Hz

• 1080p 29.97Hz

• 1080p 30Hz

• 1080i 50Hz

• 3G – Level A 1080p 50Hz

• 3G – Level A 1080p 59.94Hz

• 3G – Level A 1080p 60Hz

V-MD1012

8User Manual v1.0

3. Dimensions

Dimensions

V-MD1012

9User Manual v1.0

4. Navigation Menu

Main Menu:

Push the 4 Menu Buttons or the Marshall Electronics RotoMenu™ Knob (integrated into the BRIGHT knob) to adjust the function

configurations. To change configurations, select a configuration from the main menu by turning the knob and pressing the menu

button once to select. Edit configuration by turning knob to change levels, then press menu button again to confirm the changes.

Repeat with each selection as needed. By default, the menu automatically times out after 15 seconds of being idle.

4.1 Scaling Configuration Submenu

ITEMS

OPTIONS

Scaling Configuration

Input Crop

Off, On

Aspect Ratio

Auto, Full Screen, 4:3, 16:9, Custom

Pixel-to-Pixel

Off, On

DSLR Preset

Off, NK 16:9, NK 3:2, CN 16:9

Use the Scaling Submenu to adjust how the video signal is displayed on each screen.

Input Crop

Enable the Input Crop function to select the area of active video that you would like shown on the image display. Select the

area by accessing the Adjust Function.

Input Crop Adjust

Use the BRIGHT knob to move the selection box LEFT and RIGHT.

Use the COLOR knob to move the selection box UP and DOWN.

Use the CONTRAST knob to move the right border LEFT and RIGHT.

Use the USER knob to move the bottom border UP and DOWN.

When satisfied with the position, press the SELECT button or press the BRIGHT knob to confirm selection.

V-MD1012

10 User Manual v1.0

The new cropped selection will be displayed on the screen. If Aspect Ratio is set to AUTO, the monitor will select the closest

aspect ratio to the dimensions of the customized Input.

Aspect Ratio

Use this menu option to switch between several aspect ratio settings.

• In 4:3 Mode, images are scaled up or down to fill the maximum 4:3 portion of the screen.

• In 16:9 Mode, images are scaled to fill the entire 16:9 screen.

• In Full Screen, images are scaled to fill the entire screen.

• In Custom Mode, use the adjust function to customize the image scaling.

Aspect Ratio Adjust

Use any of the rotary knobs to select your desired aspect ratio. Standard aspect ratio settings are shown on the Aspect Ratio

selection widget. Move along the scale and the current aspect ratio will be displayed below the widget.

Pixel-to-Pixel

Use this setting to enable the Pixel-to-Pixel Mode.

This mode bypasses the monitor’s internal scaling function and displays images in their native resolution and aspect ratio,

with a one-to-one mapping of incoming image pixels to screen pixels:

• For incoming formats smaller than the native resolution of the screen (or selected aspect ratio), the image will be

displayed in the center of the screen using only the necessary LCD pixels. For example, 720p images will display

exactly 1280x720 pixels in the center of the screen. The surrounding screen area will be black.

Use the Adjust Function to customize the Pixel to Pixel zone.
