Data Concentrator TELEM-GW6

User Manual

Martem AS

2010

Contents

1. MAIN TASKS 3

2. POSSIBLE APPLICATIONS 3

3. FEATURES 3

4. VIEW 4

5. TECHNICAL DATA 4

6. TYPICAL APPLICATION FOR ELECTRIC POWER STATION 6

7. SWITCHES 6

8. INDICATION 6

9. FIRMWARE UPDATE 7

10. GW6 CONFIGURATION TOOL 8

10.1 Getting Started 8

10.2 GW6 Configuration Window 9

10.3 Tab Cards in the Configuration Window 10

10.3.1 Ports Tab Card 11

10.3.2 Devices Tab Card 13

10.3.3 Objects Tab Card 15

10.3.4 Formulas Tab Card 19

10.3.5 RTA IO Tab Card 21

10.3.6 Status Tab Card 22

11. COMMON MAIN MENU 23

11.1 Analog Groups 23

11.2 TCP/IP Settings 23

11.3 Timing Settings 23

11.3 Modem Settings 24

11.5 Port Mirroring 24

12. COMMUNICATION CABLES 25

13. NOTES 26

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 3 -

1. Main Tasks

The tasks of the Data Concentrator Telem-GW6 (GW6) include the following:

•To control and monitor the system from the control center using data

communication protocols IEC 60870-5-101 and IEC 60870-5-104

•To concentrate data collection from lower level peripheral devices and

control them by using different data exchange protocols

2. Possible Applications

•Data acquisition and control of regional and national electricity utilities in

SCADA systems for remote control and substation automation

•Comprehensive integration of different devices

•As a communication gateway

3. Features

•Telem-GW6 base model includes basic card with built-in communication

ports

•Expansion card 1 and 2 are optional extras (see 5. Technical Data)

•Data concentrator with an associated event annunciator performing sub-

station level master unit functions in the substation secondary equipment

system

•Duplex data communications between the feeder and the equipment level

versus the station control level in substations using different

communication protocols and cross-referencing between the protocols

•Full scale data exchange between the levels of the substation control

system including setting values, measurement values, registered fault

parameter values, changes of state with associated time markings etc

•Data concentrator provided with serial interfaces to facilitate the

connection between local output devices and external host systems

•All the settings can be changed using software configuration tool

•Output channel to the remote control system can be connected to a leased

or a dial-up line using a copper line-, radio- or GSM modem

•Data concentrator GW6 is provided with control input for clock

synchronizing purposes using GPS

•Logical operations between digital and analog signals can be described

•Hierarchical connection is possible

•TELEM RTU devices can be remotely configured across Telem-GW6

•Microsoft Excel direct import and export facilities are in use

•A user-friendly user interface similar to MS

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 4 -

4. View

Figure 4 Telem-GW6 view

5. Technical Data

Data communication protocols

•To higher or lower level systems IEC 60870-5-101 or IEC 60870-5-104

•To lower level devices IEC 61850, IEC 60870-5-103, IEC 60870-5-101

Unbalanced, SPA-bus, IEC 62056-21 (IEC 1107), Modbus-RTU

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 5 -

Communication ports

Communication ports may be freely configured for upper or lower level

communication

Built-in

•1x Ethernet connection with RJ45 connector

•1x RS-232 full modem serial connection with RJ45 connector

•1x RS-422 serial connection with RJ45 connector

•1x USB connection with Type B connector

Expansion card 1

•1x Fiber-optic connection with ST or Versalink connectors

•1x RS-232 with RTS, CTS handshake signal serial connection with

RJ45 optically isolated connector

•1x RS-485 serial connection with RJ45 optically isolated connector

•1x GPS Fiber-optic connection with Versalink connector

Expansion card 2

•8x RS-232 serial connections with RJ45 connectors

Data communication parameters

•1 start bit

•Odd, even or no parity

•Communication rates from 300 to 115200 bit/sec

•Configurable RTS/CTS handshake for all RS-232 ports.

Electrical characteristics of isolated input

•Dielectric withstand IEC 60255-5

•Withstand to static discharge IEC 61000-4-2

•Withstand to surges, bursts IEC 61000-4-4, 61000-4-5

Mechanical parameters

•Degree of protection IP 32

•Dimensions (W x H x D) ~ 84 x 107 x 164

•Ambient temperature in operation –20…+50°C

•Weight ~ 1kg

•Mounting DIN rail

Power supply

•Supply voltage range 10 to 32 V DC

•Power consumption < 8 VA

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 6 -

6. Typical Application for Electric Power Station

7. Switches

1 – Reset: Switch RESET to ON state and then back to OFF state for Reset

operation

2 – Dft. Set: To apply default setup:

1. Switch DFT. SET to ON state

*Alert indication LED starts blinking with 5 second interval

2. Switch DFT. SET back to OFF state when the alert indication LED is

blinking to apply default setup

*If DFT. SET is switched back to OFF state at a moment when the alert

indication LED is not blinking, default setup will NOT be applied

8. Indication

For operation

Green LED – Blinking green indicates that the program is running

Red LED – Failure

For communication

Yellow LED – RX

Green LED – TX

Green LED at GPS port – blinking indicates the existence of GPS time

synchronization.

Reset

Dft. set

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 7 -

9. Firmware Update

Loading GW6 firmware is done through Secure Digital (SD) Memory Card

slot.

Updating firmware:

1. Connect Secure Digital (SD) Memory Card to your computer

2. Extract the compressed firmware update file (provided by Martem AS)

to your SD Memory Card

3. Disconnect the card from your computer

4. Insert the card to Telem-GW6 SD Memory Card slot

* SD Memory Card slot is located at the back of the device

5. Perform reset operation to Telem-GW6 device

6. Wait until the device resumes to it’s normal operation state

7. Firmware update is complete. Remove the SD Memory Card and check

if firmfare update was successful

Checking results of the firmware update operation:

1. Connect the SD Memory Card to your computer

2. Open the folder you extracted earlier

3. Check if the file “res.txt” is present and open it

4. Check the state of installed files at the last part of the file

*If the state of update files is OK - firmware update was successful

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 8 -

10. GW6 Configuration Tool

10.1 Getting Started

When starting the GW6 configuration program, user interface window with the

main menu is opened:

Figure 10. 1.1 User interface window

The following parameters are shown for information:

•Port – PC port which is used to communicate with GW6

•Link address – Link address of GW6

•ASDU address – ASDU address of GW6

•Status –Status of the connection. RED – no connection, GREEN –

connection OK

Main menu

•Device –For selecting the device type

•Communication Setup - For changing communication parameters.

Figure 10.1.2. Communication parameters window

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 9 -

Fields in the communication parameters window

•Port – PC communication port which is used to communicate with GW6

•Baud rate – Data communication rate

•Parity – Use of parity control bit

•

Flow control – Determines whether the RTS/CTS handshaking is used

•Communication delay – Delay between reception of data and the next

query in milliseconds

•Link address – Link address of GW6

•ASDU address – ASDUI address of GW6

•ASDU address length – The length of the ASDU address in bytes:

typically 2, possible values are 1 or 2.

•Object address length – Length in bytes. Typically 2, possible values are

1, 2 or 3.

10.2 GW6 Configuration Window

To open the GW6 configuration window, select Device > GW6 / RTA-A from

the user interface main menu.

Shortcut icons below the menu bar:

Open a new configuration

Open a configuration file

Save the configuration to a file

Read the configuration from GW6

Write the configuration to GW6

*Reset GW6

* Possible Reset codes:

1 – Simple Reset

2 – Reset that also clears memory buffers

3 – Reset that also restores the default setup

Saving, editing and opening configuration data

Configuration data is saved to the hard disk in the form of comma separated

files*.CSV files when the Save or Save As command is chosen from the File

menu. Correspondingly, the Open command from the File menu opens this

type of file. Open and Save can also be accessed via shortcut icons.

*.CSV files can be conveniently edited with Excel software or even with the

Note Pad program. When editing the configuration with Excel, the file has to

be saved as a comma separated CSV file.

AS Martem Data Concentrator TELEM-GW6 User Manual

Akadeemia tee 21G Tel: +372 639 79 79 E-mail: martem@martem.eu

12618 Tallinn Fax: +379 639 79 80 www.martem.eu

Estonia

- 10 -

Table of configuration window menu items

Main menu File Common View Help

Submenu

(Shortcut key)

New (Ctrl+N)

Read

Configuration Basic Help (F1)

Open(Ctrl+O) Write

Configuration Advanced About

Save (Ctrl+S) Cancel Active

Transfer

Save As Send Reset

Exit Analog

Groups

Tcp/Ip

Settings

Timing

Settings

Modem

Settings

Port Mirroring

Options

10.3 Tab Cards in the Configuration Window

Configuration and setting parameters can be utilized by using topic tab cards:

Ports, Devices, Objects, Formulas, RTA IO, Status.

A click on a tab card button switches between tab cards.

Using the grid area

Parameters can be selected or changed in the grid area cells. Values of some

cells can be changed directly and those of others via a list box or a popup

window.

Values of the same column can be copied to clipboard. Use a left mouse click

together with the Shift key to copy and a left mouse click together with the Ctrl

key for paste operation.

Status message in the bottom left corner of the window shows the result of the

last data modification action (OK, Error, etc).

Inhaltsverzeichnis

Andere Martem Netzwerk-Hardware Handbücher

Martem

Martem TELEM-AGC Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
