LE1200

Active/passive, low profile, high power, differential

dispersion stage monitor

features

Very high output, ultra-compact, low profile stage monitor

Single 12" (300mm) ultra-long excursion high power, neodymium motor

bass driver

1.4" (35mm) exit pure titanium dome, neodymium

motor compression driver

Optimised constant directivity differential dispersion HF horn

Contemporary design multi-laminate ply and hardwood cabinet

Active/passive crossover operation via external switch

Frequency response 64Hz-18kHz ±3dB, -10dB @ 54Hz

Discreet connectors

Fitted with 4 x M8 rigging inserts

Left or Right handed versions available

applications

High power stage monitor

Flown infill via optional yoke

Century Point, Halifax Road, Cressex Business Park,

High Wycombe, Buckinghamshire HP12 3SL, England.

Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669

E-mail: [email protected]

The Martin Audio LE1200 is an ultra-compact, high performance stage

monitor which combines maximum enclosure volume with optimum

presentation angle in a low profile, contemporary design. It features a

high-specification 12" (300mm) low frequency drive unit and a 1.4"

(35mm) exit compression driver mounted on a differential dispersion

horn. Differential dispersion technology increases the area over which a

constant SPL and consistent frequency response is maintained at ear

height, enabling the artist to move around more freely.

The LE1200 is best used with the DX1 controller. When driven actively,

the DX1 provides crossover, limiting and EQ functions. When operated

in passive mode the LE1200 benefits from the EQ and limiting functions

of the DX1. This ensures that both active and passive configurations will

exhibit the same tonal balance when used together on stage.

www.martin-audio.com

overall dimensions

technical specifications

TYPE Two-way reflex active/passive stage monitor

with differential dispersion HF horn

FREQUENCY RESPONSE (1) 64Hz-18kHz ± 3dB

-10dB @ 54Hz

DRIVERS 12" (300mm)/3" (75mm) voice coil, ultra-long

excursion, water resistant cone

1.4" (35mm) exit, 3" (75mm) voice coil titanium

dome HF compression driver

RATED POWER (2) FR/LF: 400W AES, 1600W peak

HF: 80W AES, 320W peak

RECOMMENDED AMPLIFIER 500-700W into 4 ohms

SENSITIVITY (3) FR: 97dB

LF: 98dB

HF: 106dB

MAXIMUM SPL FR: 123dB continuous, 129dB peak

(calculated @ 1m) LF: 124dB continuous, 130dB peak

HF: 125dB continuous, 131dB peak

NOMINAL IMPEDANCE FR/LF: 8 ohms

HF: 16 ohms

DISPERSION (-6dB) 60º - 100º horizontal (differential dispersion)

60º vertical

CROSSOVER 1.3kHz active/passive (switchable)

ENCLOSURE 40 litres

FINISH Textured black paint

PROTECTIVE GRILLE Black perforated steel

CONNECTORS 2 x Neutrik NL4

FITTINGS 4 x skids

4 x M8 inserts

DIMENSIONS (W) 596mm x (H) 292mm x (D) 469mm

(W) 23.5ins x (H) 11.5ins x (D) 18.5ins

WEIGHT 20.5kg (45lbs)

touring and theatre
