Martin Audio W1 Bedienungsanleitung

WW11

Ultra-compact two-way trapezoid system

features

Ultra-compact trapezoid enclosure

High SPL output capability

70º coverage angle

Multi-laminate birch plywood construction

10" (250mm) LF/1" (25mm) HF driver combination

applications

Audio-visual presentations

Theatre sound systems

Club sound reinforcement

Distributed sound systems

Live sound infill system

Century Point, Halifax Road, Cressex Business Park,

High Wycombe, Buckinghamshire HP12 3SL, England.

Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669

E-mail: [email protected]

All information is Copyright © 2006 Martin Audio Ltd.

The Martin W1 Wavefront system is a high performance, ultra-

compact loudspeaker designed for specific applications where

both high output capability and small size are required. Typical

uses include audio-visual presentations and theatre sound. The

W1 features a 10" (250mm) bass driver and 1" (25mm) exit

compression driver housed in a rugged plywood enclosure built

using the same construction techniques as larger Martin touring

systems. Its 2-way passive configuration simplifies operation,

ensures predictable system performance and reduces amplifier

count.

www.martin-audio.com

overall dimensions

technical specifications

TYPE Ultra-compact two-way passive trapezoid

FREQUENCY RESPONSE (5) 75Hz-18kHz ± 3dB

-10dB @ 55Hz

DRIVERS 10" (250mm) bass driver

1" (25mm) exit HF compression driver

RATED POWER (2) 150W AES, 600W peak

RECOMMENDED AMPLIFIER 300-400W into 4 ohms

SENSITIVITY (6) 97dB

MAXIMUM SPL (7) 118dB continuous, 124dB peak

NOMINAL IMPEDANCE 8 ohms

DISPERSION (-6dB) 70º horizontal, 40º vertical

CROSSOVER 2.2kHz passive

FINISH Textured grey paint

PROTECTIVE GRILLE Grey perforated steel

CONNECTORS 2 x Neutrik NL4

FITTINGS 12 x M8 threaded inserts

1 x mounting pole socket

DIMENSIONS (W) 335mm x (H) 487mm x (D) 325mm

(W) 13.2ins x (H) 19.2ins x (D) 12.8ins

WEIGHT 14.5kg (32lbs)

touring and theatre
