Martin Audio WS18X Bedienungsanleitung

WWSS1188XX

1000 watt vented sub-bass system

features

Direct radiating, long excursion 18” (460mm) driver

High temperature 4” (100mm) voice coil

High power 132dB continuous, 138dB peak

Fitted with integral handles and castors

applications

Theatre sound systems

Small to medium touring systems

Club sound reinforcement

Special effects sub-bass

Century Point, Halifax Road, Cressex Business Park,

High Wycombe, Buckinghamshire HP12 3SL, England.

Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669

E-mail: [email protected]

All information is Copyright © 2007 Martin Audio Ltd.

The WS18X is a high performance sub-bass system designed

for use with small to medium Wavefront systems, in both

touring and install applications. It features a 1000 watt 18"

(460mm) drive unit with magnet structure and suspension

engineered for maximum linear excursion. The birch ply cabinet

is fitted with four pocket handles and four 4" (100mm) castors

for easy deployment. It features large area porting to reduce air

noise. A top hat fitting allows mid-top cabinets to be mounted

on the WS18X using the HAM09015 adjustable pole. WS18X

subwoofers are designed to be powered by Martin Audio

MA9.6K or MA4.2s amplifiers.

www.martin-audio.com

overall dimensions

technical specifications

TYPE Compact, vented sub-bass system

FREQUENCY RESPONSE (1) 35Hz-150Hz ± 3dB, -10dB @ 28Hz

DRIVER 18" (460mm)/4" (100mm) voice coil, ultra-long

excursion, water resistant cone

RATED POWER (2) 1000W AES, 4000W peak

SENSITIVITY (3) 102dB (half space)

MAXIMUM SPL (4) 132dB continuous, 138dB peak (half space)

NOMINAL IMPEDANCE 8 ohms

CROSSOVER 80Hz-150Hz, via DX1 or DX2 controller

ENCLOSURE 160 litre, multi-laminate birch ply

FINISH Textured black paint

PROTECTIVE GRILLE Black perforated steel

CONNECTORS 2 x Neutrik NL8

PIN CONNECTIONS LF+, -: 1+, 1- & 2+, 2-

Link thro’: 3+, 3-, 4+, 4-

FITTINGS 4 x 4" (100mm) castors

4 x pocket handles

2 x front lid fittings

1 x mounting pole socket

DIMENSIONS (inc. wheels) (W) 561mm x (H) 533mm x (D) 780mm (911mm)

(W) 22.1ins x (H) 21ins x (D) 30.7ins (35.9ins)

WEIGHT 52.5kg (116lbs)

touring and theatre
