OWNERS GUIDE

MARVEL UNDERCOUNTER REFRIGERATION

THE ORIGINAL REFRIGERATION EXPERTS SINCE 1892

FOR MODEL # MLRE224

OWNER'S GUIDE

MARVEL UNDERCOUNTER REFRIGERATION

THE ORIGINAL REFRIGERATION EXPERTS SINCE 1892

FOR MODEL # MLCL215

Welcome to the Marvel Experience

Congratulations on your purchase of the industry's quietest

clear ice machine with the best ice clarity and purity. Your

new investment is protected by a limited warranty for the

rst year, and hermetically sealed refrigeration system parts

are covered for an additional 4 years.

Here's your guide to the operation and maintenance of your

Marvel Clear Ice Machine to ensure years of enjoyment. If

you have any questions, please contact Marvel Customer

Service or Tech Support at:

Phone: (616) 754-5601

Email:

• Customer Service: [email protected]

• Tech Support: [email protected]

Got a Marvelous Design?

We would love to see how your Marvel product looks in its

new home. Send us photos at marketing@marvelrefrigera-

tion.com, and we might feature your Marvel home design

on our website and social media!

Thank you for investing in Marvel for your home!

WELCOME

XXXXXXXXXXXX

MARVEL

R600A

It is important you send in your warranty registration card

immediately after taking delivery of your appliance or you

can register online at www.marvelrefrigeration.com.

The following information will

be required when registering

your appliance:

Service Number

Serial Number

Date of Purchase

Dealer’s name and address

The service number and serial number can be found on the

serial plate which is located inside the cabinet on the left

side near the top.

Warranty Registration

Online registra-

tion available at

www.marvelrefrig-

eration.com

TABLE OF CONTENTS

Tip: Click on any section below to jump directly there

Safety

Important Safety Instructions

Installation

Unpacking Your Appliance

Electrical

Cutout & Product Dimensions

Side-by-Side & Stacking Installations

Integrated Panel Installation

Installing The Water Supply

Maintenance

Stainless Steel Maintenance

Service

Obtaining Service

Product Liability

Warranty Claims

Ordering Replacement Parts

System Diagnosis Guide

Compressor Specifications

Warranty

NOTE

!CAUTION

Important Safety Instructions

Warnings and safety instructions appearing in this guide

are not meant to cover all possible conditions and situa-

tions that may occur. Common sense, caution, and care

must be exercised when installing, maintaining, or operat-

ing this appliance.

Recognize Safety Symbols,

Words, and Labels.

CAUTION-Hazards or unsafe practices which could re-

sult in personal injury or property / product damage.

NOTE-Important information to help assure a problem

free installation and operation.

IMPORTANT SAFETY INSTRUCTIONS

!WARNING

WARNING - You can be killed or seriously injured

if you do not follow these instructions.

!WARNING

State of California Proposition 65 Warning:

This product contains one or more chemicals known

to the State of California to cause cancer.

!WARNING

State of California Proposition 65 Warning:

This product contains one or more chemicals known

to the State of California to cause birth defects or

other reproductive harm.

!WARNING

WARNING - This unit contains R600a (Isobutane)

which is a ammable hydrocarbon. It is safe for regular

use. Do not use sharp objects to expedite defrosting.

Do not damage refrigerant circuit.

NOTE

!WARNING

WARNING - Dispose of the plastic bags which can

be a su󰀨ocation hazard.

UNPACKING YOUR APPLIANCE

!CAUTION

!WARNING

WARNING - Help Prevent Tragedies

Child entrapment and su󰀨ocation are not problems of

the past. Junked or abandoned refrigerators are still

dangerous - even if they sit out for "just a few hours".

If you are getting rid of your old refrigerator, please fol-

low the instructions below to help prevent accidents.

Before you throw away your old refrigerator or freezer:

• Take o󰀨 the doors or remove the drawers.

• Leave the shelves in place so children may not

easily climb inside.

!WARNING

EXCESSIVE WEIGHT HAZARD

Use two or more people to move product.

Failure to do so can result in personal injury.

Remove Interior Packaging

Your appliance has been packed for shipment with all parts

that could be damaged by movement securely fastened.

Remove internal packing materials and any tape holding in-

ternal components in place. The owners manual is shipped

inside the product in a plastic bag along with the warranty

registration card, and other accessory items.

Important

Keep your carton and packaging until your appliance has

been thoroughly inspected and found to be in good condi-

tion. If there is damage, the packaging will be needed as

proof of damage in transit. Afterwards please dispose of all

items responsibly.

Note to Customer

This merchandise was carefully packed and thoroughly

inspected before leaving our plant. Responsibility for its

safe delivery was assumed by the retailer upon acceptance

of the shipment. Claims for loss or damage sustained in

transit must be made to the retailer.

DO NOT RETURN DAMAGED MERCHANDISE TO THE

MANUFACTURER - FILE THE CLAIM WITH THE

RETAILER.

If the appliance was shipped, handled, or stored in other

than an upright position for any period of time, allow the ap-

pliance to sit upright for a period of at least 24 hours before

plugging in. This will assure oil returns to the compressor.

Plugging the appliance in immediately may cause damage

to internal parts.

Electrical Connection

A grounded 115 volt, 15 amp dedicated circuit is required.

This product is factory equipped with a power supply

cord that has a three-pronged, grounded plug. It must be

plugged into a mating grounding type receptacle in ac-

cordance with the National Electrical Code and applicable

local codes and ordinances (see gure below). If the circuit

does not have a grounding type receptacle, it is the respon-

sibility and obligation of the customer to provide the proper

power supply. The third ground prong should not, under

any circumstances, be cut or removed.

NOTE

Ground Fault Circuit Interrupters (GFCI) are prone to nui-

sance tripping which will cause the appliance to shut down.

GFCI’s are generally not used on circuits with power equip-

ment that must run unattended for long periods of time, un-

less required to meet local building codes and ordinances.

ELECTRICAL

Do not remove

ground prong

Electrical Shock Hazard

• Do not use an extension cord with this appliance.

They can be hazardous and can degrade product

performance.

• This appliance should not, under any circumstanc-

es, be installed to an ungrounded electrical supply.

• Do not remove the grounding prong from the power

cord.

• Do not use an adapter.

• Do not splash or spray water from a hose on the

appliance. Doing so may cause an electrical shock,

which may result in severe injury or death.

!WARNING

"C"

CUTOUT AND PRODUCT DIMENSIONS

"A"

"B"

"D"

"E" Solid door

shown

If necessary, to gain clearance inside the rough-in

opening, a hole can be cut through the adjacent

cabinet and the power cord routed through this hole to

a power outlet. Another way to increase the available

opening depth is to recess the power outlet into the

rear wall to gain the thickness of the power cord plug.

Not all recessed outlet boxes will work for this applica-

tion as they are too narrow, but a recessed outlet box

equivalent to Arlington #DVFR1W is recommended for



ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS

"A" "B" "C" "D" "E" "F" "G" "H" "J"

15"







24"







34" to 35"



3 

(60

5 

4.7

  

4.9 2.2

5138"16 

"D"

"E"

"F"

"G"

"H"

"J"

CUTOUT AND PRODUCT DIMENSIONS

PRODUCT DATA

ELECTRICAL

REQUIREMENTS #

PRODUCT

WEIGHT

115V/60Hz/15A 105 lbs



** Minimum rough-in opening required is to be larger than

the adjusted height of the cabinet.

# A grounded 15 amp dedicated circuit is required. Follow

all local building codes when installing electrical and appli-

ance.

312

Minimum

Glass door

shown

2112"



SIDE-BY-SIDE AND STACKING INSTALLATIONS

Side-by-Side Installation

Other Site Requirements

Units must operate from separate, properly grounded elec-

trical receptacles placed according to each unit's electrical

specications requirements.

Cutout width for a side-by-side installation is the total of the

widths listed under Cutout Dimensions in each unit's Instal-

lation Guide. Each door can be opened individually (one at

a time) without interference.

Figure 10

However, to ensure unobstructed door swing (opening both

doors at the same time), 1/4" (6.4 mm) of space needs to

be maintained between the units.

Hinge-by-Hinge Installation (Mullion)

When installing two units hinge-by-hinge, 13/16" (22 mm)

is required for integrated models. Additional space may be

needed for any knobs, pulls or handles installed.

Stainless steel models which include the standard stainless

handle will require 4-9/16" (116 mm) to allow both doors to

open to 90° at the same time.

Figure 11

Figure 12

Figure 13

!CAUTION

Step 1: Removing the Door and Hinges

Hold the door secure in the closed position and remove

Hinge Pin from the Upper Hinge using a 1/8” Hex Key tool.

Slowly remove the door by sliding outward away from the

󰀨

the door, remove hinges from cabinet per Door Reversal



Remove the hinge bushing from the adaptor plate. A new

bushing is included in the literature pack with your unit.

Cut and prepare panels according to the information







through the condenser. The use of a custom grille is not

recommended and will void the warranty.

INTEGRATED DOOR PANEL INSTALLATION

Step 2: Remove the Door Gasket



corner of the door, remove the magnetic door gasket from



surface.

There are 10 holes in the gasket retainer extrusions (3 on

each side and 2 at the top and bottom) which are used to

fasten the panel to the front of the door. The screws are

provided in the literature pack.

Step 3: Assemble the Panel to the Door

The preferred method of attaching the panel to the door

is to clamp the panel to the door so it cannot move while

drilling the screw pilot holes. Use bar clamps or "C" clamps

with pads on the clamping surfaces that will not mar the



the top of the door and centered along the width of the

door. Drill holes through the gasket extrusion using the 10

holes as pilot holes. Use the drill size from the chart in the

table below being careful not to drill through the front sur-

face of the panel. Fasten the panel to the door with the 10

screws provided in the literature pack. Remove the clamps

and replace the gasket in the gasket extrusion channels of

the door. Some force may be required to seat the gasket

into the channels. Be sure the gasket corners are seated

properly.





door





door

Holes in gasket

container

Material Type #10 Wood Screw

Hardwood ¹" (3.2 mm) Diameter. Pilot Hole

Softwood  (2.8 mm) Diameter. Pilot Hole

Andere Handbücher für MLCL215

Inhaltsverzeichnis

Andere Marvel Kühlschrank Handbücher

Marvel

Marvel MLNP115-IG01A Bedienungsanleitung

Marvel

Marvel 8SBARE-BD Bedienungsanleitung

Marvel

Marvel MLRE124-SS21A Bedienungsanleitung

Marvel

Marvel 6OHKSSF Leitfaden

Marvel

Marvel MARE224-SS41A Bedienungsanleitung

Marvel

Marvel MLCR215-SS01B Bedienungsanleitung

Marvel

Marvel MPBD424-IG31A Bedienungsanleitung

Marvel

Marvel 6BARM-BN Benutzerhandbuch

Marvel

Marvel MACL415 Bedienungsanleitung

Marvel

Marvel Refrigerated Wine Cellar 3SWCE Handbuch

Marvel

Marvel MPWD424-IS31A Bedienungsanleitung

Marvel

Marvel 4570105 Bedienungsanleitung

Marvel

Marvel 66BWM-BD Bedienungsanleitung

Marvel

Marvel 8SBAR-BN Bedienungsanleitung

Marvel

Marvel MPWC424-IS31A Bedienungsanleitung

Marvel

Marvel MLWD224-SG01A Bedienungsanleitung

Marvel

Marvel 6OBARMSSFR Handbuch

Marvel

Marvel MPRE424IS31A Bedienungsanleitung

Marvel

Marvel 61RF-BB-F Bedienungsanleitung

Marvel

Marvel MORE124 Bedienungsanleitung

Marvel

Marvel 3SBARE-BN Bedienungsanleitung

Marvel

Marvel 6OCIM-SS-F Leitfaden

Marvel

Marvel MLCR215 Bedienungsanleitung

Marvel

Marvel 66SBWE-BN Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
