Maytag MDG76PCBWW Bedienungsanleitung

MDG76PC

(Phase 7.3 Coin Gas DSI)

Installation Manual

WARNING: Foryoursafetytheinformationin

thismanualmustbefollowedtominimizetherisk

of fire or explosion or to prevent property

damage,personalinjury or death.

— Donot storeor usegasoline orother flammable

vapors and liquids in the vicinity of this or any

otherappliance.

— WHATTODO IFYOU SMELLGAS:

• Donottryto lightanyappliance.

• Donottouch anyelectricalswitch; do not

useanyphoneinyourbuilding.

• Cleartheroom, buildingorareaof all

occupants.

• Immediatelycallyourgassupplierfroma

neighbor’sphone. Followthe gas supplier’s

instructions.

• Ifyoucannotreach yourgassupplier,call

thefiredepartment.

— Installationand servicemust beperformed bya

qualified installer, service agency or the gas

supplier.

AVERTISSEMENT: Assurez-vous de bien

suivrelesinstructionsdonnéesdanscettenotice

pourréduire auminimum lerisque d’incendie

ou d’explosion ou pour éviter tout dommage

matériel,touteblessureou lamort.

— Ne pas entreposer ni utiliser d’essence ni

d’autres vapeurs ou liquides inflammables à

proximité de cet appareil ou de tout autre

appareil.

— QUEFAIRESIVOUSSENTEZUNEODEUR

DEGAZ:

• Nepastenter d’allumerd’appareils.

• Netouchez àaucun interrupteur. Ne pas

vousservirdes téléphonesse trouvant dans

lebâtiment.

• Évacuezlapièce,le bâtimentoulazone.

• Appelezimmédiatementvotrefournisseur

degazdepuisunvoisin. Suivez les

instructionsdufournisseur.

• Sivousnepouvezrejoindrelefournisseur

degaz,appelez leservice des incendies.

— L’installationetl’entretiendoiventêtreassuréspar

uninstallateurou unserviced’entretienqualifié

ouparle fournisseurdegaz.

040703JEV/mcronan PartNo.113184

RETAINTHESEINSTRUCTIONSINASAFE

PLACE FOR FUTURE REFERENCE

“IMPORTANTNOTETOPURCHASER”

Informationmustbeobtainedfromyourlocalgassupplierontheinstructions

tobefollowed iftheuser smellsgas. Theseinstructions mustbeposted ina

prominentlocationnearthedryer.

FORYOUR SAFETY

Donot store or use gasolineor

otherflammablevaporsand

liquidsinthevicinityofthisor

anyotherappliance.

POURVOTRESÉCURITÉ

Nepas entreposer niutiliser d’essence

nid’autresvapeursouliquides

inflammablesàproximitédecet

appareilou detout autre appareil.

Retain This Manual In ASafe Place For Future Reference

Our products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will

provide many years of safe, efficient, and trouble free operation.

ONLY qualified technicians should service this equipment.

OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with

the dryer.

The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.

We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer reserves the

right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to

change or discontinue models.

Important

For your convenience, log the following information:

DATE OFPURCHASE________________________________ MODELNO. __________________________________________

DEALER’SNAME __________________________________________________________________________________________

Serial Number(s) ________________________________________________________________________________________

________________________________________________________________________________________

For replacement parts, contact the dealer from which the dryer was purchased or contact:

MAYTAG CO.

403 West Fourth Street North

Newton, Iowa 50208

(641)787-7000

IMPORTANT

YOUMUSTDISCONNECTANDLOCKOUTTHEELECTRICSUPPLYANDTHEGAS

SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE

MACHINETOALLOWACCESSFORCLEANING,ADJUSTING,INSTALLATION,OR

TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health

Administration)STANDARDS.

WARNING

CHILDRENSHOULD NOTBEALLOWEDTOPLAYONORNEARTHEDRYER(S).

CHILDRENSHOULDBESUPERVISEDIFNEARDRYERSINOPERATION.

CAUTION

DRYERSSHOULDNEVERBELEFTUNATTENDEDWHILEINOPERATION.

FORYOURSAFETY

DONOTDRYMOPHEADSINTHEDRYER.

DONOTUSEDRYERINTHEPRESENCEOFDRYCLEANINGFUMES.

WARNING

UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch,

or the heat circuit devices ever be disabled.

“Caution: Label all wires prior to

disconnection when servicing controls. Wiring

errors can cause improper operation.”

«Attention: Au moment de l’entretien des

commandes,étiqueteztouslesfilsavantde

les débrancher. Des erreurs de câblage

peuvent entraîner un fonctionnement

inadéquatetdangereux.»

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panelsremoved. PERSONALINJURYORFIRECOULDRESULT.

IMPORTANT

PLEASEOBSERVEALLSAFETYPRECAUTIONSdisplayedontheequipmentand/or

specified in the installation manual included with the dryer.

Dryer mustnot beinstalled or stored in an area where it willbe exposed to water or weather.

The wiring diagram for the dryer is located in the front electrical control box area.

DRYER MUST NEVER BEOPERATEDWITHOUTTHELINTFILTER/SCREENIN

PLACE,EVENIFANEXTERNALLINTCOLLECTIONSYSTEMISUSED.

WARNING

IMPORTANT

Dryer must be installed in a location/environment, which the ambient temperature

remains between 40° F (4.44° C) and 130° F (54.44° C).

SECTION I

IMPORTANT INFORMATION ...............................................................................3

A. ReceivingandHandling ............................................................................................................... 3

B. SafetyPrecautions ...................................................................................................................... 4

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION.....................................6

A. Specifications ............................................................................................................................. 6

B. ComponentIdentification ............................................................................................................ 8

SECTION III

INSTALLATION PROCEDURES .........................................................................10

A. LocationRequirements ............................................................................................................. 10

B. Unpacking/SettingUp ............................................................................................................... 11

C. DryerEnclosureRequirements .................................................................................................. 13

D. FreshAirSupplyRequirements ................................................................................................. 14

E. ExhaustRequirements ............................................................................................................... 15

F. ElectricalInformation ................................................................................................................ 19

G. GasInformation ........................................................................................................................ 23

H. Preparation ForOperation/Start-Up ......................................................................................... 27

I. PreoperationalTests ................................................................................................................. 28

J. PreoperationalInstructions ........................................................................................................ 30

K. ShutdownInstructions............................................................................................................... 30

SECTION IV

ROUTINE MAINTENANCE ..................................................................................31

A. Cleaning ................................................................................................................................... 31

B. Adjustments ............................................................................................................................. 32

C. Lubrication ............................................................................................................................... 32

Table of Contents

SECTION V

DATA LABEL INFORMATION .............................................................................33

A. DataLabel ............................................................................................................................... 33

SECTION VI

PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT

COMPONENTS........................................................................................................35

SECTIONI

IMPORTANTINFORMATION

A. RECEIVINGAND HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or

optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and

wooden skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect

further before delivering carrier leaves.

Dryers damaged in shipment:

1. ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the trucker’s receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers, which were not damaged in a

damaged shipment, should be accepted, but the number received and the number refused must be noted

on the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the

delivering carrier’s freight terminal immediately and file a claim. The freight company considers this

concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult

when more than a day or two passes after the freight was delivered. It is your responsibility to file freight

claims. Dryer/parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.

Manufacturer assumes no responsibility for freight claims or damages.

IMPORTANT: The dryermustbe transportedand handledinan uprightposition at ALLtimes.

B. SAFETY PRECAUTIONS

WARNING: Foryoursafety,theinformationinthismanualmustbefollowedto minimize theriskof

fireorexplosion ortoprevent propertydamage,personal injury,or lossoflife.

WARNING: Thedryermust neverbe operated with anyoftheback guards, outer tops, or

servicepanelsremoved. PERSONALINJURYOR FIRE COULDRESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the

user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS...

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALLoccupants.

e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryer(s) must be exhausted to the outdoors.

6. Although Maytag produces a very versatile dryer, there are some articles that, due to fabric composition or

cleaning method, should not be dried in it.

WARNING: Dryonly waterwashed fabrics. DONOT dry articlesspotted orwashed indry cleaning

solvents,acombustibledetergent,or“all purpose”cleaner.

EXPLOSIONCOULDRESULT.

WARNING: DONOT dry ragsor articlescoated orcontaminated withgasoline, kerosene,oil, paint,

orwax.

EXPLOSIONCOULDRESULT.

WARNING: DONOTdrymop heads. Contaminationbywax orflammable solventswillcreate a

firehazard.

WARNING: DONOT useheat fordrying articlesthat containplastic, foam, spongerubber,or

similarlytexturedrubbermaterials. Dryinginaheatedbasket (tumbler)maydamage

plasticsor rubberand maybe afire hazard.

7. A program shouldbeestablished for the inspection and cleaning of lint in the burner area, exhaust ductwork,

and area around the back of the dryer. The frequency of inspection and cleaning can best be determined

from experience at each location.

WARNING: Thecollectionof lintinthe burnerareaandexhaust ductworkcancreate a potentialfire

hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the Canadian Electrical

Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE: Failureto dosowillVOIDTHEWARRANTY.

9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or the heat circuit

devices ever be disabled.

WARNING: PERSONALINJURYORFIRE COULDRESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING: Articlesleftin the dryerafterthedrying and coolingcycleshavebeen completedcan

createa firehazard.

12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE

DRYER.

13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less

than sixty-six percent (66%), 50 lbs (22 kg) of its rated capacity.

WARNING: YOUMUSTDISCONNECTAND LOCKOUTTHE ELECTRICSUPPLYAND

THEGAS SUPPLYORTHESTEAMSUPPLYBEFOREANYCOVERS OR

GUARDSARE REMOVEDFROMTHE MACHINETOALLOWACCESS

FORCLEANING,ADJUSTING,INSTALLATION,ORTESTINGOFANY

EQUIPMENTPEROSHA(Occupational Safety andHealthAdministration)

STANDARDS.

IMPORTANT: Dryer mustbeinstalledina location/environment,which theambient

temperatureremains between 40°F(4.44° C) and130°F (54.44° C).

SECTIONII

SPECIFICATIONS/COMPONENTIDENTIFICATION

A. SPECIFICATIONS

Gas

Shaded areas are stated in metric equivalents

* A minimum of 3/4” pipe must be supplied to the gas inlet for each dryer.

NOTE: Manufacturerreservestherightto make changesinspecificationsatanytime withoutnoticeor

obligation.

052103

BASKET (TUMBLER) DIAMETER 44-1/2” 113.03 cm

BASKET (TUMBLER) DEPTH 24-7/8” 63.18 cm

BASKET

(TUMBLER) MOTOR 1 hp 0.746 kW

DOOR OPENING (DIAMETER) 31-3/8” 79.7 cm

BASKET (TUMBLER) VOLUME 22.4 cu.ft. 0.634 cu.m.

VOLTAGE AVAILABLE 120v 1ø, 60 Hz

HEAT INPUT 204,000 Btu/hr 51,408 kcal/hr

AIRFLOW 1,200 cfm 33.98 cmm

INLET PIPE CONNECTION 3/4” F.N.P.T.*

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Maytag Trockner Handbücher

Maytag

Maytag MD-15 Bedienungsanleitung

Maytag

Maytag NED7200TW Handbuch

Maytag

Maytag MDG120 Bedienungsanleitung

Maytag

Maytag MGD5801TW0 Bedienungsanleitung

Maytag

Maytag MDG2706AWW Bedienungsanleitung

Maytag

Maytag Performa Intellidry PYEG4500 Bedienungsanleitung

Maytag

Maytag MEDZ600TB2 Bedienungsanleitung

Maytag

Maytag MGDE500VF0 Bedienungsanleitung

Maytag

Maytag GBMDC 709T Bedienungsanleitung

Maytag

Maytag NEPTUNE MD68 Bedienungsanleitung

Maytag

Maytag MDE20PDAGW Bedienungsanleitung

Maytag

Maytag MDE28PDCZW Bedienungsanleitung

Maytag

Maytag MED5707TQ0 Bedienungsanleitung

Maytag

Maytag MED9700SB0 Bedienungsanleitung

Maytag

Maytag MDG28PN Bedienungsanleitung

Maytag

Maytag MDG30PNHWW Bedienungsanleitung

Maytag

Maytag EPIC Z MGD9800TK0 Bedienungsanleitung

Maytag

Maytag Performa HY-2 Bedienungsanleitung

Maytag

Maytag Performa PYE/G2200 Bedienungsanleitung

Maytag

Maytag MED5600TQ0 Bedienungsanleitung

Maytag

Maytag MGD6400TB - Bravos Gas Dryer Bedienungsanleitung

Maytag

Maytag MGD7100D Bedienungsanleitung

Maytag

Maytag MGDZ600TB - 27" Gas Dryer Bedienungsanleitung

Maytag

Maytag MDE2706AYW Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
