Master/slave mode
The fixtures can run at M/S mode when there are more than one par lights, which can
work simultaneously
The way of setting dipswitch is as follow：
1.Master：Dipswitch 1 is ON
2.slave：Dipswitch 1 is OFF
NOTE：In M/S mode, only one was set to master and other should be set to slave, or they
can’t work normally.
Sound mode
In this mode, the fixture run as same as in Auto mode, just activated by sound you can
adjust sensibility by potentiometer on panel.
Trouble Shooting
Check if power switch is on and cable is
connected well
One or more fixtures can
work
Change new fuse when power is off.
If it is burnt again, circuits maybe have
some problem, please contact technician
Data cables can’t be
connected correctly
Check, repair or change the data cable
and make sure good connection.
While please connect the first fixture
and controller.
Check if address code is set
correctly(Pleas note that it can’t set
Master when connect DMX controller)
Fixture is no problem, but
can’t work when it is
connected to controller or
other fixtures.
Some trouble in signal
connector of one
fixture
Please connect signal IN and OUT
directly for one fixture and check if it can
work normally. As per this way, please
find trouble fixture and let technician
repair
