SwingTM

EN Instructions for use |ES Instrucciones de uso |FR Mode d’emploi

Important Safeguards

When using electrical products, especially when children are present, basic safety precautions

should always be followed.

READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.

WARNING: To avoid ﬁre, electrocution, or serious burns:

• Do not leave product unattended when plugged into an electrical outlet.

• Close supervision is necessary when this product is used near children or persons with

disabilities.

• Use the product only for its intended use as described in this manual. Do not use

attachments not recommended by the manufacturer.

• Never operate this product if it has a damaged cord or plug, if it is not working properly, if

it has been dropped or damaged, or dropped into water.

• Keep cord away from heated surface.

• Never use while sleeping or when drowsy.

• Never drop or insert any object into any opening or tubing.

• Do not use outdoors, or operate where aerosol (spray) products are being used where

oxygen is being administered.

• Aways inspect power adaptor and battery pack wires prior to use for damage or

exposed wire. If damage is found, immediately discontinue use of power adaptor or

battery pack and call Medela Customer Service at 1-800-435-8316.

DANGER: To reduce the risk of electrocution:

• Always unplug electrical product immediately after use.

• Do not use while bathing.

• Do not place or store product where it can fall or be pulled into a tub or sink.

• Do not place or drop into water or other liquid.

• Do not reach for a product if it has fallen into water. Immediately unplug from electrical

outlet.

The warning symbol identiﬁes all instructions that are important to safety. Failure to

observe these instructions can lead to injury or damage to the breastpump. When

used in conjunction with the following words, the warning symbols stand for:

WARNING Can lead to serious injury or death.

CAUTION Can lead to minor injury.

NOTE Can lead to material damage.

INFO Useful or important information that is not related to safety.

Questions? Visit www.medela.com or call us at 1-800-435-8316. 3

WARNING: To avoid health risk and reduce the risk of injury:

• This product is intended for use by a single user only and should not be shared

between users.

• Do not drive while pumping.

• Never use while pregnant, as pumping can induce labor.

• Clean and sanitize all parts that come in contact with your breast and breastmilk prior

to ﬁrst use.

• Wash all parts that come in contact with your breast and breastmilk after every use.

• Inspect all appropriate pump components before each use.

• Do NOT continue pumping for more than 2 consecutive pumping sessions if no results

are achieved.

• Do not thaw frozen breastmilk in a microwave or in a pan of boiling water.

• If tube becomes moldy, discontinue use and replace tube.

• If breastmilk backup occurs you must clean tube before your next pumping session.

CAUTION: Can lead to minor injury:

• Do NOT wrap cord around adaptor body.

• Use only the power adaptor that comes with the Swing Breastpump.

• Pump only with the breastpump in an upright position.

• Do NOT shorten tubing.

• Make sure the voltage of the power adaptor is compatible with the power source.

• Plug the power adaptor into the breastpump ﬁrst and then into the wall socket.

• Do NOT use antibacterial or abrasive cleaners/detergents when cleaning breastpump or

breastpump parts.

• Never put breastpump motor unit in water or a sterilizer, as you can cause permanent

damage to the breastpump.

• Do not attempt to remove the breastshield from your breast while pumping. Turn the

breastpump off and break the seal between your breast and breastshield with your ﬁnger,

then remove breastshield from your breast.

• If pumping is uncomfortable or causing pain, turn the unit off, break the seal between the

breast and the breastshield with your ﬁnger and remove the breastshield from your breast.

• Plastic bottles and component parts become brittle when frozen and may break

when dropped.

• Bottles and component parts may become damaged if mishandled, e.g. dropped,

over-tightened or knocked over.

• Take appropriate care in handling bottles and components.

• Do not use the breastmilk if bottles or components become damaged.

SAVE THESE INTRUCTIONS

1. Cleaning .................................................................................................. 8-13

1.1 Before using for the ﬁrst time ....................................................................8

1.2 After each use .......................................................................................8-9

1.3 Sanitize daily......................................................................................10-11

1.4 Tubing and motor unit cleaning..........................................................12-13

2. Assembly............................................................................................... 14-21

2.1 Assembly of pump kit ........................................................................14-17

2.2 PersonalFit™ Sizing ...............................................................................18

2.3 Powering your pump .........................................................................19-21

2.3.1 Power adaptor care......................................................................19

2.3.2 Battery compartment...............................................................20-21

2.3.3 Traveling outside of the U.S. or Canada .......................................21

3. Pumping................................................................................................ 22-26

3.1 Device operation................................................................................22-25

3.2 Mobility...................................................................................................26

4. Storing, Preparing & Feeding Breastmilk ................................................27

4.1 Storing breastmilk...................................................................................27

4.2 Preparing breastmilk...............................................................................27

4.3 Feeding breastmilk..................................................................................27

5. Troubleshooting ................................................................................... 28-29

6. Supplemental Information.........................................................................30

7. EMC / Technical Description............................................................... 31-37

8. Technical speciﬁcations / Disposal guideline .........................................38

9. Warranty......................................................................................................39

Table of Contents

Questions? Visit www.medela.com or call us at 1-800-435-8316. 5

Product Description

Take a moment to read through this entire instruction manual before using this

product for the ﬁrst time.

PLEASE SAVE THESE INSTRUCTIONS.

It is best to wait until your breastfeeding routine is established (approximately

4weeks) before expressing breastmilk, unless otherwise advised by your

healthcare professional.

Glossary of Terms

2-Phase Expression®technology – research based technology that mimics a

baby’s natural nursing rhythm.

Expression Phase – slower sucking/pumping rhythm for gentle and efﬁcient milk

removal as quickly as possible.

Maximum Comfort Vacuum™ –highest vacuum setting where a mother still feels

comfortable during pumping. It is different for every mother.

Stimulation Phase – fast sucking/pumping rhythm to stimulate the milk ejection

reﬂex and to start the milk ﬂowing.

Intended Use

For lactating women to express and collect milk from their breasts to complement

breastfeeding.

If you have medical reasons or other needs for exclusively pumping, it is

recommended that you use a hospital grade breastpump such as our Symphony

breastpump. To learn more, visit us at www.medelabreastfeedingus.com.

Product Description

SwingTM is a personal use electric breastpump that includes 2-Phase Expression

technology and is capable of single pumping.

1x PersonalFit™

Breastshield M (24mm)

(for other breastshield sizes

see Section 2.2, page 18)

87073 (24 mm)

1x Connector

8007196

2x Bottles

6007135

1x Bottle Stand

8100462

3x Membranes

87088

1x Neck

Strap

8000734

1x Swing Storage Bag

8000838

1x Valve

87089

Product Description

Questions? Visit www.medela.com or call us at 1-800-435-8316. 7

1x Power Adaptor

9200043

1x Motor Unit

0300011

On/Off button

Reduce

vacuum

Increase

vacuum

Let-down

button

LED

Power

adaptor port

Tubing port

Battery

compartment

Belt clip

1x Swing Tubing

8007215

2x Lids

8107183

Overview of LEDs

lights up On

does not light up Off

even, regular ﬂashing Stimulation phase

light constantly on Expression phase

rapid ﬂashing Min./Max. vacuum

1x Backplate

• Breastshield • Connector

• White membrane • Yellow valve

• Breastmilk bottle

and lid

1.1 Before using for the ﬁrst time

Clean and sanitize the parts below before

using your pump for the ﬁrst time. Follow

the cleaning and sanitizing instructions in

Sections 1.2 (start at step 4) and 1.3

that follow.

1. Cleaning

1.2 After each use

Clean all parts that come in contact

with your breast and breastmilk.

See image in Section1.1.

Separate breastshield from

connector.

• Only use drinking-quality tap or

bottled water for cleaning.

• Take apart and wash all parts that

come in contact with the breast and

breastmilk immediately after use to

avoid dry up of milk residues and to

prevent growth of bacteria.

Caution

Rinse in cool water all separated

parts that came in contact with

breast and breastmilk in order to

remove breastmilk residue.

Questions? Visit www.medela.com or call us at 1-800-435-8316. 9

Supplies Needed: • Mild Dish Soap

• Clean Dish Towel or

Soft Brush

• Clean Sink or Bowl

• Quality Drinking

Water

Twist and pull the yellow valve off

the connector. Remove the white membrane

from the yellow valve.

Washing in sink:

Washing Options:

Washing in dishwasher:

• Soak all separated parts in

warm soapy water for

5minutes.

• Clean with a clean dish-cloth

or soft brush.

• Rinse all separated parts

with clear water.

• Allow all parts to air dry in

a clean area.

• Store dry parts when not in use.

• Wash all separated parts

on top rack of dishwasher.

• Allow all breastpump parts

to air dry in a clean area.

• Store dry parts when

not in use.

• You may wash

your kit parts

by following the

instructions on

the Quick Clean™

Breastmilk

Removal Soap

bottle.

1.3 Sanitize daily

• Wash breastpump kit parts after each

use.

• Sanitize breastpump kit parts once

daily.

• The pump kit requires no maintenance.

• Take care not to damage parts

of the pump kit during cleaning.

• If the individual components of the

pump kit are cleaned in a dishwasher

parts may be discolored by food

pigments. This has no impact on the

function.

• Store the pump kit in a clean

bag/container until next use.

Note

Wash hands thoroughly.

Allow water to cool and gently

remove parts from water with

tongs.

1. Cleaning (cont.)

Andere Handbücher für Swing

Inhaltsverzeichnis

Sprachen:

Andere Medela Brustpumpe Handbücher

Medela

Medela Freestyle Bedienungsanleitung

Medela

Medela Symphony Bedienungsanleitung

Medela

Medela Symphony Bedienungsanleitung

Medela

Medela Symphony Bedienungsanleitung

Medela

Medela Swing Flex 101033779 Bedienungsanleitung

Medela

Medela Pump In Style Advanced Bedienungsanleitung

Medela

Medela Pump In Style 101041359 Bedienungsanleitung

Medela

Medela Mini Electric Bedienungsanleitung

Medela

Medela Freestyle Bedienungsanleitung

Medela

Medela Swing Bedienungsanleitung

Medela

Medela Supplemental Nursing System Bedienungsanleitung

Medela

Medela Harmony Montageanleitung

Medela

Medela Symphony Kurzanleitung

Medela

Medela Swing Bedienungsanleitung

Medela

Medela Symphony Bedienungsanleitung

Medela

Medela Freestyle Bedienungsanleitung

Medela

Medela 57018W Bedienungsanleitung

Medela

Medela Swing Flex Bedienungsanleitung

Medela

Medela Pump In Style Advanced Bedienungsanleitung

Medela

Medela Harmony Montageanleitung

Medela

Medela 101045671 Bedienungsanleitung

Medela

Medela Pump In Style Advanced Bedienungsanleitung

Medela

Medela Single Deluxe Montageanleitung

Medela

Medela Mini Electric Bedienungsanleitung

Beliebte Brustpumpe Handbücher anderer Marken

besrey

besrey XN/MS-2246A Bedienungsanleitung

Philips

Philips AVENT SCD241/01 Bedienungsanleitung

Philips

Philips AVENT SCF301 Bedienungsanleitung

nuVita

nuVita MATERNO DUAL 1290 Bedienungsanleitung

Philips AVENT

Philips AVENT Breast Pump Bedienungsanleitung

Chicco

Chicco NaturallyMe Bedienungsanleitung

MOMCOZY

MOMCOZY S12 Bedienungsanleitung

Philips AVENT

Philips AVENT Breast Pump Bedienungsanleitung

Philips

Philips SCF292 Bedienungsanleitung

Philips

Philips AVENT SCF397 Bedienungsanleitung

Philips

Philips AVENT SCF396/11 Bedienungsanleitung

weewell

weewell WPB900 Bedienungsanleitung

CANGAROO

CANGAROO GENTLE TOUCH Bedienungsanleitung

Spectra

Spectra S2 Bedienungsanleitung

Rumble Tuff

Rumble Tuff Easy Express Montageanleitung

Motif Medical

Motif Medical Luna Bedienungsanleitung

CANGAROO

CANGAROO BIJOU Bedienungsanleitung

Bayby

Bayby BBP 1010 Bedienungsanleitung
