MEE T1M3 Bedienungsanleitung
QUICKSTART GUIDE
www.MEEaudio.com/T1M3
Bluetooth®Wireless
headphone system for tv
Includes Bluetooth Wireless Audio Transmitter
and Matrix3 Wireless HD Headphones
Visit MEEaudio.com/ConnectHelp for
easy-to-follow setup videos, full user manuals,
and the latest troubleshooting information.
CONNECT SUPPORT GUIDE
Bluetooth®Wireless
headphone system for tv
FOR ADDITIONAL SUPPORT
View and download complete user manuals for
Connect transmitter and Matrix3 headphones at
MEEaudio.com/Support
View our Connect Support Guide at
MEEaudio.com/ConnectHelp for easy-to-follow
setup videos and troubleshooting information
•
•
•
PACKAGE CONTENTS
CONNECT
Bluetooth
Transmitter
TOSLINK digital
optical S/PDIF
audio cable
3.5mm to
RCA
adapter
2 x Micro-USB
charging
cable
3.5mm
audio
cable
MATRIX3
Bluetooth
Stereo
Headphones
1
CONNECT
2
hrs
MATRIX3
CHARGE HEADPHONES
PLUG USB POWER CABLE INTO TRANSMITTER
plug into AC
adapter, TV,
or computer
USB port
AOFF ON AOFF ON
2
POWER ON TRANSMITTER
POWER ON HEADPHONES
2
seconds
HOLD
AOFF ON
B
3
CONNECTION IS ESTABLISHED
solid blue light on transmitter
indicates connection
IF NO SOLID BLUE LIGHT, PERFORM PAIRING
PROCEDURE IN STEP 6
4. choose an audio cable supported by your tv
OPTICAL S/PDIF [DIGITAL]
AOFF ON
settings
Sound / Audio
digital Audio Output
auto
dolby digital
pcm / stereo
DTS
AUDIO OUPUT
R L
OPTICAL
IF TV AUDIO PLAYS FROM HEADPHONE,
SETUP IS COMPLETE. PROCEED TO STEP 5.
NO SOUND? CHECK TV SETTINGS MENU.†
PROCEED TO STEP 5
remove
protective caps
select “PCM / Stereo” in the audio
output settings menu*of your TV
*if sound is still not audible, select “PCM / Stereo” in the audio output
settings menu(s) of your video streaming app(s) and/or device(s)
AUDIO OUPUT
OPTICAL
plug the
optical cable
into TV’s digital
audio output
†
EXACT MENU AND ITEM NAMES MAY VARY BETWEEN TVS
RCA
PROCEED TO STEP 5
set TV’s internal speakers to “OFF”
select “Variable” in the audio output
settings menu of your TV
AOFF ON
AUDIO OUPUT
R L
OPTICAL
IF TV AUDIO PLAYS FROM HEADPHONE,
SETUP IS COMPLETE. PROCEED TO STEP 5.
NO SOUND? CHECK TV SETTINGS MENU.†
AUDIO OUTPUT
R L
plug the stereo
cable into RCA
adapter and
connect to TV’s
red/white RCA
jacks labeled
“AUDIO OUT”
settings
sound / audio
Analog audio out
fixed
variable
settings
sound / audio
tv speakers
on
off
4. choose an audio cable supported by your tv
†
EXACT MENU AND ITEM NAMES MAY VARY BETWEEN TVS
4. choose an audio cable supported by your tv
3.5MM [HEADPHONE JACK]
Volume max vol+
AOFF ON
plug the stereo
cable into TV’s
headphone
jack
headphone
jack may be
located on
front, side, or
rear of TV
AUDIO
maximize the volume on your TV
5
ADJUSTING HEADPHONE VOLUME
WHEN FINISHED, POWER OFF
HEADPHONES UNTIL NEXT USE
2
seconds
HOLD
TAP
to increase
volume
TAP
to decrease
volume
POWER OFF HEADPHONES
