Operating Manual

MELAnet Box

For networking of MELAG autoclaves

from software version 1.011a

General notes

Please read these operating instructions carefully before commissioning the device. The instructions include important

safety information.

Make sure to keep the Operating Manual near to the device. It represents a component of the product.

About this manual

Symbols used

Symbol

Explanation

Draws your attention to a situation, which if not avoided, could result in damage to the

device.

Draws your attention to important information.

Formatting rules

Symbol

Explanation

Log output

Words or phrases appearing on the web browser window of the MELAnet Box

configurator are marked as menu text.

Log output

Words or phrases appearing on the display of the autoclave are marked as software

citations.

Chapter 6 - Logging

Reference to another text section within this manual.

Figure 1/(5)

Reference to a detail in a figure –in the example, to part no. 5 in figure 1.

Symbols on the device

Symbol

Explanation

The symbol of the crossed out waste bin identifies a device that must not be disposed in

domestic waste. The vendor is responsible for appropriate disposal of the device - it must

be delivered to the vendor to be disposed of.

With the designation of an apparatus with this symbol, the manufacturer furthermore

declares that he satisfies all requirements of the law concerning the release, redemption

and environmentally sound disposal of electric and electronic appliances.

Scope of delivery

Standard scope of delivery

MELAnet Box

Operating Manual

Power supply

Serial cable (RS232), 1.5 m

Ethernet cable 1:1 (LAN), 2 m

CD with associated configuration software an log output (MELAnetBox Configurator)

Table of contents

Chapter 1 –Device description.......................................................................................................5

Intended Use...................................................................................................................................................................5

Compatibility to different MELAG device types................................................................................................................5

Views of the device.......................................................................................................................................................... 6

Status displays ................................................................................................................................................................ 6

System requirements.......................................................................................................................................................7

Chapter 2 –Installation instructions ................................................................................................8

Connecting the MELAnet Box.......................................................................................................................................... 8

Settings on the autoclave .............................................................................................................................................. 12

Chapter 3 –MELAnetBox configurator..........................................................................................13

Device info menu........................................................................................................................................................... 13

Configuration menu ....................................................................................................................................................... 13

Logs menu..................................................................................................................................................................... 15

Update menu................................................................................................................................................................. 17

Password for the MELAnetBox configurator.................................................................................................................. 17

Reset user-defined settings........................................................................................................................................... 18

Chapter 4 –Troubleshooting.........................................................................................................19

Log output via TCP not possible.................................................................................................................................... 20

Hints when using a notebook......................................................................................................................................... 21

Chapter 5 –Technical Data ..........................................................................................................22

Factory settings of the MELAnet Box ............................................................................................................................ 22

Appendix –Accessories................................................................................................................23

Glossary .......................................................................................................................................24

Chapter 1 –Device description

Safety Instructions

When operating the device, please ensure that you observe the following safety instructions as well as

those contained in the following chapters.

Cables and power supply

Only the power supply included in the scope of delivery may be connected to the device.

Liquids may not be permitted to reach the interior of the device. This could result in an electrical

shock or short circuiting.

Attach only those devices to the MELAnet Box designed for operation with the MELAnet Box.

Repair

Do not open the housing of the MELAnet Box. Incorrect opening and repair can compromise

electrical safety and pose a danger to the user. The guarantee and warranty are forfeited as soon

as the device is opened by anyone other than a member of a MELAG-authorized technical

customer service.

Application

Do not place the MELAnet Box directly on the autoclave. The autoclave will become hot upon

operation. Non-observance could result in restricted function and damage to the MELAnet Box.

Chapter 1 –Device description

Intended Use

The MELAnet Box enables the connection of a MELAG autoclave to the computer network of the practice

or clinic via an Ethernet interface.

Compatibility to different MELAG device types

Table 1: Overview of the current device types

Device class

Device type

Software version

Pro-Class

Vacuklav 23 B+

Vacuklav 24 B+

Vacuklav 24 B/L+

Vacuklav 30 B+

Vacuklav 31 B+

from v 3.34

S-Class

Euroklav 23 VS+

Euroklav 29 VS+

Euroklav 23 S+

from v 3.34

Cliniklav

Cliniklav 25

from v 3.16

MELAtronic EN+

from v 4.12

MELAtronic EN

MELAtronic 23 EN

from v 4.07

MELAquick

MELAquick 12+/12+p

from v 4.12

Table 2: Overview of the former device types

Device class

Device type

Software version

Classics

Vacuklav 23-B

Vacuklav 24-B

Vacuklav 24-B/L

Vacuklav 30-B

Vacuklav 31-B

from v 3.16

Euroklav

Euroklav 23V-S

Euroklav 29V-S

Euroklav 23-S

Euroklav 29-S

from v 3.16

MELAtronic EN

MELAtronic 15 EN

MELAtronic 17 EN

from v 4.07

Chapter 1 –Device description

Views of the device

1) Reset key

for resetting the user-defined settings on

the work settings

2) LED-lights

for status indication

3) Ethernet socket (RJ45)

for connecting the Ethernet cable to the

network

4) RJ12 socket

for connecting the serial cable to the

autoclave

5) power supply socket (5V/ DC)

for connecting the plug-in power supply

cable

Status displays

LED lights

State

Meaning

Power

Device is switched on / live

OFF

Device is switched off / not live

flashes quickly

MELAnet Box start configuration was successful

Data

(Daten)

flashing

Data is being exchanged over the Ethernet interface between the

computer and the MELAnet Box.

LAN

Connected with network

OFF

Not connected with network

Chapter 1 –Device description

System requirements

Hardware

Windows 8.1, Windows 8, Windows 7 (32/64 bit), Windows Vista (32/64 bit), Windows XP

COM-connection (RS232 interface)

If no COM-connection is available: USB/Serial Adapter

PLEASE NOTE

The USB/Serial Adapter not included in the scope of delivery. The majority of adaptors will be

recognized by the operating system. Where necessary it could be necessary to install a driver by

the manufacturer.

Software

a free IP address in the user network, which you can obtain from your administrator (default IP

address: 192.168.40.100)

latest version of the media library Microsoft .NET Framework, at least .NET Framwork 3.5

Optional: a Web browser, e.g. Microsoft Internet Explorer IE7, Mozilla Firefox, Chrome etc.

Chapter 2 –Installation instructions

Connecting the MELAnet Box

Assigning a free IP address to the MELAnet Box

NOTICE

Errors in the handling of IP addresses can result in faults and data loss in your user network. It is

thus recommended that you engage IT specialists to undertake all work in your practice network.

In order for the MELAnet Box to be operated in your practice network, the first three digit blocks of the IP

address of the MELAnet Box should conform to that of the IP address of the practice network. The last

digit block is assigned to the device connected in the practice network. This number is different for every

device connected in the practice network.

If the first three digit blocks are not identical, it is necessary to change the IP address of the MELAnet Box

so that they are recognized within the practice network.

PLEASE NOTE

As the MELAnet Box does not support DHCP and is unable to allocate IP addresses

automatically, it is necessary to issue static IP addresses.

Example:

To be able to configure the MELAnet Box on the computer, i.e. to adjust the IP address, the MELAnet Box

configurator on the CD is used.

The following explains how to connect and configure the MELAnet Box:

1. Obtain a free IP address from the system administrator of the practice network.

2. Install the MELAnetBox configurator from the delivered CD and start the program.

3. Connect the power supply cable to the MELAnet Box and plug it into the socket.

Practice

network

In this case, the IP address of the MELAnet Box is

changed, e.g. to 192.168.51.13

192.168.51. …

192.168.51.10

192.168.51.11

192.168.51.12

Chapter 2 –Installation instructions

NOTICE

Only use the power cable included in the scope of delivery. Using a different power cable can

damage the device and its functioning cannot be guaranteed.

PLEASE NOTE

Use the covered network cable to prevent the emission values from being exceeded. We

recommend the type SF/UTP network cable in accordance with ISO/IEC 11801 Cat.5e.

4. Connect the serial cable to the middle socket of the MELAnet Box and plug it into the COM

socket* on the computer.

5. Click on Next.

6. Click on the Search. The following message will be displayed:

connect

Power

lights up

connect

RJ12

**If your computer no longer has a COM socket, use a USB/Serial adapter

(not included in the scope of delivery).

RS232

Power

Depending on whether your COM socket is occupied, the number after the

“COM” may vary.

Chapter 2 –Installation instructions

7. Enter the free IP address of the MELAnet Box and click on Send.

8. Remove the power supply cable from the MELAnet Box.

9. Press the reset key and hold it for 10 seconds. At the same time reconnect the power supply

cable to the MELAnet Box.

10. Note the IP address and click on Stop.

11. Click on Next.

12. Remove the serial cable from the computer and the MELAnet Box.

NOTE

The first three number blocks of the IP address must match those of the practice

network, the last block of numbers indicates the device number and must not have

been assigned.

disconnect

Power

connect

Power

hold 10 secs.

disconnect

RJ12

RS232

Power
