Memorex MT-1192 Bedienungsanleitung

MT1192

19'' Color Television

Owner's Manual

As an ENERGY STAR

Partner, MEMCORP has

determined that this product meets the ENERGY STAR ®

guidelines for energy efficiency.

– 1 –

To get the most from your new color television, read and follow this Owner's Manual

carefully.

INSTALLATION GUIDELINES

Place your TV in a room with adequate ventilation.

 Keep your TV set away from sources of direct heat, such as heat registers or direct

 sunlight.

 Do not place your TV on soft surfaces, such as rugs or blankets.

Leave enough room for air to circulate around the bottom, top and back of the set.

ANTENNA CONNECTIONS

For best picture quality, we recommend that you use an outdoor antenna. Follow in -

 structions on page 6 for proper antenna hookup.

POWER CONNECTION

Your TV works on normal household current (120 volts, 60 Hz).

 For safety purposes, your TV's electrical plug has one blade wider than the other. If

 you cannot insert the plug fully into the socket, try reversing it.

In the space provided, record the serial and model numbers, located on the rear of the

unit.

Serial No. Model No.

BEFORE YOU OPERATE YOUR NEW TELEVISION

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

The lightning flash with the arrowhead symbol within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage" within the

product's enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to someone.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

– 2 –

FEATURES

SPECIFICATIONS

 On-screen graphics guide you through setup features and operations

 Automatic programming of channels allows easy selection of stations available in your

 viewing area 

 Sleep timer programs the TV to turn itself off at a preset time

 One day timer programs the TV to come on once at a preset time

 Weekly timer programs the TV to come on at a preset time every day

26-button infrared remote control allows remote operation

 VHF/UHF/CATV tuning allows reception of standard broadcasts or cable TV channels

 Close caption decoder displays captions or half-screen text

 V-Block function

AC Power Input: 120V, 60Hz

AC Power Consumption: 98Watts

Chassis Construction: IC Solid State

Picture Tube: 19" (measured diagonally)

Speaker: 3.5 x 2 in. (90 x 50 mm) Oval, 8 ohms

Tuner: 181 Channel, Freq. Synthesized

Remote Control: Infrared, Direct Access

26 Key, 2 "AA" batteries

Receiving Channels:

 VHF 2–13

 UHF 14–69

 CATV

 Mid Band 14–22

 Super Band 23–36

 Hyper Band 37–65

 Ultra Band 66–94, 100–125

 Sub Mid Band 1, 95–99

Cabinet: Monitor Style

Antenna Input Impedance: 75 ohm (VHF/UHF) Coaxial Input

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

OF PLUG TO WIDE SLOT, FULLY INSERT.

1POWER SWITCH

2CHANNEL (UP) BUTTON

3CHANNEL (DOWN) BUTTON

4VOLUME (UP) BUTTON

5VOLUME (DOWN) BUTTON

6REMOTE CONTROL SENSOR

7AUDIO IN (PUT) JACK

8VIDEO IN (PUT) JACK

9VHF / UHF EXT. ANT. JACK (REAR OF SET)

-3-

LOCATION OF CONTROLS

REMOTE

CONTROL

– 6 –

ANTENNA CONNECTIONS

If you are using an indoor or outdoor antenna (antennas no tincluded) follow the

instructions below that correspond to your antenna system. III If you are using a cable

television service (CATV), refer to CATV connections.

Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead

wire)

Connect the 75 ohm cable from

combination VHF/UHF antenna to the

antenna jack.

If your combination antenna has a 300

ohm twin-lead wire, use the 300-75 ohm

matching transformer (not included)

For subscribers to basic cable service.

For basic cable service without a

converter/descrambler box, connect the

CATV 75 ohm coaxial cable directly to

the antenna jack on back of the unit.

NOTES

To prevent problems it is recommended

that you use only the specified trans-

former. (Transformer Part No.:1398-017)

ANT

Transformer

(not included)

75 ohm

300 Ohm

ANT

CATV CONNECTIONS

Some cable companies offer "premium pay" channels in which the signal is scrambled.

Descrambling these signals for normal viewing requires the use of a descrambler device

which is generally provided by the cable company.

The illustrations below show how to connect these types of converter/descrambler

devices with the TV's VHF antenna jack.

You may need a two-set signal splitter (sometime called a "two-set coupler) and an A/B

switch box from the cable installer or an electronic supply store. With the A/B switch in

the "B" position, you can then tune directly to any non-scrambled channels using your

TV's tuning system or remote control. In the "A" position, you can tune your TV to the

output channel of the decoder (generally Channel 3/4) and use the cable company's

equipment to tune scrambled channels. Since cable systems vary, you may wish to

consult your local cable company.

For subscribers to scrambled pay cable service

To allow viewing of all channels through converter/descrambler. TV must be set to the

output channel of the converter/ descrambler (usually ch 3 or 4).

NOTE: If you subscribe to a cable service which requires you to use a

converter/descrambler box, follow the connections shown above.

If your basic cable channels are unscrambled an are using a converter/descrambler for

premium channels, follow the connections shown below.

For subscribers of unscrambled basic cable with a converter/descrambler box for

viewing premium channels.

A – Allows viewing of scrambled channel through converter/descrambler box.

B – Allows full use of TV tuner and Remote Control.

NOTE: For other cable connections, consult your cable company.

– 7 –

INCOMING

COAXIAL CABLE To 75 ohm Coaxial

Jack On TV

Converter/Descrambler

SPLITTER

INCOMING

COAXIAL

CABLE A/B Switch

To 75 ohm Coaxial

Jack On TV

VIDEOINPUT

AUDIO VOLUME CHANNEL POWER

VIDEOINPUT

AUDIO VOLUME CHANNEL POWER

input

– 9 –

SELECTING A LANGUAGE

The menu screen that appears when you press the MENU button can be programmed to

appear in English, French, or Spanish. Follow the directions below to program the menu

screen to appear in a language other than the one that is now on-screen when you press

the MENU button.

Press the MENU button to bring up the

menu-screen.

Use the + or – button to highlight

LANGUAGE.

Press the MENU button until the menu

screen is in the language you want to

select.

Use the + or – button to highlight

EXIT.

Press the MENU button to exit.

MENU SUN - - : - - AM

CLOCK SET

PROGRAM TIMER

V-BLOCK SET

PICTURE ADJUST

CH PROGRAM

LANGUAGE

EXIT

[+] / [-] : MENU SELECT

[MENU] : ENTER

MENU SUN - - : - - AM

CLOCK SET

PROGRAM TIMER

V-BLOCK SET

PICTURE ADJUST

CH PROGRAM

LANGUAGE

EXIT

[+] / [-] : MENU SELECT

[MENU] : ENTER

MENU SUN - - : - - AM

CLOCK SET

PROGRAM TIMER

V-BLOCK SET

PICTURE ADJUST

CH PROGRAM

LANGUAGE

EXIT

[+] / [-] : MENU SELECT

[MENU] : EXIT
